User’s Manual
C4026V-M 24” Stainless Steel Freestanding Electric Range -
User’s Manual

2
Congratulations on the purchase of yourAEG appliance.
We are sure it will provide many years of great cooking experience.
You may find that it has different features and characteristics to your last
appliance.
It is essential you read this operation manual thoroughly to fully
understand all of the various functions and operations. Experiment with
your cooking and take advantage of the features your new appliance offers.
This manual should be retained for future reference. Should ownership of
the appliance be transferred, please ensure that the manual is also passed
onto the new owner.
Contents
A -Installation check and warnings Page 3 -7
B -Cooker Measurement Page 7
C -Electrical Requirements Page 8
D-Using the appliance for the first time Page 9 -10
E-Accessories Page 10 –11
F-Electronic timer Page 11 -13
G-Gas cooktop control panel Page 14
H-Gas cooktop function Page 15
ICeramic Cooktop control panel Page 16
L-Ceramic Cooktop Functions Page 17
M-Oven Functions & Control Panel Page 18 -23
N-Cleaning and maintenance Page 24 -28
O-Trouble shooting guide -Electrical wiring Page 28 -29
P-Warranty Page 30

3
A -Installation instructions check and warnings
IMPORTANT:
Please ensure that the cut out measurement, venting and wiring is as specified in the
relevant section B of this manual.
A licensed electrician with relevant qualifications must perform electrical work when installing or
servicing the appliance. The supply cable and fuse rating must be suitable for the appliance. You
must never repair or replace any part of the appliance unless specifically recommended in the
operation manual.
DO NOT LIFT COOKER BY THE FRONT DOOR AS THIS WILL DAMAGE THE OVEN
Ventilation opening must not be covered or obstructed in any way.
VENTILATION
The room containing this cooker should have an air supply in accordance with local regulations.
-All rooms require an open window, or equivalent and some rooms will require a
permanent vent as well.
-For room areas up to 5 m2an air vent of 100 cm2is required.
-For room areas between 5 m2and 100 cm2an air vent of 50 cm2is required.
-If the room is greater than 5 m2and has a door that opens directly to the outside, then no
air vent is required.
-If there are other fuel burning appliances in the same room local regulations should be
consulted to determine the air vent requirements.
DISCHARGE OF FUEL GASES
Cooking appliances must always discharge the flue
gases into special hoods (fig.1-C), which must be
connected to chimneys, flue pipes or have direct
access to the outside. If it is not possible to connect
a hood, an electric fan can be fitted to a window or
a wall (fig.1-E), which must be turned on when the
cooker is on, as long as ventilation standards are
strictly adhered to.
Fig.1

4
RECOMMENDED VENTILATION HEIGHT
-for ceramic cooktop model min. 24” above range
-for gas cooktop model min. 30” above range
When ranges are installed in close proximity to vinyl finish cabinets,
those materials should be able to withstand temperature up to 75°C centigrade.
Alternatively, heat insulating barriers should be installed to avoid any
deterioration to the finish.
The equipment must not be installed near inflammable materials, such as curtains, cloths etc.
Pay particular attention to the position of the electric cable and gas pipe: they must
not touch any hot parts of the oven
The manufacturer will not accept responsibility for damages to cabinetry where
manufacturer installation guidelines were not adhered to.
CONVERTING THE GAS-SUPPLY TO THE HOB BURNERS
Burners: auxiliary, semi-rapid, rapid, triple crown, griddle burner.
These burners are all fitted with injectors designed to create a primary input of air gauged for
each type of gas. This means that the air regulator does not have to be regulated. Proceed as
follows in order to convert from one type of gas to another: remove the grids, covers, holed flame
diffuser and the burner supports (fig. 7); replace the holed injectors as indicated in 7/C according
to the type of gas used (see table 1); put the burner supports, flame diffusers, covers and grids
back in position; regulate the minimum output following the instructions in paragraph 1.7.
REGULATING THE MINIMUM OUTPUT OF THE HOB BURNERS
Normal/valve taps:
Ignite the burners and turn the knob to the maximum position. Remove the knob and insert a
small flat-head screwdriver into the rod or through the holes on the side of the control panel, in
accordance with the type (fig. 8 A/B). Loosen the by-pass screw by two turns in an anti-clockwise
direction and rotate the rod to the minimum position. Adjust the previously loosened screws until
the flame is lowered but stable, evenwhen rapid changes are made from the maximum to the
minimum position with the burner cold. If safety taps are fitted, let the burner run on minimum for
a few minutes to ensure that the device does not cut in. If it does, increase the minimum.
N.B. For liquid gas settings, the burner minimum must be set by fully tightening the tap
by-passes

5
Fig.8
WARNINGS:
-If the burner flames accidentally go out, turn off the KNOB and wait for at least one minute
before igniting.
-Using a gas cooker produces heat and humidity in the room where it is installed. Ensure the
room is well ventilated by keeping all the natural air vents open or by installing an extraction
hood with flue pipe.
-Intensive or extensive use of the cooker may require supplementary ventilation e.g. opening
a window, or more efficient ventilation e.g. increasing the capacity of the mechanic
ventilation, if installed.
N.B. When the burners are alight, there must not be any draughts inside the room in
that they may affect the flame or even blow it out.
The operations indicated below must be followed by qualified personnel, in conformity with the
regulations in force.
The supplier refuses all responsibility for damages to person or property, resulting from
the failure to comply with such provisions.
The appliance is designed to be used near heat resistant pieces of furniture or kitchen cabinetry
only.
ELECTRICAL CONNECTIONS (FIG.7)
Before carrying out electrical connection, be sure that the characteristics of the electrical system
meet the specifications located at the bottom of the cooktop and the electrical system is provided
with effective ground in compliance with the regulations and provision of the law in your country.
The ground is required in all circumstances.
If you wish a direct connection to the line, it is necessary to use a single pole switch, with a
minimum opening between the contacts of 3 mm. suitable for the purpose and in conformity with
the rules in your country (the yellow/green ground cable should not be interrupted by the switch).

6
ATTENTION
Disregard of this precaution could cause the incorrect operation of the touch control system of the
cooktop and effect the product warranty provisions.
WARNING:
All aspects of the installation must conform with the requirement of the Standards North
America (within North America) wiring rules, as well as your local electrical and building
codes and regulations, and any other applicable requirements and conditions of your
local power supply authority. Your appliance must be properly installed and grounded by
a qualified and licensed technician.
240 Volt 60Hz 30AMP single/40AMP double service
Incorrect installation of the appliance, resulting from the kitchen maker not following the detailed
installation specifications, can affect the appliance performance
CONNECTION TO THE GAS SUPPLY: CURRENT INSTALLATION STANDARDS
The cooker should be connected according to local regulations,
using either a rigid or flexible connections.
a) For building in: Use a continuous flexible stainless steel pipe, as
per current installation standards, which can be extended to a
maximum of 2000 mm.; the ends of the pipe must be fitted with
an ISO 228/1coupling and gasket or an ISO 7/1 threaded
coupling with mechanical gasket.
b) For free standing: A non-metallic flexible pipe can be used
as long as it complies with current standards and the
following installation instructions are observed: the pipe
must be longer than 400 mm and shorter than 1500 mm; it
must not exceed 50°C in any point; it is not pulled or
twisted; it cannot be choked and the entire edges, sharp
corners or other similar hazards.
Before connecting the non-metallic flexible pipe, the brass adapter and gasket supplied with
the cooker and/or available form the reseller must be fitted to the pipe/gas train on
the back of the cooker. The regulator provided should be positioned between the brass
adapter and the non metallic flexible pipe.
c) A certified gas plumber must complete the installation and meet with local regulation
requirements for gas connections. Where the unit has an armour cable a certified electrician
must complete the electrical connection. The white, or neutral wire will not be used and must
be capped using a marrette.

7
WARNINGS:
In order to prevent tipping of the appliance, must be installed a stabilized means.
Please see the picture. The chain on the back of the range
need to be fixed to the wall
(PLEASE NOTE: The fixing hook is not provided as the type will depend on the
construction of the wall to which it will be drilled and fitted. The installer should
provide the fixing hook per customer request).
B -Cooker Measurements ( 600x640x920 )
Measurements
Please note that all dimensions provided are in millimeters (mm.) The sizes allow for only a small
degree of error so all cut-outs must be precise and square
If the range is placed on a base, measures must be taken to prevent the appliance slipping off
the base
600
640
920
600
640
920

8
C –Electrical requirements
WARNING:
All aspects of the installation must conform with the requirements of the Standard North
America (within North America) wiring rules, as well as your local electrical and building
codes and regulations, and any other applicable requirements and conditions of your local
power supply authority.
A licensed electrician must perform the electrical work when installing this appliance. The
supply cable and fuse rating must be suitable for the appliance
WARNING:
To avoid power borne interference, this appliance must be installed individually on a separate and
distinct final sub-circuit.
Voltage supply connection
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid hazard
When connected to a sub circuit, protected by a circuit breaker, it is recommended the circuit
breaker be the same as the total rating of the appliance.
To full disconnect the power supply, it is necessary to have a proper mean in the fixed
wiring in accordance with the wiring rules. It must have full disconnection under
overvoltage category III conditions.
The range is supplied with a power cord and plug, which can be withdrawn from the wall
socket
Electrical Loads
Oven
2350 W
Oven
2350 W
Grill 2800 W Grill 2800 W
Oven fan and light 90 W Oven fan and
light 90 W
Cearmic cooktop 6400 W Gas cooktop
TOTAL RATING AT 208V 8.70 KW TOTAL RATING
AT 208V 3.22KW
TOTAL RATING AT 240V 11.45 KW TOTAL RATING
AT 240V 4.05KW

9
D –Using the Appliance for the first time
After installation remove all notification labels (not identification or warning labels) and packaging
materials. After cleaning make sure cleaned surfaces are thoroughly rinsed and wiped dry using a
clean, soft cloth.
Power on
NOTE: oven will not operate unless the clock is set on manual
position
Burning in
Before cooking in the appliance an initial pre-heating is required to burn off the fine oil film used to
protect the elements for shipping.
Select a cooking mode and set the oven temperature to 180°C. With the oven door closed, leave
for approximately 5 minutes.
Repeat the above step for each cooking mode.
After completing the above make sure all controls are turned off. The oven is now ready for
cooking and grilling
DO NOT use aluminum foil on the base of ovens
The use of foil on the base of the oven to avoid spillage and improve cleaning is not
recommended. The bottom element is concealed under the base of the oven liner (not exposed).
Foil or dishes with reflective qualities must never be placed on the base of the oven during
cooking as the concentration of direct and reflected heat will damage the enamel surface.
NOTE
Damage resulting from such use isnot covered under the provisions of the warranty.
Initial heat up
Some smoke and smell may be noticed during the initial heat up cycle. This should quickly
dissipate, and is normal
If abnormal levels of smoke during use are observed (i.e.: it is not food that is burning), have the
appliance thoroughly checked.
Don’t use the appliance as a space heater
The appliance must never be used for warming or heating the surrounding room. Combustible
materials must never be placed on or near the appliance.
Do not leave children alone
Children must not be left unsupervised in the area where the appliance is in use. Children must
never be allowed to sit or stand on any part of the appliance.
Wear proper apparel when using the appliance
Loose fitting, hanging or highly flammable garments (such as synthetics) should never beworn
while using the appliance.
Use only dry pot holders

10
Moist or damp pot holders on hot surfaces may result in burns from steam. Do not allow pot
holder to touch hot heating elements. Do not use a towel or bulky cloth when handling hot
cooking utensils in the appliance.
Oven compartments must never be used for storage
Items, particularly flammable materials, must never be stored in an oven or near surface units.
Do not use water on grease fires
Fires or flame should be smothered using flameproof material or extinguished using a dry
chemical or other suitable fire retardant.
All installation, adjustments, and maintenance operations must be carried out by qualified
personnel, in accordance with the enclosed instructions and current installation standards. The
manufacturer accepts no liability for faulty installation, setting, handling and use of the cooker.
When the cooker is not in use , ensure that all the knobs are in the off position; furthermore, if it
is unused for a period of time, shut off the appliance’s main electricity supply.
E -Accessories
Your appliance should come equipped with the following items.
•1 x Deep Enameled Roasting Pan with dual height reversible Grill Rack insert –ready for
sliding into side rack positions
•2 x Wire Oven Shelves that can be fitted into Retractable Slide Runners or for sliding into
side rack positions
•Note: Additional oven shelves and pans are available as optional extras.
•2 x side catalytic panels
The oven shelf support consist of 5 positions. Always remember to position the racks before
warming up the oven, and remove all the shelves and roasting pan before cleaning operations.
2
3
4
5
1

11
Cooling Fan
The range is provided with a cooling fan motor to reduce the heat around the oven. The fan motor
is controlled by a sensor, which will start when the temperature achieves the level pre-fixed and
stop working when the temperature is reduced accordingly.
This safeguards both the oven and the adjoining cabinets from the possibility of temperature
damage.
Safety Thermostat
Your oven is fitted with an over temperature sensor that will automatically shut down your oven
for a period if it is deemed to be overheating-this sensor is fitted to the rear wall of the oven,
inside the outer case –it will only activate in extreme circumstances and is provided as protection
to the appliance and the adjoining furnishings. If activated it will shut down the appliance for a
short time and will automatically reset allowing normal operations –you should consult your
service technician if the problem re-occurs.
F -Electronic Programmer Operation
The 24 hour clock allows the setting of automatic cooking options up to 24 hours in
advance.
1-Minus Time Button
2Mode (Countdown Timer with Alarm, Cooking duration, Finish Cooking)
3+Plus Time Button
Setting the time on the 24 hour clock
IMPORTANT –NOTE FOR NEW INSTALLATION AND FIRST OPERATION
1-The clock will require setting when you first turn on the power (or following a power
failure).
2-At power on, the relay contact is opened. The display and AUTO symbol flashes and
time of day starts from 0:00.

12
3-Press PLUS and MINUS button simultaneously for minimum 3 seconds. The AUTO
symbol goes out, POT symbol goes on, the DOT is flashing. With the PLUS button
the time will advance slowly, and then speed up. If you over-shoot the desired time , use
the MINUS button)
4-Press the MODE button twice to display the time of day setting mode. The oven will be
in manual cooking mode.
5-The oven is now ready for use and to accept the selected cooking functions
6-The timer can be set for countdown up to 24 hours and for automatic cooking modes up
to 10 hours and will countdown to zero. When zero is reached the alarm will sound.
7-Setting the timer:
Press the MODE button for minimum 3 seconds. The BELL symbol is flashing and the
display shows 0:00. Using the PLUS button advance the timer to the desired time.
Once the countdown timer is set, the normal time of day will return to the display within
seconds. If you wish to check how much time remains on the countdown, press the To
MODE button for 3 seconds. The remaining time will be displayed. After 7 seconds the
normal time will return to the display.
8-To silence the alarm press the MODE button for minimum 4 seconds
Adjusting the tone of the electronic timer alarm.
The tone is adjusted simply by pressing the minus button. There are 3 different tones from which
you can select. To change the tone you press the “+” and “-“ simultaneously, then press the Mode
button, ton will be displayed. Pressing the “-“ button while ton is in the display, will change the
tone to the desired setting
The electronic timer will store in its memory the last tone activated
Manual cooking
Once the time of day is set the POT symbol will be displayed. The oven is now in manual
operation mode ready for you to select the desired cooking function and temperature
Automatic cooking modes(Based on setting the duration “DUR”)
Set function and temperature to the desired position
For example: if you wish to cook for 45 minutes. Press the MODE button minimum for 4 seconds.
Press the MODE button again. The AUTO symbol is flashing and the display shows “dur”. The
display automatically switches over between "dur" display and 0:00. During this time you can set
the duration time of 45 minutes by pressing the PLUS button (use MINUS button should you over-
shoot the required time). Release and the display will return to the normal time of day after 7
seconds. The AUTO symbol will also appear indicating that you have set the automatic cooking
function.
The oven will operate for 45 minutes only, turn off automatically and the alarm will sound. The
AUTO symbol is flashing and the POT symbol will disappear. The alarm will turn off after pressing
the MODE button.
If you hold the MODE button down longer than 4 seconds the oven will return to the normal
cooking mode.
If further cooking is required, either leave on manual or repeat the above setting sequence.
Note: If you have not turned the function and thermostat setting off, your oven will now
continue to operate manually. The AUTO symbol will disappear and the POT symbol
will reappear.
Setting a cook stop time

13
1Set the function and thermostat control to the desired position
2For example: if you commence cooking and decide you would like the oven to turn off at
6.00pm. Press the MODE button minimum for 4 seconds. Press the MODE button two times
again. The AUTO symbol is flashing and the display shows “End”. The display automatically
switches over between "End" and time of day. During this time you can set the cooking stop time
to 6.00pm, i.e.18:00 on the 24 hour clock, by pressing the PLUS button (use MINUS button
should you over-shoot the required time). Release and
The display will return to the normal time of day after 7 seconds. The AUTO symbol will
also appear indicating that you have set the automatic cooking function.
3The oven will continue to cook until 18:00 (6.00pm) and then switch off and the alarm will
sound. The AUTO symbol is flashing and the POT symbol will disappear. The alarm will
turn off after pressing the MODE button.
4If you hold the MODE button pressed longer then 4 seconds the oven will return to the
normal cooking mode.
If further cooking is required, either leave on manual or repeat the above setting sequence.
Note: If you have not turned the function and thermostat setting off, your oven will now continue
to operate manually. The AUTO symbol will disappear and the POT symbol will reappear.
Fully automatic –(Start Later –Stop Later)
Your oven may be programmed to start, cook for the desired time and turn off automatically.
This function is particularly useful in the preparation of the evening meal, should you be out
during the day, it will be ready on your return home. For example if your cooking time is 45
minutes and you want the cooking to finish at 6.00 p.m.
Press the MODE button minimum for 4 seconds. Press the MODE button again. Set the cooking
duration time for say 45 minutes using the PLUS or MINUS button.
Press the MODE button again. Set the stop cooking time to 6.00pm (18:00). Release and the
display will return to the normal time of day after 7 seconds. The AUTO symbol will be displayed.
Using the above settings, the oven is now programmed automatically to commence cooking 45
minutes prior to 6.00 pm. Then automatically turn off.
When cooking is complete the AUTO symbol is flashing and the POT symbol will disappear and
the alarm will sound. The alarm will turn off after pressing the MODE button.
If you hold the MODE button pressed longer then 4 seconds the oven will return to the normal
cooking mode.
Canceling automatic settings
To cancel a program:
Press plus and minus button simultaneously for minimum 3 seconds.
NOTE:
On oven start up or possibly at other times, due to electricity supply deviations –the
programmer may freeze on a function –if this occurs we recommend that, after checking
other solutions without success, it is recommended that power supply be disconnected to
the appliance and allow it to be in this position for some minutes before reconnecting.
This may have a result of clearing the frozen position allowing you to reset the
programmer for normal operation.

14
G -Gas Cooktop Control Panel
Technical Characteristic table
BURNERS
N° DESCRIPTION GAS
1 SEMI-RAPID
2 RAPID
3 AUXILIARY
4 WOK NATURAL 10 160 REG.
NOMINAL
HEAT INPUT
MAX.
MJ/h(bTU/H)
PROPANE 28 105 65
13.7(12000)
NORMAL
PRESSURE
mbar
INJECTOR
DIAMETER
1/100 mm
TAP BY PASS
DIAMETER
1/100mm
PROPANE 28 55 35
3.7(3500)
PROPANE 28 90 46
10.5(10000)
PROPANE 28 72 35
6.3(6000)
NATURAL 10 90 REG.
NATURAL 10 155 REG
NATURAL 10 118 REG.
21
43
1= semirapid burner 2= rapid burner
3=auxiliary burner 4= wok burner

15
H -Gas Cooktop Functions
B -Cooking Instructions
Automatic start-up with valves
Turn the corresponding knob anticlockwise up to the maximum position and press the knob.
Once the burner has been started up, keep theknob pressed for about 6 seconds.
Using the burners
In order to obtain the maximum yield without wasting gas, it is important that the diameter of
the pot is suitable for the burner potential (see the following table and fig.1). This is to avoid the
flame extremities being larger than the base of the pot. All of the operating positions must be
chosen between the maximum and the minimum ones, never between the minimum position and
the closing point.
The gas supply can be interrupted by turning the knob clockwise up to the closing position.
NOTE:
If there is no power supply, it is possible to light the burners with matches, setting the knob to the
startup
point (large flame, fig. 1).
BURNERS POWER (MJ/h) POWER (Btu/h) Ø of pots
Auxiliary 3.2
3000 10 -14 cm
Semi-rapid 6.3
6000 16 -18 cm
Rapid 11.6
11000 20 -22 cm
Wok 17.9
17000 24 -26 cm
NOTE:
When the equipment is switched off, always check that the knobs are in the closing position.
If the flame should blow out accidentally, the safety valve will automatically stop the gas supply,
after a few seconds. To restore operation, set the knob to the lighting point and press. While
cooking with fat or oil, pay the utmost attention as these substances can catch fire when
overheated.
WARNING:
-Do not use sprays near the appliance in operation.
-Do not place unstable or deformed pots on the burner, so as to prevent them from overturning or
overflowing.
-Always turn gas off if moving a pot away from the appliance.

16
I-Ceramic Cooktop Control Panel
Ceramic Cooktop Controls:
To operate Single (inner zone) and separate Dual (inner + outer zone) follow
this procedure:
a/ Inner Zone -rotate control knob in clockwisedirection selecting power from positions 1
through 12. The inner zone only will operate.
b/ Inner + Outer Zone = Full Power -rotate control knob clockwise through position 12 as
above, then through to the Dot on control panel only -a click will sound (do not Rotate control
knob all the way to OFF position as this will turn power OFF). Then rotate control knob
backwards (anticlockwise) selecting power level from 1 to 12 as before. This will activate both
Inner and Outer zones concurrently for maximum power.
c/ To deactivate (turn off) Inner Zone or Inner + Outer Zone the control knob must be returned
to the OFF position
IMPORTANT:
1/ DO NOT TURN CONTROL KNOB ANTICLOCKWISE FROM OFF POSITION AS THIS WILL
DAMAGE THE CONTROL MECHANISM -OPERATE SINGLE AND DUAL ZONES STRICTLY
ACCORDING TO THE INSTRUCTIONS AS ABOVE.
Switch controlling the
left, front hot plate.
Turning the knob
Clockwise activates
the full hot plate
Switch controlling
the left, back hot
plate.
Switch controlling
the right, back hot
plate.
Turning the knob
clockwise activates
the full hot plate.
Switch controlling
the right, front hot
plate.

17
L-Ceramic Cooktop Functions
WARNING
--If the surface is cracked, switch off the appliance to avoid the possibility of electric
shock, for hob surface of glass-ceramic or similar material which protect live parts
-- During the use the appliance becomeshot. Care should be taken to avoid touching
heating elements of the cooktop and inside the oven. Accessible parts may become hot
during use. Young children should be kept away.
All operations relative to installation and electric connection should be carried out by qualified
personnel in conformity with the regulations in force in North America
The specific instructions are described in the booklet section for the installer
NOTICE
•Use only flat pans with a sufficiently thick base, equal to or not much larger than the hot plate
selected (fig.1)
•The containers should not have rough bottoms, otherwise scratching will occur.
•Do not switch the electric plate on without the pan over the plate.
•Do not cook any food directly on the hot area. Avoid overflows of liquid and should they occur
clean away promptly.
•The appliance is not intended to be operated by means of an external timer or separate
remote-control system.
Switching on
Set the power by rotating the knob, taking into consideration that the highest number corresponds
with the maximum power.
The pilot light is switched ON when at least one element is on. The residual heat indicator will
light up when the temperature in any area is higher than 50°C.
Cleaning
Remove leftover and greaseor spillage from the cooking surface with the special scraper (fig.3)
(optional).
Then clean the heating area thoroughly with a paper towel and ceramic cleaning products for the
correct care of your appliance. Never use abrasive sponge or irritating chemical detergents such
as over spray or spot removers.
FIG-.1

18
M-Oven Functions & Control Panel
Control Panel:
-- During use the appliance becomes hot. Care should be taken to avoid touching
heating elements of cooktop and inside the oven. Accessible parts may become hot
during use. Young children should be kept away.
PREHEATING
Preheating the oven is not essential, but you will achieve better results if you do. Some foods,
particularly cakes and pastry, are better cooked in a preheated oven. Other foods, for example
casseroles, cook just as well when cooked in a non-preheated oven but may need longer cooking
times.
For faster preheating select pizza mode and the required temperature and once the oven has
reached the required level change to cooking mode/function for the task.
To preheat the oven:
1-Set the mode required for preheating.
2-Set the oven to the desired temperature
Preheating guide (for 180°C settings)
Cooking Mode Preheat Time
CONVENTIONAL
OVEN 15-20 MINUTES
FAN OVEN 15-20 MINUTES
NOTE:
Any food or other cooking utensils placed in the oven during preheating will affect the preheating
time. The preheat time may also vary with installations.
WARNING
When using an alternative cooking mode for fast preheat, be sure to turn the cooking mode to
your required setting before placing food in the oven

19
HINT:
To allow for heat loss while placing food into the oven, preheat the oven 10-20°C higher and then
reduce the temperature to your required cooking temperature.
Always preheat the oven when cooking multiple dishes at the same time.
Roasting guide. These cooking charts are intended as a guide only. Temperature and cooking
times may vary to suit individual tastes.
Type of Meat
Approx. 450 grams =
1lb
Cuts of Meat Time per lb
(allow) Oven Temperature
0C
Beef Prime Rib, rolled
sirloin bolar blade,
Top Loin, New York
Strip Sirloin
60 minutes per 2lbs
40 minutes per 2lbs
1800–2000
1800-2000
Veal Shoulder or leg (with
bone or rolled) 40-50 minutes per 2lbs. 1800-2000
Lamb Leg, shoulder (loin or
rolled) 40-50 minutes per 2lbs 1800-2000
Pork Leg loin 90 minutes per 2lbs. 2200-2300/ 1800-2000
Pork leg should be cooked at a higher temperature for the first 15-25 minutes then reduced to
lower temperature for remaining cooking time.
Type of Poultry Size of Meat Time per lb Oven Temperature
0C
Chicken Whole or pieces 30 minutes per lb. 1800-2000
Duck 3lbs –4.1lbs 30 minutes per lb.
+ 35 minutes extra 1800-2000
Turkey 5.4lbs –21lbs 20 minutes per lb.
+ 35 minutes extra 1800-2000
Turkey should be well basted and turned during cooking
Type of Fish Cuts of Fish Time per lb Oven Temperature
0C
Fish Whole or fillets 10 minutes per lb. 170-1900C
In Conventional Oven mode, fish should be covered for the first ¾ of the cooking time to help
retain moisture.
Baking guide. These cooking charts are intended as a guide only. Temperature and cooking
times may vary to suit individual tastes.
Oven Temperature 0CGeneral Times Foods Suitable
1300–under Very slow Small meringues, pavlova, custard, reheating
1300-1500Slow Rich fruit cake, light fruit cake
1500-1800Moderate Casseroles, deep butter cake
1800-2000Moderately hot Shallow butter cakes, sponges, biscuits, meat loaf,
baked fish
2000-2300Hot Swiss roll, patty cakes, rock cakes, short crust pastry
2300–and over Very Hot Scones, Choux pastry

20
DEFROST
This function activates the fan , to allow controlled and hygienic defrosting.
(no heat is required, in case you want to speed up the operation, you can set the
thermostat knob to 50°C)
As a general guide, the defrosting time for meat is approximately 15-20 minutes per
kilogram.
CONVENTIONAL OVEN
In this traditional mode, oven heat is provided from elements located at the top and under the
oven compartment and is most suitable when cooking on a single shelf. For best results, arrange
the shelves so the top of the food is near the centre of the oven.
If cooking on more than one shelf, always preheat the oven and position the pans to allow as
much free circulation of heat as possible.
Depending on the food, you may need to rearrange the tray position during cooking.
1-Adjust oven shelves to desired position/s.
2-Select Conventional Oven mode.
3-Set the oven to the desired temperature.
4-When cooking is complete turn the oven off.
HINT:
If water is used in your cooking (such as water placed in a baking dish) the water will evaporate in
the oven in the form of steam. The level of condensation will be reduced when cooking in fan
oven mode where excess moisture is circulated and evaporates during the cooking cycle.
NOTE:
Stand clear of the oven when opening the oven door as steam may escape rapid
FAN ASSIST
This style of cooking provides traditional cooking heating from top and bottom elements with the
assistance of a circulation fan to ensure fast even results. This mode is most suitable for delicate
cooking such as cakes, pastries, gateaux, biscuits and yeast dough. Best results when
thermostat is set to 150-180 degrees –depending on recipe.
This function is also excellent as the fastest oven pre heat, engaging maximum power to heat the
oven to a selected temperature before selecting an appropriate function and temperature for a
task.
