Alcatel MDR-8000 User manual

MDR-8000 /i/s /u
Alcatel Part Number 3EM11931AA
3400 West Plano Parkway
Plano, Texas 75075-5813 U.S.A.
Issue 7, October, 2005
Microwave Digital Radios
Users Manual

CUSTOMER ASSISTANCE
24 HOURS PER DAY, 7 DAYS PER WEEK
ALCATEL'S PRIMARY MISSION IS SATISFYING OUR CUSTOMERS'
QUALITY EXPECTATIONS.
The ALCATEL call center [phone] is available 24 hours per day, seven days per week
(including holidays) for helping the customer. This single-point contact for assistance
reaches out to all areas of customer support, including:
Registered customers have access to online support documentation (i.e., product bulletins and
documentation update notifications) at the following Website:
For registration information, contact your Alcatel representative.
• Quality hot line
• After-hour emergencies
• Off-site Technical support
• On-site Technical support
• Manufacturing-discontinued product support
• Module repair
• Installation and test
• Software and hardware upgrades
• Technical training
• Electronic file registration for update notification
http://www.usa.alcatel.com

T able of Contents
TOC - i
Page
Section 1 General
1.1 INTRODUCTION ............................................................................................. 1 - 1
1.2 CONTENT ....................................................................................................... 1 - 1
1.3 RELATED DOCUMENTATION ........................................................................... 1 - 2
Section 2 Operation
2.1 GENERAL ........................................................................................................ 2 - 1
2.2 TURN-ON ........................................................................................................ 2 - 1
2.3 USER SYSTEM INTERFACE (USI) PROVISIONING FUNCTION/OPERATION ...... 2 - 2
2.4 OPERATING PROCEDURES .............................................................................. 2 - 2
2.4.1 Radio Receiver Manual Switching ..................................................................... 2 - 2
2.4.2 Radio Transmitter Manual Switching ................................................................. 2 - 5
2.4.3 Radio I/O Interface Manual Switching .............................................................. 2 - 5
2.4.4 MCS-11 Operation .......................................................................................... 2 - 7
2.4.5 Lamp Tests ....................................................................................................... 2 - 8
2.4.6 Alarm Checks .................................................................................................. 2 - 8
2.4.7 Orderwire Operation ....................................................................................... 2 - 8
2.4.8 Initiating Outgoing Orderwire Calls .................................................................. 2 - 8
2.4.9 Answering Incoming Orderwire Calls ................................................................ 2 - 8
2.5 TURN-OFF PROCEDURE ................................................................................... 2 - 9
2.6 EMERGENCY OPERATION .............................................................................. 2 - 9
2.7 MODEM OPERATION ...................................................................................... 2 - 9
2.8 CONTROLS, INDICATORS, TEST POINTS, AND CONNECTORS ....................... 2 - 9
Section 3 Interconnect
3.1 SECTION INTRODUCTION .............................................................................. 3 - 1
3.2 INSTALL POWER CABLE ASSEMBLIES ............................................................... 3 - 1
3.3 PDU STRAPPING AND CONNECTIONS ........................................................... 3 - 3

Page
TOC - ii
3.4 SHELF/RACK ALARM CONNECTION .............................................................. 3 - 5
3.5 DS1 CONNECTIONS (J303 IN AND J304 OUT) .............................................. 3 - 8
3.6 DS1 REPEATER (J314 ON ONE SHELF TO J314 ON SECOND SHELF) ............ 3 - 10
3.7 DS3 LBO STRAPPING AND CONNECTIONS ................................................. 3-11
3.8 DS3 LBO DS3 BNC CONNECTIONS (J21 THROUGH J26) ............................. 3-12
3.9 DS3 LBO WAYSIDE DS1 CONNECTIONS (J201 IN AND J202 OUT) ............. 3-13
3.9.1 Wayside DS1 Terminal .................................................................................. 3-14
3.9.2 Wayside DS1 Repeater .................................................................................. 3-15
3.10 DS3 REPEATER (J401 ON ONE SHELF TO J401 ON SECOND SHELF) ............ 3-15
3.11 FIBER OPTIC CABLE CONNECTIONS ............................................................. 3-16
3.11.1 2 or 4 Fiber Management Panel ..................................................................... 3-17
3.11.2 2x4 Fiber Switched Management Panel .......................................................... 3-17
3.12 OC3 AUX INTERFACE BOARD WAYSIDE DS1 CONNECTIONS
(J201 IN AND J202 OUT) .............................................................................. 3-20
3.12.1 Wayside DS1 Terminal .................................................................................. 3-20
3.12.2 Wayside DS1 Repeater .................................................................................. 3-20
3.13 OC3 REPEATER (J203 ON ONE SHELF TO J203 ON SECOND SHELF) ........... 3-21
3.14 USI/CONTROLLER CABLE CONNECTION TO LAPTOP (J301) ......................... 3-22
3.15 SERVICE CHANNEL ....................................................................................... 3-22
3.15.1 Handset Jack ................................................................................................. 3-23
3.15.2 Service Channels Provisioning Options ............................................................ 3-24
3.15.3 Audio 1, Audio 2 (J316, J317) ....................................................................... 3-24
3.15.4 RS-232-1, RS-232-2 (J312, J313) .................................................................... 3-27
3.15.5 MCS-11 Connections ..................................................................................... 3-28
3.15.6 ELMC (J315, J318) ........................................................................................ 3-36
3.16 FOREIGN ALARM INTERFACE (J305) ............................................................. 3-40
3.17 ALARM, STATUS, CONTROLS INTERCONNECT ............................................. 3-43
3.17.1 Controller Bus ................................................................................................ 3-45
3.17.2 Control Inputs ................................................................................................ 3-45
3.17.3 Station Alarm Inputs/TBOS Interface ............................................................... 3-45
3.17.4 Station Alarm Wiring ..................................................................................... 3-46
3.17.5 Relay Alarm/Status Outputs ............................................................................ 3-47
3.17.6 Relay Control Outputs .................................................................................... 3-49

Page
TOC-iii
Section 4 Initial Turnup
4.1 SECTION INTRODUCTION .............................................................................. 4-1
4.2 RECOMMENDED SEQUENCE ......................................................................... 4-1
4.3 SECURITY MANAGEMENT .............................................................................. 4-1
4.4 TEST PROCEDURES ..........................................................................................4-2
4.5 PROVISIONING RADIO ...................................................................................4-2
Section 5 Maintenance
5.1 GENERAL ........................................................................................................5-1
5.2 RECOMMENDED TEST EQUIPMENT ................................................................ 5-1
5.3 OPTIONAL TEST EQUIPMENT .......................................................................... 5-2
5.4 RECOMMENDED PERIODIC CHECKS ............................................................... 5-3
5.5 TROUBLESHOOTING .......................................................................................5-3
5.5.1 Troubleshooting RCVR Lockup Problems ............................................................. 5-3
5.5.2 Troubleshooting performance Screen Errors ....................................................... 5-3
5.5.3 Troubleshooting Using the USI RSL Screens ........................................................ 5-4
5.6 MODULE REPLACEMENT ............................................................................... 5-19
5.7 POWER SUPPLY REMOVAL AND REPLACEMENT ............................................ 5-21
5.8 CONTROLLER REMOVAL AND REPLACEMENT ............................................... 5-22
5.9 DS3 I/O INTERFACE REMOVAL AND REPLACEMENT ..................................... 5-26
5.10 DS3 RADIO DADE .........................................................................................5-29
5.11 DS3 LINE DADE .............................................................................................5-30
5.12 OC3/STM-1 I/O INTERFACE REMOVAL AND REPLACEMENT ........................ 5-34
5.13 XMTR REMOVAL AND REPLACEMENT ............................................................ 5-35
5.14 XMT CRYSTAL OSCILLATOR FREQUENCY CORRECTION ................................ 5-41
5.15 XMTR OUTPUT LEVEL CHECK (NO PA) ........................................................... 5-42
5.16 IN-SERVICE XMTR CARRIER NULL ADJUSTMENT USING SPECTRUM ANALYZER .. 5-43
5.17 XMTR CARRIER NULL ADJUSTMENT USING SPECTRUM ANALYZER ................ 5-51
5.18 XMTR CARRIER NULL ADJUSTMENT USING DVM ........................................... 5-54
5.19 XMTR OUTPUT LEVEL CALIBRATION ............................................................... 5-56
5.20 RCVR REMOVAL AND REPLACEMENT ............................................................ 5-61
5.21 RCV CRYSTAL OSCILLATOR FREQUENCY CORRECTION ................................ 5-64
5.22 PA REMOVAL AND REPLACEMENT ................................................................ 5-65
5.23 PA OUTPUT LEVEL CALIBRATION ................................................................... 5-67

Page
TOC-iv
Appendix A CommPak Indoor Shelf
A.1 COMPONENT LOCATIONS AND OPTIONS ....................................................A-1
A.1.1 External Fan Assembly .....................................................................................A-5
A.2 INTERCONNECT .............................................................................................A-5
A.2.1 Power Cable Assembly .....................................................................................A-5
A.2.2 External Fan Assembly .....................................................................................A-8
A.2.3 SHELF/RACK ALARM CONNECTION ..............................................................A-9
A.2.4 DS1 LBO Connections ....................................................................................A-11
A.2.5 DS3 LBO CONNECTIONS .............................................................................A-13
A.2.6 Fiber Optic Cable Connections .......................................................................A-16
A.2.7 OC3 AUX Interface Board Connections ...........................................................A-17
A.2.8 Controller Cable Connection (J301) ................................................................A-19
A.2.9 Audio Cable Connections ...............................................................................A-20
A.2.10 RS-232 Cable Connections .............................................................................A-21
A.2.11 MCS-11 Cable Connections ...........................................................................A-21
A.2.12 ELMC Cable Connections ...............................................................................A-25
A.2.13 Foreign Alarm Interface (J305) ........................................................................A-26
A.2.14 Station Alarm Wiring .....................................................................................A-27
A.3 MAINTENANCE ............................................................................................A-29
A.3.1 Warnings and Cautions .................................................................................A-29
A.3.2 Troubleshooting .............................................................................................A-29
A.4 MODULE REPLACEMENT ...............................................................................A-29
A.4.1 PA Module Removal and Replacement ............................................................A-30
A.4.2 DS1/E1 LBO Module Removal and Replacement .............................................A-34
A.4.3 DS3 LBO Module Removal and Replacement ...................................................A-35
A.4.4 OC3 AUX Interface Board Removal and Replacement ......................................A-36
A.5 CAPACITY UPGRADE DS1 TO DS3 OR DS3 TO OC3 .....................................A-37
A.6 CHANGING SYSTEM SOFTWARE .................................................................A-38
Appendix B CommPak Outdoor Unit
B.1 INSTALLATION ................................................................................................ B-1
B.1.1 CommPak Indoor Shelf Installation .................................................................... B-1
B.1.2 CommPak Outdoor Unit Installation ................................................................... B-2
B.2 INTERCONNECT ............................................................................................. B-4
B.3 MAINTENANCE .............................................................................................. B-4

FM-i
SAFETY PRECAUTIONS
While the manufacturer has attempted to detail in this manual all areas of possible
danger to personnel in connection with the use of this equipment, personnel should
use caution when installing, checking out, operating, and servicing this equipment. As
with all electronic equipment, care should be taken to avoid electrical shock in all cir-
cuits where substantial currents or voltages may be present, either through design or
short circuit.
Definitions of Danger, Warnings, Cautions, and Notes used throughout this manual
are described below:
An operating procedure, practice, etc., which, if not correctly
followed could result in personal injury or loss of life.
An operating procedure, practice, etc., which, if not
strictly observed, could result in damage to or destruc-
tion of equipment.
An operating procedure, practice, etc., which, if not cor-
rectly followed, could result in an interruption of service.
An operating procedure, condition, etc., which is essential to highlight.
DANGER
Possibility of
Injury
to Personnel
WARNING
Possibility of
Damage
to Equipment
CAUTION
Possibility of
Service
Interruption
Note

FM-ii This page intentionally left blank.

1-1
1GENERAL
1.1 INTRODUCTION
This MDR-8000 Users Manual contains information on the MDR-8000 Hot-Standby Shelf,
MDR-8000 CommPak Indoor Shelf, and MDR-8000 CommPak Outdoor Unit as follows:
MDR-8000 Hot-Standby Shelf (Figure 1-1) – Section 1 through Section 5
MDR-8000 CommPak Indoor Shelf – Appendix A
MDR-8000 CommPak Outdoor Unit – Appendix B
The information in the Users Manual is a summary of the overall instruction book that is
located on the attached CD. The summary information is provided to support initial turnup,
day-to-day operation, and maintenance of the MDR-8000 equipment.
1.2 CONTENT
Refer to Table 1-1. The MDR-8000 Instruction Book Section/Appendix column lists the
parts of the MDR-8000 Instruction Book, PN 3DH03220. A check mark under the Users
Manual column or the Instruction Book CD column indicates that this information is
located in either the Users Manual, the Instruction Book, or both.
Table 1-1 Information Location
Location
Section/Appendix Users Manual MDR-8000 Instruction Book
Glossary √
General
Ordering Information
Features and Options
Supplied and Optional equipment
Part Numbers
Physical, Environmental, and Electrical Characteristics
√
√
√
√
√
Application √
Functional Description √
Physical Installation √
Interconnect √ √
Initial Turnup
Radio Provisioning
√
v
√
√
Operation
Controls and Indicators
√
√
√
√

1-2
1.3 RELATED DOCUMENTATION
The following documentation supplements the MDR-8000 Instruction Book and Must be
ordered separately:
Users Guide
USI Screen Descriptions
√
√
Maintenance
Troubleshooting
Module Replacement Procedures
Post-Replacement Test procedures
√
√
√
√
√
√
√
√
Diagrams √
Rack Installation √
Alarm/Status/Control √
MCS-11 Reference Guide √
Modem Provisioning √
Maintenance Support Procedures
Optional Over-The-Hop Performance Tests
√
√
CommPak Indoor Shelf √ √
CommPak Outdoor Unit √ √
Document Alcatel Part Number
MDR-8000U CommLite Radio Instruction Book 3EM16680AAAA
MDR-8000E Ethernet Radio Supplement 3EM17287AAAA
MDR-8000 TMN Interface Unit Instruction 3EM13538AAAA
MDR-8000 Upgrade Procedure 3EM1932AAAA
Table 1-1 (Cont.) Information Location

1-3
Figure 1-1 Typical MDR-8000 Hot-Standby Shelf Component Locations and Options (Sheet 1 of 3)
LBO/OC3 AUX INTFC
SELECT LBO/OC3 AUX INTFC
TO MATCH I/O INTFC
(DATA RATE)
CE–16BB
POWER
SUPPLY
A1
CE–16BB
POWER
SUPPLY
B1
UD–36A( )
RCVR
A2
AE–37Y
CONTROLLER
C1
AE-27AA
TMN INTFC
OR BLANK C3
UD–35A( )
XMTR
A4
UD–35A( )
XMTR
B4
UD–51( )
PWR AMP
A5
UD–36A( )
RCVR
B2
UD–51( )
PWR AMP
B5
I/O INTFC
A3
I/O INTFC
B3
LMW-7030-SM
06/09/04
ALM
ON
LINE
ALM
ON
LINE
SYNC
ALM
COM-
MON
LOSS
ALM
DX-35M
DS1/EI
SELECT A3 AND B3
I/O INTFC MODULES
BY DATA RATE
DX-35N
DS3
XMT
AUX
SC
ALM
RCVR
ON
RAD
LOF
WYSD
DS1
WYSD
ALM
DS3
ALIGN
RAD DADE
1
2
3
5
6
7
8
9
0
1
2
3
4
DX-35P
OC3
ALM
INSVC
OC3
IN
OC3
ALM
WYSD
ON
WYSD
ALM
OC3
OUT
DS1/E1 LBO
DS3 LBO
OC3 AUX INTFC
AE–27AF
RELAY
INTFC
C2

1-4
Figure 1-1 Typical MDR-8000 Hot-Standby Shelf Component Locations and Options (Sheet 2 of 3)
LBO/OC3 AUX INTFC
SELECT CAPACITY
KEY BY DATA RATE.
SELECT XTAL
OSCILLATOR
SUBBOARD BY
CRYSTAL
FREQUENCY.
SELECT DS1/E1 CAPACITY KEY BY
CAPACITY AND MODULATION SCHEME
2, 4, 8, 12, 16 DS1/E1 AND 32 OR 128 TCM.
SELECT DS3 CAPACITY KEY BY
NUMBER OF LINES – 1, 2, OR 3 LINES.
SELECT OC3 CAPACITY KEY BY
NUMBER OF STS1 LINES – 1 OR 3 LINES.
CE–16BB
POWER
SUPPLY
A1
CE–16BB
POWER
SUPPLY
B1
UD–36A( )
RCVR
A2
AE–27AF
RELAY
INTFC
C2
AE–37Y
CONTROLLER
C1
UD–35A( )
XMTR
A4
UD–35A( )
XMTR
B4
UD–51( )
PWR AMP
A5
UD–36A( )
RCVR
B2
UD–51( )
PWR AMP
B5
I/O INTFC
A3
I/O INTFC
B3
LMW-9051-SM
02/15/04
DS1/E1
DS3
OC3

1-5
Figure 1-1 Typical MDR-8000 Hot-Standby Shelf Component Locations, and Options (Sheet 3 of 3 )
RF
SWITCH
B-SIDE
POWER
RF SWITCH
XMT
A
RCV
ANT
B
RCV
ISOLATORS
HEAT
SINK
A-SIDE
POWER
LMW-7211-SM
06/08/04
DIPLEXER
FILTER
MOUNTING
BRACKET
ISOLATOR
DIPLEXER
FILTER
REAR VIEW
(TYPICAL HOT-STANDBY 1:10 COUPLER
SINGLE ANTENNA CONFIGURATION)
Location of A and B RCV ports on diplexer filter varies,
depending on RF frequency. For some frequencies, A and
B ports reverse location.
Note

1-6 This page intentionally left blank.

2-1
2OPERATION
2.1 GENERAL
This section contains turn-on, normal operation, turn-off, and emergency operating
procedures plus a description of controls. indicators, test points, and connectors for the
MDR-8000 Series Microwave Digital Radios.
Before performing any procedures, operating personnel should become
familiar with the locations of power distribution units and circuit
breakers. If an equipment performance problem occurs during the fol-
lowing procedures, refer to the Maintenance section.
2.2 TURN-ON
The radio is designed to operate continuously without operator intervention. After initial
installation and power turn-on, operating procedures are limited to periodic visual lamp
checks, alarm checks, and answering or initiating orderwire service calls. Turn-on procedures
are needed only if the system has been turned off due to a malfunction or during maintenance.
Exposure to energy radiated at microwave frequencies can
cause eye damage and eventual blindness. Do not operate
the system with either the transmit or the receive waveguide
port unterminated. Do not look into the waveguide run or the
antenna of an operating radio.
Until all radios in the transmission link are interconnected, turned on,
and operating properly, alarm conditions may exist.
Perform the following procedure to turn on the MDR-8000 series radios:
1On all power supply modules, set power ON/OFF switches to ON.
2Verify that power distribution unit rack alarm indicator (if any) is not lighted.
If indicator is lighted, troubleshoot as described in the Maintenance section.
3Verify that no red indicators are lighted. If a red indicator is lit, troubleshoot
as described in the Maintenance section.
4Perform lamp test by momentarily holding OVRD-ACO/LT switch on control-
ler to ACO/LT. All indicator lamps/LEDs should light.
Note
WARNING
Possibility of
Damage
to Equipment
Note

2-2
2.3 USER SYSTEM INTERFACE (USI) PROVISIONING FUNCTION/OPERATION
The User System Interface (USI) software is used for maintenance and support of the
radio including fault and status reporting. Refer to the Initial Turn-Up section for instruc-
tions on loading and running the software. Refer to the User’s Guide section for descrip-
tions and functions of the menus.
Refer to the Software Release Notes before performing any operating,
provisioning, or maintenance function on this equipment. The Software
Release Notes may contain information affecting these functions that is
not contained in this instruction manual.
2.4 OPERATING PROCEDURES
The USI computer is the main control for the radio. If instructions for
setting up the USI computer are needed, refer to Initial Turn-Up section.
After installation and turn-on, operating procedures are limited to periodic alarm checks
and, when necessary, answering or initiating orderwire calls. Automatic and manual
switching are provided for equipment protection. Manual switching may be accomplished
using the Control screen on the USI computer or the switches on the front panel of the con-
troller module. The following paragraphs provide operating procedures for manual
switchover of protected radio systems.
2.4.1 Radio Receiver Manual Switching
When used in conjunction with a RCVR manual switch, press the
OVRD switch to lock the receiver on line regardless of alarms. Press
again to unlock.
Controller Switch
Perform RCVR manual switch (Figure 2-1) using controls on front panel of controller
module:
USI Switch
Perform RCVR manual switch (Figure 2-2) using the USI control screen.
Note
Note
Note

2-3
Figure 2-1 Manual Switch From Controller Front Panel
ALM
OFF
NORM
SHLF
ALM
ALM
ON
LINE
RX
L
AB
ALM
ON
LINE
TX
L
AB
ALM
RSP
RSP
ON
LINE
I/O
L
A
POLL
LCL
RMT
B
A
C
O
/
L
T
O
V
R
D
RF RPTR
CMD
IDLE
T
E
L
U
S
I
TOGGLE SWITCH LEFT TO SWITCH A XMTR,
RCVR, OR I/O MODULE IN-SERVICE AND
TOGGLE SWITCH RIGHT TO SWITCH B
XMTR, RCVR, OR I/O MODULE IN-SERVICE.
LMW-5078-sm
08/15/02
OVERRIDE (OVRD) LOCKS XMTR, RCVR, OR
I/O MODULE, SELECTED ABOVE IN-SERVICE,
REGARDLESS OF ALARMS.
TO ENABLE OVERRIDE:
1. PRESS AND HOLD TX A/B ON LINE,
RX A/B ON LINE, OR I/O A/B ON LINE
SWITCH.
2. TOGGLE ACO/LT OVRD SWITCH TO OVRD
POSITION.
3. RELEASE A/B ON LINE SWITCH.
TO DISABLE OVERRIDE:
TOGGLE ACO/LT OVRD SWITCH TO OVRD
POSITION.
NOTE

2-4
Figure 2-2 RCVR Manual Switch Using USI Control Screen
File
Controls -- MDR-8000 DS3
View Setup Options
Alarm Status Performance Station Alarm User Control ProvisioningAnalog Monitor
F4 F5 F6 F7 F8 F9
LOCAL CONTROLS
Communicating*
ELMC Address:
Description:
SILVERTON
A Transmitter On Line
B Transmitter On Line
A Receiver On Line
B Receiver On Line
A I/O On Line
B I/O On Line
A ATPC HIGH Power Lock
B ATPC HIGH Power Lock
A ATPC LOW Power Lock
B ATPC LOW Power Lock
J7915
IN-SERVICE
A I/O LOOPBACK
Line 1 loopback
Line 2 loopback
Line 3 loopback
B I/O LOOPBACK
Control #1
Control #2
Control #3
Control #4
Control #5
Control #6
SYSTEM LOOP-BACK
DS1 LINE LOOP-BACK RCV to XMT
USER CONTROLS
Thursday, November 30, 2000 1:44:19 PM USI Version R1.02 Controller Version R1.02
LMW-5081-sm
08/15/02
2. SELECT RCVR TO PUT IN-SERVICE.
1. OPEN USI CONTROLS SCREEN.
3. SELECT YES ON CONFIRMATION MESSAGE
TO ENABLE FUNCTION.
4. VERIFY GREEN IN-SERVICE STATUS CIRCLE DISPLAYS.

2-5
2.4.2 Radio Transmitter Manual Switching
Switching the radio transmitter may momentarily interrupt
traffic. Before switching the transmitter, obtain permission
from the proper authority.
When used in conjunction with a XMTR manual switch, press the
OVRD switch to lock the XMTR on line regardless of alarms. Press
again to unlock.
Controller Switch
Perform XMTR manual switch (Figure 2-1) using controls on front panel of
controller module.
USI Switch
Perform XMTR manual switch (Figure 2-3) using the USI control screen.
2.4.3 Radio I/O Interface Manual Switching
Traffic and auxiliary channel service will be momentarily
interrupted. Obtain proper authorization before making this
switch.
When used in conjunction with an I/O interface manual switch, press
the OVRD switch to lock the I/O interface on line regardless of alarms.
Press again to unlock.
CAUTION
Possibility of
Service
Interruption
Note
CAUTION
Possibility of
Service
Interruption
Note

2-6
Figure 2-3 XMTR Manual Switch Using USI Control Screen
Controller Switch
Perform I/O manual switch (Figure 2-1) using controls on front panel of controller
module.
USI Switch
Perform I/O manual switch (Figure 2-4) using the USI control screen.
File
Controls -- MDR-8000 DS3
View Setup Options
Alarm Status Performance Station Alarm User Control ProvisioningAnalog Monitor
F4 F5 F6 F7 F8 F9
LOCAL CONTROLS
Communicating*
ELMC Address:
Description:
SILVERTON
A Transmitter On Line
B Transmitter On Line
A Receiver On Line
B Receiver On Line
A I/O On Line
B I/O On Line
A ATPC HIGH Power Lock
B ATPC HIGH Power Lock
A ATPC LOW Power Lock
B ATPC LOW Power Lock
J7915
IN-SERVICE
A I/O LOOPBACK
Line 1 loopback
Line 2 loopback
Line 3 loopback
B I/O LOOPBACK
Control #1
Control #2
Control #3
Control #4
Control #5
Control #6
SYSTEM LOOP-BACK DS1 LINE LOOP-BACK RCV to XMT
USER CONTROLS
Thursday, November 30, 2000 1:44:19 PM USI Version R1.02 Controller Version R1.02
LMW-5076-SM
06/12/04
1. SELECT XMTR TO PUT IN-SERVICE.
2. SELECT YES ON CONFIRMATION MESSAGE
TO ENABLE FUNCTION.
3. VERIFY GREEN IN-SERVICE STATUS CIRCLE DISPLAYS.
Switching the radio transmitter may momentarily interrupt
traffic. Switching I/Os will momentarily interrupt traffic and
auxiliary channel service. Before switching, obtain permission
from the proper authority.
CAUTION
Possibility of
Service
Interruption
