Foreword
Technical Reference
Maintenance DMX 16 CH
Thanks for using our LED Stage Lighting Equipment. Before using, please read the instruction carefully. The
instruction include important installing and using information. Please use the fixtures following the instruction
and keep the user manual properly.
Declare
This product, which is at the factory, performance in good condition, and completely packed. All users shall
strictly comply with the above warnings and instructions, any damage caused by the misuse is not within our
company guarantee, to ignore operation manual and cause of the failure and problems which is not in the scope
of dealer is responsible for. Thank you for your cooperation!
This manual if there is any technical change without prior notice.
Voltage: AC 100~240V, 50/60Hz
Output: Lumen 6000
LED: one piece of 180W white high brightness LED
Power consumption: 250W (max at full output)
Prism: rotating three-prism and auto rotation
Gobo1: 1 fixed gobo with 9 gobos.
Gobo2: 1 rotating gobo with 6 gobos.
Color: 7 colors
Focus: be available
Technical Reference
Controlled mode: auto, master / slave, sound active , DMX 512
Dimmer: 0~100%
Electronic focus: 15 degrees
Beam angle: 15 degrees
Strobe: 0~20Hz
Scan angle: Pan: 540 degrees, Tilt: 270 degrees
Scan precision: resolution of 8-16 bit
Attention
In order to guarantee the service life of the product, do not put this product in damp or water leakage;
more can't work in only more than 40 degrees
Don't put this product on easy looseness or shocks to the local
In order to avoid the risk of electric shock, this product's maintenance consult professional maintenance
The light bulb, when using the power supply change should not be more than -10% to +10%, the power
is too high, will shorten the life of the bulb, the power is too low, will affect the light color of the light
After power off, need to make the product is fully cooled after twenty minutes are energized again to use
In order to guarantee the normal use of this product, please read the instructions carefully.
Product should keep dry, avoid in wet environment
The use of intermittent can effectively prolong the life of the product
In order to obtain good ventilation and lighting effects, to pay attention to often clean fan and fan nets
and lens
Please do not use alcohol and other organic solvents to wipe the product shell, lest cause damage
To ensure the normal and stable work of the product, the surrounding environment temperature is
highest do not exceed 40 degrees, the lowest not less than 2 degrees
The product is according to the type of electric shock proof protection design, lighting to use and have
good grounding power system connection. And the ground wire must be connected with the ground wire
of the power supply system of the product; shell of the ground symbol must be connected with the
installing truss safely
During using the product, please do not remove device
Wire connections must be performed by qualified electrical professionals
Check whether the power supply voltage frequency is consistent with this product applicable voltage
frequency
1
www.alienpro.com.mx
2
www.alienpro.com.mx
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Channel
Function
Value
Instruction
1CH
X
0-255
X 0-540°
2CH
X fine
0-255
16 bit
3CH
Y
0-255
Y 0-270°
4CH
Y fine
0-255
16 bit
5CH
Motor speed
0-255
Motor speed from fast to slow
6CH
Dimming
0-255
Dimming0-100%
7CH
Strobe
0-3
NO effect
4-127
Strobe from slow to fast
128-191
Pulse from slow to fast
192-255
Random strobe from slow to fast
8CH
Zoom
0-255
Zoom0-100%
9CH
Color Wheel
0-3
White circle
4-127
Color choose
128-191
Color change(CW) from fast to slow
192-255
Color change(CCW) from slow to fast
10CH
Fixed gobo
0-3
White circle
4-127
Pattern choose
128-191
Pattern change(CW) from fast to slow
192-255
Pattern change(CCW) from slow to fast
11CH
Pattern
dither
0-15
No effect
16-255
Pattern dither from slow to fast
12CH
Rotating
gobo
0-2
No
3-65
Rotating pattern choose
66-128
Pattern dither from slow to fast
129-191
Pattern change(CW) from fast to slow
192-255
Pattern change(CCW) from slow to fast
13CH
Rotation
pattern
0-3
No effect
4-127
Rotating angle adjustment
128-191
Pattern rotation is water from fast to
slow
192-255
Pattern rotation is water from fast to
slow
14CH
Prism
0-127
No effect
128-255
Insert prism
15CH
Prism
rotating
0-64
Prism Angle adjustment
65-127
Prism rotating(CW) from fast to slow
128-191
Prism rotating(CCW) from slow to fast
192-255
Prism rotating back and forth from slow
to fast
16CH
RESET
0-100
No effect
101-150
Auto-run effect1
151-200
Auto-run effect1
201-250
Sound Control Effect
251-255
Reset in 5s
