Apotop ApoEye User manual

Wireless Camcorder
User Manual

| 1| 1English
Names of Parts
Clip Mount Magnet Mount
Tripod Mount
Strap Mount
Record Button
Status
Indicator
Mic
Micro SD
Card Slot
Micro USB Port
Strap Hook
Speaker
Video Mode
Photo Mode
Direct Mode
Cloud Mode
Mode Button
Power Button

| 2
English
Getting Started
Charging the Unit
• Before initial use, fully charge the camera via power adapter or
USB to computer system.
• During charging, the status indicator ashes in red. When the
camera is fully charged, the indicator turns off.
Modes Navigation
• Press Power button to turn on the camera.
• Press Mode button to switch among Video-Direct Mode, Photo-
Direct Mode, and Cloud Mode.
Camera Modes
Insert micro SD card (sold separately).
Video Mode
• Press Mode button to select Video Mode.
• Press Record button to shoot and press again to stop.
Photo Mode
• Press Mode button to select Photo Mode.
• Press Record button to take pictures.
Wireless Modes
Before using wireless modes, install below applications:
• Mobile app: Download [ApoEye] from Google Play or Apple Store.
• PC software: Install [PC APP] from the camera (Windows)(page 6).
Direct Mode
Connecting camera to mobile or PC directly for remote
controlling, live viewing, album managing, and camera setup.
Cloud Mode
Connecting camera to cloud server via access point (AP) or
mobile hotspot for internet video or live monitoring.

| 3| 2English
Getting Started
Direct Mode (Local)
For initial use, install [ApoEye] app
on mobile. Each camera has a unique
Camera ID. ( U2-xxxxxxxx)
Password is not required for the initial use, however, it is advised
to go to [Setup] in app to setup password after connected.
• Set camera to Direct Mode
and wait until indicator turns
steady green.
• On mobile, activate WiFi.
• Run [ApoEye].
• Press camera bar to start.
Connect to Camera
• Set camera to Direct Mode .
• On mobile, go to [Settings]
[Wi-Fi] Choose a camera.
3G connection will switch to
WiFi within 1 min.
• Run [ApoEye].
• Press camera bar to start.
For iOS user: For Android user:
Direct Mode (Intranet)
Mobile / PC
Take Photo
(SD card required) (SD card required)
Loop Recording
• Record and archive in 3 min interval
Quad View
Zoom In Zoom out Shoot Video
Invert Image
Two Way Voice • Tap to enable Quad View (up to four cameras).
• Tap a live view window to return to single view.
• Tap to talk to the camera from mobile;
tap again to allow the camera to talk back
to mobile.
Android:
iOS:
Note:1. Move the camera further away from mobile when echo occurs.
2. Mobiles with low CPU clock speed may not have audio during streaming.
Ver.1.0
U2-00000001
Available
U2-00000002
Available
U2-00000003
Available
CURRENT_AP
Connected
U2-00000001
Available
U2-00000002
Available
View
View
Album
Album
View
View Setup Setup

| 4
English
Cloud Mode (Internet)
AP
Cloud Server
Cloud AP
AP
Mobile Hotspot
Mobile / PC
USTREAM
3G/4G
A live broadcasting social media.
USTREAM
Recommended Cloud Server forAccess:
Cloud Mode (Internet)
Cloud Mode (Internet)
Before using Cloud Mode, setting up cloud AP and cloud server
on camera are required.
Step 1: Setup Cloud AP in Direct Mode
On mobile, go to app [Setup] [Cloud Settings] [Cloud AP].
Select a WiFi network from [AP List]; enter network password
when prompted.
If no preferred AP is found, press [Other...] from [AP List]
Enter network name and password.
Note: Mobile hotspot can be set as cloud AP.
Step 2: Setup Cloud Server in Direct Mode
• New user, press then enter email/username/password/
conrm for
auto-registration. Returning user, enter username/
password only .
• Press [Save to Camera].

| 5| 4English
Cloud Mode (Internet)
Cloud Mode (Internet)
Step 3: Connect Camera to Cloud Server
Options to connect to cloud server:
1. On mobile, press [Camera to Cloud] in [Setup] page.
2. On camera, set to Cloud Mode .
While connecting, the status indicator ashes rapidly in orange.
Once connected, the status indicator ashes in green. If connection
fails, the status indicator ashes in red and alerts in different
beeping frequencies.
Or go into [ApoEye] to view the error message.
Note: 1. Cloud service may change depending on their policy.
2. In some areas, mobile may not activate hotspot where there is no 3G/4G.
3. Experiencing delays while viewing live video may be due to high
internet trafc.
Alert Cause/Solution
One time
Cannot connect to cloudAP or invalid network password.
Camera not inside WiFi area or weak signal.
Check AP settings or move camera closer to cloud AP.
Two times No internet or the cloud server is not accessible. Cannot log in cloud server via internet.
Cloud service may be blocked by rewall.
Three times
Cloud server username or password is incorrect. Refer
to in [Setup] for instructions.
Username already taken. Create new account in [ApoEye].
Step 4: View Live Videos on Cloud Server
Options to view live videos:
1. Use mobile app: USTREAM is available in Google Play or
Apple Store.
2. Visit website: http://www.ustream.tv
Then search for username and select "username's show" to watch
live video through camera.

| 6
English
PC Applications
To use [ApoEye] features on PC, install [PC APP] rst. The [PC
APP] has similar features and interface to [ApoEye] for easy user
experience.
Installing [PC APP] from Camera
• Connect the camera to PC via a USB cable.
• [PC APP] AutoRun/AutoPlay activates.
• If AutoRun/AutoPlay is not starting:
Go to [My computer] and search [PC APP] for installation.
•
Once installed, unplug the camera from PC then run [PC APP].
[PC APP] Features
• Press [View HD] or double-click the viewing window to
maximize it into full screen. Double-click again to return to
the [PC APP] interface.
• To save videos or photos to PC:
Go to [Album] Select videos or photos Press [Save to PC].
Mass Storage and Webcam Modes
While camera is plugged in to PC, press Mode button on camera
to switch between Mass Storage Mode (default) and Webcam
Mode. The status indicator shows steady red in Mass Storage
Mode and steady green in Webcam Mode (
In Skype or QQ, select
"UVC_WEBCAM")
.

| 7| 6English
Camera Indication
Condition Status Indicator Alert
Recording Flashing green One time
Loop Recording Flashing orange One time
Charging Flashing red None
Fully Charged No indication Two times
Low Battery Flashing red every 5 sec.
(Warning)
Five times
(Shutdown)
Power Off No indication Two times
Auto Power Off
(5 mins idle) Flashing red Two times
Memory Full
SD Card Error Flashing red Three times
Camera Hotkey
Forced Shutdown Press and hold Power button for 5 sec. to
turn off camera.
Forced Default
Settings Press and hold Mode and Record buttons for 5 sec. to restore default settings.
Car Camcorder
Press and hold Record button for 3 sec. to start
loop recording and invert image.

| 8
English
Troubleshooting
Situation Cause/Solution
Camera cannot turn on Battery power is low. Recharge the battery.
Camera is frozen Press Power button for 5 sec. to turn off.
Press Power button twice to turn on.
Camera cannot record No SD card or SD card is full.
SD card cannot be recognized. Format SD
card in [ApoEye] or replace SD card.
Camera not found Turn on camera, switch to Direct Mode. Press
"Refresh" on mobile or PC to scan again.
Forgot camera password Press both Mode and Record buttons for 5
sec. to reset.
Cannot watch live view Move camera closer to mobile.
Flickering segments on
live view TV system setting (50Hz/60Hz) is incorrect.

| 9
English
FCC Regulations
§ 15.19 (a)(3)
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
§ 15.21
Changes or modications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
****************************************************************
************************************************************
§ 15.105 (b)
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
****************************************************************
************************************************************
RF Exposure Information (SAR)
This device is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. The exposure standard for wireless
devices employs a unit of measurement known as the Specic Absorption Rate
(SAR). The SAR limit adopted by the FCC is 1.6W/kg for an uncontrolled
environment. Tests for SAR are conducted using standard operating positions
accepted by the FCC with the device transmitting at its highest certified
power level in all tested frequency bands. The FCC has granted an Equipment
Authorization for this device with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines.
Although the SAR is determined at the highest certied power level, the actual
SAR level of the device while operating can be well below the maximum value.
This is because the device is designed to operate at multiple power levels so as
to use only the poser required to reach the network. In general, the closer you
are to a wireless base station antenna, the lower the power output.

NCC
警語第十二條：
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均
不得得擅自變更頻率、加大功率或變更通原計之特性及功能。
第十四條：
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干
擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通
信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通
信或工業、科學及醫療用電波輻射性電機設備之干擾。
| 10
English
WEEE Directive & Product Disposal
At the end of its serviceable life, this product should not
be treated as household or general waste. It should be
handed over to the applicable collection point for the
recycling of electrical and electronics equipment, or
returned to the supplier for disposal.
Internal/Supplied Batteries
This symbol on the battery indicates that the battery is
to be collected separately. This battery is designed for
separate collection at an appropriate collection point.
Manufacturer:
CARRY TECHNOLOGY CO., LTD.
www.apotop.com.tw
4F., No.119, Jiankang Rd., Zhonghe Dist.,
New Taipei City 235, Taiwan (R.O.C)
