C.F. Martin & Co DX1RAE User manual

• Fishman Onboard Electronics
• Limited Lifetime Warranty
• High Pressure Laminate
(HPL) Body Construction
• Solid Sitka Spruce Top
Featured on Specified Models
• Genuine Martin SP®Strings
Great sounding and playing
guitars, environmentally
friendly and now ready to
plug in and play.
1002-03 X-Series SpecSh 2:Layout 1 3/4/10 10:05 AM Page 1

martinguitar.com
DX1AE
D12X1AE
000X1AE
BODY SIZE & TYPE BACK & SIDES FEATURES MODEL NAME TOP
00X1AE
Java Mahogany
Dreadnou ht Maho any1 DX1AE Solid Sitka Spruce
Maho any112-Strin D12XAE Solid Sitka Spruce
Rosewood1 DX1RAE Solid Sitka Spruce
Hawaiian Koa1 DX1KAE Solid Sitka Spruce
000 Maho any1 000X1AE Solid Sitka Spruce
00 Java Maho any1 00X1AE Java Mahogany Solid Sitka Spruce
1002-03 X-Series SpecSh 2:Layout 1 3/4/10 10:05 AM Page 2

1Wood photo raphically reproduced on laminate.
Rosewood1Maho any1
Hawaiian
Koa1
Java
Maho any1
Sitka
Spruce1
Fishman Sonitone
The Fishman Sonitone system features
proven Sonicore under-saddle pickup
technolo y combined with “easy access”
volume and tone controls conveniently
and strate ically located just inside the
soundhole.
Volume Tone
DXK2AE DXMAE
BODY SIZE & TYPE BACK & SIDES MODEL NAME TOP
Dreadnou ht Maho any1 DXMAE Spruce1
Hawaiian Koa1 DXK2AE Hawaiian Koa1
All Models Equipped with:
C. F. Martin & Co. has always made prudent
use of natural resources, especially rare or
endan ered tonewoods. At the same time,
we’re committed to buildin uitars of
superior tone and playability that are
affordable to every uitarist.
The X-Series Acoustic Electric Collection
more than meets both these criteria.
Back and sides are constructed of patented
hi h-pressure laminate (HPL) and then
joined to a solid Sitka spruce or HPL top.
The result: Great soundin and playin
uitars, environmentally friendly and now
ready to plu in and play - and one of our
best values ever.
1002-03 X-Series SpecSh 2:Layout 1 3/4/10 10:05 AM Page 3

The warranty or any model covered by the Martin®Limited Li etime Warranty is not trans erable; any model
covered by the Martin Limited Li etime Warranty is warranted only to the original owner or his or her li etime
when purchased rom an authorized Martin dealer in the United States and Canada. Factory-installed electronics
on any model covered by the Martin Limited Li etime Warranty are warranted or a period o one year rom the
date o original purchase.
EFFECTIVE MARCH 2010 © 2010 C. F. Martin & Co., Inc. All rights reserved. “C. F. Martin & Co., Est. 1833,”
“Martin” and “Martin Owners Club” are trademarks used by C. F. Martin & Co., Inc. “Fishman” is a trademark
o Fishman Transducers, Inc. Model speci ications subject to change without notice. Visit our website at
martinguitar.com or the most current product in ormation. Printed in the USA. 1002-03 17LMISC
510 Sycamore Street
Nazareth, Pennsylvania 18064
[phone] | martinguitar.com
Enjoy the ultimate Martin experience. Details at >martinownersclub.com
Limited Lifetime Warranty
All models in the X-Series Non-Cutaway Acoustic Electric Collection are covered by the Martin Limited
Lifetime Warranty and are warranted only to the ori inal owner for his or her lifetime when purchased
from an authorized C. F. Martin & Co. dealer located in the United States or Canada. Sonitone factory-
installed electronics on any model covered by the Martin Limited Lifetime Warranty are warranted for a
period of one year from the date of ori inal purchase.
Patented High Pressure Laminate (HPL) Body Construction
In our on oin effort to seek viable alternatives to rare wood, we have vi orously researched and
implemented alternative materials that are well suited for uitars. The back, sides, top (soundboard)
and headplate are constructed of patented non-wooden hi h pressure laminates (HPL).
Solid Sitka Spruce Top
Six models in this Collection feature solid Sitka spruce, Picea Sitchensis, - the primary top wood for
most Martin uitars. Extremely vibrant providin an ideal “diaphra m” for transmission of sound on
any size and style of strin ed instrument. Chosen for its strai ht, uniform rain, lon evity and tensile
stren th. Models: DX1AE, D12XAE, DX1RAE, DX1KAE, OOOX1AE, OOX1AE Java Maho any
Genuine Martin SP Strings
Hi h quality strin s are critical to a uitar’s tone and playability. They brin to life all the power, nuance
and unique Martin “voice” we carefully craft into every one of our uitars. What’s more, a carefully
au ed and balanced set of strin s will reatly enhance the style of playin and facilitate technique.
That’s why we make Martin strin s ourselves. Like our uitars, each strin is made carefully and
precisely, usin only premium materials.
All models in this Collection are equipped with Martin SP Phosphor Bronze strin s. Specifically
chosen to prolon bri htness, strin life and superior tonal quality that meet the hi h expectations
of demandin musicians.
For more information on this Collection and our full line of X-Series acoustic and cutaway acoustic
electric models, visit martin uitar.com.
DCX1RE
• LimitedLifetime Warranty
• Hi h-Pressure Laminate
(HPL) Body Construction
• Solid Sitka Spruce Top
Featured on Specified Models
• Genuine Martin®Strin s
STEEL-STRING ACOUSTICS
Agreat sounding and
environmentally friendly
series of guitars.
ROSEWOOD HPL
