CFF 1977 CFF-PUBAR Installation guide
CFF WALL MOUNT PULL UP BAR
Assembly&CareInstructions
THANK YOU!
First, thank you for purchasing the CFF Pull Up Bar
(CFFPUBAR). Now let’s turn a wall into a pull up
rack. Please review these instructions to ensure your
rigiscorrectlyassembledandlasts.
INCLUDED IN THIS DOCUMENT
● explodeddrawing&partslist
● assemblysteps
● caringforyourpullupbar
EXPLODED DRAWING & PARTS LIST
PLEASE MAKE SURE YOU HAVE ALL THE PIECES!
_
V.04.13.2015
1
No.
Description
Qty
1
Bolt,M10x75mm
4
2
Washer,M10
8
3
Nut,M10
4
4
SingleBeam
1
5
SupportFrame
2
6
ExpansionScrew,M10x80mm
8
ASSEMBLY STEPS
STEP 1
Assemblethepullupbar.
Stand support frames upright on flat, level surface (eg; floor, table, or countertop). Have bolts,
washers & nuts ready. Put (1) washer on each bolt, slip the bolts through the center beam’s bolt
holes, then through the support frame. Install another washer & nut finger tight on outside of each
boltasshownbelow.Repeatforotherside.
STEP 2
Mounttowall.
! IMPORTANT ! Pull up bar MUST be mounted to solid wood studs or brick/concrete/masonry
using appropriate hardware. Failure to do so may result in damaged walls & personal injury.
CFF cannot assume liability for damaged property or personal injury as a result of incorrect
equipmentassemblyorinstallation.
_
V.04.13.2015
2
TIP#1
Use an electronic stud finder to locate the nearest studs at your desired install location. If they do
not exactly match up with the pull up bar, have your local home improvement store cut a couple
2x4s to a length long enough to fit the bar AND cross (2) studs one for the top mounting points, the
otherforthebottom.Thiswilldistributetheweightevenlybetweenthestuds.
Don’tforgettomakesureyourrackisinstalledlevel!
TIP#2
If mounting to brick/concrete/masonry, it is recommended you source proper masonry anchor bolts
(notincluded)fromyourlocalhardwareorhomeimprovementstore.
STEP 3
Tightenallhardware.
Note: Tighten wallmounting hardware first so the rig is square to the surface, THEN use a
wrenchtotightenthepullupbarbolts.
CARING FOR YOUR PULL UP BAR
MAKE YOUR INVESTMENT LAST
Cleaning
After each use, wipe your bar down with a clean, dry towel. If deeper cleaning is required, a damp
towel and mild detergent should suffice. Avoid harsh chemical cleaning products, as they may
damagethefinish.
Retightenhardware
Periodically inspect the pull up bar for signs of wear or loosening hardware. Make sure all nuts &
bolts are tight. This pull up bar is designed to support a good amount of weight and deliver reliable
serviceovermanyyears,butitwillonlydosowhenproperlyassembled,installedandmaintained.
CONTACT CFF WITH ANY QUESTIONS
WE WANT YOU HAPPY!
phone:(717)2077171
email:[email protected]
We’rehereifyouneedus.(Andweappreciateyourfeedback!)
_
V.04.13.2015
3
