FUEL AND OIL RECOMMENDATIONS
Fuel
Use only clean, fresh, unleaded regular grade
gasoline.
Octane Rating
The octane rating of a gasoline is a measure
of its resistance to “knocking”. Use of a mini-
mum of 87 octane of the anti-knock index is
recommended. The anti-knock index is posted on
service station pumps in the U.S.A.
Oxygenated Fuel
If you use oxygenated fuel (either ethanol or
MTBE added to gasoline), be sure it is unleaded
and meets the minimum octane rating require-
ment.
The following are the EPA approved percent-
ages of fuel oxygenates.
ETHANOL: (Ethyl or Grain Alcohol) You may
use gasoline containing up to 10% ethanol by
volume.
MTBE: (Methyl Tertiary Butyl Ether) You may
use gasoline containing up to 15% MTBE by
volume.
METHANOL: (Methanol or Wood Alcohol) 5% by
volume.
You may use gasoline containing up to 5%
methanol by volume, as long as it also contains
cosolvents and corrosion inhibitors to protect
the fuel system. Gasoline containing more than
5% methanol by volume may cause starting
and/or performance problems. It may also dam-
age metal, rubber, and plastic parts of your fuel
system.
Engine Oil
The following engine oils are recommended.
API Service Classification: SC, SD, SE, SF,
SG, or SH.
Oil Viscosity
Choose the viscosity according to the tem-
perature as follows:
Fuel Information
THIS VEHICLE IS CERTIFIED TO OPER-
ATE ON UNLEADED REGULAR GRADE
GASOLINE ONLY. A minimum of 87 octane of
the anti-knock index is recommended. The anti-
knock index is posted on service station pumps
in the U.S.A.
Emission Control Information
To protect the environment in which we all
live, Club Car has incorporated crankcase emis-
sion (1) and exhaust emission (2) control sys-
tems (EM) in compliance with applicable regu-
lations of the U.S. Environmental Protection
Agency and California Air Resources Board.
1. Crankcase Emission Control System
A sealed-type crankcase emission control
system is used to eliminate blow-by gases. The
blow-by gases are led to the breather chamber
through the crankcase. Then, it is led to the air
cleaner.
Oil is separated from the gases while passing
through the inside of the breather chamber
from the crankcase, and then returned back to
the bottom of the crankcase.
2. Exhaust Emission Control System
The exhaust emission control system applied
to this engine consists of a carburetor and an
ignition system having optimum ignition timing
characteristics.
The carburetors have been calibrated to
provide lean air/fuel mixture characteristics
and optimum fuel economy with a suitable air
cleaner and exhaust system.
Maintenance and Warranty
Proper maintenance is necessary to ensure
that your engine will continue to have low emis-
sion levels.Those items identified by the Periodic
Maintenance Chart are necessary to ensure
compliance with the applicable standards.
The Club Car Limited Emission Control
System Warranty requires that you return your
engine to an authorized Club Car Dealer for
remedy under warranty. Please read the warranty
carefully, and keep it valid by complying with
the owner’s obligations it contains.
Tampering with Emission Control
System Prohibited
California State law prohibits the following
acts or the causing thereof: (1) the removal or
rendering inoperative by any person other than
for purposes of maintenance, repair, or replace-
ment, of any device or element of design incor-
porated into any new engine for the purposes of
emission control prior to its sale or delivery to the
ultimate purchaser or while it is in use, or (2) the
use of the engine after such device or element of
design has been removed or rendered inopera-
tive by any person.
Among those acts presumed to constitute
tampering are the acts listed below:
Do not tamper with the original emission relat-
ed parts:
• Carburetor and internal parts
• Spark plugs
• Magneto or electronic ignition system
• Fuel filter element
• Air cleaner element
• Crankcase
• Cylinder head
• Breather chamber and internal parts
• Intake pipe and tube
EMISSION CONTROL INFORMATION
-20°C-10°C0°C10°C20°C30°C40°C
-4°F14°F32°F50°F68°F86°F104°F
SAE 5W-20
SAE 10W-30/SAE 10W-40
SAE 30
SAE 40
NOTE
• If “knocking or pinging” occurs, use a
different brand of gasoline or higher
octane rating.
• Do not mix oil with gasoline.
• Gasoline is extremely flammable and
can be explosive under certain con-
ditions. Turn the engine switch OFF.
Do not smoke. Make sure the area is
well ventilated and free from any
source of flame or sparks; this
includes any appliance with a pilot
light. Never fill the tank so the fuel
level rises into the filler neck. If the
tank is overfilled, heat may cause
the fuel to expand and overflow
through the vent in the fuel tank.
• After refueling, make sure the tank
cap is closed securely.
• If gasoline is spilled on the fuel tank
wipe it off immediately.
CAUTION
WARNING
WARNING
NOTE
• Using multi-grade oils (5W-20, 10W-
30, and 10W-40) will increase oil
consumption. Check oil level more
frequently when using them.
2003 Turf Utility Gasoline Vehicle Owner’s Manual Page 1

P. O. Box 204658
Augusta, Georgia 30917-4658 USA
Telephone [phone]
Service Parts Fax [phone]
www.clubcar.com
Page 2 2003 Turf Utility Gasoline Vehicle Owner’s Manual
Copyright © 2002 Club Car, Inc.
Club Car and ArmorFlex
are registered trademarks of Club Car, Inc.
This manual effective July 22, 2002.
NOTICE
The Transportation and Utility Vehicle Limited Warranty appears on the last pages of this manual. No other
warranties, express or implied, are contained herein. Your authorized representative checked the vehicle
before it was delivered to you and will provide you a copy of the completed vehicle warranty registration form.
Club Car is not liable for errors in this manual or for incidental or consequential damages that result from the
use of the material in this manual.
This manual contains proprietary information that is protected by copyright. All rights are reserved. No part of
this manual may be photocopied, reproduced, or translated to another language without the written consent
of Club Car, Inc.
The information contained in this document is subject to change without notice.
Club Car reserves the right to make design changes to vehicles without obligation to make these changes on
units previously sold.
These vehicles do not conform to Federal Motor Vehicle Safety Standards for automobiles or to FMVSS 500
for low-speed vehicles, and are not equipped for operation on public streets, roads, or highways.

2003 Turf Utility Gasoline Vehicle Owner’s Manual Page 3
FOREWORD
Thank you for choosing Club Car. You have chosen the finest utility vehicle on the market; the vehicle most
widely recognized as the industry leader in vehicle efficiency and long-lasting value. Please protect your
investment and ensure that your Club Car Turf utility vehicle(s) provides years of reliable, superior perfor-
mance by reading and following the maintenance instructions in this manual.
Your comfort and safety are important to us as well, so we urge you to read and follow the step-by-step oper-
ating instructions and safety precautions in this manual. These instructions must be followed in order to avoid
the risk of severe personal injury. If you rent or loan your vehicle to others, we recommend that you ask them
to read this manual before they operate the vehicle.
Club Car products are backed by a customer support system designed to offer you fast, courteous service. In
the event that your Club Car Turf utility vehicle needs repairs or service, we recommend that your local autho-
rized Club Car representative perform them. For the name and address of the Club Car representative near-
est you, logon to our web site at www.clubcar.com or call 1-800-ClubCar (258-2227). If you would prefer to
write to us, direct your letter to: Club Car, Attention: Marketing Services, P.O. Box 204658, Augusta, Georgia
30917-4658 USA.Your local authorized Club Car representative can also provide technical advice, parts, and
service manuals.
We hope you will consider this owner’s manual a permanent part of your Club Car Turf utility vehicle. If you sell
the vehicle, please include the manual so that the next owner will have the important operating, safety, and
maintenance information it contains.

!WARNING
Rotating Parts
Practice Safety
Page 4 2003 Turf Utility Gasoline Vehicle Owner’s Manual
Safety signs like you see above may at first seem shocking, but their impact is mild
compared with the reality of severe personal injury.
Your safety and satisfaction are of the utmost importance to Club Car. That is why
before operating the vehicle, we urge you to review the information in this manual.
Understand and become familiar with the DANGER, WARNING and CAUTION state-
ments and procedures it contains, along with the safety decals that are affixed to your
vehicle.
Take time to understand the language of safety. It is a language that can save your life.
PROPOSITION 65 – STATE OF CALIFORNIA
∆
WARNING
This product contains or emits chemicals or substances that have been determined
by the state of California to cause cancer and birth defects or other reproductive
harm.

2003 Turf Utility Gasoline Vehicle Owner’s Manual Page 5
TABLE OF CONTENTS
Safety Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
General Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Vehicle Feature Identification – Turf 1 and Turf 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Vehicle Feature Identification – Turf 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Model Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Pre-Operation and Daily Safety Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Driving Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Bed Latch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Prop Rod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Loading and Unloading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Towing with the Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Transporting on a Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Periodic Service Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Periodic Lubrication Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Fueling Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Cleaning the Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Subsequent Owner Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Vehicle Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Club Car
®
Limited Two Year Warranty for 2003 Transportation and Utility Vehicles. . . . . . . . . . . . . . . . . . 36

Safety Details
Page 6 2003 Turf Utility Gasoline Vehicle Owner’s Manual
SAFETY DETAILS
∆
WARNING
• This owner’s manual should be read completely before attempting to drive or service the
vehicle. Failure to follow the instructions in this manual could result in property damage,
severe personal injury, or death.
It is important to note that some vital statements throughout this manual and on the decals affixed to the vehi-
cle are preceded by the words DANGER, WARNING, or CAUTION. For your protection, we recommend that
you take special notice of these safety precautions. Safety precautions are essential and must be followed.
If any of the operation or safety decals on the vehicle become damaged, have been removed, or cannot be
easily read, they should be replaced immediately to avoid possible property damage, personal injury, or
death. Contact your Club Car distributor/dealer.
∆
DANGER
• A DANGER indicates an immediate hazard that will result in severe personal injury or death.
∆ WARNING
• A WARNING indicates an immediate hazard that could result in severe personal injury or
death.
∆
CAUTION
• A CAUTION indicates a hazard or unsafe practice that could result in minor personal injury or
product or property damage.
GENERAL WARNINGS
The following safety statements must be heeded whenever the vehicle is being operated, repaired, or ser-
viced. Vehicle feature identification information is also included on pages 8 through 11. Other specific safety
statements appear throughout this manual and on the vehicle.
Figure 1 12-Volt Battery
FRONT
OF VEHICLE
AS SEEN FROM
PASSENGER SIDE
OF VEHICLE
Remove
negative
cable first.
DISCONNECT BATTERY CABLES
BEFORE WORKING ON VEHICLE

General Warnings
2003 Turf Utility Gasoline Vehicle Owner’s Manual Page 7
∆
DANGER
•Battery –Explosive gases! Do not smoke. Keep sparks and flames away from the vehicle and
service area. Ventilate when charging or operating vehicle in an enclosed area. Wear a full face
shield and rubber gloves when working on or near batteries.
•Gasoline –Flammable! Explosive! Do not smoke. Keep sparks and flames away from the
vehicle and service area. Service only in a well-ventilated area.
•Do not operate gasoline vehicle in an enclosed area without proper ventilation. The engine
produces carbon monoxide, which is an odorless, deadly poison.
•A Club Car vehicle will not provide protection from lightning, flying objects, or other storm-
related hazards. If caught in a storm while driving a Club Car vehicle, exit the vehicle and seek
shelter in accordance with applicable safety guidelines for your location.
∆
WARNING
•Follow the procedures exactly as stated in this manual, and heed all DANGER, WARNING, and
CAUTION statements in this manual as well as those on the vehicle.
•Do not leave children unattended on vehicle.
•Prior to leaving the vehicle unattended or servicing the vehicle, turn the key switch OFF,
remove the key, and place the Forward/Reverse handle in the NEUTRAL position. Chock the
wheels when servicing the vehicle.
•Improper use of the vehicle or failure to properly maintain it could result in decreased vehicle
performance, severe personal injury, or death.
•Any modification or change to the vehicle that affects the stability or handling of the vehicle,
or increases maximum vehicle speed beyond factory specifications, could result in severe
personal injury or death.
•Check the vehicle for proper location of all vehicle safety and operation decals and make sure
they are in place and are easy to read.
•For vehicles with cargo beds, remove all cargo before raising the bed or servicing the vehicle.
If the vehicle is equipped with a prop rod, ensure that it is securely engaged while bed is
raised. Do not close bed until all persons are clear of cargo bed area. Keep hands clear of all
crush areas. Do not drop cargo bed; lower gently and keep entire body clear. Failure to heed
this warning could result in severe personal injury or death.
•Only trained technicians should service or repair the vehicle. Anyone doing even simple
repairs or service should have knowledge and experience in electrical and mechanical repair.
The appropriate instructions must be used when performing maintenance, service, or
accessory installation.
•To avoid unintentionally starting the vehicle:
- Disconnect battery cables, negative (–) cable first (Figure 1)
- Disconnect the spark plug wire from the spark plug.
•Frame ground –Do not allow tools or other metal objects to contact frame when
disconnecting battery cables or other electrical wiring. Do not allow a positive wire to touch
the vehicle frame, engine, or any other metal component.
•Wear safety glasses or approved eye protection when servicing the vehicle. Wear a full face
shield and rubber gloves when working on or near batteries.
•Do not wear loose clothing or jewelry such as rings, watches, chains, etc., when servicing the
vehicle.
•Use insulated tools when working near batteries or electrical connections. Use extreme
caution to avoid shorting of components or wiring.

Vehicle Feature Identification
Page 8 2003 Turf Utility Gasoline Vehicle Owner’s Manual
TURF 1 AND TURF 2
OFF ON
WARNING
CCI 101609401
•Vehicle rated capacity - 800 lbs. on level surface only.
Weight to include passengers, cargo bed load, and
gross trailer weight. See Owner's Manual.
•Maximum cargo load - 300 lbs. Weight to include cargo
bed load and gross trailer weight.
•Maximum trailer hitch tongue weight - 150 lbs.
•Cargo should be evenly spread over the floor of the
cargo bed as far forward as possible and secured.
•For vehicle stability, when fully loaded, drive slowly
and avoid stopping on or backing down steep hills.
•Avoid top heavy loads. See Owner's Manual.
•When driving on uneven terrain or down steep hills,
reduce speed and load.
VEHICLE
LOADING
Read Owner's Manual
and warnings on dash. CCI 101960101
•Vehicle rated capacity - 1200 lbs. on level surface only.
Weight to include passengers, cargo bed load, and
gross trailer weight. See Owner's Manual.
•Maximum cargo load - 800 lbs. Weight to include cargo
bed load and gross trailer weight.
•Maximum trailer hitch tongue weight - 150 lbs.
•Cargo should be evenly spread over the floor of the
cargo bed as far forward as possible and secured.
•For vehicle stability, when fully loaded, drive slowly
and avoid stopping on or backing down steep hills.
•Avoid top heavy loads. See Owner's Manual.
•When driving on uneven terrain or down steep hills,
reduce speed and load.
VEHICLE
LOADING
Read Owner's Manual
and warnings on dash. CCI 101960201
Riding in cargo bed
can cause severe injury
or death.
Do not ride in cargo bed.
WARNING
CCI 1015539-01
•Before using vehicle, read operating instructions.
•Remain seated and hold on to seat handle while moving.
•Do not start vehicle until all occupants are seated.
•Two (2) persons per seat maximum.
•Operate from driver side only and not on public roads.
•Keep entire body inside vehicle while moving.
•Drive slowly in turns and straight up and down slopes.
•Do not leave children unattended on vehicle.
•Never operate under the influence of alcohol or drugs.
•Use brakes to reduce speed when coasting downhill.
•Never stand in front of or behind vehicle. CCI 101960601
WARNING
ROLLOVER OR FALLING OFF MAY CAUSE DEATH.
OPERATING INSTRUCTIONS
• Read Owner's Manual and safety warnings located on dash panel prior to driving.
• Study and understand controls.
• Make sure wheels are turned in desired direction.
• Turn key to “ON” position and be sure nothing is in your path.
• While vehicle is stopped, select direction by placing
shift lever or switch in desired position:
F – Forward N – Neutral R – Reverse (Buzzer will sound)
• Vehicle will start moving when accelerator pedal is depressed.
• Slowly depress accelerator pedal to increase speed. Park brake will
release when accelerator pedal is depressed.
• To stop, release accelerator pedal and depress brake pedal.
• After stopping, firmly depress park brake until it locks.
• Place forward and reverse switch in neutral position.
Turn key “OFF” and remove key when not in use.
CCI 101621601
LOW OIL
WARNING LIGHT
FUEL GAUGE/
HOUR METER
SERIAL
NUMBER
ACCELERATOR
PEDAL
BRAKE
PEDAL
PARK BRAKE
PEDAL
KEY SWITCH
CRUSH AREA
DECAL
OPERATING INSTRUCTIONS
DRIVER/PASSENGER
WARNING DECAL
BED LOAD
WARNING DECAL
(FOR TURF 2 ONLY)
VEHICLE LOADING DECAL
(FOR TURF 1 ONLY)

Vehicle Feature Identification
2003 Turf Utility Gasoline Vehicle Owner’s Manual Page 9
TURF 1 AND TURF 2
KEEP CLEAR
Rotating parts
HOT
manifold & muffler
CAN CAUSE SEVERE INJURY
CCI 101960501
WARNING
• GASOLINE EXPLOSION / FIRE.
• CAN CAUSE SEVERE INJURY OR DEATH.
• NO SMOKING, SPARKS, OR OPEN FLAME.
• STOP ENGINE, ALLOW TO COOL BEFORE REFUELING.
• TURN FUEL VALVE ( ) ON DURING OPERATION.
( ) OFF DURING STORAGE OR TRANSPORT.
CCI 101547601
WARNING
CCI 101915201
Negative frame ground. Can cause severe injury.
Do not contact positive (+) battery post or cable to frame.
Disconnect negative battery lead first.
Excessive speed.
Can cause severe injury or death.
Do not tamper with engine governor adjustment.
WARNING
WARNING
L
A
T
C
H
O
P
E
N
Crush area. Can cause severe injury.
Stay clear when closing bed.
FUEL SHUT-OFF
VALVE
FNR
BED LATCH
BED LATCH
WARNING DECAL
TRAILER
HITCH DECAL
(TURF 2 ONLY)
GASOLINE
WARNING DECAL
(ON FRAME)
ROTATING PARTS AND
HOT MANIFOLD DECAL
(ON STARTER/GENERATOR AND ENGINE)
CHOKE
FRAME GROUND
WARNING DECAL
(ON FRAME)
FORWARD/REVERSE
HANDLE
CCI 1011553
NOTICE
MAXIMUM TONGUE
WEIGHT - 150 lbs.

Vehicle Feature Identification
Page 10 2003 Turf Utility Gasoline Vehicle Owner’s Manual
TURF 6
6
•Vehicle rated capacity - 1500 lbs. on level surface only.
Weight to include passengers, cargo bed load, and
gross trailer weight. See Owner's Manual.
•Maximum cargo load CARRYALL 6 or Turf 6 - 1000 lbs.,
TRANSPORTER - 300 lbs. Weight to include cargo bed load
and gross trailer weight.
•Maximum trailer hitch tongue weight - 150 lbs.
•Cargo should be evenly spread over the floor of the
cargo bed as far forward as possible and secured.
•For vehicle stability, when fully loaded, drive slowly
and avoid stopping on or backing down steep hills.
•Avoid top heavy loads. See Owner's Manual.
•When driving on uneven terrain or down steep hills,
reduce speed and load.
VEHICLE
LOADING
Read Owner's Manual
and warnings on dash. CCI 101960001
WARNING
CCI 101609401
• GASOLINE EXPLOSION / FIRE.
• CAN CAUSE SEVERE INJURY OR DEATH.
• NO SMOKING, SPARKS, OR OPEN FLAME.
• STOP ENGINE, ALLOW TO COOL BEFORE REFUELING.
• TURN FUEL VALVE ( ) ON DURING OPERATION.
( ) OFF DURING STORAGE OR TRANSPORT.
CCI 101547601
WARNING
KEEP CLEAR
Rotating parts
HOT
manifold & muffler
CAN CAUSE SEVERE INJURY
CCI 101960501
WARNING
ROTATING PARTS AND
HOT MANIFOLD DECAL
Riding in cargo bed
can cause severe injury
or death.
Do not ride in cargo bed.
WARNING
CCI 1015539-01
•Before using vehicle, read operating instructions.
•Remain seated and hold on to seat handle while moving.
•Do not start vehicle until all occupants are seated.
•Two (2) persons per seat maximum.
•Operate from driver side only and not on public roads.
•Keep entire body inside vehicle while moving.
•Drive slowly in turns and straight up and down slopes.
•Do not leave children unattended on vehicle.
•Never operate under the influence of alcohol or drugs.
•Use brakes to reduce speed when coasting downhill.
•Never stand in front of or behind vehicle. CCI 101960601
WARNING
ROLLOVER OR FALLING OFF MAY CAUSE DEATH.
OIL WARNING
LIGHT
FUEL GAUGE/
HOUR METER
LIGHT
SWITCH
FUEL SHUT-OFF
VALVE
VEHICLE LOADING DECAL
GASOLINE
WARNING DECAL
(ON FRAME)
BRAKE
PEDAL
PARK BRAKE
PEDAL
ACCELERATOR
PEDAL
BED LOAD
WARNING DECAL
(ON
STARTER/GENERATOR
AND ENGINE)
CRUSH AREA
DECAL
SERIAL
NUMBER
DRIVER/PASSENGER
WARNING DECAL

Vehicle Feature Identification
2003 Turf Utility Gasoline Vehicle Owner’s Manual Page 11
TURF 6
WARNING
FAILURE TO FOLLOW THESE INSTRUCTIONS
CAN CAUSE SEVERE INJURY OR DEATH.
Bed can tip up unexpectedly. Bed hold down
bolts must be fastened. CCI 101707801
6
CCI 101915201
Negative frame ground. Can cause severe injury.
Do not contact positive (+) battery post or cable to frame.
Disconnect negative battery lead first.
Excessive speed.
Can cause severe injury or death.
Do not tamper with engine governor adjustment.
WARNING
WARNING
OFF ON
OPERATING INSTRUCTIONS
• Read Owner's Manual and safety warnings located on dash panel prior to driving.
• Study and understand controls.
• Make sure wheels are turned in desired direction.
• Turn key to “ON”position and be sure nothing is in your path.
• While vehicle is stopped, select direction by placing
shift lever or switch in desired position:
F –Forward N –Neutral R –Reverse (Buzzer will sound)
• Vehicle will start moving when accelerator pedal is depressed.
• Slowly depress accelerator pedal to increase speed. Park brake will
release when accelerator pedal is depressed.
• To stop, release accelerator pedal and depress brake pedal.
• After stopping, firmly depress park brake until it locks.
• Place forward and reverse switch in neutral position.
Turn key “OFF”and remove key when not in use.
CCI 101621601
FORWARD/REVERSE
HANDLE
BED BOLT
WARNING DECAL
CHOKE
FRAME GROUND WARNING DECAL
OPERATING INSTRUCTIONS
BED HOLD
DOWN BOLTS
KEY SWITCH
FNR

General Information
Page 12 2003 Turf Utility Gasoline Vehicle Owner’s Manual
GENERAL INFORMATION
This manual features three Turf utility gasoline models: the Turf 1, Turf 2, and Turf 6. Throughout this manual,
important features unique to each model are highlighted. We urge the owner/operator to read and understand
this manual, and to pay special attention to the features specific to their vehicle(s).
MODEL IDENTIFICATION
The serial number of your Club Car vehicle is printed on a bar code decal mounted on the frame directly
above the accelerator pedal (Example: HG0301-123456) (Figure 2) . There is also a second serial number
decal mounted on the front body frame behind the center dash panel. The center dash panel must be
removed to view this decal. See following NOTE .
NOTE: Have the vehicle serial number available when ordering parts or making inquiries.
CONTROLS AND INDICATORS
Read DANGER and WARNING on page 7.
∆
WARNING
•Before allowing anyone to drive the vehicle, make sure the driver is familiar with all controls
and operating procedures.
•Do not tamper with the governor. Doing so will void the warranty, as well as damage the
engine and other components, and could result in property damage, personal injury, or death
due to unsafe speeds.
•Do not shift the Forward/Reverse handle while the vehicle is in motion. To avoid injury to an
unsuspecting passenger or damage to the vehicle, always bring the vehicle to a full stop
before shifting the handle.
•Release the accelerator pedal and then depress the brake pedal firmly until the vehicle stops.
To avoid unintentionally starting or rolling the vehicle, set the park brake, turn the key switch
to OFF, and remove the key when leaving the vehicle.
Figure 2 Serial Number Decal
FRONT
OF VEHICLE
AS SEEN FROM
PASSENGER SIDE
OF VEHICLE
Remove
negative
cable first.
DISCONNECT BATTERY CABLES
BEFORE WORKING ON VEHICLE

Controls and Indicators
2003 Turf Utility Gasoline Vehicle Owner’s Manual Page 13
KEY SWITCH
The key switch is mounted on the dash to the right of the steering column. The key switch has two positions,
OFF and ON, which are clearly labeled (Figure 3) .
NOTE: The key can be removed only when the key switch is in the OFF position.
FORWARD/REVERSE CONTROL
The Forward/Reverse handle is located on the seat support panel (Figure 4) . The handle has three distinct
positions: F (FORWARD), N (NEUTRAL), and R (REVERSE). Rotate the handle towards the driver (FOR-
WARD) to operate the vehicle in the forward direction, or towards the passenger (REVERSE) to operate the
vehicle in reverse.When the handle is in the straight up position (NEUTRAL), the vehicle will not run. Club Car
vehicles operate at reduced speed in reverse. The reverse buzzer will sound as a warning when the Forward/
Reverse handle is in REVERSE.
Figure 3 Key Switch
Figure 4 Forward/Reverse Handle Figure 5 Accelerator and Brake Pedals
OFF ON
•Before using vehicle, read operating instructions.
•Remain seated and hold on to seat handle while moving.
•Do not start vehicle until all occupants are seated.
•Two (2) persons per seat maximum.
•Operate from driver side only and not on public roads.
•Keep entire body inside vehicle while moving.
•Drive slowly in turns and straight up and down slopes.
•Do not leave children unattended on vehicle.
•Never operate under the influence of alcohol or drugs.
•Use brakes to reduce speed when coasting downhill.
•Never stand in front of or behind vehicle.
CCI 1019606-01
WARNING
ROLLOVER ORFALLINGOFF MAY CAUSE DEATH.

Controls and Indicators
Page 14 2003 Turf Utility Gasoline Vehicle Owner’s Manual
ACCELERATOR PEDAL
The accelerator pedal is the pedal on the right, with the word GO molded into it (Figure 5) . The operation of
the accelerator pedal differs from that of an automobile. When the key switch is ON, and the Forward/Reverse
handle is in either FORWARD or REVERSE, depressing the accelerator pedal will automatically release the
park brake and start the vehicle moving in the direction selected (forward or reverse). When the accelerator is
released, power will be cut off and the engine will stop running .
BRAKE PEDAL
The brake pedal is the large pedal on the left with the word STOP molded into it (Figure 5) . To slow or stop the
vehicle, depress the brake pedal (Figure 6, Page 14) .
PARK BRAKE PEDAL
The park brake pedal is the small raised portion in the upper left corner of the brake pedal. It has the word
PARK molded into it and the words PARK BRAKE marked on top of it (Figure 6) . To set the park brake,
depress the brake pedal firmly and tilt the park brake portion of the pedal forward (Figure 7) .
∆ WARNING
•The park brake will release automatically when either the accelerator or brake pedal is
depressed. The park brake has multiple locking positions and should be firmly pressed and
locked to prevent the vehicle from rolling.
NEUTRAL LOCKOUT
For the convenience of the trained technician, there is a neutral lockout cam (yellow knob) located on the back
of the Forward/Reverse shifter, inside the engine compartment. If the neutral lockout cam is pulled out approx-
imately 3/8 inch (10 mm) and then rotated one-half turn until it snaps into place, the cam will be in the SER-
VICE position (Figure 8) .
∆
WARNING
•With the cam in the SERVICE position and the engine running, the vehicle may move suddenly
if the Forward/Reverse handle is shifted or accidentally bumped. To prevent this, chock the
front and rear wheels and firmly set the park brake before servicing or leaving the vehicle.
Figure 6 Brake Pedal Figure 7 Park Brake Pedal

Controls and Indicators
2003 Turf Utility Gasoline Vehicle Owner’s Manual Page 15
When the cam is in the SERVICE position, it will allow the technician to run the engine in neutral to perform
certain maintenance and/or repair functions. With the cam in this position, the vehicle will not operate if the
Forward/Reverse handle is placed in either the FORWARD or REVERSE position.
NOTE: Be sure to return the cam to the OPERATE position after servicing the vehicle, or it will not run with
the Forward/Reverse handle in either the FORWARD or REVERSE position.
CHOKE
The choke is located on the seat support panel below and to the left of the driver’s left knee. If the vehicle is
hard to start in cool or cold temperatures, activate the choke:
•Turf 1: Depress the choke cover. Hold the choke cover in during start-up and release it after the engine
starts and runs smoothly (Figure 10) .
•Turf 2 and Turf 6: Pull the choke cable. Hold choke cable out during start-up and release it after the
engine starts and runs smoothly (Figure 11) .
Figure 8 Neutral Lockout –Service Position Figure 9 Neutral Lockout –Operate Position
Figure 10 Button Choke Figure 11 Cable Choke
NEUTRAL
SERVICE POSITION
NEUTRAL
OPERATE POSITION

Controls and Indicators
Page 16 2003 Turf Utility Gasoline Vehicle Owner’s Manual
LOW OIL WARNING LIGHT
The vehicle is equipped with a low oil warning light, located on the dash panel just above the steering column
(Figure 12) . If the warning light comes on, oil should be checked and added to the engine as necessary
before continuing to use the vehicle.The vehicle should never be driven when the low oil warning light remains
on. If the warning light goes on and off, the vehicle may be driven, but oil should be added at the first oppor-
tunity. If the oil level is correct and the warning light stays on, have a trained technician check the vehicle.
∆
CAUTION
•Failure to add oil immediately when the low oil warning light stays on may result in permanent
engine damage.
FUEL GAUGE/HOUR METER
The vehicle is equipped with a fuel gauge/hour meter, located on the dash panel (Figure 12) . The fuel gauge
allows the operator to monitor the fuel level in the vehicle. The hour meter should be used by the trained tech-
nician to track vehicle usage and determine when periodic service procedures are required. See Periodic
Service Schedule on page 26.
HEADLIGHT CONTROL
The headlight control is located on the front dash between the fuel gauge/hour meter and steering column.
Pull the headlight control knob out to turn headlights on and push the knob in to turn headlights off.
Figure 12 Fuel Gauge/Hour Meter and
Low Oil Warning Light
LOW OIL
WARNING LIGHT
FUEL GAUGE/HOUR METER
01/2
HOURS
1
1/10
•Before using vehicle, read operating instructions.
•Remain seated and hold on to seat handle while moving.
•Do not start vehicle until all occupants are seated.
•Two (2) persons per seat maximum.
•Operate from driver side only and not on public roads.
•Keep entire body inside vehicle while moving.
•Drive slowly in turns and straight up and down slopes.
•Do not leave children unattended on vehicle.
•Never operate under the influence of alcohol or drugs.
•Use brakes to reduce speed when coasting downhill.
•Never stand in front of or behind vehicle.
CCI 1
019606
WARNING
ROLLOVER OR FALLING OFF MAY CAUSE DE
A

Pre-Operation and Daily Safety Checklist
2003 Turf Utility Gasoline Vehicle Owner’s Manual Page 17
PRE-OPERATION AND DAILY SAFETY CHECKLIST
Each Club Car vehicle has been thoroughly inspected and adjusted at the factory; however, upon receiving
your new vehicle(s), you should become familiar with its controls, indicators, and operation. Carefully inspect
each vehicle to ensure that it is in proper working condition before accepting delivery.
Use the following checklist as a guide to inspect the vehicle. This checklist should be used daily to ensure that
the vehicle is in proper working condition and in conjunction with the Periodic Service Schedule on page 26.
Any problems should be corrected by a Club Car distributor/dealer or a trained technician.
•General: All the parts should be in place and properly installed. Be sure that all nuts, bolts and screws
are tight. Check all hose clamps for tight fit as well as the starter belt for tightness.
•Safety and information decals: Check to ensure that all safety and information decals are in place.
See pages 8 through 11.
•Tires: Check for proper tire pressure. See Vehicle Specifications on page 34. Visually inspect tires
for wear, damage, and proper inflation on a daily basis.
•Battery: Before using vehicle for the first time, check electrolyte to ensure it is at the proper level
(Figure 23, Page 32). Check battery posts. Wires should be tight and free of corrosion and battery
should be fully charged.
•Engine: Check for proper engine oil level. See Engine Oil on page 29.
•Fuel: Check fuel level. See Fueling Instructions on page 30. Check fuel tank, lines, cap, pump, fuel
filters, and carburetor for fuel leakage on a daily basis.
•Exhaust system: Check for leaks.
∆ WARNING
•Be sure the plastic has been removed from the seat bottom before operating the vehicle.
Failure to do so may result in a fire, property damage, personal injury or death.
PERFORMANCE INSPECTION
After you have familiarized yourself with the vehicle controls and have read and understood the driving
instructions, take the vehicle for a test drive.
Use the following checklist as a guide to inspect the vehicle and check daily for proper operation. Any prob-
lems should be corrected by a Club Car distributor/dealer or a trained technician.
•Forward/Reverse shifter: Check for proper operation. See Controls and Indicators on page 12.
•Brakes: Be sure the brakes function properly. When brake pedal is fully depressed under moderate
pressure, it should not go more than halfway to the floor, and vehicle should come to a smooth, straight
stop. If the brake pedal goes more than halfway to the floor or if the vehicle swerves or fails to stop,
have the brake system checked and adjusted as required. Brake adjustment must be maintained so the
brake pedal cannot be depressed to the floor under any circumstance.
•Park brake: When latched, the park brake should lock the wheels and hold the vehicle stationary (on
an incline of 20% or less). It should release when either the accelerator or brake pedal is depressed.
•Reverse buzzer: The reverse buzzer will sound as a warning when the Forward/Reverse handle is in
REVERSE.
•Steering: The vehicle should be easy to steer and should not have any play in the steering wheel.
•Accelerator: With the key switch ON and the Forward/Reverse handle in the FORWARD position; as
the accelerator pedal is depressed, the engine should start and the vehicle should accelerate smoothly
to full speed. When the pedal is released it should return to the original position and the engine should
stop. Club Car vehicles operate at reduced speed in reverse.

Driving Instructions
Page 18 2003 Turf Utility Gasoline Vehicle Owner’s Manual
•Governor: Check maximum speed of the vehicle. Turf 1 and Turf 2 vehicles should operate at 12-15
mph (19-24 km/h) on a level surface. The Turf 6 vehicle should operate at 14-16 mph (23-26 km/h) on a
level surface.
•General: Listen for any unusual noises such as squeaks or rattles. Check the vehicle’s ride and perfor-
mance. Have a Club Car distributor/dealer or a trained technician investigate anything unusual.
DRIVING INSTRUCTIONS
No one should drive the vehicle without first being instructed in the proper operation and use of vehicle con-
trols. An experienced operator should accompany each first-time driver on a test drive before allowing the
driver to operate the vehicle alone.
To ensure safe operation of the vehicle, follow exactly and in order, all of the following procedures. Read and
understand all instructions prior to driving the vehicle.
∆ WARNING
•Only licensed drivers should be allowed to drive the vehicle.
•Before allowing anyone to drive the vehicle, make sure the driver is familiar with all controls
and operating procedures.
•No more than two people should be on the vehicle at one time.
•Do not allow riders in the cargo bed.
•For night use, the vehicle must be equipped with headlights, taillights, and reflectors.
•The vehicle is not specially equipped for handicapped persons:
- Be sure all persons can properly operate the vehicle prior to allowing them to drive the
vehicle.
- Be sure all passengers are capable of securing themselves in a vehicle before allowing
them to ride in one.
•Stop the vehicle before shifting the Forward/Reverse handle. Failure to do so may result in
injury to inattentive passengers and (or) damage to the vehicle.
•To help avoid being struck, do not stand in front of or behind the vehicle.
•Do not leave children unattended on vehicle.
•Operate the vehicle from the driver seat only.
•To help prevent falls from the vehicle, remain seated in a moving vehicle and hold on to seat
handles or handrails at all times. Driver should keep both hands on the steering wheel when
the vehicle is in motion.
•To help prevent the possibility of serious injury, keep entire body inside the vehicle.
•To help prevent overturning the vehicle, drive slowly in turns.
•To help prevent overturning the vehicle, drive slowly straight up and down slopes. Avoid
driving the vehicle on slopes exceeding 20% incline.
•Avoid stopping a loaded vehicle on a hill. If a loaded vehicle must be stopped on a hill, avoid
sudden starts or rolling backwards and stopping suddenly. Failure to heed this warning could
result in overturning the vehicle.
•To help avoId possible injury to inattentive passengers and (or) damage to the vehicle, avoid
sudden starts, sudden stops, and abrupt turns.
•To help avoid the possibility of losing control of or overturning the vehicle, reduce speed for
adverse driving conditions such as wet grass or rough terrain.
