INTRODUCTION
This manual is applicable for the Visiotech VS-2 Body Camera. It details the high definition 4G live
transmission body camera features and setup via the on-screen display and the camera
configuration software.
Visiotech VS-2 is a state-of-the-art wearable video recording solution with the capability of
providing real time audio and video streaming together with GPS location mapping back to a
monitoring control centre.This inherent real time situation awareness provides agencies with
improved emergency response times,staff safety and active intelligence. With its AES-256 video
encryption coupled with Full High-Definition video and incredible low-light capability, lone
workers, law enforcement and security agencies can better protect their people and assets.
With VisioTech’s Digital Evidence Management Software and convenient drop-in docking station,
charging and management of recorded data is made easy, secure and intuitive.
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 6|Page
FEATURES:
REAL TIME SITUATION AWARENESS
This lightweight body camera packs a punch with its state-of-the-art features. Next generation
real time situation awareness provides next level protection for staff and assets. Press record
and capture the truth securely and know your integrity is never questioned. The simple intuitive
control allows users to capture video, audio and photographs and play them back on the
camera. Go back in time with the camera’s pre-event recording feature which automatically
attaches up to 25 seconds of buffered evidence from before the record button was pressed.
ADVANCED ENCRYPTION STANDARD (AES256)
Data is stored on the integrated 64GB solid-state memory and encased in a robust IP67 housing
that can withstand even the harshest conditions. Trust your stored video with the inbuilt
Advanced Encryption Standard (AES-256), adopted by the U.S. government and other
intelligence organisations across the world, this high-end encryption standard ensures the
integrity of your data. An optional feature of this device is a unique encryption key which can be
set for your specific organisation.
FULL HIGH DEFINITION VIDEO
The Visiotech VS-2 Body Camera comes equipped with a 1920x1080 resolution sensor. This
means the body camera records video at twice the number of pixels than the standard 720p. As
a result, this bodycam can capture a crystal-clear image of a license plate, faces, features and
more from a significantly farther distance than 720p.
AUTOMATIC INFRA-RED HIGH OUTPUT NIGHT VISION
The Visiotech VS-2 Body Camera is equipped with a low-light HD video sensor that records Full
HD colour video and snaps photos at a detailed 32 Megapixels. The 2” LCD Screen lets you
view what you are recording in real-time and plays back video and photos instantly. Infrared
night vision picks up details in complete darkness and with Visible Face Detection up to 10
metres. The camera’s 140-degree wide angle lens records peripheral images to avoid important
evidence that would otherwise be off camera.
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 7|Page
WARNING
SAFETYHAZARDWARNINGSFORLITHIUMIONBATTERIES:
The rechargeable Lithium Ion batteries within the Visiotech Body Camera are potentially hazardous and
can present a serious FIRE HAZARD if damaged, defective or improperly used. Lithium batteries
requiring frequent full discharge cycles require special precautions.
A FIRE IS MOST LIKELY TO OCCUR DURING THE CHARGING PROCESS UNDER THE FOLLOWING
CIRCUMSTANCES:
THE BATTERY HAS BEEN FULLY DISCHARGED AND IS NOT RECHARGED SHORTLY AFTERWARD.
This potential is aggravated if batteries are damaged, contain an undetected factory defect, are used or stored
at temperature extremes, or are approaching the end of their useful life. Ideally, batteries should be
recharged within 24 hours of a full discharge.
CHARGING IS ATTEMPTED AT TEMPERATURES BELOW 40°F (4°C). Charging below 40°F (4°C), causes
a chemical reaction in the battery cells that can cause permanent damage and the possibility of fire or
explosion during charging.
THE BATTERY HAS BEEN EXPOSED TO LIQUIDS, ESPECIALLY SALTWATER. Exposure to liquids can
cause internal corrosion or damage to the cells or to the Battery Management System (BMS). The BMS
protects the battery from overcharging, high self- discharge or imbalanced charging of the cells, any of which
can present the possibility of fire during recharging.
OPERATING OR CHARGING A BATTERY THAT HAS BEEN DAMAGED FROM DROPPING OR FROM
SHIPPING DAMAGE.
USING A CHARGER OTHER THAN SPECIFICALLY DESIGNATED FOR THE PARTICULAR BATTERY.
Lithium Ion battery chargers provide a specific charging voltage and microprocessor current and voltage
control.
THE BODY CAMERA SHOULD ONLY GET SLIGHTLY WARM DURING CHARGING. If the camera becomes
hot, smokes, or gives off an odour during charging, terminate charging immediately and contact Comvision.
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 8|Page
GENERALCARE:
Read the user manual carefully before using the equipment, follow the operation
instructions strictly.
Please take care during transportation and use of the body camera.
All installation and maintenance must be performed by professionally trained qualified
persons.
To avoid overheating, keep the Body Camera and docking stations well ventilated.
If the Body Camera produces smoke, smell, or unusual noise, please turn off the
power immediately and unplug the power cord and contact Comvision.
If the Body Camera is not working properly, please contact Comvision. Do not
disassemble or modify the Body Camera in any way in order to maintain your
warranty.
Do not charge at high temperature. The overheating of the battery may cause an
explosion; high temperature refers to not more than 45 degrees.
Physical damage to this product may result in data loss and void the warranty.
This product is only IP67 rated when the rubber protection covers are in place. Water
entering the device will damage it and void the warranty.
Please keep the front lens clean to ensure clear video footage.
Avoid placing equipment in direct sunlight, poorly ventilated areas, or near heat
sources such as heaters (ignoring this may lead to fire hazards).
Please take good care of your username and password.
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 9|Page
PRODUCTOVERVIEW
The main features of the Body Camera:
1. 4G Live Streaming
2. AES-256 Encryption
3. Full HD Video
4. Wide Angle Lens
5. GPS Location Mapping
6. Large 5000mAH battery
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 10|Page
PRODUCTSPECIFICATION
Encryption
AES‐256VideoEncryption
PasswordProtection
RestrictedFileDeletion
Watermark
UserID,Date/TimeStamp,GPScoordinatesembeddedintovideo.Includes7‐digit
DeviceIDand6‐digitUserID
RealTimeStreaming
LiveAudioandVideostreamingbacktoacontrolcentre
RealTimeGPSTracking
T
r
a
c
k
use
r
s
i
n
r
ea
l
t
i
me
on
Vi
s
i
ote
ch
’
s
i
nteg
r
ate
d
G
IS
mappi
ng
soft
w
a
r
e
DuressAlert
Initiatedfromthecamera,duressalarmalertstogetherwithrealtimeaudioand
video can be streamed back to a control centre. The location oftheuseris
dynamicallydisplayedonVisiotech’sintegratedGISmappingsoftware
PresstoTalk(PTT)
PresstoTalkaudiocommunication(Two‐way)
Camera
Capturecrystalclearrecordingoflicenseplates,facesandfeaturestogetherwithhigh
qualityaudioonthisFullHighDefinitionDay/NightCamera
•
OnebuttonTouchRecordingOperation
•
32Megapixelsnapphotos
•
Wideangleofview,140Degrees
•
H.264VideoCompression,dualstream supported
•
G.711/G.726AudioCompression
•
WDRtechnology,ElectronicImageStabilisation,ElectronicShutter
•
Dewarpprocessingforwideanglelens
RecordingResolution
•
Mainstream:1920x1080,1280x720,VGA
•
Secondarystream:1280x720,VGA,WVGA
•
Recordingcontent:VideoandAudio
Pre‐EventRecording
Configurable
StorageCapacity
32GB(64GBand128GBoptional)
NightVision
Auto/ManualIRLED,WhiteLightandLaserLight
•
Upto10MetreswithVisibleFaceDetection,lightSensitivity0.0LUXwithIR
Battery
Largerinternalbatteryincludedwithupto9hourscontinuousrecordingtime
•
Chargetime:4hours
•
5000mAhLi‐ionbattery
Transmission
4GFDD‐LTE/TD‐LTE,Wi‐Fi802.11a/b/g/n2.4G
DataPort
MicroUSBanddockingport
InterfaceProtocol
RTSP
RuggedisedCase
Theruggedballisticshellmadeforlawandsecurityagenciesisweatherresistantand
canhandlethemostextremeconditions.Itsruggedclipattachestoanypocket,belt,
lapel,collar,
placket,andmostprotectivearmour
•
Lightweight217Grams(includingbattery)
•
IP67weatherresistantCase
•
Workingtemperature‐20to+60DegreesCelsius
•
360degreesRotatableClip
Dimensions
H96mmxW63mmxD35mm
Drop‐inDock
Singleslotormultislotoption
Screen
2.0‐inchTFT‐LCDHighResolutionColourDisplay
OS
LinuxwithAmbarellaA12chipset
VideoPlayback
Play,Pause,FastForward,SlowPlay
StandardAccessories
USBCable,Drop‐inDockCharger,Clip,5000mAhbattery
OptionalAccessory
8‐PortDockingstation(modelDS8PVS)
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 11|Page
PRODUCTAPPLICATION
The 4G high-definition Body Camera is a highly integrated device specially developed for
the law enforcement industry. The equipment supports photo snap shots, video and audio
recording, local storage, infrared night vision, laser positioning and 3G / 4G wireless
transmission. Video can be uploaded directly to the server through 4G or WIFI network.
Users can view the video from the body camera through a mobile phone or PC client.
The body camera uses a docking process to charge the body camera batteries and manage
the footage on the camera. The Visiotech DEMS Dock Software is loaded on a PC that
contains adequate Hard Disk capacity to keep the incident footage for the preferred amount
of time. Body cameras connect to the DEMS Dock PC via a USB connection. The Visiotech
single USB docking stations and the 8 port docking stations connect to the PC via USB, the
DEMS Dock software detects a new connection and automatically starts the charging and
file management process. The DEMS Dock software is protected by user level passwords
with general users only having the ability to dock and undock body cameras. Higher level
users are programmed for access to view and playback incident footage, management
encrypted files, export and delete files.
Contects via USB
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 12|Page
Live transmission of video, audio, GPS location, duress alarms and duress footage is
available with the Visiotech VS-2 Body Camera. The body camera transmits to the
Visiotech DEMS Live Server and then onto the DEMS Live Client applications or the
mobile phone application.
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 13|Page
BODYCAMERABUTTONS
Button
Icon
Method
Function
Powerkey
Short
press
On/offscreen
Intheshutdownstate,noeffect.
Long
press Alongpressof3secondscanturnon/offthebodycamera.
Intercom
key
Long
press
Activatetheintercom,presstotalk.
Recordkey
Short
press
InONstate,shortpressrecordkeytostartrecording,shortpress
againtostoprecording.
IntheOFFstate,shortpresstoturnonthebodycameraandstart
videorecording.
Long
press
Sameasshortclickfunction.
Photokey
Short
press
IntheOnstateaphoto can be taken bypressingthePhotokey.
Duringvideorecording,aphotocanbecapturedandsaved.
Long
press
In any state, the white light can be turned on by pressingthe
photokeyfor 2seconds,andthewhitelightcanbeturnedoffby
pressingthephotokeyagainfor2seconds.
Audiokey
Short
press
IntheOnstate,audio recordings can be started bypressingthe
audiokey.Pressingtheaudiokeyagain willstopaudiorecording.
Laser
infrared
key
Short
press
IntheONstatethe laser position indicator can beturnedonby
shortpressingthelaserkey.Pressagaintoturnoff.
Long
press
IntheONstate,thelongpressingtheinfraredkeywillforcetheIR
lampson.Longpressagaintoturnoff.
SIM SIM Socket InsertSIMmobilephonetrafficcardtorealisereal‐time
transmissionfunction.
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 14|Page
USB
USBConnect Portusedfordatatransferinterfaceifnotusingthedocking
station.
Menukey
Short
press
InOnstate,pressthisbuttontoentermenusettings.Itisalsoused
toselectamenupageandreturntotheprevioussetting.
Upward
key
Short
press
In thebodycameramenu system,usedfor anupwardchange
function.
Downkey
Short
press
In thebodycameramenu system,usedfor adownwardchange
function.
Returnor
playback
key
Short
press
Inthebodycameramenusystemorfileselectionstate,ashort
clickisusedtoreturntothepreviouspage.
Itisalsousedtoenterthe playback menu.
Emergency
Alarmkey
Short
press
ShortpresstheREDemergencybutton.Thisstartsrecordingforthe
programedperiodinthebodycamerasetup.Italsosendsan
emergencybuttonpressalarmtotheDEMSLivesoftware.
Long
press
Intherecordingstate,longpressingtheemergencykeythe
currentvideofileasanalarmvideo
BODYCAMERALEDSTATEDESCRIPTION
LED Indicator State
Colour
State Description
Green Idle
Red Video Recording
Orange Sound Recording
Blue Connected to CMS
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 15|Page
INTERFACEICONDESCRIPTIONONBODYCAMERALCDSCREEN
IconDescription
Short press on the RED emergency button. This starts recording for the
programed period in the body camera setup. It also sends an emergency
button press alarm to the DEMS Live software.
Indicates that the GPS signal is successfully located.
Turn on 4G function, indicates that the device has a 4G signal, and the grid
indicates the signal strength. The symbol indicates that 4G module is normal
and SIM card is inserted.
Turn on the Wi-Fi function, indicates that the device has successfully
connected to Wi-Fi, it displays signal strength with 4 arcs indicating the
strongest signal.
Represents the battery level. 4 bars indicate a fully charged battery.
Short press the record button, the red icon indicates the device is recording.
Indicates that the device is connected to the DEMS live server.
13.7G/1
4.5G
The first half indicates the free storage capacity.
The second half represents the total storage capacity of the device.
2017/01
/01 04:24:51 Represents the current date and time of the device.
000000
0_000000 Indicates Equipment ID number_ User number
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 16|Page
TURNINGTHECAMERAONANDOFF
Long press the "Power Key" for 3 seconds, the body camera will turn power on. In any state long
press "Power Key" for 3 seconds to shutdown the body camera.
Short press the "power key" will turn on / off the LCD screen.
VIDEORECORDING
After the body camera is turned on, the camera enters the On state, pressing "Record Key"
will start recording, the camera short vibrates once, the top red indicator light on the LCD
screen indicates the camera is in recording state and the LED light on the top of the camera
turns red. If the "Record key" is pressed again, the camera will long vibrate to indicate the
recording has stopped. The LED on the top of the camera will also turn off. A voice prompt
can be turned on in the body camera setup to indicate when the camera starts and stops
recording.
In the camera Off state, short pressing the "Record key" will start the camera and turn on
recording.
When recording at night without light, you need to long press the "Infrared key". At this time,
the infrared light is turned on to the night mode, and the night photo is black and white.
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 17|Page
AUDIORECORDING
In the On state, pressing "Audio key" starts audio recording, the body camera will short vibrate
once, the top LED indicator light will turn orange and the camera LCD screen prompt has the
audio status picture. Press the “Audio key” again to stop audio recording, the camera will long
vibrate. A voice prompt can be turned on in the body camera setup to indicate when the
camera starts and stops recording.
EMERGENCYDURESSALARM
In the On state, short pressing the RED “Emergency Alarm key” starts recording for the
programed period in the body camera setup. It also sends an emergency duress alarm to the
DEMS Live software.
TAKEAPHOTO
In the On state, press the "Photo key" to take 32 mega pixel pictures. The body camera will
short vibrate once and an audio prompt can be turned on in the body camera setup to indicate
a picture has been taken. Photos can also be taken during recording state.
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 18|Page
PLAYBACK
Press "Return key" to enter the playback menu, press "up and down" to choose the video,
photo or audio folder, press "Menu key" to open the selected directory folder.
Note, if AES-256 encryption is turned on, this menu is not available on the body
camera. Using the playback function in the Visiotech DEMS Docking software is the
only way to playback encrypted files.
VIDEOPLAYBACK
The Video directory is divided into multiple time period folders, press the "Menu key" to open
the folder:
Each folder contains a number of video files recorded during this period:
Press the "Menu key" to playback the selected video file. The video file format is MP4.
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 19|Page
AUDIOPLAYBACK
From the Playback menu, select the “Audio folder” by pressing the "Menu key" to open the
folder:
The Audio directory is divided into multiple time period folders, press the "Menu key" to open
the folder you require:
Each folder contains a number of audio files recorded during this period:
Press the "Menu key" to playback the selected audio file. The audio recording file format is
AAC.
VisiotechVS‐2Manualv1.1 Copyright–ComvisionPtyLtd 20|Page
PHOTOPLAYBACK
From the Playback menu, select the “Photo folder” by pressing the "Menu key" to open the
folder:
The Photo directory is divided into multiple time period folders, press the "Menu key" to open
the folder you require:
Each folder contains a number of photo files taken during this period:
Press the "Menu key" to open the selected photo file. The photo file format is .jpg.
Table of contents
