Defy 800 SMART DRIVE AUTOWASHER User manual

OCTOBER 2012
Laundry & Dishwashers
23860_Defy_Laundry_Broc.indd 1 2012/10/03 1:02 PM

Since our inception in 1932, Defy has always had a keen
alertness of the latest worldwide trends in pursuit of creating
designs that inspire, and has forever stretched the limits of
technological advancement – all while realising the value of
conserving our environment.
An iconic brand name that evokes trust with its steadfast
reputation of reliability, ecient after-sales service and
premium quality, it’s no wonder Defy is leader of the Southern
African household appliance market, with over 14 million
appliances in use throughout South Africa.
Whether it’s the experience of warm, freshly tumble dried
clothing or spotlessly clean linen, our comprehensive range of
laundry appliances oer intelligent designs built to consistently
achieve the nest washing and drying results, whilst cleverly
conserving resources like water, electricity and detergent –
only using the required amount without careless waste.
Defy’s washing machine range is technologically equipped
with convenient and unique solutions tailored to suit every
market. From front load, top load and twin tub models
oering a selection of washing capacities, smarter and simpler
components to reduce mechanical wear and an array of
features to save time and the environment.
Our tumble dryers also oer a range of advanced
programmes; from refreshing to preventing creasing,
accommodating large loads with extreme eciency and
more. Defy’s dishwashers couple simplicity with practicality,
highly capable of washing all types of cutlery and crockery,
using state-of-the-art technology ensures lowered noise
levels, reducing energy and water consumption.
A true pioneer in appliance manufacture, Defy provides every
owner with the assurance of sheer excellence and reliability –
adding ease and simplicity to life.
All products carry a
two year guarantee.
A culture of quality for over a century
Through our belief of fusing elegance with
innovation we have created beautifully
simple and reliable appliances, offering
effortless functionality and the highest
standards of quality for over a century.
23860_Defy_Laundry_Broc.indd 2 2012/10/03 1:02 PM

Washing
Washing Solutions ------------------------------------------------- 1 - 4
Front Load Automatic Washing Machines ------------------- 5 - 8
Top Load Automatic Washing Machines ------------------------- 9
Semi-Automatic Twin Tub Washing Machines ----------- 10 - 12
Drying
Drying Solutions ------------------------------------------------ 13 - 14
Dryers ---------------------------------------------------------------- 15 - 18
Dishwashing
Dishwasher Solutions ------------------------------------------- 19 - 20
Dishwashers ------------------------------------------------------- 21 - 23
Specications ---------------------------------------------------- 25 - 28
Contact Details ------------------------------------------------ Backpage
Contents
23860_Defy_Laundry_Broc.indd 3 2012/10/03 1:02 PM

01
Washing Solutions
TECHNOLOGICAL SOLUTIONS
SAFETY & COMFORT SOLUTIONS
Smart Drive Motor
Smarter and simpler components mean a more ecient motor with
fewer parts to vibrate. Power is not wasted in friction, resulting in
a quieter system with a longer lifespan. Defy’s smart drive washing
machines have a 12 year motor guarantee.
AquaFusion Technology
In regular machines, nearly 25% of the detergent is lost through
the drain before interacting with the laundry. The Defy AquaFusion
Technology blocks the tub outlet to keep all the detergent inside the
washing tub, giving you perfect cleaning results.
Automatic Water Control System
To ensure optimum performance, the amount of water is automatically
adjusted to suit the load of the laundry and the type of fabric washed.
Controlled water consumption leads to greater eciency, beneting
the environment and saving costs.
Electronic Unbalanced Load Control
Through an intelligent stabilising system, it ensures that laundry is
evenly distributed around the drum eliminating vibration and noise
and automatically adjusts spin speed to provide stability during
spinning.
Overow Safety
Any variation from the correct water level in the drum is detected by
a sensor and water automatically begins to drain when the level is
exceeded.
Auto Re-start
In the case of interference, such as a power cut, the auto restart feature
allows the programme to restart automatically when power is back.
23860_Defy_Laundry_Broc.indd 4 2012/10/03 1:02 PM

02
Washing Solutions
ENVIRONMENTAL SOLUTIONS
Energy Eciency
Improved energy eciency compared to A energy rating to save more
on electricity costs and benet the environment.
Eco Wash 20oC Programme
A super energy ecient programme to wash a 3,5 kg load of lightly
soiled and unstained laundry at 20oC, saving on electricity costs and
beneting the environment.
Cotton Eco 40oC Programme
A programme oering the maximum energy and water savings for
normally soiled cotton and linen laundry in comparison to other cotton
programmes.
23860_Defy_Laundry_Broc.indd 5 2012/10/03 1:02 PM

03
Washing Solutions
TIME SAVING SOLUTIONS
Xpress
14 minute express programme for a 2 kg lightly soiled and unstained
laundry at a maximum of 30oC.
Refresh
A fast and eective 17 minute programme suited for clothes that simply
need to be freshened up and rid of odours.
Quick Wash
A full capacity wash programme for lightly soiled laundry at 30oC in just
39 minutes.
23860_Defy_Laundry_Broc.indd 6 2012/10/03 1:02 PM

04
Washing Solutions
HYGIENE SOLUTIONS
Pet Hair Removal
Through a specially developed function, pet hair is eortlessly removed
from laundry. This function automatically adds pre-wash and additional
rinse cycles to remove pet hair eectively, providing anti-allergy
benets.
Child Care
An extra hygienic programme designed for babies with sensitive skin or
people with allergies. Combined intensive wash and additional rinse
cycles ensure thorough results on laundry that requires special care.
Self Clean
A maintenance programme at 70oC to provide better machine hygiene,
cleaning the drum, detergent drawers, pipes and the tub.
23860_Defy_Laundry_Broc.indd 7 2012/10/03 1:02 PM

Front Load Automatic Washing Machine
05 Available in metallic.
Note: Specifications and design subject to modifications without notice. For more information, turn to the specifications section at the back.
• 8kgWashingcapacity
• Smartdrivemotor
• AEnergyeciency
• Stainlesssteeldrum
• Automaticwatercontrolsystem
• LCDDisplay
• Electroniccontrol
• Variablespinspeedupto1400
• 9Washprogrammes
• 3Auxiliaryfunctions
• Programmefollower
• Timedelayupto12hours
• Remainingtimeindicator
• Childlock
800 SMART DRIVE AUTOWASHER (DAW 327)
8 kg Load
Smart Drive Motor
AEnergy
NEW
23860_Defy_Laundry_Broc.indd 8 2012/10/03 1:02 PM

Front Load Automatic Washing Machine
06
Available in metallic.
Note: Specifications and design subject to modifications without notice. For more information, turn to the specifications section at the back.
• 7kgWashingcapacity
• A+Energyeciency
• AquaFusionTechnology
• LCDDisplay
• Electroniccontrol
• Variablespinspeedupto1200
• 16Washprogrammes
• 4Auxiliaryfunctions
• Programmefollower
• Timedelayupto24hours
• Remainingtimeindicator
• 180oDoor opening angle
• Automaticwatercontrolsystem
• Stainlesssteeldrum
• Durableheater
• Unbalancedloadcontrol
• Overowsafety
• Childlock
• DecorativeSshapedsidewall
7KG AUTOWASHER (DAW 372)
Automatic Water
Control System
PetHairRemoval
A+Energy
AquaFusion Technology
NEW
23860_Defy_Laundry_Broc.indd 9 2012/10/03 1:02 PM

Front Load Automatic Washing Machine
07 Available in white.
Note: Specifications and design subject to modifications without notice. For more information, turn to the specifications section at the back.
• 7kgWashingcapacity
• A+Energyeciency
• AquaFusionTechnology
• LCDDisplay
• Electroniccontrol
• Variablespinspeedupto1200
• 16Washprogrammes
• 4Auxiliaryfunctions
• Programmefollower
• Timedelayupto24hours
• Remainingtimeindicator
• 180oDoor opening angle
• Automaticwatercontrolsystem
• Stainlesssteeldrum
• Durableheater
• Unbalancedloadcontrol
• Overowsafety
• Childlock
• DecorativeSshapedsidewall
7KG AUTOWASHER (DAW 371)
Automatic Water
Control System
PetHairRemoval
A+Energy
AquaFusion Technology
NEW
23860_Defy_Laundry_Broc.indd 10 2012/10/03 1:02 PM

DAW 370 available in metallic. DAW 369 available in white.
Note: Specifications and design subject to modifications without notice. For more information, turn to the specifications section at the back.
• 6kgWashingcapacity
• A+Energyeciency
• AquaFusionTechnology
• LCDDisplay
• Electroniccontrol
• Variablespinspeedupto1000
• 16Washprogrammes
• 4Auxiliaryfunctions
• Programmefollower
• Timedelayupto24hours
• Remainingtimeindicator
• Automaticwatercontrolsystem
• Stainlesssteeldrum
• Durableheater
• Unbalancedloadcontrol
• Overowsafety
• Childlock
• DecorativeSshapedsidewall
6KG AUTOWASHER (DAW 369 / DAW 370)
Front Load Automatic Washing Machine
08
A+Energy
Automatic Water
Control System
AquaFusion Technology
NEW
23860_Defy_Laundry_Broc.indd 11 2012/10/03 1:02 PM

• 13kgwashingcapacity
• Airbubbletechnology
• LEDDisplay
• Fuzzylogicsensors
• 6Washprogrammes
• 3Washtemperatures
• Spinspeed650
• 7Waterlevels
• Pre-settimer
• Timedelayupto48hours
• Remainingtimeindicator
• Outofbalancesensor
• Stainlesssteeldrum
• Selfdiagnosticdisplay
• Frontmountedeasycleandrainlter
LAUNDROMAID 1300 (DTL 131 / DTL 132)
DTL 132 available in metallic. DTL 131 available in white.
Note: Specifications and design subject to modifications without notice. For more information, turn to the specifications section at the back.
Top Load Automatic Washing Machine
09
23860_Defy_Laundry_Broc.indd 12 2012/10/03 1:02 PM

DTT 165 available in metallic. DTT 164 available in white.
Note: Specifications and design subject to modifications without notice. For more information, turn to the specifications section at the back.
• 9kgwashingcapacity
• Advancedpaddledpulsator
• Adjustablewaterlevelindicator
• 3Washmodes
• See-throughlid
• Washandspintimers
• Polypropylenewashandspintubs
• Drainpump
• Lintanddrainlters
• Castors
TWINMAID 1300 (DTT 164 / DTT 165)
Semi-Automatic Twin Tub Washing Machine
10
23860_Defy_Laundry_Broc.indd 13 2012/10/03 1:02 PM

DTT 162 available in metallic. DTT 161 available in white.
Note: Specifications and design subject to modifications without notice. For more information, turn to the specifications section at the back.
• 8kgwashingcapacity
• Advancedpaddledpulsator
• Adjustablewaterlevelindicator
• 3Washmodes
• See-throughlid
• Washandspintimers
• Polypropylenewashandspintubs
• Drainpump
• Lintanddrainlters
• Castors
TWINMAID 1000 (DTT 171 / DTT 172)
Semi-Automatic Twin Tub Washing Machine
11
23860_Defy_Laundry_Broc.indd 14 2012/10/03 1:02 PM

Available in white.
Note: Specifications and design subject to modifications without notice. For more information, turn to the specifications section at the back.
• 6kgwashingcapacity
• Solidlid
• Advancedpaddledpulsator
• Waterlevelindicator
• 2Washmodes
• Washandspintimers
• Polypropylenewashandspintubs
• Drainpump
• Lintanddrainlters
TWINMAID 750 (DTT 166)
Semi-Automatic Twin Tub Washing Machine
12
23860_Defy_Laundry_Broc.indd 15 2012/10/03 1:02 PM

13
Drying Solutions
TECHNOLOGICAL &
ENVIRONMENTAL SOLUTIONS
SAFETY & COMFORT SOLUTIONS
Easily Reachable Condenser Unit
Defy’s condenser unit is easy to reach so it can be regularly cleaned for
best possible drying performance.
Easily Accessible Filter
Defy’s tumble dryers feature user friendly lters that can be easily
accessed and cleaned for excellent drying performance.
Auto Anti-creasing
Automatically following the drying cycle, laundry is kept wrinkle-free
inside the dryer for 2 hours while the machine continues to make gentle
drum actions.
Heat Pump Technology
Combining the technology of an air conditioner and a condenser dryer,
heat pump technology creates an ecient system that dries laundry
by condensing water out of garments while using minimum amounts
of energy.
Electronic Sensor Control
Advanced moisture and temperature sensors provide the convenience
of choosing the desired dryness level for laundry making sure they are
evenly dried at the requested level.
Energy Eciency
Improved energy eciency by 30% compared to A energy rating to
save more on electricity costs and benet the environment.
23860_Defy_Laundry_Broc.indd 16 2012/10/03 1:02 PM

14
Drying Solutions
DRYING SOLUTIONS
Xpress
Designed to deliver speed for emergencies, the Xpress programme is
capable of drying 2 kg laundry load in only 35 minutes.
Refresh
This programme rids clothes of odours ensuring they are refreshed
without having to be washed.
Daily
A daily programme developed to dry a 4 kg laundry load in just one hour.
Delicates
Sensor controlled dryers feature a special care programme at a very low
temperature to ensure the safety of delicate garments.
Jeans
Thicker fabrics such as denim are dicult to dry thoroghly in normal
drying cycles. This programme provides the convenience of drying
thicker fabrics properly in a single cycle.
Wool
Speciallydesignedtogivewoolbackitsbounce,byungupbres,
restoring a soft and new feel to your jerseys.
35
23860_Defy_Laundry_Broc.indd 17 2012/10/03 1:02 PM

Dryer
15 Available in metallic.
Note: Specifications and design subject to modifications without notice. For more information, turn to the specifications section at the back.
• 8kgDryingcapacity
• A-30%Energyeciency
• LCDDisplay
• Electronicsensorcontrol
• 16Programmes
• Autoanti-creasing
• Programmefollower
• Timedelayupto24hours
• Remainingtimeindicator
• Drumlight
• Stainlesssteeldrum
• Easilyaccessiblelter
• Cleanlterindicator
• Watertankfullindicator
• Childlock
HEAT PUMP DRYER (DTD 315)
ElectronicSensor
Control
Heat Pump Technology
A-30%Energy
Auto Anti-Creasing
NEW
23860_Defy_Laundry_Broc.indd 18 2012/10/03 1:02 PM

Dryer
Available in metallic.
Note: Specifications and design subject to modifications without notice. For more information, turn to the specifications section at the back.
• 8kgDryingcapacity
• LEDDisplay
• Electronicsensorcontrol
• 15Programmes
• Autoanti-creasing
• Programmefollower
• Timedelaywith3h-6h-9hoptions
• Drumlight
• Easilyaccessiblecondenserunit
• Easilyaccessiblelter
• Cleanlterindicator
• Watertankfullindicator
• Childlock
CONDENSER DRYER (DTD 313)
16
EasilyReachable
CondenserUnit
8 kg Load
Xpress
35
ElectronicSensor
Control
NEW
23860_Defy_Laundry_Broc.indd 19 2012/10/03 1:02 PM

DTD 311 available in metallic. DTD 310 available in white.
Note: Specifications and design subject to modifications without notice. For more information, turn to the specifications section at the back.
• 6kgDryingcapacity
• Air-venteddryer
• LEDDisplay
• Electronicsensorcontrol
• 11Programmes
• Autoanti-creasing
• Programmefollower
• Easilyaccessiblelter
• Cleanlterindicator
• Childlock
6KG AUTODRYER (DTD 294 / DTD 295)
Dryer
17
EasilyAccessibleFilter
ElectronicSensor
Control
Auto Anti-Creasing
6kgLoad
23860_Defy_Laundry_Broc.indd 20 2012/10/03 1:02 PM
