Dilog DL10 SeriesDL107 User manual

DL107 - Voltage Detector
24 - 1000V AC Voltage Detector
with High/Low Sensitivity
Instruction Manual

DL107 Operating Manual
Di-LOG
...measurably better
Contents
I. Overview 3
II. Safety Notice 3
III. Instrument Symbols 5
IV. Specication 6
V. Display and Controls 7
1. Operating Instructions 7
2. Battery Replacement 9
3. Warranty Information 10
1

DL107 Operating Manual DL107 Operating Manual
Di-LOG
...measurably better
Certicate of conformity
As the manufacturer of the instrument
listed below, we declare under our sole
responsibility that the product:
Di-LOG DL107 - Voltage Detector
to which this declaration relates is in
conformity with the relevant clauses of
the following standards:
EN 61010-1
EN 61010-2-030
EN 61326-1
EN 61326-2-2
LVD & EMC
The performance of this instrument
operates within its specication when
used under the conditions in the above
safety and EMC standards.
The product identied above conforms
to the requirements of council directive
89/336/EEC and 73/23 EEC.
2

DL107 Operating Manual
Di-LOG
...measurably better
I. Overview
The DL107 is a non-contact voltage detector
with a built-in ashlight and audible/optical
alarm function. The CAT IV 1000V safety
class ensures user safety, making it an
essential tool for the electrical industry.
Low voltage mode (24V AC - 1000V AC)
Suitable for testing low-voltage motors (<
90V) , audio systems, arc welding machines,
cables with a thick insulation layer, and
other weak electromagnetic AC signals.
High voltage mode (90V AC - 1000V AC)
For detecting domestic electric supply and
three-phase systems. For example, power
distribution units, electrical panels, and
electrical appliances.
II. Safety Notices
1. Please carefully read and fully understand
the warnings and operating instructions
before use. If the instrument is used in a
manner not specied by the manufacturer,
the protection provided by the instrument
may be impaired.
2. Please test the detector on a known live
source within the rated AC voltage range
before use.
3. If the detector appears damaged or is not
working properly, stop using it immediately.
4. Do not detect voltage higher than 1000V.
5. Use caution when working with voltages
above AC 30Vr.m.s, 42Vpeak or DC 60V.
Such voltages pose a shock hazard. Clean
the tester casing with a damp cloth and mild
detergent. Do not use abrasives or solvents!
3

DL107 Operating Manual DL107 Operating Manual
Di-LOG
...measurably better
II. Safety Notices (continued)
6. There may still be voltage even when no
audible/optical alarm is on.
7. The insulation type, conductor thickness,
distance from voltage source, shielded
conductors, other cables, socket design,
and other factors may adversely a󰀨ect test
result. If there are any uncertainties, please
use other methods to verify the voltage.
8. Do not assume neutral or earth wire is
safe to touch. Incorrect or poorly connected
circuits may cause conductors to be charged.
9. When low battery indication appears,
please replace the batteries.
10. When using the detector, please keep
ngers behind the nger guard before the
clear detector head and do not cover.
11. Comply with local and national safety
regulations and requirements.
12. The detector will not detect any voltage if:
a. The conductor is shielded.
b. The operator is not in contact with the
ground or isolated from an e󰀨ective grounding
point.
c. The voltage is DC.
13. The detector may not detect any voltage if:
a. The operator does not hold the detector.
b. The operator is wearing gloves.
c. The conductor under test is partially
buried or in earthed metal conduit.
d. The magnetic eld generated by the
voltage source is blocked, suppressed or
interfered with.
e. The frequency of the voltage being
detected is not a perfect sine wave and may
be distorted by harmonics
f. The detector is used outside of the
operating specications (see Technical
Specications for details)
4

DL107 Operating Manual
Di-LOG
...measurably better
Warning! Warns of potential danger,
and to comply with the instruction
manual.
Caution! Dangerous voltage,
potential risk of electrical shock.
Continuous double or reinforced
insulation complies to IEC 536,
Class II
Symbol of conformity, conrms
conformity with relevant EU
directives. The instrument complies
with the EMC Directive (89/336/
EEC) specically standards
EN 50081-1 and EN 50082-1, as
well as the Low Voltage Directive
(73/23/EEC) described in the
standard EN 61010-1.
III. Instrument Symbols
Symbols displayed on the instrument and
in the instruction manual:
DL10x Series Voltage Detector Specification
DL107 DL108
Detection voltage range Low: 24V - 1000V AC
High: 90V - 1000V AC
Frequency range 50Hz/60Hz
Operation mode Automatic Indication
Vibration mode N/A 
LED flashlight 
Audible and visual
indication 
Auto power o About 5 minutes
Low battery indication ≤2.4V
IP rating N/A IP67
Drop tested 1M 2M
Safety rating CAT IV 1000V Double Insulated
Operating temperature 0°C - 40°C
Storage temperature -20°C - 50°C
Relative humidity ≤80% non-condensing
Dimensions 150mm x 18mm x
23mm
160.5mm x 21.5 mm
x 25mm
Weight (net) 50g 72g
Power supply 2 x 1.5V (RO3) AAA (supplied)
5

DL107 Operating Manual DL107 Operating Manual
Di-LOG
...measurably better
DL10x Series Voltage Detector Specification
DL107 DL108
Detection voltage range Low: 24V - 1000V AC
High: 90V - 1000V AC
Frequency range 50Hz/60Hz
Operation mode Automatic Indication
Vibration mode N/A 
LED flashlight 
Audible and visual
indication 
Auto power o About 5 minutes
Low battery indication ≤2.4V
IP rating N/A IP67
Drop tested 1M 2M
Safety rating CAT IV 1000V Double Insulated
Operating temperature 0°C - 40°C
Storage temperature -20°C - 50°C
Relative humidity ≤80% non-condensing
Dimensions 150mm x 18mm x
23mm
160.5mm x 21.5 mm
x 25mm
Weight (net) 50g 72g
Power supply 2 x 1.5V (RO3) AAA (supplied)
IV. DL10x Series Specication
6

DL107 Operating Manual
Di-LOG
...measurably better
1. Operating Instructions
Turning the detector on
With a short press of the power button, the
buzzer will beep twice and the red indicator
display on the panel will illuminate, indicating
that the detector is on and ready for use.
The default AC voltage detection range is
set to high (90 - 1000V).
Turning the ashlight on/o󰀨
A short press of the ashlight button will
turn the ashlight on/o󰀨. The ashlight
will automatically turn o󰀨 when the detector
is not used for 5 minutes.
V. Display and Controls
1. Non-contact voltage sensor
2. LED Flashlight
3. LED for Voltage Indication
4. High/Low mode status indicator light
5. Power button
6. Flashlight On/O󰀨 button
7. Pocket clip
8. Battery case cover
Note: Please unplug other electrical
devices connected to the socket
before detection.
7

DL107 Operating Manual DL107 Operating Manual
Di-LOG
...measurably better
AC voltage detection
Place the sensor head near the test
object or the power socket with AC
voltage. When AC voltage is detected,
the red LED located within the sensor
head will ash and an audible buzzer will
sound. Audible buzzer and sensing LED
frequencies increase when detector gets
closer to the test object.
Detection range selection
a) When the detector is switched on, the
default setting is pre programmed to high
voltage mode, with a detection range of
90-1000V. The red indicator light on the
display panel will illuminate.
b) With an additional short press of
the power button, the red indicator light
will switch to green, and the device will
switch to low voltage mode, with range of
24-1000V.
In low voltage mode, the detector is more
sensitive to electrical interference/noise.
Please only use the low voltage mode
when detecting weak electromagnetic eld.
Auto power o󰀨
The detector will auto power o󰀨 when it is
not used for 5 minutes.
Turning the detector o󰀨 manually
A long press of the power button for 2
seconds will turn the detector o󰀨.
Low battery indication
When the battery voltage is lower than
2.4V, the detector will automatically shut
down.
8

DL107 Operating Manual
Di-LOG
...measurably better
2. Battery Replacement
1. Hold the detector with one hand, use
the thumb of your other hand to press
down on the battery compartment latch,
and pull the end of the detector.
2. Pull out the end of the detector in the
direction shown in the above picture and
replace the batteries according to the
polarity indicated on the instrument.
Re-t the battery cover once complete
making sure the latch clicks back into
place.
Do not mix old and new batteries.
Do not mix alkaline, standard
(Zinc Carbon), or rechargeable
(Ni-Cad, Ni-Mh, etc) batteries.
9

DL107 Operating Manual DL107 Operating Manual
Di-LOG
...measurably better
3. 24 Month Warranty
Di-LOG instruments are subject to strin-
gent quality controls. If in the course of
normal daily use a fault occurs we provide
a 24 month warranty (only valid with proof
of purchase). Faults in manufacture and
material defects will be rectied by us free
of charge, provided the instrument has not
been tampered with and returned to us
unopened. Damage due to dropping, abuse
or misuse are not covered by the warranty.
Di-LOG Ltd
Unit 28 Wheel Forge Way
Tra󰀨ord Park
Manchester M17 1EH
UK
Tel:[phone]
Email: [email protected]
Website: www.dilog.co.uk
10
