DR XD26 Quick start guide

Serial No.
Order No.
Read and understand this manual and all instructions before operating the DR FIELD and BRUSH MOWER.
DR Power Equipment
Toll-free phone: 1-800-DR-OWNER (376-9637)
Website: www.DRpower.com
DR®FIELD and BRUSH MOWER
SAFETY & OPERATING INSTRUCTIONS
Models:
XD26
XD30

2DR® FIELD and BRUSH MOWER

CONTACT US AT www.DRpower.com 3
Table of Contents
Chapter 1: General Safety Rules............................................................................................................................................................ 4
Chapter 2: Setting Up the DR FIELD and BRUSH MOWER ................................................................................................................ 7
Chapter 3: Operating the DR FIELD and BRUSH MOWER ................................................................................................................. 13
Chapter 4: Maintaining the DR FIELD and BRUSH MOWER.............................................................................................................. 18
Chapter 5: Troubleshooting .................................................................................................................................................................. 30
Chapter 6: Parts Lists and Schematic Diagrams.................................................................................................................................. 32
Conventions used in this manual
Serial Number and Order Number
A Serial Number is used to identify your machine and is located on the Serial
Number Label on your machine (Figure 1). An Order Number is used to check
and maintain your order history and is located on your packing slip. For your
convenience and ready reference, enter the Serial Number and Order Number in
the space provided on the front cover of this manual.
Additional Information and Potential Changes
DR Power Equipment reserves the right to discontinue, change, and improve its
products at any time without notice or obligation to the purchaser. The
descriptions and specifications contained in this manual were in effect at
printing. Equipment described within this manual may be optional. Some
illustrations may not be applicable to your machine.
California Proposition 65
Figure 1
This indicates a hazardous situation, which, if not avoided, could result in death or serious injury.
This indicates a hazardous situation, which, if not avoided, could result in minor or moderate injury.
This information is important in the proper use of your machine. Failure to follow this instruction could result in damage
to your machine or property.

4DR® FIELD and BRUSH MOWER
Chapter 1: General Safety Rules
Labels
The DR FIELD and BRUSH MOWER carries prominent labels as reminders for its proper and safe use. Shown below are copies of
all the Safety and Information labels that appear on the equipment. Take a moment to study them and make a note of their
location on your mower as you set up and before you operate the unit. Replace damaged or missing safety and information labels
immediately.
Warnings, Cautions, and Notices
General Safety
Read this safety & operating instructions manual before you use the DR FIELD and BRUSH MOWER. Become familiar with the
operation and service recommendations to ensure the best performance from your machine. If you have any questions or need
assistance, please contact us at www.DRpower.com or call toll-free 1-800-DR-OWNER (376-9637) and one of our Technical
Support Representatives will be happy to help you.
Safe operation of the DR FIELD and BRUSH MOWER is necessary to prevent death or serious injury. Always take the following
precautions when operating this machine:
The DR FIELD and BRUSH MOWER is designed to mow grass and brush. Do not use it for any other purpose.
If the machine makes an unusual noise or vibration or if there are obstructions underneath the machine, shut off the DR
FIELD and BRUSH MOWER engine. Wait five minutes for the engine to cool. Disconnect the spark plug wire(s) and then
inspect the machine for clogs or loose parts. Clear any obstructions and repair and/or replace damaged parts.
The mower blades are sharp. Wrap the blades or wear gloves and use extra caution when servicing.
Always keep the machine in good, safe operating condition. Always make certain nuts and bolts are tight. Do not use
substitute hardware.
See manufacturer’s instructions for proper operation and installation of accessories. Only use accessories approved by DR
Power Equipment.
#136831
#A0001645278
#A0001645284
#136491
#137581
#A0001645279
#A0001645291
(XD26)

CONTACT US AT www.DRpower.com 5
General Safety (Continued)
Protecting Yourself and Those around You
Slope Operation
Slopes are a major factor related to slip and fall accidents. All slopes require caution. If you feel uneasy on a slope, do not mow it.
Always take the following precautions when using this machine on slopes:
Always mow across the face of slopes. Exercise extreme caution when changing direction on slopes.
Never operate near drop-offs, ditches, or embankments, or on slopes greater than 20 degrees
Never operate on wet or slippery slopes.
This is a high-powered machine with moving parts operating at high speeds. Always take the following precautions when
operating this machine:
Always wear protective goggles or safety glasses with side shields.
Wear sturdy shoes with non-slip treads.
Wear long pants while operating the mower.
Avoid wearing loose clothing or jewelry which can catch on moving parts
Use ear protectors or ear plugs.
We recommend wearing gloves while mowing. Be sure your gloves fit properly and do not have loose cuffs or drawstrings.
Allow only responsible adults who are familiar with these safety rules and operating instructions to use your DR FIELD and
BRUSH MOWER.
Keep your hands and feet away from the blades, belt, pulley, and concealed areas while the engine is running.
Keep people and pets away from your machine and out of the work area at all times. Disengage the blade and stop the engine
if a person or pet is within 100 feet of the machine.
Children are often attracted to the machine and the mowing activity. Never assume that children will remain where you last
saw them.
Never allow people to ride on the mower.
Before mowing, clear the area of objects such as rocks, toys, wire, bones, sticks, etc.
Never remove or alter standard parts or add anything to the DR FIELD and BRUSH MOWER especially all shields and guards.
Before and while moving backwards, look behind, and down, for small children.
Use extra care when approaching blind corners, shrubs, trees, or other objects that may obscure your vision.
Use caution when mowing close to fences, buildings, and trees so as not to hit the handle bar. You could injure your hand or
lose control of the machine.
Use the DR FIELD and BRUSH MOWER only in daylight or very well lit work areas.
Be sure all blade and wheel controls are disengaged before attempting to start the engine.
Always give undivided attention to the machine and your surroundings. Watch for traffic when mowing near roadways.
Disengage the mower blades and exercise extreme caution when on or crossing drives, walks, or roads.
In an emergency, to quickly stop the cutting blade and shut off the engine, remove your hand from the operator presence
lever on the left handlebar.
Always shut off the engine whenever you leave the machine.
When operating over uneven and/or slippery terrain, use extreme caution to ensure solid and firm footing. Keep a firm hold
on the handlebars and walk, never run.
Do not operate the machine when under the influence of drugs, alcohol, or medication.

6DR® FIELD and BRUSH MOWER
Safety with Gasoline - Powered Machines
A Note to All Users
Under California law, and the laws of some other states, you are not permitted to operate an internal combustion engine using
hydrocarbon fuels without an engine spark arrester. This also applies to operation on US Forest Lands. All DR®FIELD and
BRUSH MOWERS shipped to California, New Mexico and Washington State are provided with spark arresters. Failure of the
owner or operator to maintain this equipment in compliance with state regulations is a misdemeanor under California law and
may be in violation of other state and/or federal regulations. Contact your appropriate local or state organization for specific
information in your area.
No list of warnings and cautions can be all-inclusive. If situations occur that are not covered by this manual, the operator must
apply common sense and operate this DR FIELD and BRUSH MOWER in a safe manner. Contact us at www.DRpower.com or call
1-800-DR-OWNER (376-9637) for assistance.
Gasoline is a highly flammable liquid that gives off flammable vapor that can be ignited and cause a fire or explosion. Always
follow these precautions:
Never run the engine in an enclosed area or without proper ventilation as the exhaust contains carbon monoxide, an odorless,
tasteless, and poisonous gas.
Store all fuel and oil in containers specifically designed and approved for this purpose. Keep away from heat and open flame
and out of the reach of children.
Replace rubber fuel lines and grommets when worn or damaged or after 5 years of use, whichever comes first.
Fill the gasoline tank outdoors with the engine off and after the engine has cooled completely. Do not handle gasoline if you
or anyone nearby is smoking.
If you spill gasoline do not start the engine. Move the machine away from the area until the gas vapors have dissipated.
Before performing engine maintenance or repairs; shut down the engine, disconnect the spark plug wire(s), and wait 5
minutes for the engine to cool.
Never change the engine governor settings or modify the engine speed.
Never check for an ignition spark with the spark plug or spark plug wire(s) removed. Always use an approved spark tester.
Never tamper with safety devices. Regularly check their proper operation.
Allow the engine to cool completely before storing in any enclosed area.
Keep combustible substances away from the engine when it is hot. Never cover the machine while the muffler is still hot.
To reduce fire hazard, keep the engine and muffler free of debris build-up.
Do not operate the engine with the air cleaner or the carburetor air intake cover removed.
Do not use flammable solutions to clean the air filter.
Never operate the engine without the muffler and deflector, if so equipped. Inspect the muffler and deflector periodically and
replace if necessary.
The muffler and engine become very hot and can cause a severe burn. Do not touch.

CONTACT US AT www.DRpower.com 7
Brush Bar
Rubber Debris
Guard
Brush Deck with
Heavy Duty 30″
Brush Blade
Oil Fill/
Dipstick
Oil Drain
Tube
ON
OFF
18.5 hp
Kawasaki Engine
Muffler
Oil Filter
Belt Cover
Key Switch
Battery
Hand Guards
Neutral Bypass
Link (Both Sides)
Multi Tool
Service Wrench
Right Side Traction
Drive Lever
Left Side Traction
Drive Lever
Operator Presence
Control Lever
Throttle/Choke
Lever
Blade Engage
Lever
Maintenance
Meter
All Terrain
Pneumatic
Wheels with
Sealant
Chapter 2: Setting Up the DR FIELD and BRUSH MOWER
It may be helpful to familiarize yourself with the controls and features of your DR FIELD and BRUSH MOWER as shown in Figure
2a and 2b before beginning these procedures. If you have any questions, contact us at www.DRpower.com.
DR FIELD and BRUSH MOWER Controls and Features (XD30 with Kawasaki Engine)
Figure 2a
Fuel Shut-Off Valve
Fuel Fill
Cap
Fuel Tank
Fuel Filter
Rear Cover
Plate
Transport
Tie-down
(Both Sides)
Transport
Tie-down
(Both Sides)

8DR® FIELD and BRUSH MOWER
Right Side
Traction Drive
Lever
Left Side Traction
Drive Lever
Operator Presence
Control Lever
Throttle Lever
Blade Engage
Lever
Maintenance
Meter
Oil Fill/
Dipstick
Hand Guards
Oil Drain
Tube
All Terrain
Pneumatic
Wheels with
Sealant
Neutral Bypass
Link (Both Sides)
Rubber Debris
Guard
Belt Cover
Brush Deck with
Heavy Duty 26″
Brush Blade
Brush Bar
10.2 hp Honda
Engine
Multi Tool
Service Wrench
ON
OFF
ON
OFF
DR FIELD and BRUSH MOWER Controls and Features (XD26 with Honda Engine)
Figure 2b
Rear Cover
Plate
Transport Tie-down
(Both Sides)
Transport
Tie-down
(Both Sides)
Pull Start
Handle
Fuel Shut-Off Valve
Choke Lever

CONTACT US AT www.DRpower.com 9
OFF
Specifications
XD26
XD30
Engine
Honda 10.2 HP
Kawasaki 18.5 HP
Fuel Capacity
2.2 Quarts
2 Gal. (7.57 L)
Oil Capacity
38.4 oz.
57.6 oz.
Cutting Capacity
4' Tall Grass
8' Tall Brush
2" Thick Saplings
6' Tall Grass
8' Tall Brush
3" Thick Saplings
Cutting Width
26"
30"
Cutting Height
4"
4"
Drive/Steering System
Dual Hydrostatic Transmissions
Dual Hydrostatic Transmissions
Speeds
Infinite Variable Speed
0-3.2MPH Forward
0-1.9MPH Reverse
Infinite Variable Speed
0-3.2MPH Forward
0-1.9MPH Reverse
Torque
Up to 100 lb-ft
Up to 100 lb-ft
Shaft
.75″Diameter, Keyed
.75″Diameter, Keyed
Maintenance
None
None
Weight
18 lbs per Transaxle
18 lbs per Transaxle
Steering
X-Drive Power Steering
X-Drive Power Steering
Tires
16X6.5, All Terrain
Sealant Filled
16X6.5, All Terrain
Sealant Filled
Machine Dimensions
74″L, 30″W, 42″H
76″L, 34″W, 42″H
Machine Weight
313 lbs.
379 lbs.
Installing the Spark Arrestor (XD30 Only)
Note: The XD26 Honda model is shipped with the Spark Arrestor already installed.
There is a Tube, Screen, and Clamp included in the Spark Arrestor Kit (Figure 3).
The Kit is shipped in the Product Package. The Instructions included in the Kit
are not used this application.
Tools and Needed:
3/8″Wrench
1/2″Wrench
1. Remove the Spark Arrestor Parts from the Product Package (Figure 3).
2. Remove the four Bolts (two on each side) securing the Muffler Guard using
a 3/8″Wrench (Figure 4).
Muffler
Guard
Figure 4
Bolts
Screen
Figure 3
Tube
Clamp

10 DR® FIELD and BRUSH MOWER
Figure 6
3. Insert the Screen into the Spark Arrestor Tube and position the larger end of
the Tube fully onto the Muffler (Figure 5).
4. Install the Clamp around the Spark Arrestor Tube and against the Inner
Muffler Guard. Secure using a 1/2″Wrench.
5. Reposition the Muffler Guard over the Spark Arrestor first and then down
over the opposite end (Figure 6). Note: You may need to pull the end of the
Guard out as you position the Guard on the opposite side to clear the
Muffler.
6. Secure the Guard onto the Muffler with the four Bolts.
Installing the Brush Bar (XD30 Only)
Note: The XD26 model is shipped with the Brush Bar installed.
Tools and Supplies Needed:
Gloves
Wire Cutters
Two 1/2" Wrenches
1. Cut the Cable Ties securing the Brush Bar to the Frame with Wire Cutters
and rotate the Brush Bar forward to align with the mounting holes at the
front of the Deck. (Figure 7).
Note: the XD30 model is shipped with Brush Bar mounting Hardware included in
the product package.
2. Secure the Brush Bar to the Deck with the six 5/16-18 X 1-1/4″Bolts and
5/16-18 Locknuts. Note: Install all by hand first and then use two 1/2″
Wrenches to tighten.
Connecting the Battery Wire (Electric Start Models)
We ship all Electric-Starting Mowers with the negative terminal Battery wire
disconnected. This prevents the Battery from discharging during shipment.
Before using your Mower, you must connect the Battery wire.
1. Connect the negative (black) wire to the negative terminal on the Battery by
sliding the Connector onto the Terminal (Figure 8).
Figure 8
Negative
Battery Wire
Battery
Bolts and
Locknuts
Figure 7
Brush Bar
Spark
Arrestor
Figure 5
Clamp

CONTACT US AT www.DRpower.com 11
Figure 9
Adding Oil and Gasoline
* SAE 30 is our recommendation for typical warmer season use.
** 10W30 is our recommendation for typical colder season use.
Note: Refer to the Oil type Chart for selecting the proper Oil for ambient
temperature range (Figure 9).
ENGINE CAPACITIES
Honda
Kawasaki
Oil
38.4 oz.
57.6 oz.
Fuel
2.2 Quarts
2 Gal
1. Place the machine on a level surface and initially add 1/2 of oil
recommended into the Oil Fill (Figure 10a for XD26 Honda machines or
Figure 10b for XD30 Kawasaki machines).
2. Wait one minute for the oil to settle and check the Dipstick (Figure 11a for
XD26 Honda machines or Figure 11b for XD30 Kawasaki machines).
Continue adding a few ounces of oil at a time, rechecking the Dipstick until
the oil reaches the full mark. Be careful not to overfill.
3. Remove the Gas Fill Cap and add Gas to the Fuel Tank to not more than
1/4" from the bottom of the Fill Neck with fresh, unleaded gas (Figure 10a
for XD26 Honda machines or Figure 10b for XD30 Kawasaki machines).
Full
Figure 11b
Add
XD30 Oil
Fill/Dipstick
Full
Figure 11a
Add
XD26 Oil
Fill/Dipstick
Figure 10b
Gas Fill Cap
Oil Fill/Dipstick
Figure 10a
Oil
Fill/Dipstick
Gas Fill Cap
Before filling the Fuel Tank at any point after this initial fill; turn the Engine
OFF and let it cool at least five minutes before removing the Gas Fill Cap
You must add Oil before starting the engine. This machine is shipped
without oil. Traces of oil may be in the reservoir from factory testing, but
you must add oil before starting the engine. Fill the reservoir slowly,
checking the level frequently to avoid overfilling.
To get an accurate reading when checking the oil level:
- The machine must be on a level surface.
- The dipstick SHOULD NOT be screwed down.

12 DR® FIELD and BRUSH MOWER
Valve Stem
Protective Cap
Figure 12
Check the Tire Pressure
Tools Needed:
Tire Pressure Gauge
Air Compressor
1. Remove the Valve Stem Protective Cap (Figure 12) and check the tire
pressure with a Tire Pressure Gauge.
2. Compare the tire pressure reading from step 1 with the manufacturer's
recommended tire pressure stamped on the side of the tire.
3. If the pressure is too low, add air through the Valve Stem with an air hose.
4. Replace the Valve Stem Protective Cap when finished.
Deck Pivot Bolt Check/Adjustment
There are two Deck Pivot Carriage Bolts on your DR Field and Brush Mower
Frame. The machine should have been shipped with both Bolts in the highest
position (screwed in fully) as shown (Figure 13). If they are not both in the
highest position, and some of the Carriage Bolt threads are shown, perform the
following procedures.
Tools Needed:
1/2″Wrench
5/16″Wrench
Note: The Carriage Bolts should be adjusted all the way up for easy to moderate
mowing. For aggressive mowing adjustment, see “Cutting Brush and Saplings” in
Chapter 3.
1. Loosen both Locknuts using a 1/2" Wrench as you hold the square portion
of the Carriage Bolts using a 5/16" Wrench (Figure 13). Turn the Locknut
down against the Bolt Head.
2. Turn the Carriage Bolts up into the Frame until the Nut is contacting the
Frame.
3. Turn the Locknut against the Frame to lock the Carriage Bolt into position.
Engaging/Disengaging the Transmissions
The Hydrostatic Transmissions (one for each Wheel) must be engaged for the
Drive Levers to function (machines are shipped in the Drive orientation). They
also can be disengaged when moving the machine by hand. The following
instructions explain this procedure.
Drive Position
1. Push each of the two Neutral Bypass Links in toward the Frame until they
stop (Figure 14).
Free Wheel Position
1. Pull each of the two Neutral Bypass Links out toward the deck and at the
same time toward the outside of the Frame (Figure 14).
Note: The machine will not move easily even with the Transmissions disengaged.
Pulling in reverse may be easier depending on conditions and slope.
Figure 14
Neutral Bypass
Link
Engaged for Mowing
Disengaged for
Transporting
Figure 13
Locknut
Frame
Carriage
Bolt
Do not over inflate the tires. Inflate to the manufacturers recommended
pressure found on the tires.

CONTACT US AT www.DRpower.com 13
Key Switch
Figure 16
Throttle Lever
Blade Engage Lever
Chapter 3: Operating the DR FIELD and BRUSH MOWER
You may find it helpful to review the DR FIELD and BRUSH MOWER Controls
and Features in Figure 2a (page 7) or Figure 2b (page 8) before reading this
chapter.
Before Starting the Engine
Check the Engine Oil level every time before you use the machine.
Check the gas level.
Ensure that the Fuel Shut-Off Valve located under the Fuel Tank is open
(Figure 15a XD30 Machines or Figure 15b XD26 machines).
Ensure the Blade Engage Lever is disengaged.
Starting
XD 30 with Kawasaki Engine
1. Move the Throttle Lever to Choke (to Fast if the Engine is already
warm) (Figure 16).
2. Rotate Key to the Start position until the Engine starts, then release.
The Key will return to the Run position and the Engine will continue to
run.
3. Move the Throttle Lever to the Fast position.
XD 26 with Honda Engine
1. Pull out the Choke Lever located on the back of the Engine (leave Choke
pushed in if the Engine is already warm) (Figure 17).
2. Move the Throttle to Fast Position (Figure 16).
3. Grasp the Recoil Starter Handle and slowly pull until you feel resistance. Let
the Cord retract a little bit, and then pull the Cord rapidly to start the Engine.
4. When the Engine starts, push the Choke Lever all the way in. (Figure 17).
Stopping the Engine
XD 30 with Kawasaki Engine
1. Ensure the Blade Engage Lever is Disengaged (Figure 16).
2. Move the Throttle Control Lever to the IDLE position.
3. Turn the Key to the Stop position and remove it for safety.
Note: Close the Fuel Shut-Off Valve when transporting or storing the Mower
(Figure 15a).
Fuel
Shutoff
Valve
Figure 15a
Gas Tank
CLOSED
OPEN
Recoil Starter
Handle
Figure 17
Choke Lever
Fuel Shutoff
Valve
Figure 15b
Engine
CLOSED
OPEN

14 DR® FIELD and BRUSH MOWER
Operator Presence
Control Lever
Figure 18
XD 26 with Honda Engine
1. Ensure the Blade Engage Lever is Disengaged (Figure 16).
2. Move the Throttle Control Lever fully to the IDLE position.
Note: Close the Fuel Shut-Off Valve when transporting or storing the Mower
(Figure 15b).
Emergency Stopping When Mowing
Releasing the Operator Presence Control Lever with the Blade engaged with
stop the Engine (Figure 18). If the Blade is not engaged, releasing the Operator
Presence Control Lever will not stop the Engine.
Transmission Engagement
See “Engaging/Disengaging the Transmissions” on page 12
X-Drive Power Steering
The DR FIELD and BRUSH MOWER features the X-Drive Power Steering which gives you independent control of each wheel to
provide enhanced maneuverability and traction. The System has two configurations; Cross-Drive and Inline Drive. All Machines
are shipped from the factory in the Cross Drive Configuration. Some practice time is necessary to become comfortable with the
controls.
Cross Drive (as shipped)
In the Cross Drive Configuration, the machine will turn in the direction of the lever that is squeezed (i.e. squeeze right Lever to
turn right or squeeze left Lever to turn left) (Figure 19).
Inline Drive
In the Inline Drive Configuration, each wheel is controlled by the lever that is on the same side (i.e. squeeze right to operate the
right wheel to turn left and squeeze left to operate the left wheel to turn right).
Note: We recommend practicing and becoming comfortable with cross drive configuration at varying speeds and terrain before
considering changing to inline drive. If after practicing with cross drive you find that you would prefer the inline configuration, see
Chapter 4 “Changing Drive Configurations” for instructions on changing drive configurations.
Operating the X-Drive Power Steering
Practice and become comfortable with the controls at slow speed in a safe
environment before using faster speed or for mowing/cutting.
The X-drive power steering system is designed to minimize operator fatigue.
Use the hand controls as much as possible to drive the machine in the
desired direction rather than trying to muscle it around.
Mowing Speed will impact cutting performance. Mowing at a slower speed
will improve cut quality.
For best operator control of the DR Field and Brush Mower, always drive at
speed that matches the conditions. For example, use a slower speed when
operating in wet, heavy growth, slippery, and/or steeply sloped areas.
When improved traction is needed, apply a downward force on the handlebar
to get more grip on the tires
Figure 19
Right Turn
Controls
Left Turn
Controls
Cross Drive
Configuration

CONTACT US AT www.DRpower.com 15
Cross Drive Configuration
Driving Straight Forward
Gently squeeze both the left and the right Traction Drive Levers the same
amount. The speed is determined by how much the levers are squeezed
(Figure 20).
Driving Straight Reverse
Gently press both left and right Reverse Thumb Pads the same amount (Figure
21).
To Turn Left or Right Forward
Gently squeeze one Traction Drive Lever more than the other to initiate a turn
(Figure 22 thru Figure 25). Apply more force to the lever on the right side to turn
right or more force to the lever on the left side to turn left.
To Turn Left or Right Reverse
Uses the same concept as above but push down on the Thumb Pads instead.
Inline Drive Configuration
The Inline Drive procedures for engaging the wheel drive is the same when
driving in a straight line. Inline Drive is the opposite of what is described for
the Cross Drive Configuration for turning. Pull more on the right Lever to turn
left etc.
X-Drive Troubleshooting
The transmission speeds have been adjusted at the factory to be balanced left
to right. However, due to variances within the transmissions and linkages, it is
possible that there is a slight variance in wheel speeds when traveling at full
speed. If the machine is tracking noticeably to the left or to the right at full
speed forward or full speed reverse, refer to Chapter 4 “Adjusting the Forward
Speed Limit” for adjusting the forward speed limits to match or “Reverse Drive
Limit Adjustment” for adjusting the reverse speed limits to match.
Turn
Reverse/Left
Figure 25
Turn
Forward/Left
Figure 23
Turn
Forward/Right
Figure 22
Turn
Reverse/Right
Figure 24
Figure 20
Forward
Straight
Figure 21
Reverse
Straight

16 DR® FIELD and BRUSH MOWER
Blade Engage
Lever
Figure 26
Engaging the Blade
1. With the Engine running, hold the Operator Presence Control Lever down to
the Grip with your left hand without touching the Drive Levers. (Figure 18).
2. Push the Blade Control Lever forward, then to the left and down to the
“Engaged” position (Figure 26).
Note:If you engage the Blade Control Lever before holding down the Operator
Presence Lever, the Engine will shut off.
Stopping the Blade
1. Stop the Blade by pushing the Blade Control Knob up and to the right, then
pulling back to the “Disengaged” position (Figure 26).
Note:Releasing the Operator Presence Lever will stop the Blade and also cause the
Engine to shut off. The Engine will not start again until the Blade Control Lever is
moved to the “Disengaged” position.
Cutting Brush and Saplings
DECK PIVOT BOLT ADJUSTMENT (aggressive mowing conditions)
For aggressive mowing (Brush and Saplings) the Deck Carriage Bolts should be adjusted all the way down to stabilize the Deck.
Note: The entire machine must be on a flat surface for the following procedures.
Tools Needed:
1/2″Wrench
5/16″Wrench
1. Hold the square portion of the Carriage Bolts using a 5/16" Wrench and
loosen both Locknuts from against the Frame using a 1/2" Wrench (Figure
27).
2. Turn the Carriage Bolts down until they are contacting the Deck Bracket.
3. Hold the square portion of the Carriage Bolts as you turn the Locknut
against the Frame to lock them into position.
Note: The Carriage Bolts should be adjusted all the way up for easy to moderate
mowing when aggressive mowing is finished.
Figure 27
Locknut
Frame
Carriage
Bolt
Deck Bracket
If you need to leave the operating position to clear debris from the deck, stop the engine, wait five minutes to allow all parts to
cool. Disconnect the spark plug wire(s), keeping it away from the spark plug(s).

CONTACT US AT www.DRpower.com 17
Mowing on Slopes
Tip: Cross Drive operation - When mowing on side hills, press the uphill Drive Lever more than the downhill Lever so the machine
steers slightly up the hill. This should keep the machine moving in a straighter line without additional operator effort. Operate the
opposite Levers for Inline Drive setups.
Obstacle Tips
Dealing with obstacles in the terrain is easy with your new DR FIELD and BRUSH MOWER. The following section explains how to
approach most common obstacles.
Always check your work area before mowing and remove any debris that might tangle or damage the machine.
If you do run into debris and the mower becomes tangled, turn off the Engine, allow the engine to cool for 5 minutes and
disconnect the Spark Plug wire(s) before attempting to untangle the machine.
If the machine gets hung up
1. Disengage the Blade. Do not try to free the machine from stumps or debris with the Blade engaged.
2. Push down on the Handlebars to lift the Mowing Deck over the obstacle.
3. Move the machine in reverse and try backing away from the obstacle.
Transporting
Ensure the Transmissions are engaged before transporting the machine in a truck (see Engaging/Disengaging the Transmissions
on page 12). Also use Wood Chocks for the Wheels and Tie-down Straps so the machine does not shift during transport. There are
four convenient and secure Tie Down points on the Frame.
New Photo
The mower’s blade can easily throw stones, sticks, and other debris at great velocity, which could cause personal injury or property
damage. Do not run the machine over gravel driveways or over loose stones or mulch with the mower blade spinning.
Slopes are a major factor related to slip and fall accidents. All slopes require caution. If you feel uneasy on a slope, do not mow it.
Always take the following precautions when using this machine on slopes:
Always mow across the face of slopes. Do not mow up and down.
Exercise extreme caution when changing direction on slopes.
Never operate near drop-offs, ditches, or embankments.
Never operate on wet or slippery slopes.
When operating the DR FIELD and BRUSH MOWER over uneven terrain or slopes, use extreme caution not to tip the machine
over.
Use a much slower speed when mowing on slopes.
Do not use the DR FIELD and BRUSH MOWER on slopes greater than 20 degrees. Doing so could result in serious injury or
damage to your machine.
Be very careful of your footing when operating the machine in reverse. Know what's behind you and take your time.
Mow when moving Forward only, using Reverse for maneuvering.

18 DR® FIELD and BRUSH MOWER
Chapter 4: Maintaining the DR FIELD and BRUSH MOWER
Regular maintenance will ensure the best performance and long life of your machine. Please refer to this manual and the engine
manufacturer's owner's manual for maintenance procedures. Service intervals listed in the checklist below supersede those listed
in the engine manufacturer's owner's manual.
Regular Maintenance Checklist
PROCEDURE
BEFORE EACH USE
EVERY 25 HOURS
EVERY 100 HOURS
Check function of Operator Presence Switch

Check Engine Oil Level

Check General Equipment Condition

Check Blade for Sharpness

Clean Engine Exterior and Cooling Fins

Check Blade Belt Condition (replace if damaged)

Check Drive Belt Condition (replace if damaged)

Lubricate Grease Fittings

Check Tire Pressures

Change Engine Oil and Filter*
1st time 5 hours

Check the Battery charge (Electric Start Machines)

Replace Air Paper Filter and outer Foam Filter

Check Blade Engage Cable Tension

Replace Blade Belt

Replace Drive Belt

Replace Spark Plug(s)

Replace Fuel Filter (Electric Start Machines)

*The XD26 model does not have an Oil Filter.
LUBRICATION
Replacing Engine Oil (XD26 with Honda Engine)
Note: Drain the oil when the Engine is warm. Warm Oil drains more quickly and
completely than cold Oil.
Tools & Supplies Needed:
Oil (Refer to “Adding Oil and Gasoline” in Chapter 2 for Oil type and
quantity)
Rags and an approved Oil Container
1. Position an approved oil container near the Oil Drain Hose.
2. Unscrew the Oil Drain Cap counterclockwise to open the end of the Drain
Hose Assembly (Figure 28).
3. Remove the Oil Drain Hose Assembly from the Retainer and lower the drain
end over the Oil Container to drain.
4. Replace the Hose onto the Retainer and close the Oil Drain Cap. Replace
the Oil as described on page 11.
Figure 28
Oil Drain
Hose Cap
Hose
Retainer
Before performing any maintenance procedure or inspection, stop the engine, wait ten minutes to allow all parts to cool.
Remove the Key and disconnect the spark plug wire(s), keeping it away from the spark plug(s)
Always wear gloves when performing maintenance on the machine.

CONTACT US AT www.DRpower.com 19
Figure 31
Figure 30
Replacing Engine Oil and Filter (XD30 with Kawasaki Engine)
Note: Drain the oil when the Engine is warm. Warm oil drains quickly and
completely.
Tools & Supplies Needed:
Oil Filter Wrench
Oil (Refer To Engine Operator Manual for Oil type and Capacity)
Rags and an approved oil container
1. Position an approved oil container near the Oil Drain Hose.
2. Unscrew the Oil Drain Cap counterclockwise to open the end of the Drain
Hose Assembly (Figure 29).
3. Remove the Oil Drain Hose Assembly from its stowed position and lower
the drain end over the Oil Container to drain.
4. Position Rags under the Oil Filter to catch oil drips.
5. Remove the old Oil Filter with an Oil Filter Wrench. Ensure that the rubber
Seal comes off with the Oil Filter.
6. Apply a thin layer of fresh Oil over the face of the new Filter rubber Seal.
7. Install the Oil Filter by hand until the rubber Seal is touching the mounting
surface, then turn the Oil Filter 3/4 turn to create a snug fit.
8. Replace the Oil Drain Hose Assembly onto the Storage Hook and close the
Oil Drain Cap. Replace the Oil as described on page 11.
Greasing the Belt Idler
Tools needed:
Grease Gun with General purpose Grease
Clean Rags
1. Clean the Grease Fitting with a clean Rag (Figure 30).
2. Add a few pumps of Grease to the Zerk Fitting.
Greasing the Transmission Linkage
Tools needed:
Grease Gun with General purpose Grease
Clean Rags
1. Clean the Grease Fitting with a clean Rag (Figure 31).
2. Add a few pumps of Grease to each Grease Fitting.
Figure 29
Oil Drain
Hose Cap
Hose Retainer

20 DR® FIELD and BRUSH MOWER
Figure 33
Greasing the Transmission Idler
Tools needed:
Grease Gun with General purpose Grease
Clean Rags
1. Remove the seven Bolts that secure the rear Cover Plate to the Frame using
a 9/16″Wrench and remove the Cover Plate (Figure 32).
2. Clean the Grease Fitting with a clean Rag (Figure 33).
3. Add a few pumps of Grease to the Grease Fitting.
4. Replace the Cover when finished.
Rear Cover
Plate
Figure 32
Bolt (7 Places)
