Edisons Rossi wldcrtrosbd55 User manual

Welding Cart with Drawers

Assembly Guide

Parts List

1. Base (1)

2. Wheel (2)

3. Caster (2)

4. Rear Panel (1)

5. Shelf (1)

6. Welder Tray (1)

7. Left-Side Support Leg (1)

8. Right-Side Support Leg (1)

9. Hook (2)

10. Axle (1)

11. M6x12 Bolt/Flat Washer/Lock Washer/Nut (33)

12. M12 Flat Washer (4)

13. Split Pin (2)

14. Bottle Chain (1)

15. Drawer Assembly (4)

16. Left-Side Drawer Runner Plate (1)

17. Right-Side Drawer Runner Plate (1)

18. Keys (2) (for top drawer only. Not shown)

Note: Tools required for assembly: Suitable spanners.

SKU WLDCRTROSAD55 Revision 2.0 October 2016

10 12

ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI ROSSI

Welding Cart with Drawers

Assembly Guide

Install axle (10) to base (1), then on each side place a washer (12) then wheel (2) (wheel “spokes”

facing out). Place another washer (12) on outside of wheel, then secure with split pin (13). Bend legs of

split pins to prevent them falling out.

Attach casters (3) to base (1) using 8 M6 fastener sets (11).

Assemble rear panel (4) to base (1) using 2 M6 fastener sets (11).

Install the left-side drawer runner plate (16) and left-side support leg (7) to the base (1) using 2 M6

fastener sets (11). The drawer runner plate sits on the inside of the base, with support leg on outer side

of base. Do not tighten the fasteners at this stage.

Install the right-side drawer runner plate (16) and right-side support leg (7) to the base (1) using 2 M6

fastener sets (11). The drawer runner plate sits on the inside of the base, with support leg on outer side

of base. Do not tighten the fasteners at this stage.

Install the shelf (5) to the back panel (4) and to the left and right-side drawer runner plates and left and

right-side support legs using 6 M6 fasterner sets (11). The shelf sits in the inside of the drawer runner

plates. Do not tighten the fasteners at this stage.

Install the welder tray (6) to the back panel (4) and to the left and right-side support legs using 8 M6

fasterner sets (11). Tighten all fasteners installed in steps 4 to 7.

Insert the drawers (15) into the drawer runners. Do this gently and do not force the drawers. The

lockable drawer must be at the top.

Attach the hooks (9) to the left and right-side suport legs using 4 M6 fastener sets (11).
