Electrix iLas G User manual

iLas iLas
G W
PATENT PENDING PATENT PENDING
FIELD INSTALLATION GUIDE
TM TM
© ELECTRIX, LLC 45 Spring Street New Haven, CT 06519 • ElectrixIllumination.com •  203.776.5577 •  203.824.7545 • [email protected]

PRE-INSTALLATION
FRAMING INSTALLATION
6.125"
WALL MOUNT EXTRUSION OR 12"
ADJUSTABLE FILL KITS MAY REQUIRE
FIELD TRIMMING. PLEASE VIEW ALL
DIMENSIONS PRIOR TO INSTALLATION.
USE SUPPLIED LINKING BARS TO CONNECT &
ALIGN WALL MOUNT EXTRUSIONS END TO END.
FASTEN WALL MOUNT
EXTRUSION TO VERTICAL
STUDS
ENGAGE FRAMING
TIGHTEN LINKING BAR
TILT
PLEASE NOTE:
1
2
© ELECTRIX, LLC 45 Spring Street New Haven, CT 06519 • ElectrixIllumination.com •  203.776.5577 •  203.824.7545 • [email protected]
FINISHED CEILING PLANE

CEILING INSTALLATION
OR
LUMINAIRE INSTALLATION
7" for iLas6
4.75" for iLasG
ATTACH GUY WIRE
USE SUPPLIED SCREWS
TO JOIN FRAMING END TO
END.
CONNECT DRIVER TO
120V THROUGH 277V AC
ATTACH TRAIL WITH GUY
WIRE, TO SUPPLIED TABS
INSTALL DROP CEILING
INSTALL DRYWALL CEILING
SECURE SAFETY LANYARDS
TO LUMINAIRE WITH SUPPLIED
SCREWS.
TIGHTEN LINKING BAR
REST LUMINAIRE
3
4a
© ELECTRIX, LLC 45 Spring Street New Haven, CT 06519 • ElectrixIllumination.com •  203.776.5577 •  203.824.7545 • [email protected]
3a
3b
3c
3d
1
2

IMPORTANT NOTE!
CONNECT POWER CABLES
FORCING A CONNECTION WILL CAUSE
DAMAGE TO THE LUMINAIRE AND VOIDS
PRODUCT WARRANTY.
PLUG & PLAY CABLE
VERIFY ALIGNMENT
ADJUST THE
PEAK OUTPUT ANGLE
TUCK CABLE SLACK BEHIND LUMINAIRE AFTER IT HAS LOCKED INTO PLACE.
4b
4d
4c
09-19 1
