ELUSIVE WILDLIFE The Kill Light Sportsman User manual

The Sportsman™ Solar Powered Motion Activated Light
Thank you for purchasing the Kill Light®Sportsman™ Solar Powered
Motion Activated Light from Elusive Wildlife Technologies, LP. If you have
not already done so, please check your local game laws to ensure it is
legal to use an articial light source while hunting or observing animals at
night. Elusive Wildlife Technologies, LP and its aliates do not condone or
promote the use of any of our products as a means to illegally harvest any
animal. Please take a moment to read these instructions thoroughly before
initial use.
TOP
Bottom
Motion Sensor
Durable Metal Housing
Solar Charger
High Output LED Panel
On/Off
Mode Selector Button
Charging Indicator
Dusk-To-Dawn Sensor
Internal Battery for
All Night Run Time
Mounting Bracket Slot
To activate the light or change modes, insert the included Key Pin into the
small hole labeled ON/OFF to press the button. Wait for the light to stop
ashing before pressing the button again to move to a dierent mode.
IMPORTANT: Choose a location that receives full sun and is oriented south.
Mode 1 Power Saver Mode. The light will ash one time. Turns on 50%
power when motion is detected. (Recommended Mode For
Longest Battery Life).
Mode 2 All Night Power Saver Mode. The light will ash two times.
Stays on 10% power all night. Increases to 50% power when
motion is detected.
Mode 3 Extreme Bright Mode. The light will ash three times.
Gradually increases to 100% power when motion is detected.
Mode 4 All Night Extreme Bright Mode. The light will ash four times.
Stays on 10% power all night. Gradually increases to 100%
power when motion is detected.
Mode 5 All Night Acclimation Mode. The light will ash ve times.
Stays on all night at 25% power, every night, to acclimate the
animals to the light.
OFF The light will ash six times and turn o.
Quick Start Guide
Mounting
RemoveThe Kill Light® Sportsman Motion Activated
Light from the package and place in direct sunlight
for a full day or install early in the morning to ensure
the light is fully charged before installation. Leave
the protective lm on the solar panel until after
installation to prevent scratching during mounting.
The charge indicator light will illuminate red when
the solar charger is receiving sunlight.
Select a location that will receive full sunlight all
day. It is important that the light face the South so
that it receives the most sunlight. If the light is not
facing South, or if the light receives partial sunlight
it may not receive a full charge. If the light does not
receive a full charge it may not work properly and/or
ruin the battery.
If mounting to a feeder, align the mounting bracket
to the very bottom of the feeder, and mark the
screw holes. Use the included self drilling/tapping
screws to attach the bracket to the feeder. NOTE:
Apply some silicone to the mounting screw holes
or across the top of the mounting bracket to avoid
water seepage into the feeder.
Then slide the light onto the mounting bracket
and tighten the locking screws on the back of the
mounting bracket.
If mounting to a tree or post, slide the light onto the
mounting bracket, and tighten the locking screws
on the back of the bracket.
Then use the included screws to attach to the post or
tree. NOTE: Angle the mounting screws downward
to avoid damaging the solar panel with the screw
driver.
Remove the protective lm from the solar panel.
1
2
3
4
Warranty
Elusive Wildlife Technologies, LP warranties this product for a period of 1
year from original date of purchase. This warranty covers manufacturer
defects as well as malfunction during normal operation. Please complete
the warranty registration and mail in along with proof of purchase to
register your light. You may also e-mail your registration and proof of
purchase to [e-mail].
Your Kill Light® Sportsman™ Motion Activated Light is water resistant
when installed with the solar panel facing up. Do not submerse your
light, this will void your warranty. Take care to insure the light is mounted
properly and securely.
Elusive Wildlife Technologies, LP will not warranty any light damaged by
user neglect or failure to adhere to these instructions and guidelines. No
lights will be warrantied due to animal damage, or theft.

To turn on the light or change modes, insert
the included ON/OFF Key (a straight pin
or small paper clip will also work) into the
recessed hole to press the button. Wait for
the light to stop ashing before pressing
the button again to move to a dierent
mode.
Mode 1 - Power Saver
Press the Button One Time: The light will ash one time and turn o. The light is
now activated. When it is dark, it will turn on 50% when motion is detected. It will
stay on as long as it senses motion. It will turn o after 20 seconds when motion is
no longer detected.
If mounted properly to receive a full charge during the day, The Sportsman™ light
is expected to run up to 1,350 motion activations per night in mode 1. That is up to
7.5 hours per night.
Mode 2 - On All Night - Power Saver
Press the Button a Second Time: The light will ash twice and turn o. The light is
now activated. It will turn on at dusk, and run all night at 10% power. When motion
is detected, it will increase in brightness to 50% power. It will stay on 50% power as
long as it senses motion. When motion is no longer detected, it will drop down to
10% power after 20 seconds.
If mounted properly to receive a full charge during the day, The Sportsman™ light
is expected to run up to 990 motion activations per night in addition to running
all night at low power. That is up to 5.5 hours per night in the power saver mode in
addition to running all night at low power.
Mode 3 - Extreme Bright
Press the Button a Third Time: The light will ash three times and turn o. The
light is now activated. When it is dark, it will turn on and gradually increase to
100% power when motion is detected. It will stay on as long as it senses motion. It
will turn o after 20 seconds when motion is no longer detected.
If mounted properly to receive a full charge during the day, The Sportsman™ light
is expected to run up to 720 motion activations per night in mode 3. That is up to
4 hours per night.
Mode 4 - On All Night - Extreme Bright
Press the Button a Fourth Time: The light will ash four times and turn o. The
light is now activated. It will turn on at dusk, and run all night at 10% power.
When motion is detected, it will gradually increase in brightness to 100% power.
It will stay on 100% power as long as it senses motion. When motion is no longer
detected, it will drop down to 10% power after 20 seconds.
If mounted properly to receive a full charge during the day, The Sportsman™ light
is expected to run up to 450 motion activations per night in addition to running
all night at low power. That is up to 2.5 hours per night in addition to running all
night at low power.
Mode 5 - On All Night - Acclimation
Press the Button a Fifth Time: The light will ash ve times and turn o. The light
is now activated. It will turn on at dusk, and run all night at 25% power.
If mounted properly to receive a full charge during the day, The Sportsman™ light
is expected to run all night at the 25% power level. The light will not increase or
decrease in brightness with motion. If needed, this mode is used to acclimate the
animals to the light. Many hunters report that they can see enough to make a clear
shot in this mode. It is not necessary to change out of this mode if it works for you.
Deactivation
Press the Button a Sixth Time: The light will ash six times and turn o. The light
is now deactivated.
Important Note: The dusk-to-dawn sensor is built into the solar charger. The light
will not turn on unless it is dark or the solar charger is completely covered with a
dark object.
ON/OFF
ON/OFF KEY
Setting The Mode
Warranty Registration
Troubleshooting & Helpful Tips
_______________________________________________________________________________
Date of Purchase Name
_______________________________________________________________________________
Address City, State, Zip
_______________________________________________________________________________
Phone E-mail
_______________________________________________________________________________
Name of store where purchased Received as a gift ror Purchased for yourself r
Please rate your level of satisfaction with this product from 1-10 with 10 being most satised. If
you have yet to use this product, please circle N/A. Please circle one.
1 2 3 4 5 6 7 8 9 10 N/A
Elusive Wildlife Technologies, LP respects your privacy and we will not sell or
provide your personal information to any other party. However, we would like to
occasionally send you information about your Elusive Wildlife product or special
oers. If you do not wish to receive this information please check here r.
Please mail or e-mail warranty info to:
Elusive Wildlife Technologies, LP • 1107 West Dallas Street
Suite A • Conroe, TX 77301
800-780-6861 email: [email protected]
Is it important to face the light south?
As with all solar powered products, the amount of sun that shines on the solar
charger greatly aects the performance of the light. The more sun exposure the
light receives, the longer the light will operate. In the northern hemisphere, the
sun’s transit across the sky is south of “high noon”. In fact, the farther north you are
located, the lower the sun’s transit is in the sky.
This means if the light is not oriented south, it will spend some portion of the day
in the shadow of whatever the light is mounted to. This will reduce the amount of
sun exposure the solar charger receives and the light will not receive a full charge.
Is it important to receive full sun exposure all day?
The Sportsman™ light is designed to receive full sun all day. This allows the solar
charger to charge the battery completely. A completely charged battery will
provide the longest runtime during the night. If the light is not receiving full sun
exposure all day, then the expected runtimes will decrease. If you nd that your
Sportsman™ light is not running all night or if it stops activating with motion
during the night, then it most likely not receiving a full charge during the day.
Which mode is best for me?
Mode 1 gives the longest runtime. This is the mode that is recommended if you
have a lot of activity or if your location does not get enough sun. If you would like
the light to be on all night, then Mode 2 will give you the next longest runtime.
If you are having trouble spooking animals when the light comes on suddenly,
Mode 2 and Mode 4 stay on all night at 10% power, the light slowly increases in
brightness when motion is detected. Mode 5 is also helpful if you are trying to
acclimate the animals to the light. This mode will stay on all night at 25% power.
Many hunters report that they can see enough to make a clear shot at 10% and
25% power. More power may not be necessary.
Why does the light not last all night?
The Sportsman™ light utilizes an over-sized battery to store more power than it
needs to function all night. Even the best solar panels will not charge properly
when there is no sun shine. Even with the over-sized battery, a day or two of rainy
or cloudy weather will not charge the light completely. If the activity during the
night does not decrease, the light may not be charged enough to last all night.
This does not mean the light is bad or broken. Once the daytime returns to full
sunshine, the lights will completely charge and resume all night function.
What if my location does not get full sun?
If your location gets partial to no sun, then it is best to use Mode 1; this mode uses
the least amount of power. You may also remove the light from the mounting
bracket and charge the light in full sun, and replace the light when you go to hunt.
