Endress+Hauser Fieldgate FXA720 User manual

BA030S/04/en/07.07
Product Version 2.00.xx
56004856
Operating Instructions
Fieldgate FXA720
Ethernet/PROFIBUS DP gateway with Web server
8
All manuals and user guides at all-guides.com
all-guides.com

All manuals and user guides at all-guides.com

Fieldgate FXA720
Endress+Hauser 1
Table of Contents
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Software Compatibility . . . . . . . . . . . . . . . . . . . . . . 3
Registered Trademarks . . . . . . . . . . . . . . . . . . . . . . . 3
1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Installation, commissioning and operation . . . . . . . . 3
1.3 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Technical improvement . . . . . . . . . . . . . . . . . . . . . . 3
1.5 Declaration of conformity . . . . . . . . . . . . . . . . . . . . 4
1.6 Writing conventions . . . . . . . . . . . . . . . . . . . . . . . . 5
1.7 Drawing conventions . . . . . . . . . . . . . . . . . . . . . . . 6
2 Identification . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Device designation . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Licensing agreement . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Function and System Design . . . . . . . . . . 8
3.1 Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2 Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2.1 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2.2 Display elements (LEDs) . . . . . . . . . . . . . . . 9
3.3 System architecture . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4 System requirements . . . . . . . . . . . . . . . . . . . . . . . 12
4 Hardware Installation . . . . . . . . . . . . . . . 13
4.1 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2.1 Power supply . . . . . . . . . . . . . . . . . . . . . . 14
4.2.2 Communication ports . . . . . . . . . . . . . . . . 15
5 Getting Started . . . . . . . . . . . . . . . . . . . . . . 16
5.1 Preparing for installation . . . . . . . . . . . . . . . . . . . . 16
5.1.1 Checking the system requirements . . . . . . 16
5.1.2 Installing the documentation . . . . . . . . . . . 17
5.1.3 Adobe Acrobat Reader . . . . . . . . . . . . . . . . 17
5.2 Establishing communication . . . . . . . . . . . . . . . . . 18
5.2.1 Making initial contact . . . . . . . . . . . . . . . . 18
5.2.2 Changing the Fieldgate address . . . . . . . . . 20
5.3 Installing FXA720 PROFIBUS Driver . . . . . . . . . . . 21
5.3.1 Installing the driver . . . . . . . . . . . . . . . . . . 21
5.3.2 Configuring the driver . . . . . . . . . . . . . . . . 23
5.3.3 Setting PROFIBUS DP bus parameters
in FieldCare . . . . . . . . . . . . . . . . . . . . . . . 26
5.3.4 Setting PROFIBUS DP bus parameters
in P View . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.4 Modifying, repairing or removing the application . . 28
5.4.1 Fieldgate FXA720 PROFIBUS Driver . . . . . 28
5.4.2 Fieldgate FXA720 documentation . . . . . . . 28
6 Configuring the Web Server . . . . . . . . . 29
6.1 Logging on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.2 User interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.2.1 Menu bar . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.2.2 Navigation bar . . . . . . . . . . . . . . . . . . . . . . 31
6.2.3 Information & Configuration pages . . . . . . . 32
6.3 Fieldgate location page . . . . . . . . . . . . . . . . . . . . . . 33
6.4 Security setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.5 Network setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.5.1 Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.5.2 E-mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.5.3 Time server . . . . . . . . . . . . . . . . . . . . . . . . 37
6.6 PROFIBUS setup . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.6.1 Communication settings . . . . . . . . . . . . . . 38
6.6.2 Scan settings . . . . . . . . . . . . . . . . . . . . . . . 40
6.6.3 Live list . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.7 Overview of selected devices . . . . . . . . . . . . . . . . . 41
6.7.1 Device detail parameters . . . . . . . . . . . . . . 42
6.7.2 E-mail on alarm . . . . . . . . . . . . . . . . . . . . . 42
6.7.3 Expert mode for Slot/Index configuration . 43
7 Viewing Information (User Mode) . . . 44
7.1 Logging on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.2 Live list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7.3 Overview of selected devices . . . . . . . . . . . . . . . . . 46
7.4 Fieldgate information . . . . . . . . . . . . . . . . . . . . . . . 47
7.5 XML export . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7.6 Other view functions . . . . . . . . . . . . . . . . . . . . . . . 49
7.6.1 Refresh function . . . . . . . . . . . . . . . . . . . . 49
7.6.2 Endress+Hauser function . . . . . . . . . . . . . . 49
8 Firmware Update . . . . . . . . . . . . . . . . . . . 50
9 Trouble-Shooting . . . . . . . . . . . . . . . . . . . 51
9.1 Problems and remedies . . . . . . . . . . . . . . . . . . . . . 51
9.2 FAQ - Frequently Asked Questions . . . . . . . . . . . . . 51
9.3 Troubleshooting on no connection . . . . . . . . . . . . . 52
10 Accessories . . . . . . . . . . . . . . . . . . . . . . . . 53
10.1 E+H power supply units . . . . . . . . . . . . . . . . . . . . 53
11 Technical Data . . . . . . . . . . . . . . . . . . . . . 54
12 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . 55
12.1 Changing the Internet address (Windows 2000) . . . 55
12.2 XML data elements . . . . . . . . . . . . . . . . . . . . . . . . 57
12.3 PROFIBUS bus parameter ranges . . . . . . . . . . . . . . 58
Index . . . . . . . . . . . . . . . . . . . . . . . . . 59
All manuals and user guides at all-guides.com

Fieldgate FXA720
2Endress+Hauser
Revision History
Software Compatibility
* Also supplied with FieldCare, backwards compatible.
Registered Trademarks
PROFIBUS
®
Registered trademark of the PROFIBUS User Organisation, Karlsruhe Germany.
Microsoft
®
, Windows
®
, Windows 2000
®
,Windows XP
®
and the Microsoft logo are registered
trademarks of the Microsoft Corporation.
All other brand and product names are trademarks or registered trademarks of the companies and
organisations in question
Product
version Manual Changes Remarks
1.00.xx BA030S/04/en/02.04 Original manual
1.01.xx BA030S/04/en/12.04 Single channel version
Getting started revised
Update of user interface
Addition of limit alarms
New security set-up
E-mails now possible
Chapter 4 revised accordingly
Chapter 5 describes web and pass through set-up
Chapter 7.2
Chapter 7.4
Chapter 7.5, Maintenance user added
Chapter 7.6
2.00.xx BA030S/04/en/07.07 Product Java Applets no longer supported
Revision of Web server pages
Editorial Removal of Java Applets
TOF-Tool/Commuwin II replaced by Fieldgate
Product
version DTM (PROFIdtmDPV1) PROFIBUS Driver PROFIBUS DP OPC Server
Supplied on Fieldgate FXA720 CD-ROM Purchased Separately
1.00.xx Version 1.00 (74)* Version 26.00.00 Version 1.15
1.01.xx Version 1.00 (74)* Version 27.00.00 Version 2.00
2.00.xx Version 1.00 (74)* Version 27.00.00 Version 2.00
All manuals and user guides at all-guides.com

Fieldgate FXA720 1 Safety
Endress+Hauser 3
1 Safety
1.1 Designated use
Fieldgate FXA720 is a PROFIBUS/Ethernet Gateway with integrated web server that can be used:
• as a PROFIBUS DP/Ethernet gateway within a PROFIBUS monitoring and control system
• as a remote data acquisition module for PROFIBUS devices connected to its PROFIBUS DP
channels.
More information on these applications is to be found in the manual, or visit the Fieldgate web page
at www.products.endress.com/fieldgate.
1.2 Installation, commissioning and operation
Fieldgate FXA720 must be installed, connected, operated and maintained according to the
instructions in this manual: personnel must be authorised and suitably qualified.
Warning
• You require a unique IP address to set up Fieldgate. The use of IP addresses is strictly
controlled. Usually your system administrator will be authorised to allocate unique addresses
for your Fieldgates. Assigning an unauthorised address to a Fieldgate may result in conflicts
within your system and the failure of the associated devices!
1.3 Operational safety
The unit must not be used in explosion hazardous areas. The permissible ambient conditions given
in the technical data must be complied with.
Repair Do not open the housing of the Fieldgate FXA720. It does not contain any parts that need to be
maintained or repaired by the user. In the event of a fault or defect, return the unit to the vendor.
Opening the unit will void the warranty!
1.4 Technical improvement
Endress+Hauser reserves the right to make technical improvements toits hardware and software at
any time and without prior notification. Where such improvements have no effect on the operation
of the equipment, they are not documented. If the improvements effect operation, a new version of
the operating instructions is normally issued, see Revision History.
