Enessere Hercules User manual

Installation stages of Hercules & Pegasus

3x3 m *
1 m *
* according to site conditions
Installation stages of Hercules & Pegasus
1. Realization of foundation
3. Tower installation 4. Placing the rotor on the tower
5. Electrical connections 6. Tests and system start-up
www.enessere.com 1
2. Assembly of spokes and wings
on the assembly stand
technician technician lifting platform
operator
crane
operator
technician technician crane
operator
assembly stand
technician
16 hours 2 hours
3 hours 3 hours
3 hours
technician technician lifting platform
operator
crane
operator
PLE
Wheeled
crane
PLE Wheeled
crane
Wheeled
crane

Lifting vehicles
Wheeled crane
Mobile elevating work platform (PLE)
• Minimum basket size 1,40x0,70 m
• Working height 16 ÷ 23 m
www.enessere.com 2
• 6÷11T bearing capacity with 15 m outreach
• Lifting of the load at a height of 15 m, with the same
height of upper tower connection level and level of
stabilization of the crane
