ENIX GV-300 User manual

www.enix.pl
GV-300, GV-600, GV-900
instr. GV,11.21.EN instr. , EN-2GV, 11.21 instr. GV,11.21.E3
Thermoregulator with
cable x 1
CONTENTS OF PACKAGE
Heating element x 1
Operating instructions x 1
Key x 1
GVCh-300, GVCh-600, GVCh-900
The GV and GVCh heaters each with rated power of 300 W can be in the
radiators with standard heating power Ös exceeds 300 W.
The GV and GVCh heaters each with rated power of 600 W can be in the
radiators with standard heating power Ös exceeds 600 W.
The GV and GVCh heaters each with rated power of 900 W can be in the
radiators with standard heating power Ös exceeds 900 W.
Electric heater with electronic temperature regulator is intended for heating
water inside a bathroom radiator, and through it, drying clothing. It is
designed to work with bathroom radiators manufactured by ENIX and by
other manufacturers.
GV GVCh maintains a constant, present temperture of heater,
additionally, enables a 2-hours full power operation, regardless of
set temperature.

ACTIVATION AND PRINCIPLE OF OPERATION CONTD
6. The heater does not require any maintenance or care during operation.
Should it be necessary, wipe the device with a damp cloth.
instr. ,EN-6GV,11,21
TECHNICAL PAREMETERS OF HEATERS
ENVIRONMENT PROTECTION
When the working life of the device has expired, do not dispose of
it in the same place as other household waste.
The user is obliged to return the device to the collecting
centres that collect used-up electronic and electric
equipment.
Improper utilisation may result in hazard to the environment and human
health.
The centres that collect such equipment, including local collecting and
municipal centres, constitute the proper system, intended for the collecting
of such equipment.
instr. GV,11.21.EN-4 instr. , EN-5GV,11.21
STRUCTURE
1
2
3
4
5
6
7
S=22
8
11
1.Termoregulator
enclosure
2.Connection
cable
3.Connection
plug
4.Control
hand-wheel
5.Optical indicator
/button (only for GV, GVCh)
6.Heating element
7.Sensor guard
8.Plug for special coupling
9.Seat for special coupling
10.Interlocking screw
10
9
11.Coupling guard
ASSEMBLY
ATTENTION: it is possible to install the radiator with an electric
heater in zone III (more than 60cm), exceeding the overall
dimensions of a shower or tub (NEVER OVER THE TUB OR
INSIDE THE SHOWER CUBICLE!)
DANGER: do not connect the thermoregulator unit to
the mains, before the installation process has been
completed!
ASSEMBLY CONTD
1. Use the open-ended spanner no.22 to screw the heating element to the
connection opening in the vertical collector of the radiator.
2. Remove the shield (12) from the end of the heating element and slide the
regulator completely over the plug of the special coupling (8), thus
enabling the fitting of the pins of the plug into the appropriate indentations
inside the special seat (9).
3. Determine the position of the enclosure, in relation to the radiator, and lock
the enclosure, using a set screw (10).
4. Fill the radiator with water.
ACTIVATION AND PRINCIPLE OF OPERATION
2. If the radiator has been connected to the central heating system
in such a way that the supply water (hot water from the boiler)
enters the radiator from the top (the connection on the top ferrule
on the radiator's collector), close one of the valves on the
return/feed line of the radiator.
1. ATTENTION! Make sure that the radiator is filled with water.
ATTENTION! Never close both valves at the same time.
Now the radiator can be filled with water. All other assembly activities
can be carried out, after having completed all finishing work in the
bathroom.
GV-300, GVCh-300
GV-600, GVCh-600
GV-900, GVCh-900
POWER OUTPUT
230V 50Hz~
230V 50Hz~
230V 50Hz~
300W
600W
900W
Insulation class: I (requires an earthing circuit), IP54
3. Connect the connection plug (3) to the power outlet that has an earthing
bolt. Supply voltage: 230V, 50Hz.
At start-up, the device measures the temperature and activates the heating
element, depending on the results of the measurement and comparison with
the required temperature.
4. Set expected temperature using the hand-wheel (4).
If the temperature value set by the hand-wheel (4)
has been achieved, the heating element is
deactivated and the diode (5) turned off.
If the set temperature is higher than the measured
temperature, the heating element is activated and
the diode (5) lights up in red.
+
-set the
temperature
Connect the plug
to the socket and
Press for
0.5 s
Do not use
hand-wheel
The activation of the 2-hour mode is signalled by
the flashing of the diode (5).
Repeated pressing and holding of the button for
3 seconds cancels the command.
5. Point 5 refers to the heaters of the GV and GVCh type, exclusively.
The pressing of the button (5) activates the heater for 2 hours, regardless
of the hand-wheel settings. After 2 hours, the heater returns to the normal
working mode (see point 4).
Prior to the commencement of installation work, it is
required to study this instruction carefully. All actions
are to be carried out with care. Do not alter the
sequence of installation activities.
Screw tight delicately and carefully without exceeding the
maximal torque amounting 0,3 Nm.
