Fissler CJ-511B User manual

1
Operating Instructions
Induction Hotplate FISSLER
Content
Page
Foreword 2
The Function Mode and Product Advantages of Induction Hotplates 2
Prior to Commissioning 3
General Safety Regulations 3
Installing the Device 4
Commissioning the Device 4
Suitable and Unsuitable Cookware 5
Operating Panel 5
Operating Device 6
Problem and Solution 7
Cleaning and Maintenance 7
Disposal 8
Technical Data 8
CE Declaration of Conformity 8
Guarantee 9

2
Foreword
Dear Customer,
please read these operating instructions carefully before commissioning the induction
hotplate.
Please especially observe the safety notices on the following pages.
Keep these instructions for future reference and pass them on if you give the hotplate
away to someone else.
The Function Mode and Product Advantages of Induction Hotplates
With induction hotplates, an electric voltage is applied on a conductor spool beneath
the glass ceramics. This creates magnetic fields, which directly heat up the bottom of
the cookware through a physical effect.
This means saving time and energy, because contrary to common hotplates, the cookware
is heated up, not the heating element and the glass ceramics. Due to the technical
characteristics described above, another advantage is the very short start-up cooking
time.
In addition, the heat supply promptly adapts to changed settings and can be controlled
in small steps. The induction hotplate reacts to changed settings just as fast as a gas
stove, as the energy reaches the pot immediately without having to heat up other materials
first. The induction technology combines this fast reaction with the basic advantage of
electricity, meaning being able to exactly adjust the heat supply.
Additional advantages of an induction hotplate:
• As the hotplate is only heated up indirectly via the bottom of the cookware, over spilling
food cannot stick and burn and there is hardly any danger of burns for the user. The glass
ceramics is only heated up by the hot cookware.
•Once you take the cookware off the hotplate, the device automatically switches to standby
mode.
•The device detects whether suitable cookware is placed on the hotplate. If this is not
the case, no energy is transmitted.

3
rior to commissioning
Check the device for visible damage.
The power connections and the plug may not show any damages. If you detect damage, have
the device checked by a qualified technician prior to putting it into operation in order
to avoid any danger.
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed including
the following:
1. Read all instructions
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cord, plugs, or (state specific part or parts
in question) in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or
taking off parts.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return appliance to the nearest authorized
service facility for examination, repair, or adjustment.
7. The use of accessory attachments not recommended by the appliance manufacturer may
cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution must be used when moving an appliance containing hot oil or other hot
liquids.
12. To disconnect, turn any control to off”, then remove plug from wall outlet.
13. Do not use appliance for other than intended use.
14.Do Not Cook on Broken Cook-Top – If cook-top should break, cleaning solutions and
spillovers may penetrate the broken cook-top and create a risk of electric shock.
15. Clean Cook-Top with Caution – If a wet sponge or cloth is used to wipe spills on a hot
cooking area, be careful to avoid steam burn, some cleaners can produce noxious fumes if
applied to a hot surface.
16. A short power-supply cord should be used to reduce the risk resulting from becoming
entangled in or tripping over a longer cord.
b) Extension cords are available and may be used if care is exercised in their use.
c) If a extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance; and
2) The cord should be arranged so that it will not drape over the countertop or tabletop
where it can be pulled on by children or tripped over unintentionally.
17. The appliance is of the grounded type, the extension cord should be a grounding-type
3-wire cord.
18. Save these Instructions.
Attention:
In order to prevent possible injuries or electric shock, please observe the
following:
•Never touch the device and the power plug with wet hands. 
•Do not connect the device to the same outlet with other devices. 

4
• Connect the device to a suitable outlet.
• Never move the device by pulling on the power cable. 
• Do not move the induction hotplate during cooking or with hot cookware on top of it.
•Do not place any empty containers on the device. 
• Do not place any metal objects on the device.
• Check the mains connection cable for damage from time to time. Never operate the device
when the cable is damaged. If the mains connection cable shows defects, let a qualified
electrician exchange it.
• Never use the device when it does not function properly, shows damage or in case it was
dropped.
• Do not leave the device unsupervised during operation. Keep children and other
incompetent persons as well as persons under influence of drugs or alcohol away from the
device.
• Do not submerge the device in water or other liquids and do not wash it in the dishwasher.
• Only qualified experts may perform repair and maintenance work on the device using
original replacement and accessory parts. Never attempt to repair the device yourself!
• WARNING: This appliance is not intended for use by persons (including children) with
limited physical, sensory or mental abilities or who lack the necessary experience and/or
skills unless these persons act under the supervision of a person responsible for their
safety or they were instructed by such a person on how to use the appliance.
• Scientific tests have proven that induction hotplates do not pose a risk. However, persons
with a pacemaker should clear with their doctor wether to take care of some special handling
advises.
Installing the device
• Place the device on a stable and level surface.
•Never place the device on a flammable surface (e.g. table cloth, carpet, etc.).
• Do not block the ventilation slots of the device. This may overheat the device. Keep
a minimum distance of 5 to 10 cm to walls or other items.
• Do not place the induction hotplate next to devices or objects, which react sensitively
to magnetic fields (e.g. radios, TVs, cassette recorders, computer, etc.).
• Do not place induction hotplates next to open fires, heaters or other sources of heat.
• Make sure that the mains connection cable is not damaged or squashed beneath the device.
•
Make sure that the mains connection cable does not come into contact with sharp edges
and/or hot surfaces.
•
The device should be connected to a rolled-out extension cable with a maximum length of
3 m and a cross-section of 2 mm. If an intermediate switch is used, it must be rated at
min. 16 A.
Commissioning the device
• Prior to connecting the device, check whether the voltage indicated on the type
plate corresponds to the voltage supply in your home. A wrong connection may lead to grave
damage on the device and injury to persons.
• The two hotplate surfaces consist of temperature-resistant ceramics. In case of
damage, even if this concern only a small tear, disconnect the device from the power supply

5
immediately and contact the customer service.
• We recommend not placing any metal kitchen utensils, cookware or pan lids, knives
or other metal objects on the hotplate. These may heat up when the device is turned on.
Attention: Place the hot pans in the hob area only. Never place them on the control panel
or the frame.
• Do not place any magnetically objects like credit cards, cassettes etc. on the
glass surface while the device is in operation.
• On order to avoid overheating, do not place any aluminium foil or metal plates
on the device.
Warning: Please do not put the induction cooker on an iron/steel board, while
operating.
• Due to electromagnetic reason, the iron/steel board may heat and damage the bottom
of the induction cooker.
• Do not insert any objects like wires or tools into the ventilation slots. Attention:
this may cause electric shocks.
• Do not touch the hot surface of the ceramic field. Please note: the induction
hotplate does not heat up itself during cooking, but the temperature of the cookware heats
up the hotplate!
• Do not heat up any unopened tins on the induction hotplate. A heated tin could
explode; therefore remove the lid under all circumstances beforehand.
•If you do not use the device for an extended period, we recommend you disconnect it
Suitable and unsuitable cookware
Suitable Cookware
•pots and pans with magnetic bottom, as stainless
steel pots with iron bottom, cast iron, enamelled pans
•Flat-bottom pans and pots with a diameter of 22 to 26 cm with magnetic bottom
•Max. weight pot and content 6 kg
Unsuitable Cookware
•Pots/pans with a diameter of less than 12 cm
• Ceramic pots, heat-proof glass
• Copper pots and pans, aluminium pots and ans
• Cookware with feet
• Containers with a curved bottom
Operating panel

6
9 8 7 6 5 4 3 2 1
1. Power switch
2. Selection button (Up), increase of the power stage, temperature or
duration
3. Selection button (Down), reduction of the power stage, temperature or duration
4. LED display: power stage
5. LED display: temperature
6. LED display: timer
7. Function key Booster
8. Menu press 1x: power stage
Menu press 2x: temperature
Menu press 3x: timer
9. Function key Keep Warm
Operating the device
• Connect the plug to a suitable power outlet.
• The control light of the „ Power” button lights up and an audible signal sounds. The
device is now in stand-by mode.
• Place a suitable cooking pot or pan centrally onto the cooking hob.
• Now press button 1. „Power” to turn on the induction cooker. The device heats up and
an audible signal sounds. Then press button 8. Menu 1x. The wattage display 4. will blink.
• You can use the selection buttons 2. and 3. + / - to adjust the setting in the range
0,
P-1（300W）,P-2 （400）,P-3 （600）,P-4 （800）, P-5（1000）, P-6（1200）,P-7 （1300）,
P-8（1400）, P-9（1500） watts.
• Then press button 8. Menu again to preset the temperature (2x). The temperature display
5. will blink.
• You can use the selection buttons 2. and 3. +/- to adjust the setting in the range 155–
430F. (Temperature levels: 155, 180, 210, 250, 290, 320, 360,390 and 430F)
The temperature is measured by a sensor under the glass-ceramic plate so that the

7
displayed temperature can differ from the temperature inside the pot.
Please note that the two functions „ level” and „ temperature” must be selected
alternately. You can either use the power levels or the temperature selection. The
most recently selected function is active and blinks.
•
Timer function button: Press 8. Menu 3x.
• You can use the selection buttons 2. and 3. +/- to adjust the setting in the range 1
– 120 minutes. Selected in 1 minute intervals (up to 120 minutes). The selected duration
is then counted down in the Display in 1 minute steps. When the time has elapsed an audible
signal sounds and the device automatically switches to stand-by mode. Note: During timer
operation the duration can be changed at any time with selection buttons. Due to the
device's memory feature the set temperature level remains unchanged.
•When the induction cooker is set to general heating mode you can press button 7. Booster
to turn on the full power of 1500 watts for the first 30 seconds. After that the power
is reset to the preset level.
•Button 9.Keep Warm: Press „ Keep Warm” When press the “keep warm ” button, the induction cooker
will entered into the “keep warm” mode, the keep warm indicator light will be on; LED display show 140
degree, you can set the keep warm temperature under this keep warm mode, the maximum keep warm
period will be within 2 hours.
•Do not place empty cooking pots or pans onto the ceramic field. Heating an empty pot or
pan activates the overheat protection and turns off the device.
• Do not use the device if it is damaged in any way or does not function properly.
•The use of accessories and spare parts not recommended by the manufacturer can result
in damaging the devices and injuries.
• When „ E2” or „ E6” appears in the display this indicates that the overheat protection
was activated to protect the device and cooking pots.
An activated overheat protection can be reset by unplugging the power cord. The device
can then be used in the normal way
As the temperature limit of 170°Cat the bottom of the pan is reached particularly rapidly when frying
with very little fat you should switch to the „temperature” mode for frying. The upper temperature limit
for this mode is 220°C.
•For cooking we recommend you use the power levels 0、300、400、600、800、1000、1200、
1300, 1400, 1500 watts as used by conventional cookers.
Problem and solution
Error
Code Reason Solution
Waiting status Place a suitable pot/pan onto the induction cooking field. The
plate will work as usual

8
--- ----
E0
Cooking field does not
work Please return the device for repair
E1 Use of wrong, too small
a pot Use a correct pot
E2 Overheat protection Allow the device to cool down, turn it off completely and then on
again
E3, E4 Voltage too low, too
high Connect the device to a correct power outlet
E5 Open circuit Please return the device for repair
E6 Ceramic plate is
overheated Allow the device to cool down, turn it off completely and then on again
Cleaning and maintenance
• Pull the power plug prior to cleaning the device. Do not use any caustic cleaning
agents and make sure that no water penetrates the device.
• To protect yourself from electric shock, never immerse the device, its cables
and the plug in water or other liquids.
• Wipe off the ceramic field with a damp cloth or use a mild, non-abrasive soap
solution.
• Wipe off the casing and the operating panel with a soft cloth or a mild detergent.
• Do not use any petrol products to not damage the plastic parts and the
casing/operating panel.
• Do not use any flammable, acidy or alkaline materials or substances near the device,
as this may reduce the service life of the device and lead to deflagration when the device
is turned on.
• Make sure that the bottom of the cookware does not scrape across the surface
of the ceramic field, although a scratched surface does not impair the use of the device.
• Make sure that the device was properly cleaned before storing it in a dry place.
Disposal
Any other servicing should be performed by an authorized service representative
Dispose of the packaging in the proper manner.
If at any time in the future you should need to dispose of this product please note that
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice.
(Waste Electrical and Electronic Equipment Directive) Technical data
Name Induction Hotplate fissler
Modell CJ-511B、CJ-511C
Item no.

9
Temperature range: 155F bis 430F
Power: 1500 Watt
Stand-By 1,5 Watt
Connection: 120V 60 Hz
Dimensions l/w/h : 360 x 280 x 68 mm
NOTICE：
This device complies with part 18 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s
authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits of the FCC Rules. These limits
are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may case harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
·Reorient or relocate the receiving antenna.
·Increase the separation between the equipment and receiver.
·Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
·Consult the dealer or an experienced radio/TV technician for help.
Changes reserved

10
For the caso Induction Hotplate fissler we grant a
Guarantee
of 3 years
For this device we grant a guarantee of 36 months, starting with
the date of sale
regarding defects due to faulty manufacture or material. Your
legal warranty claims according to §439 ff. BGB-E are not
affected by this.This guarantee does not accept defects due
to inappropriate treatment or use as well as defects which do
not influence the function or the value of the induction
hotplate essentially. Furtheron we do not grant a guarantee
for wear parts or damage in transit as well as for defects due
to repairs which have not been effected by us.
In case of legitimate claims we will decide wether to repair
the device or to send you a new one.
Apparent defects have to be indicated within 14 days after
delivery.
Additional claims will not be accepted.
In order to assert your warranty claims please contact us before
sending the device (always together with the sales slip!) to
the following address.
Braukmann GmbH
Raiffeisenstraße 32
59757 Arnsberg
Repairs beyond any guarantee claim will be charged as low as
possible.
