Flymo HVT52 User manual

®
GB
IMPORTANT INFORMATION
Read before use and retain for future
reference
D
WICHTIGE INFORMATION
Bitte vor dem Benutzen des Gerätes
durchlesen und gut aufbewahren
F
RENSEIGNEMENTS IMPORTANTS
A lire avant usage et à conserver pour
référence ultérieure
NL
BELANGRIJKE INFORMATIE
Leest u deze informatie voor het
gebruik en bewaar ze voor
toekomstige raadpleging
N
VIKTIG INFORMASJON
Les bruksanvisningen før bruk og
oppbevar denne for senere bruk.
S
VIKTIG INFORMATION
Läs anvisningarna före användningen
och spara dem för framtida behov
DK
VIGTIGE OPLYSNINGER
De bør læse dette før brug og gemme
til senere henvisning
E
INFORMACIÓN IMPORTANTE
Léase antes de utilizar y consérvela
como referencia en el futuro
P
INFORMAÇÕES IMPORTANTES
Leia antes de utilizar e guarde para
consulta futura
I
INFORMAZIONI IMPORTANTI
Leggere prima dell’uso e conservare
per consultazione futura
SF
TÄRKEÄÄ TIETOA
Lue tämä ennen käyttöä ja säilytä
myöhempää tarvetta varten
(GB) INSTRUCTION MANUAL
(D) BEDIENUNGSANWEISUNG
(F) MANUEL D’UTILISATION (NL) GEBRUIKSAANWIJZING
(N) BRUKSANVISNING
(SF) KÄYTTÖHJE (S) BRUKSANVISNING (DK) BRUGSANVISNING
(E) MANUAL DE INSTRUCCIONES (P) INSTRUÇNÕES PARA O USO (I) ISTRUZIONI PER L’USO
HVT52

GB - CONTENTS
1. Start/Stop Switch
2. Upper Handle
3. Tie Wrap
4. Washer
5. Locknut
6. Upper Handle Fixing
Bolt (X4)
7. Lower Handle Fixing
Bolt (x2)
8. Starting Handle
9. Fuel Tank Cap & Air
Vent Screw
10. Air Filter
11. Fuel tap & Choke Control
12. 8 spare cutting lines
(coloured yellow)
13. Spark Plug Lead
14. Instruction Manual
15. International Service
Directory
ENGLISH PAGES (2-9)
D - INHALT
1. Start-/Stoppschalter
2. Oberer Griff
3. Kabelhalter
4. Unterlegscheibe
5. Sicherungsmutter
6. Befestigungsbolzen,
oberer Griff (x4)
7. Befestigungsbolzen,
unterer Griff (x2)
8. Starterseil
9. Einfüllverschluß &
Entlüftungsschraube
10. Luftfilter
11. Kraftstoffhahn &
Chokeregelung
12. 8 Ersatzfaden (gelb)
13. Zündkerzenzuleitung
14. Bedienungsanleitung
15. Internationales
Kundendienstverzeichnis
DEUTSCHE SEITEN
(10-17)
F - TABLE DES MATIÈRES
1. Interrupteur de
marche/arrêt
2. Poignée supérieure
3. Attache
4. Rondelle
5. Contre-écrou
6. Boulon de fixation de la
poignée supérieure (x4)
7. Boulon de fixation de la
poignée inférieure (x2)
8. Poignée de démarrage
9. Capuchon de réservoir
de combustible & vis
d’évent
10. Filtre à air
11. Robinet de
combustible &
commande de starter
12. 8 lignes de coupe de
réserve (de couleur
jaune)
13. Fil de bougie
14. Manuel d’instructions
15. Répertoire d’entretien
international
LES PAGES EN LANGUE
FRANÇAISE (18-25)
NL - INHOUD
1. Start/Stopschakelaar
2. Bovenste duwboom
3. Bindveter
4. Borgschijfje
5. Borgmoer
6. Bevestigingsbout voor
bovenste duwboom (x4)
7. Bevestigingsbout voor
onderste duwboom (x2)
8. Starthendel
9. Dop voor brandstoftank
en schroef voor
luchtuitlaat
10. Luchtfilter
11. Brandstofkraan en
carburateurcontrole
12. 8 extra maaikoorden
(geel)
13. Bougiekabel
14. Handboek
15. Internationale service-
adressen
NEDERLANDSE
PAGINA’S (26-33)
N - INNHOLD I ESKEN
1. Start/Stopp bryter
2. Øvre håndtak
3. Kabel strips (2 stk)
4. Skiver (8 stk)
5. Låsemutter (6 stk)
6. Festebolt for øvre
håndtak (4 stk)
7. Festebolt for nedre
håndtak (2 stk)
8. Starthåndtak/snor
9. Drivstofftanklokk
(bensinlokk) & lufteventil
10. Luftfilter
11. Drivstoffkran
(drivstoffuttak) & choke
kontroll
12. Ekstra trad (8 stk)
(gule)
13. Ledning/hette for
tennplugg
14. Bruksanvisning
15. Servicetasjonsliste
NORSKE SIDER (34-41)
SF - SISÄLTÖ
1. käynnistys/pysäytysk-
atkaisin
2. ylävarsi
3. kiinnityskappale
4. pultin välirengas
5. lukitusmutteri
6. ylävarren kiinnityspultti
(4 kpl)
7. alavarren kiinnityspultti
(2 kpl)
8. käynnistyskahva
9. polttoainesäiliön korkki
ja ilma-aukon ruuvi
10. ilmansuodatin
11. polttoainehana ja
rikastimen säätö
12. kahdeksan (keltaista)
varaleikkuusiimaa
13. sytytystulpan johdin
14. käyttöohjeet
15. kansainvälinen
Flymo/Partner-
huoltohakemisto.
SUOMALAISET SIVUT
(42-49)
S - INNEHÅLL
1. Start/stoppkontakt
2. Övre handtag
3. Kabelband
4. Bricka
5. Låsmutter
6. Övre handtagets
fästbultar (4 st)
7. Nedre handtagets
fästbultar (2 st)
8. Starthandtag
9. Tanklock &
luftventilationsskruv
10. Luftfilter
11. Bränslekran och
chokereglage
12. 8 kaplinor i reserv
(gulfärgade)
13. Tändkabel
14. Instruktionsbok
15. Internationell
servicekatalog
SVENSKA SIDOR (50-57)
DK - INDHOLD
1. Start/stopkontakt
2. Øvre håndtag
3. Kabelklemme
4. Spændskive
5. Låsemøtrik
6. Fastgøringsbolt til øvre
håndtag (4 stk.)
7. Fastgøringsbolt til
nedre håndtag (2 stk.)
8. Starthåndtag
9. Benzindæksel og
luftventilskrue
10. Luftfilter
11. Benzinhane og
chokerregulering
12. 8 ekstra klippesnører
(gule)
13. Tændrørsledning
14. Brugsvejledning
15. International
servicetelefonbog
DANSKE SIDER(58-65)
E - CONTENIDO
1. Interruptor de contacto
2. Manillar superior
3. Amarra
4. Arandela
5. Tuerca inaflojable
6. Perno de fijación de
manillar superior
7. Perno de fijación de
manillar inferior
8. Manilla de arranque
9. La tapa del tanque de
combustible y el tornillo
del respiradero de aire.
10. Filtro de aire
11. Llave de combustible y
el control del ahogador
12. 8 cuerdas para cortar
de repuesto (color
amarillo)
13. Cable de la bujía
14. Manual de
Instrucciones
15. Directorio de Servicio
Internacional
PAGINAS EN
CASTELLANO (66-73)
P - LEGENDA
1. Interruptor de
Ligar/Desligar
2. Cabo Superior
3. Presilha
4. Arruela
5. Porca de Aperto
6. Parafuso de Fixação
do Cabo Superior (x4)
7. Parafuso de Fixação
do Cabo Inferior (x2)
8. Pega de Arranque
9. Tampa do depósito de
combustível e parafuso
da ventilação
10. Filtro de Ar
11. Torneira do
combustível e controlo
do redutor de ar
12. 8 linhas de corte
sobresselentes (de cor
amarela)
13. Fio da vela de ignição
14. Manual de Instruções
15. Lista de Assistência
Internacional
PÁGINAS
PORTUGUESAS (74-81)
I - NOMENCLATURA
1. Interruttore
acceso/spento
2. Manico superiore
3. Fermo
4. Rondella
5. Controdado
6. Bullone di fissaggio per
manico superiore (x4)
7. Bullone di fissaggio per
manico inferiore (x2)
8. Maniglia di avviamento
9. Tappo serbatoio del
carburante e vite
passaggio aria
10. Filtro aria
11. Rubinetto carburante e
comando dell’aria
12. 8 lamelle di scorta
(colore giallo)
13. Conduttore candela
14. Manuale d’istruzioni
15. Elenco centri
assistenza
internazionali
ITALIANO (82-89)

1
(GB) CARTON CONTENTS
(D) KARTONINHALT
(F) CONTENU DU CARTON
(NL) INHOUD
(N) KARTONGENS
INNHOLD
(SF) PAKETIN SISÄLTÖ
(S) FÖRPACKNINGENS
INNEHÅLL
(DK) KARTONINDHOLD
(E) CONTENIDO DEL
CARTON
(P) LEGENDAS DOS
DESENHOS
(I) DE CARTONE
A
12
3
4
7
5
6
3
4
5
9
11
10
12
13
8
7
4
5
4
14
15

2
(GB) SAFETY
If not used properly this trimmer can be dangerous! This trimmer can cause
serious injury to the operator and others, the warnings and safety instructions
must be followed to ensure reasonable safety and efficiency in using this trimmer.
The operator is responsible for following the warning and safety instructions in
this manual and on the trimmer.
Explanation of Symbols on the HVT52
Warning
Read the user instructions
carefully to make sure you
understand all the controls and
what they do.
The use of ear protection is
recommended.
Disconnect the spark plug before
attempting any maintenance,
cleaning or adjustment, or if you
are going to leave the trimmer
unattended for any period.
Never allow children or people
unfamiliar with these instructions
to use the trimmer. Local
regulations may restrict the age
of the operator.
Never use, or attempt to fit, a
metal/bar blade with this product.
General
1. Only use the trimmer in the manner and for
the functions described in these instructions.
2. Keep bystanders away. Do not trim whilst
people, especially children or pets, are in the
trimming area.
3. Never operate the trimmer when you are
tired, ill or under the influence of alcohol,
drugs or medicine.
4. The operator or user is responsible for
accidents or hazards occurring to other
people or their property.
Fuel Safety
1. WARNING - Petrol is highly flammable
-Store fuel in a cool place in a container
specifically designed for the purpose.
-Only use a container that is specially
designed for mixing fuel.
-Your trimmer has a 2-stroke
engine which runs on fuel
of 1 part of oil to 25 parts of
petrol.
-Do not use standard 2-stroke mixture as
supplied by garages, neat petrol or multi
grade oil.
-Use a good quality 2-stroke oil or a quality
SAE 30 oil mixed with fresh REGULAR grade
unleaded petrol.
-Refuel outdoors only and do not smoke while
refuelling.
-Wipe dirt and grass clippings from the fuel tank
filler cap to avoid getting dirt into the fuel tank.
-Add fuel BEFORE starting the engine. Never
remove the cap of the fuel tank or add fuel
while the engine is running or when the
engine is hot.
-If petrol is spilled, do not attempt to start the
engine but move the machine away from the
area of spillage and avoid creating any
source of ignition until petrol vapours have
dissipated.
-Never use stale fuel left from last season or
fuel which has been stored for long periods.
-Replace all fuel tanks and container caps
securely.
-Fuel should be stored in a cool place away
from naked flames.
-Your carburettor is pre-set. Normally no
further adjustment is required.
Preparation
1. Do not trim barefoot or in open sandals.
Always wear suitable clothing, gloves, and
stout shoes.
2. Make sure the area to be cut is clear of
sticks, stones, bones, wire and debris; they
could be thrown by the cutting line.
3. Before using always visually inspect to see
that cutting lines, disc bolts and disc
assembly are not worn or damaged. Replace
worn or damaged cutting lines together with
their fixings in sets to preserve balance.
4. Replace faulty mufflers.
25

3
(GB) SAFETY
Use
1. Do not operate the engine in a confined
space where exhaust fumes (carbon
monoxide) can collect.
2. Use the trimmer only in daylight or good
artificial light.
3. Avoid operating your trimmer in wet grass,
where feasible.
4. Take care in wet grass, you may lose your
footing.
5. On slopes, be extra careful of your footing
and wear non-slip footwear.
6. Exercise extreme caution when changing
direction on slopes.
7. Trimming on banks and slopes can be
dangerous. and you should use extreme
caution if using the trimmer in this manner.
Please see further important information below.
8. Do not walk backwards when trimming, you
could trip. Walk never run.
9. Never cut grass by pulling the trimmer
towards you.
10. Stop the engine before pushing the trimmer
across surfaces other than grass and when
transporting the trimmer to and from the
area to be mowed.
11. Do not overspeed the engine or alter
governor settings. Excessive speed is
dangerous and shortens trimmer life.
12. Always start the trimmer carefully with feet
well away from the cutting lines.
13. Do not tilt the trimmer when starting the
engine, except if the trimmer has to be tilted
for starting. In this case, do not tilt more
than absolutely necessary and lift only the
part which is away from the operator.
Always ensure that both hands are in the
operating position before returning the
appliance to the ground.
14. Never pick up or carry a trimmer while the
engine is running
15. Spark plug lead may be hot - handle with
care.
16. Do not attempt any maintenance on your
trimmer when the engine is hot.
17. Cutting disc continues to rotate after the
machine is switched off. Wait until all
machine components have completely
stopped before touching them.
18. Switch off the engine, wait
until the cutting disc has
stopped and disconnect the
spark plug lead:-
19. Switch off the engine, wait until the cutting
disc has stopped, close the air vent screw,
close the fuel tap and disconnect the spark
plug lead.
Maintenance and storage
1. Keep all nuts, bolts and screws tight to be
sure the trimmer is in safe working
condition.
2. Replace worn or damaged parts for safety.
3. Only use the replacement cutting disc,
cutting line, disc bolt, spacer and impeller
specified for this product.
4. Never store the trimmer with fuel in the tank
inside a building where fumes can reach an
open flame or spark.
5. Allow the engine to cool before storing in
any enclosure.
6. To reduce fire hazard, keep the engine,
muffler and fuel storage area free of grass,
leaves or excessive grease.
7. If the fuel tank has to be drained, this
should be done outdoors.
8. Be careful during adjustment of the
machine to prevent entrapment of the
fingers between moving parts and fixed
parts of the machine.
- before leaving the trimmer unattended
for any period;
- before refuelling
- before clearing a blockage;
- before checking, cleaning or working
on the trimmer;
- if you hit an object. Do not use your
trimmer until you are sure that the
entire trimmer is in a safe operating
condition;
- if the trimmer starts to vibrate
abnormally. Check immediately.
USE ON STEEP SLOPES
When operating the trimmer on banks or steep slopes it is important that the feet of the
operator remain firmly on level ground. Where it is not possible we recommend that the
operator use a rope kit specifically designed for this purpose. Any operator so doing must
be adequately trained in the operation of the trimmer in this mode. Further please note that
it is important that every operator carries out a risk assessment or any site before operation
commences. More details of how to use a rope kit or how to obtain one is available from the
Manufacturer or your local Distributor.

4
(GB) ASSEMBLY
Assembly of lower handle to deck
(Fig C)
With the trimmer on the ground:-
1. Remove the bolts (C1), washers (C2)
and lock nuts (C4) from the polythene
bag.
2. Place one washer (C2) on to the bolt
(C1) and secure the lower handle (C4)
by placing bolt (C1) through deck
bracket (C5) and lower handle (C4).
3. Place washer (C2) on bolt and secure
with lock nut (C3).
Assembly of upper handle to lower
handle (Fig D)
Assemble upper handle (D5) to lower handle
(D4) by fitting bolts (D6) and washers (D2)
and securing with lock nuts (D3).
Handle Position
The handle position can be altered by
moving it forward for the park position (Fig
E) or back for the trimming position (Fig F).
Product Rating Label
Product Number . . . . . . . . . . . . . . . . . .
Model Number . . . . . . . . . . . . . . . . . . . .
Serial Number . . . . . . . . . . . . . . . . . . . .
Date of Purchase . . . . . . . . . . . . . . . . . .
Place of Purchase . . . . . . . . . . . . . . . . .
•PLEASE KEEP PROOF OF PURCHASE•
Every Flymo product is uniquely identified by
a silver and black product rating label.
To ensure you have full product information
when obtaining spares or advice from one of
our approved service centres, or if you need
to contact Flymo/Partner's own customer
service department, you should make a note
in the space provided of the information
shown in fig.B. It will also be useful to make
a note of the date and place of purchase
before you return your guarantee card.
B
Assembly and Adjustment
C
D
4
1
5
2
3
5
23
4
6
E F
2
Fuel Mixing Instructions
1. Ensure mixing bottle and cap are clean and standing on a level surface.
2. Add fresh regular grade unleaded petrol up to the 1 litre mark on the bottle.
3. Add a good quality 2 stroke oil, to the 25 : 1 mark (40 ml of oil) on the bottle.
4. Screw cap on, shake container until petrol and oil are thoroughly mixed.
5. Clean fuel tank filler cap and fill fuel tank.
●UK ONLY:- Flymo/Partner manufacture a specially designed fuel mixing bottle. For further
information contact your local Flymo/Partner Service Centre/Stockist or contact the
Flymo/Partner Customer Careline on 01325 300303

5
(GB) USE
Before Starting your Trimmer
Filling the Fuel Tank
1. Clean around fuel cap (See fig A).
2. Remove cap.
3. Add fuel mix (See Fuel mixing
instructions)
4. Never use stale fuel left from last season
or fuel which has been stored for long
periods.
5. Refit fuel tank cap and wipe up any spilled
fuel.
To Start your Trimmer
1. Move the handle to the parking position
(Fig E).
2. Open the fuel tank air vent screw See Fig.
G.
3. Open the fuel tap (H1).
4. Connect the spark plug lead. See fig. J.
5. Set the choke control lever (H2) to 'cold
start' when the engine is cold, or 'normal'
when the engine is hot.
6. Move the start/stop switch to 'start'
position See Fig K.
7. Place your right foot on the deck and
grasp the top of the lower handle with
your left hand. Tilt the trimmer towards
you. See fig L. This prevents a ring
being cut in your lawn.
8. Pull the starting handle (Fig. A) gently
until you feel a resistance, return the
starting handle slowly.
9. Pull the starting handle firmly towards you
to its full extent.
10.Allow the engine to reach its full running
speed then gently lower the trimmer to
the ground.
11.When the engine has warmed up make
sure the choke control lever (H2) is in the
'normal' position.
To Stop your Trimmer
1. Move start/stop switch to stop position.
See Fig K.
2. As the engine dies, tilt the trimmer to one
side. See fig. M. This prevents a ring
being cut in your lawn.
3. When the engine has stopped, lower the
trimmer to the ground.
4. Put the handle in the Parking position (Fig.
E).
5. Close the fuel tap (H1) and the fuel tank
air vent screw (Fig. G).
Starting and Stopping
G
H
K
L M
1
2
J
STOP - STOP
START -

6
(GB) USE
●●The cutting line is sharp, wear gloves
and take care when handling it.
●●Check the cutting line frequently
during use and on completion of
trimming.
Removing the Cutting Line
1. Switch machine off and disconnect spark
plug lead.
2. Push the line towards the centre of the
cutting disc and carefully remove. See Fig
N.
Fitting the Cutting Line
1. Holding the line with thumb and forefinger
and using other thumb as a guide, curve
around centre portion of the cutting disc
(as illustrated in Fig P) and thread
through the hole on the rim of the cutting
disc.
2. Carefully pull the line into place as
illustrated in Fig. Q.
●At all times the amount of line extending
beyond the edge of disc should be of an
even length. If there is a variation of
more than half an inch between the four
lengths of line replace immediately with
four full new lengths.
●●Important:- Only fit four cutting
lines at any one time.
●●Only use Yellow coloured cutting
line on the HVT 52.
Changing the height of cut
1. Loosen bolt (R1), using a 14mm socket.
Remove bolt (R1), spring washer (R2),
washer (R3) cutting disc (R4) and spacer
(R5) (if fitted).
2. Carefully remove impeller (R6) from
engine shaft.
3. Select required height of cut,
(See Figs S, T, U & V)
and replace any cutting lines required,
ensuring that cutting line is fitted on
correct side of cutting disc.
●●Important:- Cutting line must be on
the side of the disc facing the grass
when fitted.
4. Replace impeller (R6) on to engine shaft
ensuring that it is correctly located.
Replace spacer (R5) (if fitted), cutting
disc (R4), washer (R3), spring washer
(R2) and bolt (R1).
5. Secure assembly with bolt (R1), making
sure complete assembly is tight, (if in
doubt, contact your service dealer).
Removing and Fitting Cutting Line -
Height Adjustment
N
P
Q
R
4
32
1
5
6
S
Highest
height of
cut
T
U
V
Lowest
height of
cut

7
(GB) USE
If you do not intend to use your trimmer
for long periods it is advisable to follow
this procedure after use:-
1. Close the fuel tank air vent screw. (Fig. G)
2. The engine will begin to stop, tilt the trimmer
(Fig M).
3. After the engine has stopped move the
start/stop switch to the stop position. (Fig. K)
4. Disconnect the spark plug lead (Fig. X) and
close the fuel tap.
5. Remove all fuel from the fuel tank.
Cleaning
●Keep your trimmer clean - grass clippings
left in any of the air intakes, around the
engine or under the deck could become a
potential fire hazard.
●Do not clean with chemicals, including
petrol, or solvents - some can destroy
critical plastic parts.
1. Remove grass from under the deck with a
piece of wood or similar.
2. Using a soft brush - remove grass clippings
from around the engine and from all air intakes.
3. Remove the fan, See 'Height adjustment',
and clean with a soft brush.
4. Wipe over the surface of your trimmer with a
dry cloth.
Carrying your Trimmer
●Never carry a trimmer when it is running
Carry the trimmer at the point of balance with the
cutting system facing away from you (See Fig W).
Storing Your Trimmer
Store in a cool, dry, damp-proof and safe place.
Service your trimmer after the last cut of the year
as follows:-
Caring for your Trimmer
W

8
(GB ) MAINTENANCE
Caring for your Trimmer
Cleaning the Air Filter
●Your Tecumseh engine is fitted with a turbo
filter, the maintenance for which is as follows:-
When the engine performance drops (e.g. difficult
starting or loss of revs) check the air cleaner.
1. Remove the two screws (Y4). Take off the
filter cover (Y1).
2. Remove the two filters (Y5) and (Y6).
Clean inside the filter cover thoroughly.
3. Shake or tap the thick filter (Y5) to remove
any dirt or dust.
4. Replace the thin filter (Y6) if it is contaminated
with dust. DO NOT OIL THE FILTERS.
5. Install the thick filter (Y5) in the filter cover
(Y1). Place the thin filter (Y6) on top. DO
NOT CREASE THE FILTERS.
6. Clean the filter body (Y7) with a small
brush. Replace the filter cover (Y1) and
the two screws (Y4).
7. DO NOT REMOVE the cap (Y2) or screws
(Y3) unless there is visual evidence of
grass or dirt.
Y5
2
3
1
4
67
●●Never run the engine without a filter or with a
dirty filter. This will greatly reduce engine
efficiency and lead to engine damage.
At the end of the Trimming Season.
1. Allow the engine to cool. Drain the fuel tank (Fuel
left in the engine becomes stale and causes
difficult starting).
2. Remove the spark plug lead and spark plug
(See Fig X). Pour one teaspoon (5ml) of oil
through the spark plug hole. Pull the starting
handle 2 or 3 times. This will distribute oil on
the internal surfaces of the engine. Inspect,
clean and replace the spark plug. If a new
spark plug is required contact your local
approved Flymo Service Centre/Dealer.
Do not re-connect the spark plug lead.
3. Clean the air filter. See 'Cleaning the Air
Filter'.
4. Renew the cutting disc if it is cracked, damaged
or bent. Renew the disc bolt if necessary. See
'Height Adjustment' for complete
instructions.
5. Use only genuine Flymo parts and accessories
specified for this product.
6. Clean your trimmer thoroughly. See 'Cleaning'.
7. Your local approved Flymo/Partner Service
Centre/Dealer will carry out any service or
repairs required.
8. Store your trimmer in a cool, dry, damp-proof
and safe place.
●Switch off the engine, wait until the cutting disc
has stopped and disconnect the spark plug lead
BEFORE attempting any maintenance or
adjustment.
X

9
(GB ) MAINTENANCE
Guarantee, Fault Finding Hints, Service Recommendations &
Certificate of Conformity
Guarantee & Guarantee Policy
If any part is found to be defective due to faulty
manufacture within one year of original purchase,
Flymo/Partner, through its Authorised Service Repairers will
effect the repair or replacement to the customer free of
charge providing:
(a)Where the machine is used commercially the guarantee
is 90 days.
(b)The fault is reported directly to the Authorised Repairer.
(c) Proof of purchase is provided.
(d)The fault is not caused by misuse, neglect or faulty
adjustment by the user.
(e)The failure has not occurred through fair wear and tear.
(f) The machine has not been serviced or repaired, taken
apart or tampered with by any person not authorised by
Flymo/Partner.
(g)The machine has not been used for hire.
(h)The machine is owned by the original purchaser.
(i) The machine has not been used outside of the country
for which it was specified.
* This guarantee is additional to, and in no way diminishes
the customers statutory rights.
Failures due to the following are not covered, therefore it is
important that you read the instructions contained in this
Operator's Manual and understand how to operate and
maintain your machine:
Failures not covered by guarantee
* Replacing worn or damaged cutting lines and cutting
disc.
* Failures as a result of not reporting an initial fault.
* Failures as a result of sudden impact.
* Failures as a result of not using the product in
accordance with the instructions and recommendations
contained in this Operator's Manual.
* Machines used for hire are not covered by this
guarantee.
* The following items listed are considered as wearing
parts and their life is dependent on regular maintenance
and are, therefore not normally subject to a valid
warranty claim: Cutting lines, cutting disc, belts, cables,
recoil ropes, filters.
*Caution!
Flymo/Partner does not accept liability under the
warranty for defects caused in whole or part, directly or
indirectly by the fitting of replacement parts or additional
parts that are not either manufactured or approved by
Flymo/Partner, or by the machine having been modified
in any way
I, the undersigned P. Howells of
Flymo/Partner, a Division of Electrolux
Outdoor Products Limited, Aycliffe
Industrial Estate, NEWTON AYCLIFFE,
Co. Durham. DL5 6UP. Certify that a
sample of the above product has been
tested and found to comply with
directives:-
89/392/EEC, 89/336/EEC
Signed at
NEWTON AYCLIFFE...................1998
I, the undersigned P. Howells of
Flymo/Partner, a Division of Electrolux
Outdoor Products Limited, Aycliffe
Industrial Estate, NEWTON AYCLIFFE, Co.
Durham. DL5 6UP. Certify that a sample
of the above product has been tested
using directive 81/1051/EEC as a guide.
The maximum A-weighted sound pressure
level recorded at operator position under
free field semi anechoic chamber
conditions was:-
Signed at
NEWTON AYCLIFFE...................1998
I, the undersigned P. Howells of
Flymo/Partner, a Division of Electrolux
Outdoor Products Limited, Aycliffe
Industrial Estate, NEWTON AYCLIFFE, Co.
Durham. DL5 6UP. Certify that a sample
of the above product has been tested
using ISO 5349 as a guide. The maximum
weighted root mean square value of
vibration recorded at operator’s hand
position was:-
Signed at
NEWTON AYCLIFFE...................1998
Fault Finding Hints
Engine Will Not Start
1. Ensure that the start/stop switch is in the start position.
2. Check that there is sufficient fuel of the correct mix in the fuel tank,
the fuel tap is open and the fuel tank air vent screw is open.
3. Check that the choke control lever is in the correct position:-
'normal' - for a hot engine
'cold start' - for a cold engine. See Fig. H.
4. The engine may have flooded. Remove and dry the spark plug.
5. Fuel mixture may be incorrect or stale - if so - replace with fresh
mixture.
6. Check that the disc bolt is tight. A loose disc bolt could cause
difficult starting.
7. If the engine will still not start - disconnect the spark plug
lead and consult your local approved Flymo/Partner Service
Centre/Dealer.
Poor Flotation or Lack of Power
1. Disconnect the spark plug lead.
2. Clean the underside of the hood, the air filter, the fan, around the
engine and the air intakes.
3. Check that the engine choke control lever is in the 'normal'
position (Fig. H).
4. Fuel mixture may be incorrect or stale - if so - replace with fresh
mixture.
5. If poor flotation or lack of power persists - disconnect the
spark plug lead and consult your local approved
Flymo/Partner Service Centre/Dealer.
Excessive Vibration
1. Disconnect the spark plug lead.
2. Check that the cutting disc and cutting lines are correctly fitted.
See ' Cutting Line and Height Adjustment'.
3. If the cutting lines or cutting disc are damaged or worn replace
them with a new ones.
4. If vibration persists - do not use - disconnect the spark plug
lead and consult your local approved Flymo/Partner Service
Centre/Dealer.
Service Recommendations
To ensure the maximum life and reliability from your Flymo product
we recommend that it is serviced regularly by an approved
Flymo/Partner Service Centre/Dealer. They have the equipment
facilities and trained personnel to advise you on the service
requirements of your machine. Depending on the machine's use
they will recommend one of the various types of service which are
designed to ensure the maximum economic service life of your
machine.
Certificate of Conformity
Type
Identification of Series
Level
HVT52
See Product Rating
Label
84.5 dB(A)
Type
Identification of Series
Value
HVT52
See Product Rating
Label
5.41 m/s2

5118543-02
Flymo/Partner, a division of Electrolux Outdoor Products Ltd.,
Aycliffe Industrial Estate
NEWTON AYCLIFFE
Co.Durham DL5 6UP
ENGLAND
Telephone - (00) 44 1325 300303 Fax - (00) 44 1325 310339
UK Telephone - 01325 300303 Fax - 01325 310339
Our policy of continuous improvement means that the specification of products may be altered from time to time
without prior notice. Flymo/Partner, a division of Electrolux Outdoor Products Ltd. manufacture products for a
number of well known brands under various registered patents, designs and trademarks in several countries.
© Electrolux Outdoor Products Ltd. Registered Office, Electrolux Works, Oakley Road, Luton LU4 9QQ
Registered number 974979 England
