Genie Z45/25J User manual

Self-PropelledServicingPlatform PartNo.114047
Operator's Manual Second Edition · Fifth Printing
Copyright © 2003 by Genie Industries
Second Edition: Fifth Printing, December 2012
"Genie" and "Z" are registered trademarks of
Genie Industries in the U.S.A. and many other
countries.
These machines comply with
ANSI/SIA 92.5-1992.
Printed on recycled paper
Printed in U.S.A.
NOTICE: CONTROLLED DOCUMENT.
ANY CHANGES MUST BE APPROVED BY
FACTORY MUTUAL RESEARCH
CORPORATION.
Important
Read,understandandobey thesesafety rulesand
operating instructions before operating this machine.
Only trained and authorized personnel shall be
permitted to operate this machine. This manual should
be considered a permanent part of your machine and
should remain with the machine at all times. If you
have any questions, call Genie Industries.
Contents
Page
SafeOperationinHazardousLocations ..................... 1
Safety Rules .............................................................. 2
Controls .................................................................... 10
Pre-operationInspection ........................................... 13
Maintenance ............................................................. 15
Function Tests.......................................................... 17
WorkplaceInspection................................................ 22
OperatingInstructions............................................... 23
TransportandLifting Instructions .............................. 31
Decals ...................................................................... 34
Specifications ........................................................... 36
Contact us:
Internet:http://www.genielift.com
E-mail:[email protected]

PartNo.114047 Self-PropelledServicingPlatform 1
Operator's ManualSecond Edition • Fifth Printing
Operating the Machine in
Hazardous Locations
Read,understandandobeythefollowing
instructions before entering a Class 1, Division 2,
GroupDhazardouslocation:
1 If the engine is running, turn off the engine.
2 Allow the engine to cool down until the
thermometerreadsbelow348°F.
3 Locatetheengine and chargerswitches.
4 Move the switches to the off position and lock.
5 Lock all 3 AC plug covers.
6 Be sure the lanyards on the battery disconnect
plugs are in place and secured.
7 Be sure the engine side chassis cover is latched
andlocked.
8 Be sure the plate in the back of the battery box
is in place to prevent battery movement.
Safe Operation in Hazardous Locations
Danger
Failure to obey the instructions and
safety rules in this manual will result
in death or serious injury.
This machine may be operated
in a Class 1, Division 2, Group D
hazardous location only if the
following safety rules and
requirements are strictly
followed.
Detailed definitions of a Class 1, Division 2
HazardousEnvironment canbe foundin NFPA505,
and NFPA 70.
Definitions for Hanger and Aircraft Class 1, Division
2 Hazardous Environments can be found in NFPA
70 Section 513.3 and are as follows:
Areas Not Cut Off or Ventilated. Theentire area of
thehangar,includinganyadjacentand
communicating areas not suitably cut off from the
hangar, shall be classified as a Class I, Division 2
or Zone 2 location up to a level 450 mm (18 in)
abovethe floor.
Vicinity of Aircraft. The area within 1.5 m (5 ft)
horizontallyfrom aircraftpower plantsor aircraft
fuel tanks shall be classified as a Class I, Division
2 or Zone 2 location that shall extend upward from
the floor to a level 1.5 m (5 ft) above the upper
surface of wings and of engine enclosures.
Onlytrainedandauthorizedpersonnelshallbe
permittedto operatethis machine inhazardous
locations.
Donot enterhazardous locationsunless theengine
and charger switches are off.
Do not enter hazardous locations unless the
thermometerreadsbelow348°F.
Do not operate the engine while the machine is in
hazardouslocations.
Do not charge the batteries in hazardous locations.
Do not remove the red AC plug covers in hazardous
locations.
Do not disconnect the battery pack plugs in
hazardouslocations.
Do not open the covers in hazardous locations.
Donot perform maintenanceor repairsonthis
machineinhazardouslocations.

2 Self-PropelledServicingPlatform PartNo.114047
Operator's Manual Second Edition • Fifth Printing
Safety Rules
Danger
Failure to obey the instructions and
safety rules in this manual will result
in death or serious injury.
Do Not Operate Unless:
You learn and practice the principles of safe
machineoperationcontainedinthisoperator's
manual.
1 Avoidhazardoussituations.
Knowandunderstandthesafetyrulesbefore
going on to the next section.
2 Alwaysperformapre-operationinspection.
3 Always perform function tests prior to use.
4 Inspect the workplace.
5 Only use the machine as it was intended.
Youread,understandandobeythe
manufacturer'sinstructionsand safetyrules—
safetyandoperator'smanualsandmachine
decals.
Youread,understandandobeyemployer's
safety rules and worksite regulations.
Youread,understandandobeyallapplicable
governmentalregulations.
Youare properlytrained tosafely operate the
machine.

PartNo.114047 Self-PropelledServicingPlatform 3
Operator's ManualSecond Edition • Fifth Printing
SAFETY RULES
Electrocution Hazards
This machine is not electrically insulated and will
not provide protection from contact with or
proximity to electrical current.
Maintain safe distances from electrical power lines
andapparatusinaccordancewithapplicable
governmentalregulationsandthefollowingchart.
Voltage Minimum Safe
Phase to Phase ApproachDistance
Feet Meters
0 to 300V Avoid Contact
300V to 50KV 10 3.1
50KV to 200KV 15 4.6
200KV to 350KV 20 6.1
350KV to 500KV 25 7.6
500KV to 750KV 35 10.7
750KV to 1000KV 45 13.7
Allow for platform movement, electrical line sway or
sag and beware of strong or gusty winds.
Keep away from the machine if it contacts
energizedpowerlines.Personnelonthegroundor
in the platform must not touch or operate the
machine until energized power lines are shut off.
Donotoperatethemachineduringlightningor
storms.
Do not use the machine as a ground for welding.
Tip-over Hazards
Occupants,equipment and materialsshall not
exceed the maximum platform capacity or the
maximum capacity of the auxiliary platform (if
equipped).Weight inthe auxiliaryplatform (if
equipped) is part of the total platform load.
Maximum capacity
Main platform without
auxiliary platform 500 lbs 227 kg
Main platform with auxiliary
platform unoccupied 500 lbs 227 kg
Auxiliary platform 300 lbs 136 kg
Maximum occupants
Main platform without auxiliary platform 2
Main platform with auxiliary platform stowed 2
Main platform with auxiliary platform occupied 1
Auxiliary platform 1
The weight of options and accessories, such as
pipecradles,panel cradlesandwelders,will reduce
the rated platform capacity and must be factored
into the total platform load. See the decals on the
options.
Do not raise or extend the boom unless the
machine is on a firm, level surface.
Do not depend on the tilt alarm as a level indicator.
The tilt alarm sounds in the platform only when the
machine is on a severe slope.

4 Self-PropelledServicingPlatform PartNo.114047
Operator's Manual Second Edition • Fifth Printing
SAFETY RULES
If the tilt alarm sounds:
Do not extend, rotate or raise the boom above
horizontal. Move the machine to a firm, level
surface before raising the platform. If the tilt alarm
sounds when the platform is raised, use extreme
caution to retract the boom and lower the platform.
Donot rotate theboom while lowering.Move the
machine to a firm, level surface before raising the
platform.
Do not use the platform controls to free a platform
thatiscaught, snaggedorotherwise prevented
from normal motion by an adjacent structure. All
personnelmust beremoved from theplatform
before attempting to free the platform using the
groundcontrols.
Do not raise the boom when wind speeds may
exceed 28 mph / 12.5 m/s. If wind speeds exceed
28 mph / 12.5 m/s when the boom is raised, lower
the boom and do not continue to operate the
machine.
Do not operate the machine in strong or gusty
winds. Do not increase the surface area of the
platform or the load. Increasing the area exposed to
the wind will decrease machine stability.
Use extreme care and slow speeds while driving
the machine in the stowed position across uneven
terrain,debris, unstableor slippery surfaces and
nearholesanddrop-offs.
Do not alter or disable the limit switches.
Do not use air-filled tires. These machines are
equippedwithfoam-filledtires.Wheelweightand
propercounterweightconfigurationarecriticalto
stability.
Donot drivethe machine on or nearuneven terrain,
unstablesurfacesorotherhazardousconditions
withthe boomraised orextended.
Do not drive the machine on a slope that exceeds
the maximum uphill, downhill or side slope rating of
the machine. Slope rating applies only to machines
in the stowed position.
Maximum slope rating, stowed position
Platform downhill 30% (17°)
Platform uphill 20% (11°)
Side slope 25% (14°)
Note: Slope rating is subject to ground conditions
andadequatetraction.
Do not push off or pull
towardanyobject
outside of the platform.
Maximum allowable
side force - ANSI & CSA
150 lbs / 667 N
Do not alter or disable machine components that in
any way affect safety and stability.
Do not replace items critical to machine stability
with items of different weight or specification.
Do not modify or alter an aerial work platform
withoutpriorwrittenpermission from the
manufacturer.Mountingattachmentsforholding
toolsor other materialsonto the platform,toeboards
or guard rail system can increase the weight in the
platform and the surface area of the platform or the
load.

PartNo.114047 Self-PropelledServicingPlatform 5
Operator's ManualSecond Edition • Fifth Printing
SAFETY RULES
Do not place or attach fixed or overhanging loads to
any part of this machine.
Do not place ladders or scaffolds in the platform or
against any part of this machine.
Do not use the machine on a moving or mobile
surface or vehicle.
Do not transport tools and materials unless they are
evenly distributed and can be safely handled by
person(s)intheplatform.
Be sure all tires are in good condition and lug nuts
areproperlytightened.
Do not use batteries that weigh less than the
originalequipment.Batteries areusedas
counterweight and are critical to machine stability.
Each battery must weigh 105 pounds / 47.6 kg.
Each battery box including batteries must weigh a
minimum of 530 pounds / 240.4 kg.
Fall Hazards
Occupants must wear a
safety belt or harness in
accordancewith
governmentalregulations.
Attach the lanyard to the
anchorprovidedinthe
platform.
Do not sit, stand or climb on the platform guard
rails. Maintain a firm footing on the platform floor at
all times.
Do not climb down from the platform when raised.
Keep the platform floor clear of debris.
Lowertheplatformentrymid-railbeforeoperating.

6 Self-PropelledServicingPlatform PartNo.114047
Operator's Manual Second Edition • Fifth Printing
Collision Hazards
Be aware of limited sight
distance and blind spots
whendrivingoroperating.
Beaware of theboom position whenrotating the
turntable.
Operators must comply with employer, job site and
governmentalrulesregardingtheuseofpersonal
protectiveequipment.
Checkthe work areafor overheadobstructionsor
otherpossiblehazards.
Beawareofcrushinghazardswhengraspingthe
platformguardrail.
Observeandusecolor-codeddirectionarrowson
the platform controls and drive chassis for drive
and steer functions.
Do not lower the boom unless the area below is
clearofpersonnel andobstructions.
Limit travel speed according to the condition of the
ground surface, congestion, slope, location of
personnel, and any other factors which may cause
collision.
Do not operate a boom in the path of any crane
unless the controls of the crane have been locked
outand/or precautionshavebeen takento prevent
any potential collision.
Nostunt driving orhorseplay whileoperatinga
machine.
Do not operate any of the machine controls when
the auxiliary platform is occupied.
Bodily Injury Hazard
Do not operate the machine with a hydraulic oil or
air leak. An air leak or hydraulic leak can penetrate
and/orburnskin.
Whentheengine isrunning,operate themachinein
awell-ventilatedareatoavoidcarbonmonoxide
poisoning.
Impropercontactwith componentsunderany cover
will cause serious injury. Only trained maintenance
personnel should access compartments. Access
by the operator is only advised when performing a
pre-operationinspection.Allcompartmentsmust
remainclosedandsecuredduringoperation.
Component Damage Hazards
Do not use any battery or charger greater than 12V
tojump-start theengine.
Do not use the machine as a ground for welding.
Do not stand on Aircraft Protection Package.
Damagetoequipment orinjuryto personnelmay
occur.
SAFETY RULES

PartNo.114047 Self-PropelledServicingPlatform 7
Operator's ManualSecond Edition • Fifth Printing
SAFETY RULES
Explosion and Fire Hazards
Do not charge the batteries in hazardous locations.
Do not operate the engine while the machine is in
hazardouslocations.
Do not start the engine if you smell or detect liquid
petroleumgas (LPG),gasoline, diesel fuelor other
explosive substances.
Donot refuelthe machine withthe enginerunning.
Refuel the machine and charge the battery only in
anopen,well-ventilated areaawayfromsparks,
flames and lighted tobacco.
Donotspray etherintoengines equippedwithglow
plugs.
Damaged Machine Hazards
Donot usea damaged ormalfunctioning machine.
Conductathoroughpre-operationinspectionofthe
machine and test all functions before each work
shift. Immediately tag and remove from service a
damaged or malfunctioning machine.
Be sure all maintenance has been performed as
specified in this manual and the appropriate service
manual.
Be sure all decals are in place and legible.
Be sure the operator’s, safety and responsibilities
manualsare complete, legible and inthe storage
containerlocated onthe platform.
Auxiliary Platform Safety
(if equipped)
Do not raise or stow the auxiliary platform unless
the boom and main platform are in the fully stowed
position.
Do not enter the auxiliary platform unless it is
completely raised and all retaining pins are in place.
Do not sit, stand or climb on the auxiliary platform
guardrails. Do notlean throughorover theguard
rails to work.
Do not operate any of the
machinecontrolswhenthe
auxiliary platform is
occupied.
Occupants must wear a
safety belt or harness in
accordancewith
governmentalregulations. Attachthe lanyardto the
anchorprovidedintheplatform.

8 Self-PropelledServicingPlatform PartNo.114047
Operator's Manual Second Edition • Fifth Printing
Battery Safety
Burn Hazards
Batteries contain acid. Always wear protective
clothingandeyewearwhen working withbatteries.
Avoid spilling or contacting battery acid. Neutralize
battery acid spills with baking soda and water.
The battery pack must remain in an upright
position.
Do not expose the batteries or the charger to water
orrain.
Explosion Hazards
Do not charge the batteries in hazardous locations.
Do not operate the engine while the machine is in
hazardouslocations.
Keep sparks, flames and
lightedtobaccoaway
from batteries. Batteries
emit an explosive gas.
The battery pack cover
mustremain off during
the entire charging cycle.
Do not contact the
battery terminals or the
cable clamps with tools
that may cause sparks.
Component Damage Hazards
Do not use any battery charger greater than 48V to
chargethebatteries.
Both battery packs must be charged together.
Disconnect the lanyard and the battery pack plug
beforeremoving the battery pack.
Electrocution Hazards
Connect the battery charger to a
grounded,AC3-wireelectrical
outlet only.
Inspect daily for damaged cord,
cablesandwires.Replace
damageditemsbefore
operating.
Avoid electrical shock from contact with battery
terminals. Remove all rings, watches and other
jewelry.
Tip-over Hazard
Do not use batteries that weigh less than the
originalequipment.Batteries areusedas
counterweight and are critical to machine stability.
Each battery must weigh 105 pounds / 47.6 kg.
Each battery box including batteries must weigh a
minimum of 530 pounds / 240.4 kg.
Lifting Hazard
Use a forklift to remove or install the battery packs.
SAFETY RULES

PartNo.114047 Self-PropelledServicingPlatform 9
Operator's ManualSecond Edition • Fifth Printing
Decal Legend
Genie product decals use symbols, color coding
and signal words to identify the following:
Safety alert symbol—used to alert
personneltopotentialpersonal
injury hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Red—usedtoindicatethe
presence of an imminently
hazardous situation which, if not
avoided, will result in death or
seriousinjury.
Orange—usedtoindicatethe
presence of a potentially
hazardous situation which, if not
avoided, could result in death or
seriousinjury.
Yellow with safety alert symbol—
used to indicate the presence of a
potentiallyhazardoussituation
which, if not avoided, may cause
minorormoderateinjury.
Yellow without safety alert
symbol—used to indicate the
presence of a potentially
hazardous situation which, if not
avoided, may result in property
damage.
Green—usedtoindicateoperation
ormaintenanceinformation.
SAFETY RULES

10 Self-PropelledServicingPlatform PartNo.114047
Operator's Manual Second Edition • Fifth Printing
13
7 Platform level switch
8 Functionoverrideswitch
9 Glowplug switch
10 Engine start switch
11 Engine idle (rpm) select switch
PlatformControlPanel
1 Hornbutton
2 Auxiliarypower switch
3 Driveenableindicatorlight
4 Driveenableswitch
5 Jibboom up/downswitch
6 Platform rotate switch
2
Controls
56 7
181921
4
2022

PartNo.114047 Self-PropelledServicingPlatform 11
Operator's ManualSecond Edition • Fifth Printing
CONTROLS
· Rabbit & Foot Switch: foot switch activated
highidle
· Turtle:low idle
· Rabbit:high idle andquickest battery charging
12 Drive lights switch
13 Machine not level indicator light
14 RedEmergencyStopbutton
15 Proportionalcontrolhandlefordrivefunctionand
thumb rocker for steer function
810 11
1516
912 13 14
17
16 Boomfunctionspeedcontroller
17 Primaryboom extend/retract switch
18 Primaryboomup/downswitch
19 Secondaryboomup/downswitch
20 Turntablerotate left/right switch
21 Beacons switch
22 Batterychargeindicator

12 Self-PropelledServicingPlatform PartNo.114047
Operator's Manual Second Edition • Fifth Printing
6
9
7
2
1
4
3
10
11
12
1314151617
GroundControlPanel
1 Platform rotate switch
2 Turntablerotateswitch
3 Primaryboom extend/retract switch
4 Primaryboomup/downswitch
5 Engine idle (rpm) select switch
· turtle: low idle
· rabbit: high idle and quickest battery
charging
6 Auxiliarypower switch
7 Thermometer
8 Key switch for platform/off/ground selection
9 RedEmergencyStopbutton
10 Hourmeter
11 Glowplug switch
12 Functionenableswitch
13 Engine start switch
14 Secondaryboomup/downswitch
15 10A breaker for control electrical circuits
16 Jibboom up/downswitch
17 Platform level switch
5
CONTROLS
8

PartNo.114047 Self-PropelledServicingPlatform 13
Operator's ManualSecond Edition • Fifth Printing
Pre-operation Inspection
Do Not Operate Unless:
You learn and practice the principles of safe
machine operation contained in this operator's
manual.
1 Avoid hazardous situations.
2 Always perform a pre-operation
inspection.
Knowandunderstandthepre-operation
inspection before going on to the next
section.
3 Always perform function tests prior to use.
4 Inspect the workplace.
5 Only use the machine as it was intended.
Fundamentals
It is the responsibility of the operator to perform a
pre-operationinspectionandroutinemaintenance.
Thepre-operation inspection is a visualinspection
performed by the operator prior to each work shift.
The inspection is designed to discover if anything
is apparently wrong with a machine before the
operator performs the function tests.
Thepre-operationinspectionalsoservesto
determine if routine maintenance procedures are
required. Only routine maintenance items specified
in this manual may be performed by the operator.
Refer to the list on the next page and check each
of the items.
Ifdamageor any unauthorizedvariationfrom
factory delivered condition is discovered, the
machinemust betaggedand removedfrom
service.
Repairs to the machine may only be made by a
qualified service technician, according to the
manufacturer's specifications. After repairs are
completed, the operator must perform a
pre-operation inspection again before going on to
the function tests.
Scheduled maintenance inspections shall be
performed by qualified service technicians,
according to the manufacturer's specifications and
the requirements listed in the responsibilities
manual.

14 Self-PropelledServicingPlatform PartNo.114047
Operator's Manual Second Edition • Fifth Printing
PRE-OPERATIONINSPECTION
Pre-operation Inspection
RBe sure that the operator's, safety and
responsibilities manuals are complete, legible
and in the storage container located on the
platform.
RBe sure that all decals are legible and in place.
See Decals section.
RCheck for engine oil leaks and proper fluid level.
Add oil if needed. See Maintenance section.
RCheck for engine coolant leaks and proper fluid
level. Add coolant if needed. See Maintenance
section.
RCheck for hydraulic oil leaks and proper oil
level. Add oil if needed. See Maintenance
section.
RCheck for battery fluid leaks and proper fluid
level. Add distilled water if needed. See
Maintenancesection.
Checkthe followingcomponents orareas for
damage,improperly installed ormissing parts and
unauthorizedmodifications:
RElectricalcomponents, wiringand electrical
cables
RHydraulicpowerunit,hoses,
fittings, cylinders and manifolds
REngine,beltsandrelatedcomponents
RFuel and hydraulic tanks
RDriveandturntablemotorsandtorquehubs
RBoomwearpads
RTiresandwheels
REngineandrelatedcomponents
RLimit switches, alarms and horn
RNuts, bolts and other fasteners
RPlatformentrymid-rail
RBeaconandalarms
RAuxiliaryplatformcomponents
RAircraftprotectionpackagecomponents
Checkentire machinefor:
RCracks in welds or structural components
RDentsordamage tomachine
RBe sure that all structural and other critical
components are present and all associated
fasteners and pins are in place and properly
tightened.
RAfter you complete your inspection, be sure that
all compartment covers are in place and
secured.

PartNo.114047 Self-PropelledServicingPlatform 15
Operator's ManualSecond Edition • Fifth Printing
Check the Batteries
Proper battery condition is essential to good
machineperformanceandoperationalsafety.
Improperfluidlevels ordamagedcables and
connectionscan result incomponent damage and
hazardousconditions.
Bodily injury hazard. Batteries
contain acid. Avoid spilling or
contacting battery acid. Neutralize
battery acid spills with baking soda
andwater.
Explosionhazard.Donot charge
thebatteriesinhazardous
locations.
Explosionhazard.Donotoperate
the engine while the machine is in
hazardouslocations.
Chargingthebatterieswiththe
engine does not fully charge the
batteries. Periodically, use the AC
battery charger to fully charge the
batteries.
Perform this test after fully
charging the batteries.
1 Put on protective clothing and eye wear.
2 Be sure that the battery cable connections are
tight and free of corrosion.
3 Remove the battery vent caps.
4 Check the battery acid level. If needed,
replenish with distilled water to the bottom of
the battery fill tube. Do not overfill.
5 Install the vent caps.
Maintenance
Observe and Obey:
Only routine maintenance items specified in this
manual shall be performed by the operator.
Scheduled maintenance inspections shall be
completed by qualified service technicians,
according to the manufacturer's specifications
and the requirements specified in the
responsibilitiesmanual.
Maintenance Symbols Legend
The following symbols have been
used in this manual to help
communicate the intent of the
instructions. When one or more of
the symbols appear at the
beginning of a maintenance
procedure, it conveys the meaning
below.
Indicates that tools will be required to
perform this procedure.
Indicates that new parts will be required to
perform this procedure.

16 Self-PropelledServicingPlatform PartNo.114047
Operator's Manual Second Edition • Fifth Printing
MAINTENANCE
Check the Engine Oil Level
Maintaining the proper engine oil level is essential
to good engine performance and service life.
Operating the machine with an improper oil level
can damage engine components.
Check the oil level with the
engine off.
1 Check the oil level dipstick. Add oil as needed.
Result: The oil level should be at the FULL mark
on the dipstick.
Kubota Engine Z482-E
Oil viscosity requirements 10W-30
Engine oil should have properties of API classification
CC/SE, CD/SE, CC/SF or CD/SF grades. Units ship
with 10W-40 SG/CC
Check the Engine Coolant Level
Maintaining the engine coolant at the proper level is
essential to engine service life. Improper coolant
level will affect the engine's cooling capability and
damage engine components. Daily checks will
allow the inspector to identify changes in coolant
level that might indicate cooling system problems.
1 Check the fluid level in the coolant recovery
tank. Add fluid as needed.
Result: The fluid level should be at the
FULLmark.
Coolantspecification 50%/50%
water and coolant
Check the Hydraulic Oil Level
Maintaining the hydraulic oil at the proper level is
essential to machine operation. Improper hydraulic
oil levels can damage hydraulic components. Daily
checks allow the inspector to identify changes in oil
level that might indicate the presence of hydraulic
system problems.
1 Be sure the boom is in the stowed position, then
visually inspect the oil level in the hydraulic
tank.
Result: The hydraulic oil level should be within
the FULL and ADD marks on the hydraulic tank.
Hydraulic oil specifications
Hydraulic oil type Mil-5606H
Mil-83282D
Scheduled Maintenance
The scheduled maintenance items must be
completed by a person trained and qualified to
perform maintenance on this machine according to
the procedures found in the service manual for this
machine.
Machines that have been out of service for more
than three months must receive the quarterly
inspection before placing the machine back into
service.

PartNo.114047 Self-PropelledServicingPlatform 17
Operator's ManualSecond Edition • Fifth Printing
Function Tests
Fundamentals
The function tests are designed to discover any
malfunctions before the machine is put into
service. The operator must follow the step-by-step
instructions to test all machine functions.
A malfunctioning machine must never be used. If
malfunctions are discovered, the machine must be
tagged and removed from service. Repairs to the
machine may only be made by a qualified service
technician, according to the manufacturer's
specifications.
After repairs are completed, the operator must
perform a pre-operation inspection and function
tests again before putting the machine into service.
Do Not Operate Unless:
You learn and practice the principles of safe
machine operation contained in this operator's
manual.
1 Avoid hazardous situations.
2 Always perform a pre-operation
inspection.
3 Always perform function tests prior to
use.
Knowandunderstandthefunctiontests
before going on to the next section.
4 Inspect the workplace.
5 Only use the machine as it was intended.

18 Self-PropelledServicingPlatform PartNo.114047
Operator's Manual Second Edition • Fifth Printing
FUNCTIONTESTS
14 Hold the function enable switch to either side
and activate each boom and platform function
toggle switch.
Result: All boom and platform functions should
operate through a full cycle. The alarm should
sound while any function is operating.
Test the Tilt Sensor
15 Turn the key switch to platform control. Pull out
the platform red Emergency Stop button to the
onposition.
16 Opentheengineside
turntablecoverandlocate
the tilt sensor to the right of
theengine.
17 Press down one side of the
tilt sensor and hold for 5
seconds.
Result: The alarm, located
in the platform, should
sound.
TestAuxiliaryControls
18 Turn the key switch to ground control.
19 Pull out the red Emergency Stop button to the
onposition.
20 Simultaneouslyhold theauxiliary
power switch on and activate
eachboomfunctiontoggle
switch.
Note: To conserve battery power, test each
function through a partial cycle.
Result: All boom functions should operate.
1 Select a test area that is firm, level and free of
obstruction.
At the Ground Controls
2 Turn the key switch to ground control.
3 Pull out the red Emergency Stop button to
the on position.
4 Startthe engine. SeeOperating Instructions
section.
TestEmergencyStop
5 Push in the red Emergency Stop button to the
off position.
Result: The engine should turn off and all
functionsshouldnot operate.
6 Pull out the red Emergency Stop button to
the on position.
TestThermometer
7 Startthe engine.
8 Checkthe thermometeron the controlpanel.
Result:Thetemperatureshouldrise.
9 Push in the red Emergency Stop button to turn
off the engine.
TesttheEngineLock-out Switch
10 Move the engine lock-out switch to the off
position.
11 Push the engine start button.
Result: The engine should not start.
12 Move the engine lock-out switch to the on
position.
TesttheMachineFunctions
13 Do not hold thefunction enable
switch to either side. Attempt to
activate each boom and platform
function toggle switch.
Result: All boom and platform functions should
notoperate.
