Grundig GML-1730M User manual

GML-1730M.23.1.10.01.2013
Owner's Manual
EN
© ASP AG
Monitors
GML-1730M 43 cm (17") LCD/TFT Monitor LED Backlight
GML-1930M 48 cm (19") LCD/TFT Monitor LED Backlight
GML-1931M 48 cm (19") LCD/TFT Monitor LED Backlight

Content:
1. Important Safety Instructions 1
2. Installation 2
3. Package Contents 3
4. Rear View with Connections 3
5. Turning the Monitor Off/On 4
6. Switching the Monitor Source 4
7. OSD Menu Configurations 4
1. Picture Menu 5
2. Sound Menu 6
3. Setting Menu 6
4. PIP/POP Setup Menu 7
8. Frequently Asked Questions 8
1. Important Safety Instructions
Do not insert sharp objects or spill liquid into the monitor through the ventilation holes.
This may cause fire, electric shock or failure.
Do not attempt to service this product yourself, as opening or removing covers may
expose you to dangerous voltage potentials or other risks.
When you transport this monitor for repair or shipment, use the original carton and
packing materials.
Do not rub, touch, or tap the surface of the screen with sharp or abrasive items such as
a pen or screwdriver. This could scratch the display.
The LED monitor's plastic casing and LED panel can be cleaned with a soft, lint-free
cloth. Never use scrub pads or other cleaning materials with abrasive surfaces to clean
your LED monitor!
A. A slightly damp cloth may be used to clean the display of fingerprints or smudges.
B. For the plastic case, a mild detergent may be used to clean the surface. However,
you should ensure not to use too much detergent or water as this could leak into the
interior of the casing.
1
English

Do NOT use cleaning fluids based on alcohol, methylated spirit or ammonia. The glass
plate has a hard surface coating to prevent scratches. However, the use of strong
chemical cleaning agents may damage this coating. Use only a mild soap or detergent
and water or specially formulated cleaners made for cleaning glass panels.
Avoid direct contact with water or other liquids. Never use the LED monitor in or around
areas where water may pose a potential hazard to normal operation.
Use the LED monitor only indoors, and avoid the contact with oil, vapor, steam, moisture
and dust. The LED monitor should be used in a clean environment with low humidity.
Do not touch the screen directly with your fingers. You may damage the screen, and it is
difficult to remove skin oil from the monitor.
Do not apply pressure to the screen. The LED display is very delicate.
WARNING: Any unauthorised modification of this equipment could result in the
revocation of the authorisation to operate the equipment and void the product warranty.
2. Installation
Do not install the monitor near heat sources such as radiators or air ducts, or in a place
subject to direct sunlight, excessive dust, mechanical vibration or shock.
Do not cover or block the ventilation holes in the case.
Place the monitor on a flat and leveled surface.
Do not remove any of the prongs of the monitor’s three-pronged power plug.
Use an appropriate power cord for your local power supply.
Do not allow anything to rest on the power cord.
Do not locate this product where persons will walk on the cord.
Connect the power supply to the socket and plug the video cable or VGA cable to the
desired signal source.
Use the proper power cord with a correct attachment plug type. If the power source is
120 V AC, use a power cord that has UL and C-UL approvals. If the power source is a
240 V AC supply, use the tandem (T blade) type attachment plug with a ground
conductor power cord that meets the respective European country’s safety regulations,
such as VDE for Germany.
Do not overload wall outlets and extension cords as this can result in a risk of fire or
electric shock.
Ensure that the total ampere rating of all units plugged into the extension cord is not
over the cord’s rating.
2English

If the power supply cord, that came with your monitor, is to be connected to the PC
instead of the wall outlet, this equipment is to be used with UL/TUV approved
computers with receptacle rated 100-240 V AC, 50/60 Hz, 2.0 A (minimum).
Check the monitor specification carefully. This GRUNDIG monitor has a 1280 x 1024
resolution and works with both PAL and NTSC signal modes. This GRUNDIG monitor is
for 24/7 security purposes; therefore, the environmental specifications such as the
operating temperature and the voltage needed have to be maintained at all times.
3. Package Contents
These parts are included:
- LED Monitor
- 12V DC Adapter
- Power Cord
- D-Sub 15-pin VGA Connector Cable
- Remote Control with Battery (CR2025 3V)
- Owner’s Manual
4. Rear View with Connections
Up to 16 zone titles can be set with a maximum of 20 characters for each title.
Follow the steps below to set a camera title.
DC: Connect the 12V power adapter that is included in the package.
HDMI (High Definition Multimedia Input): Here you can connect a monitor with a HDMI
cable (the cable is not included in the package).
NOTE: HDMI includes not only the image transfer but also the ability to transmit audio.
VGA: Connect the monitor with the VGA cable that is included in the package.
PC Audio: Please use the 3.5 mm jack to transmit audio signals for VGA mode.
AV Audio: Please use the RCA plugs to transmit audio signals for AV1 or AV2 mode.
AV1 Input: Connect a video source with coaxial cable (with Composite Video Signal) to
the BNC connector for AV1 mode.
AV1 Output: Here you can pick off the signal of the AV1 input and make it available for
other devices. If no cable connected, the monitor automatically sets a 75 Ωresistance.
3
English

AV2 Input: Connect a video source with coaxial cable (with Composite Video Signal) to
the BNC connector for AV2 mode.
AV2 Output: Here you can pick off the signal of the AV1 input and make it available for
other devices. If no cable is connected, the monitor automatically sets a 75 Ωresistance.
PLEASE NOTE:
The audio inputs only work if the appropriate video mode is enabled. (PC Audio - VGA /
AV Audio - AV1 or AV2). In PIP or POP mode, you can choose which of the two audio
sources will be played.
5. Turning the Monitor Off/On
PLEASE NOTE:
After pressing the “Power” button, it will take approximately 6 sec. until the monitor is
ready and the display is visible.
These are the various power states of the LED monitor represented by the different LED
colours on the POWER button:
BLUE: On
RED: Standby
BLANK: Off or No power supply
6. Switching the Monitor Source
- Press the "A" button to make the source menu visible.
- Press "+ / -" to choose the source from the modes “VGA”, “HDMI", “AV1”, “AV2”.
- Press "A" again to apply the selected source.
7. OSD Menu Configurations
- Press the "M" button to see the menu.
- Press "+ / -" to switch between the four menus.
- After having selected a menu, press "A" to select a menu item. Press "+ / -" to adjust
the settings of this item.
- To go to another menu, press the "M" button again and go with the "+ / -" buttons to the
desired menu. Press "A" again to select a menu item and press "+ / -" to adjust the
settings of this item.
4English

7.1. Picture Menu
AV1 / AV2 Mode VGA / HDMI Mode
Picture Mode:
Press - or + to select the picture mode ("User, Standard, Movie, Vivid").
Contrast:
This is used to set the brightness of the screen. Press - or + to adjust the parameter.
Brightness:
This is used to adjust the image contrast. Press - or + to adjust the parameter.
Hue:
This is used to adjust the image hue. Press – or + to adjust the parameter.
Saturation:
This is used to adjust the image saturation. Press – or + to adjust the parameter.
Sharpness:
Adjust the sharpness. It makes the image become soft. Press – or + to adjust the
parameter.
Colour Temp.:
In AV1 or AV2 mode, press – or + to adjust the colour tones (“Cool, Warm, Normal").
In VGA and HDMI mode, a sub-menu will appear when you press - or + to select
<Colour Temp.>. In this sub-menu it is possible to adjust the colour tones (“Cool, Warm,
Standard, SRGB, User"). When you select <User>, it is possible to set user defined
Red/Green/Blue values (R/G/B).
DNR:
Press – or + to adjust the noise reduction (“High, Low, Off, Mid“).
Auto Adjust:
In VGA mode it is possible to select this item to perform an automatic adjustment of the
image.
5
English

7.2. Sound Menu
Volume:
Press – or + to adjust the volume level.
Mute:
Press – or + to turn the sound “Off, On”.
7.3. Setting Menu
VGA Mode AV1 / AV2 / HDMI Mode
Language:
Press – or + to select the language.
H Position:
Move the display picture to the left or right. Press – or + to adjust the parameter.
H Zoom:
Adjust the H-size of the display picture. Press – or + to adjust the parameter.
V Position:
Move the display picture up or down. Press – or + to adjust the parameter.
V Zoom:
Adjust the V-size of the display picture. Press – or + to adjust the parameter.
6English

Pixel Clock:
Press – or + to adjust the parameter.
Phase:
Press – or + to adjust the parameter.
Scale Mode:
Adjust the V-size of the display picture. Press – or + to set it the V-size to “Full” or “16:9”.
Reset:
Press – or + to recall the default settings.
NOTE:
The “Pixel Clock” and “Phase” setting is only available in VGA Mode.
7.4. PIP/POP Setup Menu
Multi Window:
Press – or + to select “PIP, POP, Off” mode.
Sub Source:
Press – or + to select “AV1, AV2" in VGA
and HDMI mode or "HDMI, VGA" in AV1
and AV2 mode.
Size:
Adjust the size of the Sub Source window.
Press – or + to select “Large”, “Small” or
“Mid”.
Position:
Move the position of the Sub Source window. Press – or + to select the position (“UR,
BR, UL, BL”).
Border Colour:
Choose the border colour of the Sub Source window. Press – or + to select “Black” or
“Blue” colour.
Sound Source:
Press – or + to select the mode (“Main, Sub”).
7
English

Swap:
Press – or + to to swap the windows of the Main and Sub Source.
NOTE:
1. In PIP / POP mode, AV1 or AV2 and HDMI or VGA can be displayed at the same time
on one monitor.
2. If POP mode is selected, both images are scaled to fit the screen.
8. Frequently Asked Questions
The Power button does not respond:
- Check the power cord to ensure that it is securely plugged into the monitor base and
also into the electrical outlet.
- Ensure that there is electrical power coming from the AC outlet. Use another device to
check the power.
- Unplug the power cord of the monitor from the AC outlet, wait a few minutes, then plug
the power cord into the AC outlet again. This will reset the monitor and power supply.
No image on the screen:
- Ensure that the DB-15 signal cable is properly connected to the display card/computer.
- Check the DB-15 signal cable connector on both ends for bent or pushed-in pins.
- The display card should be properly seated in its card slot.
- Ensure that the computer's power switch is ON.
- Ensure that the monitor's power switch is ON.
- Unplug the power cord of the monitor from the AC outlet, wait a few minutes, then plug
the power cord into the AC outlet again. This will reset the monitor and power supply.
The Power LED is red (with no image on the screen):
- Check the DB-15 signal cable to ensure that it is properly attached to the graphics
display card.
- Check the DB-15 signal cable on both ends for bent or pushed-in pins.
- Make sure the computer is not in a power-saving mode (move the mouse or press a
key on the keyboard).
8English

No sound coming from the audio speakers:
- The audio cable should be connected to the line-out on the audio card and the line-in
on the monitor. Ensure that the audio cable is properly connected.
- Inspect the audio cable for any apparent damage. Double-check by switching to
another audio cable to see if the audio works.
NOTE: The different video modes have different Audio Inputs. You will only receive here
the sound of the corresponding Inputs (VGA - PC Audio / AV1 and AV2 - AV Input /
HDMI - HDMI).
9
English

Specifications GML-1730M
LCD Panel size 17" Diagonal AM-TFT LED Backlight
Pixels - Total 1280(H) x 1024(V)
Pixel Pitch 0.264 mm(H) x 0.264 mm(V)
Resolution 1280 x 1024 pixel, 650(H) TV Lines
Aspect Ratio 5 : 4
Video Standard PAL/NTSC
Video Inputs 2 CH Composite, BNC, Looped
1 HDMI, 1 CH VGA
Audio Inputs 3 CH (stereo), (1xHDMI, 1xCinch (L/R), 1xTRS Connector)
Brightness 300 cd/m²
Contrast ratio 10.000:1
Number of Colours 16.7 million
Viewing Angle 170°(H) ~ 160°(V)
Response Time 5 ms
Display protection Tempered Glass
Speaker Output 3W (2x1.5W built-in)
PIP On/Off
PBP On/Off
MTBF at 25° C > 100,000 hours
Operating Temperature 0°C ~ +40°C
Humidity 10 ~ 90% no condensation
Storage Temperature -10°C ~ +60°C
Suitable for VESA 75
Supply Voltage 12VDC, (100~240VAC, 50/60Hz)
15 WPower Consumption
3.4 kgWeight
385 x 384 x 165 mmDimensions (wxhxd)
Specifications GML-1930M
LCD Panel size 19" Diagonal AM-TFT LED Backlight
Pixel Pitch 0.294 mm(H) x 0.294 mm(V)
15 WPower Consumption
3.5 kgWeight
424 x 415 x 165 mmDimensions (wxhxd)
Specifications GML-1931M
LCD Panel size 19" Diagonal AM-TFT LED Backlight
Pixel Pitch 0.294 mm(H) x 0.294 mm(V)
10 English

Suitable for VESA 100
15 WPower Consumption
5.41 kgWeight
415.5 x 367 x 72 mmDimensions (wxhxd)
Dimensions
11English

EC Declaration of Conformity
GML-1730M 43 cm (17") LCD/TFT Monitor LED Backlight
GML-1930M 48 cm (19") LCD/TFT Monitor LED Backlight
GML-1931M 48 cm (19") LCD/TFT Monitor LED Backlight
It is hereby certified that the products meet the standards in the following relevant
provisions:
EC EMC Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
Applied harmonised standards and technical specifications:
EN 60950-1: 2006 + A12: 2011
EN 55022: 2010
EN 55024: 2010
EN 61000-3-2: 2006 + A2: 2009
EN 61000-3-3: 2008
Ludwig Bergschneider
CEO
Remscheid, 14.01.2013
ASP AG
Lüttringhauser Str. 9
42897 Remscheid
Germany
12 English
