GSS compact classic STC 4-16 light User manual

Assembly Instruction
STC 4-16 light
Default access data:
192.168.0.120
User: admin
Password: geheim

- 2 - STC 4-16 light
Contents
1 Safety regulations and notes ........................................................................3
2 General information ....................................................................................5
2.1 Packing contents ............................................................................5
2.2 Meaning of the symbols used ..........................................................5
2.3 Technical data ...............................................................................5
2.4 Description ...................................................................................7
Block diagram ...............................................................................7
General ........................................................................................7
3 Assembly ....................................................................................................8
3.1 Installing the device .......................................................................8
3.2 Device overview ............................................................................9
3.3 Potential equalisation (PE) .............................................................10
3.4 Connecting the device ..................................................................10
4 Configuration / Updates ............................................................................11
4.1 Initial configuration ......................................................................11
4.2 Configuration ..............................................................................14
Overview window .......................................................................14
Perform changes .........................................................................15
Number format............................................................................15
Configuration menus ....................................................................16
Input ................................................................................................16
Output .............................................................................................18
Filter ................................................................................................21
System menus ...................................................................................23
Logbook ...........................................................................................23
Notification ......................................................................................24
Network ...........................................................................................26
Security ............................................................................................27
Firmware ..........................................................................................28
- System settings: ...............................................................................28
- Firmware update: ............................................................................29
- Backup: ..........................................................................................30
- Manager: .......................................................................................30
- Reset to factory defaults: ...................................................................30
- System restart: .................................................................................30
- Ping (Network Diagnostic Tool): .........................................................31
User .................................................................................................31
5 Channel and frequency tables ....................................................................32

- 3 - STC 4-16 light
1 safety regulations and notes
• The devices meet the EU directives 2011/65/EU, 2014/30/EU and
2014/35/EU.
• This device is subject to the provisions of protection class I. Operate the
device only to mains sockets with protective conductor connection!
• If the power cord needs to be replaced, only use an OEM power cord.
• The standards EN/DIN EN 50083 resp. IEC/EN/DIN EN 60728 must be
observed, especially concerning equipotential bonding and earthing.
• Observe the relevant country-specific standards, regulations and guidelines
on the installation and operation of antenna systems.
• Before starting installation or service work disconnect the receiving system
from mains.
• Do not perform installation and service work during thunderstorms.
• Assembly, installation and servicing must be carried out by an authorised
electrician.
• For a complete disconnection from the mains, the mains plug must be pulled
out of the mains socket. Ensure that the mains plug can be pulled out without
difficulties.
• The head-end station should only be installed in a room where the permis-
sible ambient temperature range (0 °C … +50 °C ) can be maintained, even
during fluctuations in climatic conditions.
• Make sure there is a minimum space of 10 cm on either side and 50 cm
above and below.
• To avoid too strong interacted heating of the head-end stations it is not
admissible to mount them one upon the other without using thermic precau-
tions (e.g. permanently air recirculation, ventilation, heat deflectors etc.).
• If additional fans are to be used to circulate the air, ensure that the system
will be shut down (disconnected from mains) should any one of the fans fail.
• Install the head-end station
- in a dry, dust-free environment, in such a manner that it is protected from
moisture, fumes, splashing water and dampness
- where it is protected from direct exposure to sunlight
- on a vibration-free wall or floor construction
- not within the immediate vicinity of heat sources
• In case of the formation of condensation wait until the system is completely
dried.
• Ensure that the head-end station is adequately ventilated.
• Do not cover the ventilation openings!
• Do not install the head end in cabinets or recesses which are not ventilated.

- 4 - STC 4-16 light
• Do not place any vessels containing liquids on the head-end station.
• Do not place anything on the head-end station which could initiate fires
(e.g. candles).
• Due to the risk of fires caused by lightning strikes, we recommend that
all mechanical parts (e.g. distributor, equipotential bonding rail, etc.) be
mounted on a non-combustible base. Wood panelling, wooden beams,
plastic covered panels and plastic panels are all examples of combustible
bases.
• Avoid short circuits!
• To ensure electromagnetic compatibility, make sure all connections are tight
and that the covers are screwed on securely.
• No liability is accepted for damage caused by faulty connections or inap-
propriate handling of the device.
• The firmware contains components which are licensed as Open Source
software. The components to which this relates and the respective license
terms can be called up via menu Help/Licences.
This parts of software source code can be provided at cost price on CD
upon request. The licensee is granted a non-exclusive right of use for the
Open Source Software by the respective right holders used; the conditions
stipulated by the respective valid license terms apply. The license terms of
this license only apply to the components which are not listed as Open
Source software.
In relation to the licensor the regulations on liability and warranty in these
license terms apply for the whole software. The liability and warranty regu-
lations of the Open Source licenses only apply in relation to the respective
right holders.
• Test the firmware versions of the device and update them if necessary. The
current firmware version can be found at "www.mygss.eu".
Take action to prevent static discharge when working on the device!
Electronic devices should never be disposed of in the household rubbish. In accordance
with directive 2002/96/EC of the European Parliament and the European Council from
January 27, 2003 which addresses old electronic and electrical devices, such devices
must be disposed of at a designated collection facility. At the end of its service life,
please take your device to one of these public collection facilities for proper disposal.

- 5 - STC 4-16 light
2 general information
2.1 PaCkin g C o nt e n t s
1 STC 4-16 light 1 LAN cable
1 Brief assembly instructions 1 Mains cable
2.2 me a n ing of th e symbol s us e d
Important note
Danger by electrical shock
—> General note
• Performing works
2.3 teChn i C al data
The devices meet the following EU directives:
2011/65/EU, 2014/30/EU, 2014/35/EU
The product fulfils the guidelines and standards for CE labelling (page 33).
Unless otherwise noted all values are specified as "typical".
RF input DVB-S/S2 (ETSI 300 421)
Frequency range: ....................................................... 950 … 2150 MHz
DVB-S modes: ............................................................................... QPSK
DVB-S2 modes: ........................................ QPSK, 8PSK, 16APSK, 32APSK
Symbol rate DVB-S: ............................................ QPSK: 1 … 45 MSymb/s
Symbol rate DVB-S2:
QPSK ................................................................... 4.5 … 45 MSymb/s
8PSK .................................................................... 4.5 … 45 MSymb/s
16APSK ................................................................ 4.5 … 39 MSymb/s
32APSK ................................................................ 4.5 … 32 MSymb/s
Maximum data rate/tuner ......................................................... 83 MBit/s
Level range: ............................................................ 60 dBμV … 80 dBμV
Input impedance: ............................................................................75 Ω
LNC supply total: ........................................................13V; max. 500 mA

- 6 - STC 4-16 light
RF output
Frequency range: ............................................. 42.0 MHz … 868.0 MHz
Channels: ............................................................................ S21 … C69
Types of modulation: ......................................QAM 16, 32, 64, 128, 256
Dynamic phase error: .................................................................... < 0.2°
MER: ............................................................................................45 dB
Symbol rate ................................................................. 1000…7500 kBd
Output level: ......................................................................80…96 dBμV
Output impedance: .........................................................................75 Ω
LAN interface for HTML control/update
Standard: ............................................................................. 100-BASE-T
Connections
SAT inputs: ............................................................................. 4 F sockets
RF output: .............................................................................. 1 F socket
RF test output (-25 dB): ............................................................ 1 F socket
LAN: ................................................................................ 1 RJ 45 socket
General
Mains voltage: .................................................. 100…240V~, 50/60 Hz
Power consumption without LNC supply ...........................................40 W
Maximum Power consumption: ........................................................ 55 W
Admissible ambient temperature: ............................................0 … +50 °C
Dimensions (WxHxD): ............................................... 341 x 282 x 85 mm
Weight: .......................................................................................... 5 kg

- 7 - STC 4-16 light
2.4 desCri P ti on
The head-end station converts 16 transponders modulated acc. to DVB-S/
DVB-S2 standard (up to 32 APSK) into 16 DVB-C modulated transponders.
bl o C k d i ag r a m
Tuner "1"
SAT IN 1
RF OUT
TPS
SAT IN 4
SAT IN 2
SAT IN 3
Modulator
"1"
Tuner "2"TPS Modulator
"2"
Tuner "3"TPS Modulator
"3"
Tuner "16"TPS Modulator
"16"
Combiner
TEST
–25dB
gen e r al
The station is equipped with four SAT IF inputs, one RF output and one test
output (–25 dB). It is preset to receive the most popular ASTRA transponders.
Different programming is possible at any time. Each of the 16 tuners can be
assigned to any SAT input. Via the RF output of the station, the QAM modulated
RF output signals are output. The output levels of the channel strips can be set.
The configuration of the station is to be done via an HTML user interface via a
PC and a standard HTML browser connected to the LAN input.

- 8 - STC 4-16 light
3 assembly
3.1 insta l l i ng t h e d eviCe
– The device must not be operated lying down, since the function of the heat
sink will be severely restricted. Only with vertically arranged cooling fins
sufficient cooling is ensured.
– The device should only be installed in a room where the permissible ambi-
ent temperature range (0 °C … +50 °C ) can be maintained, even during
fluctuations in climatic conditions.
– Mount the device on a non-combustible base.
– Use mounting material suitable for the wall properties.
– Position the device with a minimum distance on the left and right side of 10
cm, below and above 50 cm.
• Attach four mounting screws at the installation site. The drilling distances
are shown in the drawing below.
318 mm
Ø6 mm
Ø12 mm
222 mm
# #
• Hang the unit with the mounting supports # on the 4 screws.
• Tighten the screws.

- 9 - STC 4-16 light
3.2 de v i Ce ove rvi e w
1
09 ! @ ##
3 4 5 6 7 8
09 ! @$
1 Connector potential equalisation
3 SAT IF input vertical low* 4 SAT IF input vertical high*
5 SAT IF input horizontal low* 6 SAT IF input horizontal high*
* Factory defaults for ASTRA reception, can be changed individually.
7 QAM output 8 Test output –25dB
9 IEC connector C14; connector for mains cable
10 Reset IP address /host name / password (hold depressed for more than 5
seconds) to 192.168.0.120 / gss / geheim
11 LAN socket** for configuration 12 LAN-Status-LED
13 Mounting support
14
Without function
** Use at least CAT6 LAN cables!

- 10 - STC 4-16 light
3.3 Po te n t i a l e q ualisati o n (Pe)
Equalise the potential (PE) in accordance with IEC/EN/DIN EN 60728.
• Connect the PE connection terminal
1
to a PE rail (supplied by customer)
using the PE wire (Cu 4 mm2 - 9 mm2).
3.4 Conn eC t i n g t h e d eviCe
• Connect the SAT IF inputs 3 vertical low*,
4
vertical high*,
5
horizontal
low* and
6
horizontal high* to the corresponding outputs of an LNB.
*Factory defaults for the preprogrammed ASTRA reception, can be changed individually.
• Make sure that all inputs have the same level!
• Connect the attached mains cable to the IEC connector C14 9.
—> If you would like to integrate the device to an existing plant, now
first you should connect it to the mains and perform all settings (Con-
figuration page 11).
• Connect the mains cable to a mains socket with protective conductor con-
nection. Thereby note the voltage specified on the device.
—> This device has no power switch and starts immediately after con-
necting the operating voltage.
• Configure the device (page 11).
• If the programming is finished connect the RF output 7 to the cable net-
work.

- 11 - STC 4-16 light
4 Configuration / uPdates
The configuration of the station is to be done via an HTML user interface via a
PC and a standard HTML browser.
4.1 initial C on fi g ur ati on
• Connect a PC via a LAN cable directly to the LAN input 11.
—> The PC and the head-end station must be within the same network
(same IP address range). Cookies must be accepted and JavaScript
must be active.
Use current browser versions.
—> Example for IP address setting with Windows 7 operating system:
• For the initial setup open the properties for TCP/IPv4 of the PC:
> Control Panel
> Network and Sharing Center
> LAN connection
> Properties

- 12 - STC 4-16 light
> Internet Protocol Version 4 (TCP/IPv4)
> Properties
• Activate point "Use the following IP address".
• Enter e.g. 192.168.0.2 for the IP address.
• Enter for the Subnet mask 255.255.255.0.
• Confirm the setting with "OK".

- 13 - STC 4-16 light
• Start the browser, enter the IP address of the device (factory default is
192.168.0.120) and start the establishment of the connection.
• Enter user "admin" and your Password and click on button "Login".
The default password is "geheim".
—> We recommend that you replace the default password to a pass-
word of your choice in order to prevent unauthorized access to the
head-end station (menu System > Security)!
—> The Overview window is displayed.
First, an "empty" table is displayed (as with all menus). While the
data is read from the device ...
… is displayed.
—> Changes in the menus are only transmitted to the head-end station
when you click the button!

- 14 - STC 4-16 light
4.2 Co nf i gu r at i on
overv i ew win d ow
50
51
57
56
54
55
58
53
52
59
65
66
50 Via the selection System you
have access to the menus of
the System settings:
Logbook (page 23);
Notification (page 24);
Network (page 26);
Security (page 27);
Firmware (page 28);
User (page 31)
51 In all menus you will return
to the Overview via the but-
ton Overview.
52 Via the selection Configura-
tion you have access to the
menus of the Configuration
settings: Input (page 16); Out-
put (page 18); Filter (page 21)
53 Herein the installed firmware version is displayed.
54 This location text can be modified arbitrary in menu System/User.
—> If you remote control head-end station at different locations, herein
you can enter the location and a local contact person.
55 Herein select the menu language English or German.
56 Herein the current system temperature as well as date and time of the last
login is displayed.
—> If a system temperature of 85°C will be reached, the system will be
shut down.
57 Via button Logout you can leave the graphical user interface.

- 15 - STC 4-16 light
58 Via the Help menu you can call up the assembling instructions (PDF) as
well as a ZIP file containing a list and all licences of the used Open-
Source software.
59 Overview of the transponder set, with input frequency, C/N value,
output frequency and data rate. Via the background colour of col-
umn Line you are informed about the quality of the input signals
( good/ bad/ no signal), a possible exceeding the output data
rate ( ), or whether the modulator is switched off ( ).
—> If in menu Configuration/Input (page 16) transponder names are
NOT assigned, the name of the first station of each transponder is
displayed.
—> The maximum displayed C/N value is 15.0dB at DVB-S resp.
20.0dB at DVB-S2. This means the actual value is ≥15/20dB.
65 Via button Download a configuration protocol can be stored as text file
resp. opened using a text editor.
—> From this protocol file e.g. a list of the programmed stations can be
prepared using e.g. a text editor.
66 Herein notes are displayed, which you can enter in menu System/User.
Pe r fo r m Chan g e s
Before leaving a menu, changes must be transmitted to the head-end station.
• Therefore click on button .
After that is displayed for a short time in the upper right corner.
num be r f o r m at
For entering/indication of the different IDs the number format can be set to
hexadecimal or decimal in menu System > Firmware.

- 16 - STC 4-16 light
Co n fi g ur ati on menus
in Pu t
100
101
102
104
105
106
107
108
109
112
—> Via the background colour of column Line you are informed about
the quality of the input signals ( / / ), a possible exceeding
the output data rate ( ), or whether the modulator is switched off
( ).
100 In column fLNB, enter the LNB Oscillator frequencies for the 4 inputs – de-
pendent on the LNB used.
101 In column Name, enter a personal input name.
102 With this button switch on or off the LNB supply (13V/max. 500mA).
104 In column Name, you can enter a personal transponder name
—> If you delete a transponder name, the name of the first station of
this transponder is entered. If the transponder will be changed, the
transponder name will NOT be changed automatically!
105 In column Input, select the desired input for each tuner.
106 In column f (MHz), enter the desired input frequency for each tuner.
107 In column SR (kS/s), enter the related input symbol rate for each tuner.

- 17 - STC 4-16 light
108 In column foffset, the current frequency offset is displayed.
—> The frequency offset should not exceed ± 1.5 MHz!
IF necessary correct the LNB oscillator frequency (if all transpond-
ers of one input are affected) resp. the input frequency (if only one
transponder is affected) accordingly.
109 In this column, the C/N is displayed with reserve.
—> The maximum displayed C/N value is 15.0dB at DVB-S resp.
20.0dB at DVB-S2. This means the actual value is ≥15/20dB.
112 Before leaving the menu, changes must be transferred to the head-end
station!
• Therefore click on button .
—> After that is displayed for a short time in the upper right corner.

- 18 - STC 4-16 light
out P u t
151150 152 154
161
155 156
153
180
—> Via the background colour of column Line you are informed about
the quality of the input signals ( good/ bad/ no signal), a
possible exceeding the output data rate ( ), or whether the modu-
lator is switched off ( ).
150 The upper value shows the current needed data rate.
The lower value shows the maximum possible output data rate (depend-
ant on the output settings).
—> The background colour in column Line indicates an output data
overflow.
In this case change the output settings or remove stations from the
data stream using the station filter.
151 In column Modulator, switch on or off the modulators of the individual lines.

- 19 - STC 4-16 light
152 In column Chan. / Freq. [MHz], enter the desired output channel/fre-
quency of the individual lines.
—> Double assignments are indicated by a
warning icon .
—> A output signal is normally transmitted
with a bandwidth of 8 MHz. This means
that you can only use the channel centre frequency of the existing
channel grid in the range of channels C21…C69 (frequency grid
8 MHz). The CCIR channel grid is 7 MHz in the range of the lower
frequency bands (channels C5 … C12). If 8 MHz QAM signal
packages are transmitted in these channel ranges, this will result in
interference (overlapping) and transmission problems.
For programming in these channel ranges and in the frequency rang-
es below them, we recommend starting with frequency 306 MHz
going back in steps of 8 MHz (see frequency table on page 32).
Please note thereby that many DVB-T receivers cannot receive the
channel ranges S21…S41 (306 … 466 MHz).
153 In column SR [kS/s], enter the desired output symbol rate of the individual
lines.
—> The background colour in column Line indicates an output data
overflow.
In this case increase the output symbol rate or the QAM modulation
or remove stations from the data stream using the station filter.
154 In column Modulation, select the desired kind of modulation of the indi-
vidual lines – QAM 16, 32, 64, 128, 256
—> The background colour in column Line indicates an output data
overflow. In this case change the output settings or remove stations
from the data stream using the station filter.
155 For exceptional cases and "older" digital cable receivers, in column
Spectrum the spectral position of the user signal can be inverted (invers).
Factory default is "normal".

- 20 - STC 4-16 light
156 In column Level [dB], balance the output levels of the different lines
(0…-10dB). Therefore measure and note down the output level of each
modulator. Adjust the higher output levels to the output level of the modu-
lator with the lowest output level incrementally.
—> Changes must be transmitted to the head-end station!
Therefore click on button .
161 Balance here the master output level of the station to the level of the ca-
ble network (0…-31dB; off).
0dB = unchanged level; -31dB = 31dB attenuation
off = Level 0 (no output signal)
—> Changes must be transmitted to the head-end station!
Therefore click on button .
180 Before leaving the menu, changes must be transferred to the head-end
station!
• Therefore click on button .
—> After that is displayed for a short time in the upper right corner.
