Hayter Spirit 41 User guide

(English Version)
CODE FROM SERIAL NO:
615E 270000001 HANDBOOK: 111-1070 (A)
ISSUE 27.10.06
OWNER'S HANDBOOK
SPIRIT 41 Electric
CODE
615E
111-1070 (A) 10/8/07 12:27 pm Page 1.1

1.2
MAIN FEATURES /SPECIFICATIONS
Code 615E
Supply 230V
Rated Input 1.5 kW
Fuse Rating 13A
Weight 29 Kg
Cutterblade Speed 2950 rpm
Cutting width 410mm
Cutting height 13 - 65mm
Overall dimensions 1,380mm x 476mm x 1,058mm
615TH01A
3
10
5
7
8
9
4
2
1
6
11
1 Motor Housing
2 Serial No. Decal
3 Handlebar Securing Knob
4 Rear Deflector
5 Switch Control Unit
6 Stop Lever
7 Handlebar
8 Cable Cleat
9 Grassbag Assembly
10 Cable
11 Height of Cut Lever
Specifications
Main Features
111-1070 (A) 10/8/07 12:27 pm Page 1.2

1st Year (12 months)
We certify that this service has been
carried out by an Authorised Hayter
Service Dealer
Date:
1st Year (12 months)
Owner’s Name:
Serial Number:
Date:
2nd Year (24 months)
We certify that this service has been
carried out by an Authorised Hayter
Service Dealer
Date:
Owner’s Name:
Serial Number:
Date:
Note for dealer: Please retain this voucher for your records.
Note for dealer: Please retain this voucher for your records.
2nd Year (24 months)
111-1070 (A) 10/8/07 12:27 pm Page 1.3

111-1070 (A) 10/8/07 12:27 pm Page 1.4

1.2 Main Features/Specifications
1.5 Contents
1.6 Introduction
1.7 Warranty
1.8 - 1.11 Safety Precautions
1.11 Safety Symbols
1.11 Control Symbols
1.12 - 1.13 Assembling the Mower
1.12 - Delivery Checklist
1.12 - Handlebar
1.12 - Grassbag Assembly
1.12 - Grassbag Attachment
1.13 - Supply Cable
1.13 - 1.17 Operating The Mower
1.13 - Electrical Connections
1.13 - Starting
1.13 - Forward Travel
1.14 - Turning
1.14 - Stopping
1.14 - Height of Cut
1.14 - Before Mowing
1.15 - Grassbag
1.15 - Without Grass Collection
1.15 - Heavy Growth
1.15 - Non-Grassed Areas
1.16 - Safe Mower Practice
1.17 - Overloading Protection
1.18 - 1.19 - Lawn Care Calendar - Guide Only
1.19 - Lawn Stripes
1.20 Maintenance Schedule
1.5
1.21 - 1.24 Mower Maintenance
1.21 - Deck Housing
1.21 - Securing Nuts and Bolts
1.21 - Lubrication
1.21 - Motor
1.21 - Switch Control Unit
1.22 - Cutterblade Removal
1.23 - Cutterblade Sharpening
1.23 - Supply Cable
1.24 - Storage
1.25 - 1.26 Trouble Shooting
1.27 EC Declaration of Conformity
1.28 - 1.31 Parts List
1.28 Parts List - Upper -
1.29 Exploded View - Upper
1.30 Parts List - Lower
1.31 Exploded View - Lower
1.32 Customer Info / Notes
CONTENTS
111-1070 (A) 10/8/07 12:27 pm Page 1.5
