Children should be supervised to ensure that they do not play
with the appliance or get in.
Children getting inside may not be able to get out.
This appearance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.

4
Installation
1. Install on a rigid and level floor.
2. Please use this refrigerator between the room temperature of 10
o
C to 43
o
C.
Sufficient performance may not be obtained, if the room temperature is too low or too high.
3. Do not install where the refrigerator is exposed on a direct sunlight or other heat sources.
4. Install in a atmosphere which is dry or has air ventilation.
5. The refrigerator requires enough air ventilation space around the cabinet to have efficient cooling performance
space of at least 5 cm over the top and 5 cm at rear and 1 cm at both sides for proper air circulation.
6. Ground the refrigerator to prevent electric shock and noise interference. Always ground this refrigerator
when using it in places with high humidity or moisture. (Please consult with retailers or HITACHI service centre.)
7. Adjusting the adjustable legs to keep the left/right refrigerator door level.
■ Without adjusting the legs, door height may not be level,
or there may be abnormal vibration or noises depending
on floor conditions. Follow the instructions below.
(1) Turn the adjustable legs until they touch the floor firmly.
Preparations before Use
Before use
1. Cleaning inside the refrigerator. Wipe the surface gently with soft cloth.
2. Connect the refrigerator to an exclusive wall power outlet.
The refrigerator can be connected to an outlet soon after it is installed.
Surely use with the rated voltage and exclusive power outlet.
3. The compressor will start running in approximately 30 seconds,
if inside is not cold.
4. Allow enough duration for sufficient cooling before storing food.
It may take about 4 hours to fully cool down and could even take about
24 hours when the ambient temperature is high.
1. Keep enough space between food. Several food placed to
close together may obstruct the flow of cold air.
2. Make food cool enough before putting it in the refrigerator.
Putting warm food in the refrigerator raises the inside temperature and wastes electricity.
3. Do not block the cold air vent. This will adversely affect the cold air flow and may not keep
the temperature inside even. Moreover, it could result in food near the vent freezing.
4. Using food wrap or sealed containers prevent the food from drying or transition of smells.
Food storage
4 hrs.
More than 5 cm
More than 1 cm
Rear side
more than 5 cm
Location of Food Storage
Vegetable Compartment 4°C~7°C
Vegetable Drawers
●Storage of fruits and vegetables.
Refrigerator Compartment 2°C~5°C
●Storage of side
dish, desert, etc.
Refrigerator Shelves
●Storage of fresh
meat, fish, prawn
and process foodstuff.
Fresh Room
Refrigerator Door Pockets
●Storage of packed small
food and drinks such
as juice, milk, etc.
Water Tank
● WHEELS
● LEVELING LEGS
Notice
● Above temperatures are the approximate values in the conditions of outside temperature 32
° C, the temperature setting of the refrigerator compartment “Mid”,
freezer compartment “Mid”, doors being closed and without food storage.
● Door pocket temperatures may be little higher than above temperatures.
● The specification of your purchased model may be different from one of the above illustration.
Right door has fallen Left door has fallen
● 1 rotation of adjustable leg is about 1 mm in difference.
● 1-5 days might take for the main body of the refrigerator
becomes familiar with the floor, and until the door is
reconciled in parallel.
Please turn the left leg in
the direction of the arrow.
Please turn the right leg in
the direction of the arrow.
Adjustable left leg. Adjustable right leg.
Parallel adjustment of the door.
Child
Lock
Cooling
Mode
Eenergy
Saving
Quick
Freezing
Ice
Maker
ON
OFF
(Press5 Sec.)
Freezing
Cooling
Max.
Mid.
Min.
Tank
Empty
Max.
Mid.
Min.
$GMXVWRU&RYHU
+RRN
$GMXVWDEOH/HJ
Freezer Compartment
●Storage of frozen food and ice
cream, etc.
Automatic Ice Maker
Freezer Compartment -20°C~-18°C

(Continued)
Press “Child Lock” button
for 5 seconds
( “ ” light is on)
(Press 5 Sec.)
To stop this function,press
“Child Lock” for 5 seconds again
( “ ” light is off )
Upon shipment, the alarm and sound are activated.
Unplugging and inserting the power plug or in the event of a power
failure the refrigerator will automatically reset the alarm and sound
to activated.
If [“eco” Operation indicator lamp] isn’t illuminated, check the following things.
࣭ Immediately after it is installed, or plentiful foods are stored at a time
࣭I f the door is frequently opened / closed
࣭ If the door is not closed completely because any food/bag is wedged between the door and the body
of the refrigerator.
࣭
Quick Freezing is set.
Noti c e
“eco”Operation
indicator lamp
55
Child
Lock
Child
Lock
Cooling Mode Cooling Mode
(Press 5 Sec.)
5. “eco” Operation indicator lamp
Press “Cooling Mode”
Saving” operation, light is off.
button again to stop “ Energy
Press “Cooling Mode”
button to start Energy Quick
Energy
Saving
Freezing
Quick
Energy
Saving
Freezing
Quick
Energy
Saving
Freezing
Start Child Lock Stop Child Lock
Start Energy Saving Stop Energy Saving
Saving operation, light is on.
Door Alarm Functions

Caution
Light ON
6. Water Supply indicator
7
Noti c e
7. Adjusting temperature in a refrigerator compartment
Press button to set the temperature as you like.
Each time you press the button, the corresponding indicator lamp changes
in the order shown in the figure on the right.
The temperature is set to “ Mid ” before shipping.
Select “ Mid ” in ordinary usage. The temperature may change
depending on the operation states.
The above temperatures are standard values in the
Refrigerator Compartment under the condition that the
refrigerator is stable with no food stored and the door
closed, at ambient temperatures of 32ºC.
8. Adjusting temperature in a freezer compartment
Press button to set the temperature as you like.
Each time you Press the button, the corresponding indicator lamp changes
in the order shown in the figure on the right.
The temperature is set to “ Mid ” before shipping.
Select “ Mid ” in ordinary usage. The temperature may change
depending on the operation states.
Notice
If operating the refrigerator for a long time with the Freezer
Compartment “Max” selected, ice cream etc. may become
hard or it may take a longer time to thaw food.
Notice: For the Freezer Compartment ( “Max”Lower temperature freezer),
food is stored at a lower temperature than the conventional
freezer temperature. The energy consumption is approximately 20%
higher than that for the conventional freezer operation.
“Tank Empty” may come on regardless of water level if the water supply
water tank is not placed properly. Push in the water tank straight and
completely if the indicator lamp comes on.
“Tank Empty” indicator lamp turns off once (for up to 3 hours) when the left door
of the Refrigerator Compartment is opened and closed while the indicator
lamp is on, and it turns on again if no water is added to replenish the water tank.
“Tank Empty” indicator lamp remains off when “OFF” is selected for automatic ice making.
“ Tank Empty ” indicator lamp comes on when water in the water supply water tank is getting low.
Replenish the water tank with water. While the “ Tank Empty ” indicator lamp is on, the Ice Making function
doesn’t work even if the “ON” is set.
About 2〜5˚C
(Factory setting)
About 1〜3˚C
lower than “ Mid ”
About 1〜3˚C
higher than “ Mid ”
About -20 〜-18˚C
(Factory setting)
About 1〜3˚C
lower than “ Mid ”
About 1〜3˚C
higher than “ Mid ”
Freezer
Freezer
Freezer
Refrigerator
Refrigerator
Refrigerator
Press it
Press it
Press it
Press it
Press it
Press it

9
flashing This flashing shows that there is a problem. Consult your dealer.
Min
Max
The Control Panel does not respond:
The Control Panel
does not respond:
● Approximately 40 seconds after the end of operation, Indicator LED become unlit (except “eco”, “Quick Freezing”, “Energy Saving”,
The Control Panel is unlit.
● Is “Child Lock” selected by using the lock function on the panel for operation?
● Is Refrigerator the compartment Door open? Operate after closing it.
● Are you wearing gloves or applying a plaster?
“Tank Empty”, “OFF”)
● Are you touching a next button? Touch only one button at a time.
● Is there water or dirt on the Control Panel?
