Intenza 450 series Instruction Manual

INTENZA EQUIPMENT MAINTENANCE GUIDELINES

INTENZA CARDIO PRODUCT BASIC AND TECHNICAL MAINTENANCE

Escalate Stairclimber

Treadmill

Elliptical Trainer

Upright Bike

Recumbent Bike

550 GC Series

Intenza Weight Vest

Contents

INTENZA_____ EQUIPMENT MAINTENANCE GUIDELINES CONTENTS

Escalate Stairclimber

INTENZA_____ EQUIPMENT MAINTENANCE GUIDELINES ESCALATE STAIRCLIMBER

•DAILY Wipe down console and touchables with a soft lint—free cloth and neutral cleaner. DO NOT spray any liquid

directly at or onto any part of Intenza equipment •WEEKLY Wipe all cover and stair surfaces with a soft lint—free cloth

and neutral cleaner. DO NOT spray any liquid directly at or onto any part of Intenza equipment •MONTHLY Vacuum

around the unit and inside the cup holders •TOUCHABLES Handlebars. HR Sensors. Central Keypad. Rear Upright

Posts •PLEASE NOTE For conducting general basic maintenance technical skills are NOT required •CLEANING

MATERIALS PLEASE DO NOT use any type of window cleaner, soap, scouring powder or any other cleaner with

solvents such as benzene, ammonia or paint thinner to clean, sanitise or maintain Intenza products

IN ORDER TO CONDUCT GENERAL TECHNICAL MAINTENANCE, TECHNICAL SKILLS AND TOOLS FOR MAINTAINING AND

REPAIRING FITNESS EQUIPMENT ARE NECESSARY. REQUIRED TORQUE VALUES, BELT TENSIONS, ACCEPTABLE RANGES

FOR MENTIONED PARAMETERS AND MATERIAL SPECIFICATIONS (E.G.LUBRICANTS) ARE AVAILABLE ON THE INCARE™

SUPPORT WEBSITE http://support.intenzafitness.com

GENERAL TECHNICAL MAINTENANCE

QUARTERLY

TOOLS

1CHECK ALL CONSOLE SOFTWARE AND UPDATE IF NECESSARY INTERNET/USB

INSPECT CHAINS AND TRACKS. ADD LUBRICATION IF NECESSARY

VACUUM INSIDE FRONT AND BOTTOM COVERS TO REMOVE DUST BUILD—UP

SOLID GREASE

VACUUM CLEANER

YEARLY

1INSPECT DRIVE BELT, ADJUST TENSION OR REPLACE AS NECESSARY BELT TENSION METRE, DRIVE BELT

2REMOVE RESIDUAL GREASE/ACCUMULATED DEBRIS FROM TRACKS. ADD LUBRICATION SOLID GREASE

450 SERIES. 550 SERIES

INTENZA_____ EQUIPMENT MAINTENANCE GUIDELINES TREADMILL

Treadmill

IN ORDER TO CONDUCT GENERAL TECHNICAL MAINTENANCE, TECHNICAL SKILLS AND TOOLS FOR MAINTAINING AND

REPAIRING FITNESS EQUIPMENT ARE NECESSARY. REQUIRED TORQUE VALUES, BELT TENSIONS, ACCEPTABLE RANGES

FOR MENTIONED PARAMETERS AND MATERIAL SPECIFICATIONS (E.G.LUBRICANTS) ARE AVAILABLE ON THE INCARE™

SUPPORT WEBSITE http://support.intenzafitness.com

•DAILY Wipe down console and touchables with a soft lint—free cloth and neutral cleaner. DO NOT spray any liquid

directly at or onto any part of Intenza equipment •WEEKLY Wipe all cover surfaces with a soft lint—free cloth and

neutral cleaner. DO NOT spray any liquid directly at or onto any part of Intenza equipment. Wipe the running belt

surface with a soft dry/damp, lint—free cloth. DO NOT use/apply liquid or wet cloth directly onto the running deck

in order to avoid damage •MONTHLY Vacuum around the unit, inside the cup holders and the gap between belt and

side landings. Wipe between the running belt and deck with a soft, lint—free dry cloth •TOUCHABLES Handlebars. HR

Sensors. Central Keypad •PLEASE NOTE For conducting general basic maintenance technical skills are NOT required

•CLEANING MATERIALS PLEASE DO NOT use any type of window cleaner, soap, scouring powder or any other

cleaner with solvents such as benzene, ammonia or paint thinner to clean, sanitise or maintain Intenza products

GENERAL TECHNICAL MAINTENANCE

QUARTERLY

TOOLS

1CHECK ALL CONSOLE SOFTWARE AND UPDATE IF NECESSARY INTERNET/USB

INSPECT AND ADJUST THE RUNNING BELT TENSION AS NEEDED

INSPECT DRIVE MOTOR'S CURRENT. IF OUT OF ACCEPTABLE RANGE SERVICE MODE OPERATION

4VACUUM UNDER MOTOR PAN COVER TO REMOVE DUST BUILD—UP VACUUM CLEANER

CHECK BELT AND DECK CONDITION

ALLEN WRENCH, BELT TENSION METRE

YEARLY

1LUBRICATE BELT AND DECK USING SILICONE OIL REFER TO INTENZA SOP FOR SILICONE

OIL SPECIFICATION/IMPLEMENTATION

2INSPECT DRIVE BELT. ADJUST TENSION OR REPLACE AS NECESSARY BELT TENSION METRE, DRIVE BELT

450 SERIES. 550 SERIES

INTENZA_____ EQUIPMENT MAINTENANCE GUIDELINES ELLIPTICAL TRAINER

Elliptical Trainer

•DAILY Wipe down console and touchables with a soft lint—free cloth and neutral cleaner. DO NOT spray any liquid

directly at or onto any part of Intenza equipment •WEEKLY Wipe all cover and pedal surfaces with a soft lint—free cloth

and neutral cleaner. DO NOT spray any liquid directly at or onto any part of Intenza equipment •MONTHLY Vacuum

wheel tracks to ensure wheels operate smoothly •TOUCHABLES Handlebars. HR Sensors. Central Keypad •PLEASE

NOTE For conducting general basic maintenance technical skills are NOT required •CLEANING MATERIALS PLEASE

DO NOT use any type of window cleaner, soap, scouring powder or any other cleaner with solvents such as benzene,

ammonia or paint thinner to clean, sanitise or maintain Intenza products

IN ORDER TO CONDUCT GENERAL TECHNICAL MAINTENANCE, TECHNICAL SKILLS AND TOOLS FOR MAINTAINING AND

REPAIRING FITNESS EQUIPMENT ARE NECESSARY. REQUIRED TORQUE VALUES, BELT TENSIONS, ACCEPTABLE RANGES

FOR MENTIONED PARAMETERS AND MATERIAL SPECIFICATIONS (E.G.LUBRICANTS) ARE AVAILABLE ON THE INCARE™

SUPPORT WEBSITE http://support.intenzafitness.com

GENERAL TECHNICAL MAINTENANCE

QUARTERLY

TOOLS

1CHECK ALL CONSOLE SOFTWARE AND UPDATE IF NECESSARY INTERNET/USB

INSPECT WHEEL TRACKS. LUBRICATE OR REPLACE IF DAMAGED

INSPECT AND ADJUST PEDAL TO PIVOT BLOCK BEARING CONNECTION WRENCH

4INSPECT AND LUBRICATE JOIN BEARINGS ON LINKARMS SOLID GREASE

DRY LUBRICANT (PTFE), WHEEL TRACKS

YEARLY

1INSPECT 2 DRIVE BELTS. ADJUST TENSION OR REPLACE AS NECESSARY BELT TENSION METRE, DRIVE BELT

450 SERIES. 550 SERIES

Upright Bike

INTENZA_____ EQUIPMENT MAINTENANCE GUIDELINES UPRIGHT BIKE

•DAILY Wipe down console, seat and touchables with a soft lint—free cloth and neutral cleaner. DO NOT spray any

liquid directly at or onto any part of Intenza equipment •WEEKLY Wipe all cover and pedal surfaces with a soft lint—free

cloth and neutral cleaner. DO NOT spray any liquid directly at or onto any part of Intenza equipment •MONTHLY

Vacuum around the unit and inside the cup holders•TOUCHABLES Handlebars. HR Sensors. Seat Adjustment Lever

•PLEASE NOTE For conducting general basic maintenance technical skills are NOT required •CLEANING MATERIALS

PLEASE DO NOT use any type of window cleaner, soap, scouring powder or any other cleaner with solvents such as

benzene, ammonia or paint thinner to clean, sanitise or maintain Intenza products

IN ORDER TO CONDUCT GENERAL TECHNICAL MAINTENANCE, TECHNICAL SKILLS AND TOOLS FOR MAINTAINING AND

REPAIRING FITNESS EQUIPMENT ARE NECESSARY. REQUIRED TORQUE VALUES, BELT TENSIONS, ACCEPTABLE RANGES

FOR MENTIONED PARAMETERS AND MATERIAL SPECIFICATIONS (E.G.LUBRICANTS) ARE AVAILABLE ON THE INCARE™

SUPPORT WEBSITE http://support.intenzafitness.com

GENERAL TECHNICAL MAINTENANCE

QUARTERLY

TOOLS

1CHECK ALL CONSOLE SOFTWARE AND UPDATE IF NECESSARY INTERNET/USB

INSPECT CRANKS AND TIGHTEN IF LOOSE

INSPECT PEDAL TO CRANK CONNECTION. TIGHTEN IF LOOSE. REPLACE AS NECESSARY WRENCH AND PEDAL

4INSPECT PEDAL STRAPS AND REPLACE AS NECESSARY PEDAL STRAP

WRENCH

YEARLY

1INSPECT DRIVE BELT. ADJUST TENSION OR REPLACE AS NECESSARY BELT TENSION METRE, DRIVE BELT

450 SERIES. 550 SERIES

INTENZA_____ EQUIPMENT MAINTENANCE GUIDELINES RECUMBENT BIKE

Recumbent Bike

•DAILY Wipe down console, seat, backrest and touchables with a soft lint—free cloth and neutral cleaner. DO NOT

spray any liquid directly at or onto any part of Intenza equipment •WEEKLY Wipe all cover surfaces with a soft lint—free
