JVC LX-WX50 User manual

USER MANUAL
DLP PROJECTOR
LX-WX50

2 Table of contents
Table of contents
Safety precautions................. 3
Important safety instructions
.............................................. 4
Overview ............................... 7
Shipping contents........................7
Projector exterior view.................8
Controls and functions................. 9
Control panel ......................................9
Remote control .................................10
Installation ........................... 12
Choosing a location...................12
Obtaining a preferred projected
image size .................................13
Projection dimensions ......................13
Shifting the projection lens vertically
..........................................................14
Connection .......................... 15
Operation............................. 16
Starting up the projector ............16
Shutting down the projector....... 16
Selecting an input source .......... 17
Adjusting the projected image ... 18
Adjusting the projection angle ..........18
Auto-adjusting the image..................18
Fine-tuning the image size and clarity
..........................................................18
Correcting keystone..........................19
Correcting image corners .................19
Menu Functions................... 20
About the OSD Menus ..............20
Using the OSD menu ................20
DISPLAY menu ................................21
PICTURE menu................................23
SOURCE menu ................................25
SYSTEM SETUP: Basic menu ........25
SYSTEM SETUP: Advanced menu 26
INFORMATION menu ......................28
OSD menu structure ........................ 29
Controlling the projector
remotely............................... 31
Configuring the LAN Settings......... 31
Controlling the projector using a web
browser (e-Control™) ...................... 32
Controlling the projector
using PJLink™................................. 34
Maintenance........................ 36
Care of the projector ................. 36
Lamp information ...................... 37
Getting to know the lamp hour......... 37
Extending lamp life .......................... 37
Timing of replacing the lamp............ 38
Replacing the lamp .......................... 39
Indicators .................................. 42
Troubleshooting ........................ 43
Specifications............................ 44
Projector specifications.................... 44
Dimensions ...................................... 45
Timing chart ..................................... 46
Warranty and Copyright
information........................... 51
Warranty ................................... 51
Copyright .................................. 51
Disclaimer ................................. 51

3
Safety precautions
Safety precautions
This product has a High Intensity Dis-charge (HID) lamp that contains mercury. Manage in
accord with disposal laws. Disposal of these materials may be regulated in your community due
to environmental considerations. For disposal or recycling information, please contact your local
authorities or for USA, the Electronic Industries Alliance: http://www.eiae.org. or call 1-800-252-
5722(For USA) or 1-800-964-2650(For Canada).
FCC INFORMATION (U.S.A. only)
CAUTION:
Changes or modification not approved by JVC could void the user’s authority to operate the
equipment.
NOTE:
This equipment has been tested and found to comply with the limits for Class B digital devices,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encourage to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Declaration of Conformity
Model Number: LX-WX50
Trade Name: JVC
Responsible party: JVCKENWOOD USA Corporation
Address: 1700 Valley Road Wayne, N. J. 07470
Telephone Number: 973-317-5000
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOISE EMISSION DECLARATION
The sound pressure level at the operator position is equal or less than 60dB(A) according to
ISO7779.

4 Important safety instructions
Dear Customer,
This apparatus is in conformance with the valid European directives and standards regarding
electromagnetic compatibility and electrical safety.
European representative of JVC KENWOOD Corporation is: JVC Technical Services Europe
GmbH Konrad-Adenauer-Allee 1-11 61118 Bad Vilbel Germany
Information for Users on Disposal of Old Equipment and Batteries
[European Union only]
These symbols indicate that equipment with these symbols should not
be disposed of as general household waste. If you want to dispose of
the product or battery, please consider the collection systems or
facilities for appropriate recycling.
Notice: The sign Pb below the symbol for batteries indicates that this
battery contains lead.
Important safety instructions
Your projector is designed and tested to meet the latest standards for safety of information
technology equipment. However, to ensure safe use of this product, it is important that you follow
the instructions mentioned in this manual and marked on the product.
1. Please read this user manual before you operate your projector. Keep this manual in a safe place
for future reference.
2. Always place the projector on a level, horizontal surface during operation.
- Do not place the projector on an unstable cart, stand, or table as it may fall and be damaged.
- Do not place inflammables near the projector.
- Do not use if tilted at an angle of more than 10 degrees left to right, nor at angle of more than 15
degrees front to back.
3. Do not store the projector on end vertically. Doing so may cause the projector to fall over, causing
injury or resulting in damage.
4. Do not place the projector in any of the following environments:
- Space that is poorly ventilated or confined. Allow at least 50 cm clearance from walls and free
flow of air around the projector.
- Locations where temperatures may become excessively high, such as the inside of a car with all
windows closed.
- Locations where excessive humidity, dust, or cigarette smoke may contaminate optical
components, shorten the projector’s lifespan and darken the screen.
- Locations near fire alarms.
- Locations with conditions beyond those listed in "Projector specifications".
5. Do not block the vents while the projector is on (even in standby mode).
- Do not cover the projector with any item.
- Do not place the projector on a blanket, bedding or any other soft surface.
6. In areas where the mains power supply voltage may fluctuate by ±10 volts, it is recommended that
you connect the projector through a power stabilizer, surge protector or uninterruptible power
supply (UPS) as appropriate to your situation.
7. Do not step on the projector or place any objects upon it.
8. Do not place liquids near or on the projector. Liquids spilled into the projector will void your
warranty. If the projector does become wet, disconnect it from the power outlet and contact JVC to
have the projector repaired.
Products
Battery

5
Important safety instructions
9. Do not look straight into the projector lens during operation. It may harm your sight.
10. Do not operate the projector lamp beyond the rated lamp life. Excessive operation of lamps
beyond the rated life could cause a lamp to break on rare occasions.
11. The lamp becomes extremely hot during operation. Allow the projector to cool for approximately 45
minutes prior to removing the lamp assembly for replacement.
12. Never attempt to replace the lamp assembly until the projector has cooled down and is unplugged
from the power supply.
13. This projector is capable of displaying inverted images for ceiling mount installation. Use only a
proper ceiling mount kit for mounting.
14. THIS APPARATUS MUST BE EARTHED.
15. When installing the unit, incorporate a readily accessible disconnect device in the fixed wiring, or
connect the power plug to an easily accessible socket-outlet near the unit. If a fault should occur
during operation of the unit, operate the disconnect device to switch the power supply off, or
disconnect the power plug.
High temperature Caution
The temperature of the cabinet around and above the exhaust vents can become hot during
projector operation. Touching these areas during operation could cause burns to the hands. Do
not touch these areas. Doing so may cause burns. Pay particular attention in preventing young
children from touching these parts. Additionally, do not place any metal objects on these areas.
Due to the heat from the projector, doing so could cause an accident or personal injury.
Ceiling mounting the projector
If you intend to mount your projector on the ceiling, we strongly recommend that you use a
proper fitting projector ceiling mount kit and ensure it is securely and safely installed.
If not, there is a safety risk that the projector may fall from the ceiling due to an improper
attachment through the use of the wrong gauge or length screws.
You can purchase a proper projector ceiling mount kit from the place you purchased your
projector. We recommend that you also purchase a separate Kensington lock compatible
security cable and attach it securely to both the Kensington lock slot on the projector and the
base of the ceiling mount bracket. This will perform the secondary role of restraining the
projector should its attachment to the mounting bracket become loose.
Do not attempt to disassemble this projector. There are dangerous high voltages inside which
may cause death if you should come into contact with live parts. The only user serviceable part is
the lamp. See page 39.
Under no circumstances should you ever undo or remove any other covers. Refer servicing only to
suitably qualified professional service personnel.
Please keep the original packing for possible future shipment. If you need to pack your projector
after use, adjust the projection lens to an appropriate position, put the lens cushion around the
lens, and fit the lens cushion and projector cushion together to prevent damage during
transportation.
When you think service or repair is required, take the projector only to a suitably qualified
technician.
RG2 IEC 62471-5:2015

6 Important safety instructions
Moisture condensation
Never operate the projector immediately after moving it from a cold location to a hot location.
When the projector is exposed to such a change in temperature, moisture may condense on the
crucial internal parts. To prevent the projector from possible damage, do not use the projector for
at least 2 hours when there is a sudden change in temperature.
Avoid volatile liquids
Do not use volatile liquids, such as insecticide or certain types of cleaner, near the projector. Do
not have rubber or plastic products touching the projector for a long time. They will leave marks
on the finish. If cleaning with a chemically treated cloth, be sure to follow the cleaning product’s
safety instructions.
Disposal
This product contains the following materials which are harmful to human bodies and
environment.
• Lead, which is contained in solder.
• Mercury, which is used in the lamp.
To dispose of the product or used lamps, consult your local environment authorities for
regulations.

7
Overview
Overview
Shipping contents
Carefully unpack and verify that you have the items below. Some of the items may not be
available depending on your region of purchase. Please check with your place of purchase.
Some of the accessories may vary from region to region.
*Pull the tab before using the remote control.
Projector Remote control with battery* Power cable
VGA cable User manual CD Quick start guide
(US) (EU)

8 Overview
Projector exterior view
Front and upper side view
1. Control panel (See "Control panel"
for details.)
2. Vent (heated air exhaust)
3. Lamp cover
4. Speaker grill
5. Projection lens
6. Front IR remote sensor
7. LED indicator
8. Lens adjustment panel cover (See
"Control panel" for details.)
9. Vent (cool air intake)
10.AC Power cable inlet
11. RJ45 LAN input jack
12.RS-232 control port
13.Mini USB port
Used for service.
14.USB Type-A port
Used for charging external device.
15.HDMI-2 port
16.HDMI-1 port
17.RGB signal output jack
18.RGB (PC)/Component video (YPbPr/
YCbCr) signal input jack
19.S-Video input jack
20.Audio (R) input jack
21.Audio input jack
22.12VDC output terminal
Used to trigger external devices such as
an electric screen or light control, etc.
Consult your dealer for how to connect
these devices.
23.Security bar
24.Kensington lock slot
25.Video input jack
26.Audio (L) input jack
27.Microphone jack
28.Audio output jack
29.Ceiling mount holes
30.Adjuster feet
Rear/bottom view
9
4
2
5
6
4
8
7
1
3
2423 25 26 27 28
29
29
30 30
29
29
151413 16 1817 19 20 21 22
12
1110

9
Overview
Controls and functions
Control panel
1. Focus ring
Adjusts the focus of the projected image.
2. Zoom ring
Adjusts the size of the image.
3. Lens shift ring
Adjusts the position of the projected image.
4. TEMPerature warning light
Lights up red if the projector's temperature
becomes too high.
5. POWER indicator light
Lights up or flashes when the projector is
under operation.
6. LAMP indicator light
Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem.
7. Top IR remote sensor
8. POWER
Toggles the projector between standby
mode and on.
9. BLANK
Used to hide the screen image. Press most
of the keys on the projector or remote control
to restore the picture.
10.MODE
Selects an available picture setup mode.
ENTER
Activates the selected On-Screen Display
(OSD) menu item.
11. MENU
• Accesses the On-Screen Display (OSD)
menu.
• Goes back to previous OSD menu, exits
and saves menu settings.
EXIT
Goes back to previous OSD menus, exits
and saves any changes made using the
On-Screen Display (OSD) menu.
12.Keystone keys ( , )
Launches the Keystone window. Use ,
, , to manually correct distorted
images resulting from an angled projection.
13.AUTO
Automatically determines the best picture
timings for the displayed image.
14.
Activates panel key lock. To unlock the keys,
press and hold for 3 seconds or setting
OSD menu using the remote control.
15.SOURCE
Displays the source selection bar.
16.Arrow keys ( , , , )
When the On-Screen Display (OSD) menu
is activated, these keys are used as
directional arrows to select the desired
menu items and to make adjustments.
2
1
4
6
5
11 1312
15
16
3
7
10
12
8
9
14

10 Overview
Remote control
1. POWER
Toggles the projector between standby
mode and on.
2. SOURCE
Displays the source selection bar.
3. MENU
• Accesses the On-Screen Display (OSD)
menu.
• Goes back to previous OSD menu, exits
and saves menu settings.
4. Arrow keys ( Left, Right, Up,
Down)
When the On-Screen Display (OSD)
menu is activated, these keys are used as
directional arrows to select the desired
menu items and to make adjustments.
5. ENTER
Activates the selected On-Screen Display
(OSD) menu item.
MODE
Selects an available picture mode.
6. BLANK
Used to blank the screen picture. Press most
of the keys on the projector or remote control to
restore the picture.
7. D. ZOOM-/D. ZOOM-
Displays the Zoom bar.
• D. ZOOM+: After the Zoom bar displays,
magnifies the projected picture size. After
the image is magnified, use /// to
navigate the image.
• D. ZOOM-: After the image is magnified,
reduces the projected picture size. To
quickly restore the picture to its original size,
press AUTO.
8. MUTE
Temporarily mutes the audio.
9. Keystone keys ( , )
Launches the Keystone window. Use , ,
, to manually correct distorted images
resulting from an angled projection.
10.AUTO
Automatically determines the best picture
timings for the displayed image.
11.
Activates panel key lock. To unlock the keys,
press and hold for 3 seconds or setting OSD
menu using the remote control.
12.FREEZE
Freezes the projected image.
13.TIMER
Activates or inactivates an on-screen timer
based on your own timer setting.
14.VOL+
Increases the projector audio volume.
VOL-
Decreases the projector audio volume.
1
12
10
11
14
2
7
3
6
8
5
9
4
9
13

11
Overview
Installing/replacing the remote control battery
1. Pull out the battery holder, as illustrated. Push and hold the
locking arm whilst pulling out the battery holder.
2. Insert the new battery in the holder. Note the positive
polarity should face outward.
3. Push the holder into the remote control.
• Avoid leaving the remote control and battery in an excessive heat
or humid environment like the kitchen, bathroom, sauna,
sunroom or in a closed car.
• Replace only with the same or equivalent type recommended by
the battery manufacturer.
• Dispose of the used batteries according to the manufacturer's instructions and local environment
regulations for your region.
• Never throw the batteries into a fire. There may be danger of an explosion.
• If the batteries are drained or if you will not be using the remote control for an extended period of time,
remove the batteries to avoid damage to the remote control from possible battery leakage.
Remote control effective range
The remote control must be held at an angle within 30 degrees perpendicular to the projector's
IR remote control sensor(s) to function correctly. The distance between the remote control and
the sensor(s) should not exceed 8 meters (~ 26 feet).
Make sure that there are no obstacles between the remote control and the IR sensor(s) on the
projector.
• Operating the projector from the front
Approx.+30º
• Operating the projector from the top
Approx.+30º

12 Installation
Installation
Choosing a location
Before choosing an installation location for your projector, take the following factors into
consideration:
• Size and position of your screen
• Electrical outlet location
• Location and distance between the projector and the rest of your equipment
You can install your projector in the following ways.
1. Front Table:
Select this location with the
projector placed near the floor
in front of the screen.
This is the most common way
to position the projector for
quick setup and portability.
Turn on the projector and
make the following settings:
SYSTEM SETUP: Basic >
Projector Position > Front
Table
3. Front Ceiling:
Select this location with
the projector suspended
from the ceiling in front of
the screen.
Turn on the projector and
make the following
settings:
SYSTEM SETUP: Basic
> Projector Position >
Front Ceiling
Purchase the proper ceiling mount kit from
your dealer to mount your projector on the
ceiling.
2. Rear Table:
Select this location with the
projector placed near the floor
behind the screen.
Turn on the projector and
make the following settings:
SYSTEM SETUP: Basic >
Projector Position > Rear
Table
4. Rear Ceiling:
Select this location with
the projector suspended
from the ceiling behind
the screen.
Turn on the projector and
make the following
settings:
SYSTEM SETUP: Basic
> Projector Position >
Rear Ceiling
A special rear projection screen is required. A special rear projection screen and a
proper ceiling mount kit are required.

13
Installation
Obtaining a preferred projected image size
The projected image size is determined by the distance from the projector lens to the screen, the
zoom setting, and the video format.
Projection dimensions
Use the illustration and the table below to help you determine the projection distance.
All measurements are approximate and may vary from the actual sizes. If you want a permanent
installation of the projector, we recommend that you use the actual projector to physically test the
projection size, distance, and the projector's optical characteristics prior to the installation. This helps you
determine the exact mounting position which best suits your installation.
H
W
Projection distance
Center of lens
Screen
Vertical offset
16:10 Screen diagonal
Display size (16:10) Projection distance Vertical Offset
(inch)
Screen diagonal (inch) W (inch) H (inch) Wide (feet) Tele (feet)
60 50.9 31.8 4.8 7.6 1.6
70 59.4 37.1 5.6 8.9 1.9
80 67.8 42.4 6.4 10.2 2.1
90 76.3 47.7 7.2 11.5 2.4
100 84.8 53.0 8.0 12.7 2.6
110 93.3 58.3 8.8 14.0 2.9
120 101.8 63.6 9.5 15.3 3.2
130 110.2 68.9 10.3 16.6 3.4
140 118.7 74.2 11.1 17.8 3.7
150 127.2 79.5 11.9 19.1 4.0
160 135.7 84.8 12.7 20.4 4.2
170 144.2 90.1 13.5 21.6 4.5
180 152.6 95.4 14.3 22.9 4.8
190 161.1 100.7 15.1 24.2 5.0
200 169.6 106.0 15.9 25.5 5.3
210 178.1 111.3 16.6 26.6 5.6
220 186.6 116.6 17.4 27.9 5.8
230 195.0 121.9 18.2 29.1 6.1
240 203.5 127.2 19.0 30.4 6.4
• The screen aspect ratio is 16:10
and the projected picture is in
16:10 aspect ratio

14 Installation
Shifting the projection lens vertically
The vertical lens shift control provides flexibility for installing your projector. It allows the projector
to be positioned slightly above or below the top level of the projected images.
The lens shift (offset) is expressed as a percentage of the projected image height. It is measured
as an offset from the projected image's vertical center. Use the lever to shift the projection lens
upwards or downwards within the allowable range depending on your desired image position.
To shift the lens:
1. Press down lightly on the lens adjustment panel cover switch (indicated by a dot) to click it
open.
2. Lift the lens adjustment panel cover up.
3. Turn the lens shift ring to adjust the projected image position.
4. When done, press down and click close the lens adjustment panel cover.
• When the screen position is fixed
• When the projector position is fixed
• Do not over-tighten the lever.
• Lens shift adjustment does not result in a degraded picture quality. In the unlikely event that the image
distortion is produced, see "Adjusting the projected image" for details.
Screen
Range of placement
b
a

15
Connection
Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Make sure the cables are firmly inserted.
• In the connection illustrations shown below, some cables may not be included with the projector (see
"Shipping contents"). They are commercially available from electronics stores.
The illustrations below are for reference only. The rear connecting jacks available on the
projector vary with each projector model.
1. VGA cable
2. VGA to DVI cable
3. USB cable
4. Component Video to VGA (D-Sub)
adapter cable
5. HDMI cable
6. S-Video cable
7. Video cable
8. Audio cable
9. Microphone
8 7
8
1 63 8
8
5
9
41 2
Notebook or desktop computer
(VGA)
A/V device
Speakers
(DVI)
or
or

16 Operation
Operation
Starting up the projector
1. Plug the power cable into the projector and a power outlet.
Turn on the power outlet switch (where fitted). The POWER
indicator light on the projector lights orange after power
has been applied.
Please use the supplied power cable to avoid possible dangers such
as electric shock and fire.
2. Press to start the projector. The POWER indicator light
flashes green and stays green when the projector is on.
The fans start operating, and a start-up image displays on
the screen while it warms up. The projector does not respond to further commands while it is
warming up.
Shutting down the projector
1. Press . The projector displays a shutdown confirmation message.
2. Press a second time. The POWER indicator light flashes
orange and the fans run for about two minutes to cool the
lamp. The projector doesn’t respond to any commands
during the cooling process.
3. When the cooling process ends, the POWER indicator light
will show a solid orange.
If the projector will not be used for an extended period,
unplug the power cable from the power outlet.
Avoid turning on the projector immediately after turning it off as excessive heat may shorten lamp life. The
actual lamp life may vary due to different environmental conditions and usage.

17
Operation
Selecting an input source
The projector can be connected to multiple equipment at the same time. However, it only
displays one full screen at a time. When starting up, the projector automatically searches for the
available signals.
If you want the projector to always automatically search for the signals:
• Go to the SOURCE menu, and then enable Quick Auto Search. (see "Quick Auto Search"
on page 25)
To select the video source:
1. Press SOURCE to display the source selection bar.
2. Press /until your desired signal is selected and press ENTER.
Once detected, the selected source information displays on the screen for seconds. If there
are multiple pieces of equipment connected to the projector, repeat steps 1-2 to search for
another signal.
Refer to "Projector specifications" for the native display resolution of this projector. For best display
picture results, you should select and use an input signal which outputs at this resolution. Any other
resolutions will be scaled by the projector depending upon the Aspect Ratio setting, which may cause
some image distortion or loss of picture clarity. See "Aspect Ratio" for details.

18 Operation
Adjusting the projected image
Adjusting the projection angle
The projector is equipped with 2 adjuster feet. These
adjusters change the image height and projection angle.
Screw the feet in or out as appropriate to aim and level the
projection angle.
If the screen and the projector are not perpendicular to each
other, the projected image becomes vertical trapezoidal. To
correct this, see "Auto-adjusting the image" for details.
Auto-adjusting the image
In some cases, you may wish to optimize the picture
quality of PC signal. To do this, press AUTO. Within 3
seconds, the built-in Intelligent Auto Adjustment function
will re-adjust the values of Frequency and Clock to provide
the best picture quality.
The current input source information will be displayed in the corner of the screen for 3 seconds.
This function is only available when PC signal is selected.
Fine-tuning the image size and clarity
To adjust the projected picture size, turn the zoom ring on the projector after opening the lens
adjustment panel cover.
To sharpen the picture, rotate the focus ring on the projector after opening the lens adjustment
panel cover.
Do not look into the lens while the
lamp is on. The strong light from
the lamp may cause damage to
your eyes.
Be careful when you press the
quick-release button as it is close
to the exhaust vent where hot air
comes from.

19
Operation
Correcting keystone
Keystoning refers to the situation where the projected image is noticeably wider at either the top
or bottom. It occurs when the projector is not perpendicular to the screen.
Besides adjusting the height of the projector, you may correct this manually by following the
instructions below:
1. Do one of the following steps to display the Keystone window:
• Press / or / on the projector.
• Press / or / on the remote control.
• Go to the DISPLAY menu, highlight Keystone and press ENTER. (To access the OSD
menu, see "Using the OSD menu" for details.)
2. The illustrations below show how to correct keystone distortion:
Correcting image corners
see "Corner Correction" on page 21.
• To correct keystoning at the bottom of the image,
use or / .
• To correct keystoning at the top of the image,
use or / .
• To correct keystoning at the left side of the
image, use or / .
• To correct keystoning at the right side of the
image, use or / .
When done, press MENU to save your changes and
exit.
Press / .
Press /.
Press /.
Press /.

20 Menu Functions
Menu Functions
About the OSD Menus
To access the OSD menu, press MENU.
Using the OSD menu
To access the OSD menu, press MENU on the projector or remote control. It consists of the
following main menus. Check the links after the menu items below to learn more details.
1. DISPLAY menu (see page 21)
2. PICTURE menu (see page 23)
3. SOURCE menu (see page 25)
4. SYSTEM SETUP: Basic menu (see page 25)
5. SYSTEM SETUP: Advanced menu (see page 26)
6. INFORMATION menu (see page 28)
Available menu items may vary depending on the connected video sources or specified settings.
Menu items that are not available will become grayed out.
• Use the arrow keys ( ///) on the projector or remote control to move through the
menu items.
• Use ENTER to confirm the selected menu item.
Current input signal
Main menu icon
Sub-menu
Highlight
Status
Screen Color
3D Sync
3D
Digital Zoom
H. Size
Phase
Position
Keystone
Aspect Ratio
Analog RGB
Off
Auto
16
0
Exit
DISPLAY
Press MENU
to go back to
the previous
window or to
exit.
main menu
Corner Correction
