Kaidan 900 User manual

KiWi™900/950
User’sGuide
PhotographicVR
PanoramicTripod Head
DesignedexpresslyfortheNikonCoolpix
900,900Sand950DigitalCameras

Copyright Information
Copyright © 2000 Kaidan, Inc. All Rights Reserved. First Edition, Septem er
2000. KiWi is a trademark of Kaidan, Inc. Other products mentioned herein may
e trademarks of their respective companies. Patents Pending.
Information in this manual is su ject to change without notice and does not
represent a commitment on the part of Kaidan. No part of this manual may e
reproduced or transmitted in any form or y any means, electronic or mechani-
cal, including photocopying, recording, or information storage and retrieval sys-
tems, or translated to another language, for any purpose other than the licensee’s
personal use and as specifically allowed in the licensing agreement, without the
express written permission of Kaidan.
Kaidan Warranty and Return Policy
A • Limited Warranty
In the event of a defect in materials or workmanship, Kaidan will repair the
product with new or re uilt parts for a period of three-hundred and sixty five
(365) days from the date of original purchase. Such work will e performed free
of charge. Follow the Product Return Procedure (Section D following).
Likewise, any software purchased from Kaidan also comes with a one year
warranty if your disc or media is defective or damaged. This warranty is ex-
tended only to the original purchaser and is not transfera le. A purchase receipt
or other proof of original purchase will e required efore warranty performance
is rendered.
This warranty only covers failures due to defects in materials or workman-
ship which occur during normal use. It does not cover damages or failures which
are caused from accident, misuse, a use, neglect, mishandling, misapplication,
alteration, faulty installation, modification, service y anyone other than an au-
thorized representative of Kaidan, Acts of God, or y products not supplied y
Kaidan.
This warranty covers any damage incurred during original shipment of prod-
uct to customer. Any item resold, or distri uted y, and not explicitly manufac-
tured y Kaidan will e covered y their respective company’s product warranty.
B • Warranty Exclusions
There are no express warranties except as listed a ove.
Kaidan shall not e lia le for special, incidental, consequential or punitive
damages, including, without limitation, loss of goodwill, profits or revenue, loss
of the use of this product or any associated equipment, cost of su stitute equip-
ment, downtime costs, or claims of any party dealing with uyer for such
damages,resulting from use of this product or arising from reach of warranty
or contract, negligance, or any other legal theory .
All express and implied warranties, including the warranties of merchant-
a ility and fitness for a particular purpose, are limited to the applica le war-
ranty period set forth a ove. Some states do not allow the exclusion or limitation
of consequential damages, or limitations on how long an implied warranty lasts,
so the a ove exclusions or limitations may not apply to you.
This warranty and any claims which arise with the Kaidan product(s) are
governed y the laws of the state of Pennsylvania. By purchasing this product,
customer acknowledges and agrees to these Limits and Exclusions. If a pro lem
with your Kaidan product develops during the warranty period, immediately
contact Kaidan for assistance.
C • Product Return Policy
All Kaidan products come with a 30-day return policy (a minimum 10 percent
re-stocking fees will apply) from date of purchase, with the exception of software
or videotapes.
Both of the aforementioned items are copyrighted and su ject to the laws
concerning intellectual property. Kaidan will replace defective software/video-
tapes free of charge upon return receipt of defective item(s). Products returned
under this policy, excluding replacement of defective items, must e shipped at
purchaser’s expense. Purchaser must ship product with an approved tracea le
service, such as FedEx, and with appropriate levels of shipping insurance for the
item eing returned. Kaidan will not e held responsi le for returned items lost
or damaged in transit.
Kaidan ill issue a refund to customer’s account if the follo ing condi-
tions are satisfied:
1) Receipt of item(s) in a restocka le condition.
Criteria for Restocka le Condition is as follows:
• All parts are included in ox; hardware, manuals, discs, nuts/ olts, tools.
• No signs of damage; scratches, ent parts, missing pieces, markings, alter-
ations, or additions to the product.
• All packaging materials are intact; foam, peanuts, card oard, u le ags.
• No signs of excess usage or wear to the product.
Items of Non-restocka le condition are su ject to the following:
• Restocking Fee/s - a minimum of 10 percent and possi le additional fees
ased on the condition of the product (how the product est meets the criteria
a ove), at Kaidan’s discretion.
Non-Restocka le Condition - constitutes the following:
• Missing parts; hardware, manuals, discs, nuts/ olts, tools, and packaging
materials; foam, peanuts, card oard, u le ags.
• Signs of damage; scratches, ent parts, missing pieces, markings, alter-
ations, additions to the product.
• Signs of excess usage or wear to the product.
• Damage or loss incurred during uninsured shipping to Kaidan. In this case,
Kaidan cannot issue any type of refund. Customer will e responsi le to su -
mit claim with their shipping company.
• If damages occur in shipping, customer must su mit claim with shipping
company prior to any action y Kaidan.
Items Part of Special Bundle
If item(s) are part of a special undle offer, return of part of the undle will
void any special pricing and the item(s) remaining in the possession of the cus-
tomer will revert to their regular Suggested Retail Price (SRP). The credit, to
customer, will reflect the difference of the actual product SRP from the amount
of credit due customer.
Shipping Costs
All shipping costs, VAT, duties and return costs are sole responsi ility of cus-
tomer. If customer purchases thru Kaidan distri utor or reseller, customer is
responsi le for all shipping and VAT costs incurred y that distri utor or reseller.
These charges are non-refunda le.
For instructions on the return of your product, follow the Product Return
Procedure elow
D • Product Return Procedure
When returning a product, customer must first contact Kaidan (or the dis-
tri utor/reseller) and o tain a Return Material Authorization Num er (RMA#).
After receiving the RMA#, customer will e instructed to return product directly
to Kaidan. Returned goods must e shipped with an approved tracea le service,
such as FedEx, and with appropriate levels of shipping insurance for the item
eing returned. Kaidan will not e held responsi le for returned items lost or
damaged in transit. RMA num ers are valid for 15 days, and the product(s)
must e received y Kaidan efore the RMA expires. We are una le to accept for
return any product(s) received after the expiration of the RMA.
Return Packaging
The product packaging must reflect customer name, address, RMA# as well as
Kaidan information:
Kaidan Incorporated
703 E. Pennsylvania Blvd • Feasterville, PA 19053 • U.S.A.
Attention: Return Department per RMA# ______
Contact Information: Voice: 215-364-1778 • Fax: [phone]
http://www.kaidan.com • E-mail: [email protected]

Page-3
1SettingUpYourKiWi900/950™
UNPACKINGTHE BOX
The KiWi 900/950is shipped ina single boxandconsistsofthecomponentsde-
tailedbelow.Pleasemakesurethatallpartsareincluded.Examinethepartsfor
anysignsofshippingdamage.Intheeventofshippingdamage,immediatelycon-
tactKaidantoprocessclaims.Ifanyitemsaremissingoryounoticeanydamage,
callKaidanat215-364-1778,betweenthehoursof9:00AMand 6:00 PMEST,Mon-
Fri.
TheKiWi 900/950alsocomeswithtwodetentdiscs(14and18positions,not
shown)andacameraadjustmentshoe(attachedto theverticalbracket).
VerticalBracket
CaptiveCameraKnob
&MountingHolesfor
standard andwide
anglesettings
(Notvisible)
AngleIndicator
Friction Cap and
RetainingKnob
Twin-axis BubbleLevel
Access Hole for
Flash Sync
NikonCoolpixCamera
(notincluded)
Indexinghub

Page-4
REMOVING THE FRICTION CAP
TheFrictionCapneedstoberemovedinordertochangedetentdiscs.Thediscs
providethemeansforestablishingandchangingthenumberandspacingofthe
angularincrementsofthe tripod head.Thetwodiscsthatcomestandardwith
the KiWi 900/950 provide for14 and 18 shots per revolution.Use the 18 position
detentdiscwhen capturing images with the normal wide-angle setting of the
camera. Use the 14 position detent disc when using the optional Nikon 24mm
wide-anglelensfortheCoolpix900/950camera.
ToremovetheFrictionCap,loosenthesilvercoloredRetainingKnobwhichislo-
catedonthesideoftheFrictionCap.ItdoesnothavetoberemovedfromtheCap,
butonlybackedoutfarenoughtoallowtheCaptobeunscrewedfromtheaxle.
YoucanlookintotheopeninginthecenterofthecaptoseewhentheRetaining
Knobisclearofthehexagonal-shapedaxle.Rotatethecapcounterclockwiseand
removeitfromtheunit.
OncetheFrictionCaphasbeenremoved,separatetheVerticalBracketfromthe
IndexingHub.Youmightneedtowigglethepiecesasyoupullthemapart.
Retaining
Knob
FrictionCap
IndexingHub
Vertical Bracket

Page-5
REMOVING &REPLACING THE DETENT DISC
Oncethe Indexing Hubis removed,the detent disc canbe removed from its re-
cessinthebottomoftheVerticalBracket.ThediscmayslipoutoncetheIndex-
ingHubisremoved.Ifit sticksinsidetherecess,simplyinsertthetipofaballpoint
penora pin small enoughtofitintothedetentdiscejectionholeonthetopof
thebracketandpushthedetentdiscoutofthedetentdiscrecess.
With the disc removed,a different disc can be inserted to change the angular
spacing.The 14 position detent disc (includedwithyourbracket) is foruse with
theoptionalNikonwideanglelens(availablefromNikonfortheCoolpix900/950).
Toinstalla differentdisc,simplyalignthe keyedslotandpush the disc intothe
recess.Makesurethediscisproperlyseated andflushtothebottomsurfaceof
theVerticalBracket.Withthenewdiscinserted,reassemblebyinsertingtheIn-
dexingHubbackthroughthebearingintheVerticalBracket.
REPLACING THE FRICTION CAP
Replace the Friction Cap by threading the Cap back onto the axle. Continue to
threadthecapsothatthereisnofreeplaybetweentheVerticalBracketandthe
Indexing Hub. The rubberwasheron the bottom ofthe Friction Cap should be
slightlycompressed.Whenthedragfeelsadequate,turntheFrictionCapsothat
thethreadedshaftoftheRetainingKnobis alignedwiththe closestflatonthe
axle.TightentheRetainingKnobtolocktheCapinplace.
RubberWasher

Page-6
ADJUSTING THE DETENT FORCE
Thespringplungerthatprovidesthedetentactioncanalsobeadjustedtovary
theforce.Useaflatbladescrewdrivertomovetheplungerinandoutasdesired.
A convenientway to adjust the plunger is to screw the plunger all the way in
untilitgentlybottomsout.Thenunscrewtheplungeraboutonecompleteturn.

Page-7
2ShootingPanoramas
HOW MANY SHOTS?
TheKiWi900/950isdesignedtobeusedwith:
•Thenormalwide-anglesettingofthecameralens
•TheoptionalNikon24mmlens(screwon)
•OtherthirdpartylensesusablewiththeCoolpix900/950camera
Thenormalwide-anglesettingofthecamerawillrequirethe18positiondetent
disc.The24mmNikonlensrequirestheuseofthe14positiondetentdisc.
MOUNTINGTHECAMERA?
TheKiWi900/950alsocomeswithaCameraAdjustmentShoetohelpkeepyour
cameramountedvertically.Italsomakesiteasytoremoveandreplaceyourcam-
erainthesameposition.Beforethecameraisattached, loosentheknobonthe
CameraAdjustmentShoe.Oncetheknobisloosened,theshoecanslideforward
orbackwardstohelppositionthecamera.Youmayneedtoremovetheshoeand
repositionitagainsteitherthefrontorthebackofthecamera,dependingwhich
configurationisselected.
Camera
AdjustmentShoe
(Knobisonthe
otherside)

Page-8
MOUNTING THECAMERA?(CONTINUED)
The KiWi 900/950 is designed to be used at the standard wide-angle setting or
with the additional 24mm wide-angle Nikon lens.The two threaded mounting
holes directly above the slot on the camera bracket will position the camera at
itspropernodalpointsettingforeitherconfiguration.
The diagram below shows the propermounting holes for the camera . When
usingthecamerawiththestandardlens, FigureAshowsthepropermounting
withtheadjustmentshoebehindthecamera.
Whenusingthecamerawiththeoptional24mmwide-angleNikonlensmounted,
Figure B shows the propermounting with the adjustment shoe in frontof the
camera.
Note:theslotbelowthecameramountingholeswillacceptthecameraknoband
can be used to locate the camera in accordance with the nodal points of other
3rdpartylenses(seeChapter3forinstructions).
FigureA:
ViewofVertical Camera
Bracketwith camera
attachedusingthe
standardcameralens
Figure B:
ViewofVertical Camera
Bracketwith camera
attachedusingthe24mm
wide-angleNikon lens
Cameraadjustment
Shoe andknob Cameraknob
Cameraadjustment
Shoe andknob
Cameraknob
MountingHolefor
standardcameralens
MountingSlotfor
usewith3rdparty
lenses&the Camera
AdjustmentShoe AccessHolefor
external FlashSync
connection
MountingHolesfor
otheraccessories
(FlashBracket,
Sunshade)
Mounting Holeforusing
wide angle Nikon lens

Page-9
TAKING THE PHOTOS
TheKiWi900/950hasafemale1/4-20threadonthebottomoftheIndexingHub
formountingtomoststandardtripods.Whenreadytoshoot,makesurethat
theKiWi900/950issecurelyattachedtothetripod. Useatripodthatissturdy,
ideallyonethathasacentersupportsystemofbracestohelpkeepthecamera
andKiWi900/950fromexcessiveflexing.
Itmaybepossiblethatyourtripodusesalarger3/8inchthread.Ifthisisthe
case,youcanpurchasea3/8to1/4adapteratacamerastoreorphotographer
equipmentsupplier.
Whenreadytoshoot,itisimportantthattheunitislevel.Observethetwin-axis
bubblelevelontheKiWi900/950whilelevelingthetripod.Ofcourse,thistaskis
mucheasierifthetripodisequippedwithatilthead.Ifthetripoddoesnot
haveatilthead, aQuickTilt™levelercanbepurchasedfromKaidanforusewith
theKiWi900/950.
OncetheKiWi900/950 islevel,doublechecktoseeifthecameraismounted
levelinelevation.UsetheCameraAdjustmentShoeandplaceitagainstthe
camera.Byplacingtheshoesnuglyagainstthecamera,itwillhelptovertically
alignandpositionthecamera.
You’renowreadytobegincapturingyourfirstpanorama.Youshouldalso,at
thistimereviewthedocumentationofthepanoramicstitchingsoftwarethat
isbeingusedinordertogetrecommendationsforexposuresettingsandother
camerasettings.

Page-10
3UsingOtherLenses
HOW DOILOCATE MYCAMERA’SNODAL POINT?
ThepriorinstructionscovertheNikonCoolpixstandardlensandtheNikonwide-
angle lens.Since the Coolpix900 series has a threaded barrel,you can screw on
other 3rd party lenses.These lenses will have a different mounting location,or
nodal point, along the bracket, and you’ll need to discover this location.Follow
thesestepsandyou’llbeabletoeasilylocatethenodalpointforanycameraand
lenscombination.
Simplyput,the nodalpointisthepointinsideyourcamerawherethe lightrays
convergeandflipover.Whenshootinganimmersivepanorama,it’snecessaryto
rotateaboutthispointtoeliminatetheimagemismatchcausedbyparallaxer-
ror.
Parallaxerrorcan be easilydemonstratedbythis simple experiment.Closeone
eyeandholdyourindexfingeruprightaboutsixinchesawayfromyouropeneye.
Rockyourheadfromsideto side.Noticehowyourfingermoveswithrespectto
thebackground.Thisrelativemovementisduetothefactthatyou’renotrotat-
ingyourheadaroundyoureye’snodalpoint,whichissomewhereinthecenterof
youreyeball.Instead,you’rerotatingaboutyourspinewhichisseveralinchesto
therearandofftooneside.Itisthisrelativeside-to-sidemotionthatwewillstrive
toeliminatewhensettingupacameraforVRpanoramas.
STEP 1:THE EASY PART -THE SIDE-TO-SIDE ADJUSTMENT
OncethecameraisfastenedtotheKiWi900/950PanHead,thecenterofthelens
willbedirectlyoverthepivotaxis.Noside-to-sideadjustmentwillbeneeded.

Page-11
STEP 2:THE SLIGHTLY HARDER PART -FORE-AFTADJUSTMENT
Put the Captive Camera Knob in the long slot of the Vertical Bracket. This will
allowyou to slide the camera (along with the CameraAdjustment Shoe) as re-
quired.Note:Thisstepismosteasilyaccomplishedoutside.Findaverticaledgeor
line,suchasadoorwayoredgeofabuilding.Position the unitandtripod about
fourfeetaway,or as close as possible with the edge still in focuswhen looking
throughtheviewdisplayedontheLCDscreenofthecamera.
Lookingatthecamera’sLCD,findanotherverticaledgeorobjectthatisfaraway,
suchasanotherbuildingortelephonepole.Alignthetwoobjectsandrotatethe
VerticalBracketsotheyareinthelefthandsideoftheviewfinder.
Rotatethepanhead so the twoobjectsmoveoverto the righthandsideofthe
viewfinder. Unless you’ve managed to unwittingly locate the right nodal point
position,youshouldnoticethetwoobjectswillmovewithrespecttoeachother
astheVerticalBracketisrotated fromlefttoright.Slidethecameratothefront
orrearasrequiredtoeliminatethisrelativemovement.
Looking throughtheviewfinder,alignacloseobject(brickwall)witha faraway
object(telephone pole).Asthecameraisrotatedfromside-to-side,thereshould
benorelativemovementbetweenthetwoobjects.
If,asshowntotheright,thetwoobjectsmovewithrespecttooneanotherin
theviewinder,slidethecameraforeoraftinordertoeliminatethismovement.
Here,thetelephonepolehasmovedbehindthebrickwall.
Good.
No relative movement
betweenobjectwhen
rotating camerafrom
sidetoside.
Bad.
Relativemovement
betweenobjectwhen
rotating camerafrom
sidetoside.

Page-12
STEP 3:DETERMINING THEACTUAL POSITION
IfyouwereusingaSLRcamerainthepreviousstepsyoucouldhavelookedthrough
theviewfinderinordertodeterminethenodalpoint.However,withtheCoolpix
900series,theviewfinderisnotviewingtheexactsameimageaswhattheCCD
(imagingchip)isseeing.Therefore,inordertoaccuratelydetermineatwhatposi-
tion along the slot does the nodal point lay,you’ll need to take a series of test
shots.
Thebestwaytodothisistostartwiththecameraatthefrontmostpositionof
theVerticalbracket.Usingtheobject-alignmenttechniquementionedpreviously,
takeasequenceofleft-rightpairsoftestshots.Eachpairwillhavethevertically
aligned objects in the left and then the rightside ofthe viewfinder.Aftereach
pair of photos,slide the bracket rearward a small amount and repeat the pro-
cess.Slide the bracketthesame incrementeachtime(i.e.10mm).Placing a tem-
porarystripoftapeinordertomeasureandmarktheincrementsshouldmake
iteasiertorecordyourresults.Besuretorecordthescalesettingforeachpairof
images.
Whenyou’redone,youshouldhaveapairofleft-rightimagesforeachpositionof
the camera along the slot. Transfer the images to your computer and inspect
eachleft-rightpair.You’relookingforthepairofimagesthathastheleastrelative
movementbetweenthenearandfarobjects.Gobacktoyourrecordedmarkings
and determine which location on the tape corresponds to the best pairof im-
ages.
Insomecasesyoumightfindthatnopairofimagesisoptimum.Inthatcase,you
should lookforthe two pairs thatare closest and reshoot a testpair between
thosepairs.Withalittletrialanderroryouwillbeabletoaccuratelydetermine
thenodalpointforanylens.
Onceyou’vefoundtheposition,youcanmarkthatlocationwiththeCameraAd-
justmentShoeorleaveapieceoftapeasamarkerforfuturereference.

Page-13
KW-900/950ADDENDUM
Wehaveincludedafrictionpadcorkstrip to be usedwith
theCoolpix950camera only.See Fig.Abelowforthe correct
placement.NOTE:Ifyou areusingtheCoolpix900 camera
thecorkdoesnotneedtobeinstalled.
5 JUNE 2000
FIG.A
