INSTRUCTION
MANUAL
VirtuaLine™ PRO LED Line Projector

Notice
This document and its contents are the intellectual property of Laserglow.com Limited (hereafter referred to as
"Laserglow") and are intended for use only by Laserglow customers for the purpose of operating their Laserglow products.
Unauthorized reproduction or distribution is prohibited without express written consent from Laserglow. An exception is
granted for personal archival copies, distribution within an organization which is itself a customer of Laserglow or
transferring this document to a new owner upon sale of the product. Careful and reasonable efforts have been made to
ensure the quality and accuracy of this document, but Laserglow shall not be liable for errors or omissions contained
herein, or for any incidental or consequential damages arising from the use of this document or the product itself. Safety
information provided in this document is for reference only and should not be considered an adequate substitute for
industry-standard laser safety training. Laserglow recommends that the Customer consult with a Certified Laser Safety
Officer before using any type of laser device for any application. Failure to heed the recommendations, warnings, and
safety information provided herein may result in property damage, serious injury, or death. Please read this entire
document before attempting to operate the product and always store these instructions with the product.
Introduction
Thank you for purchasing the Virtualine™ LED PRO light fixture from Laserglow. This fixture is designed to provide a
bright and highly visible line for hazard awareness and a wide range of other industrial and commercial applications. This
manual contains complete instructions on how to set up and operate your Virtualine™ LED PRO, descriptions of all
features, and some troubleshooting tips. If after reading this manual you still have questions about the safe and proper
operation of your projector, please contact us and we would be happy to assist you. Our contact information is listed at the
bottom of this page.
laserglow.com/industrial VirtuaLine™ PRO LED Line Projector

laserglow.com/industrial VirtuaLine™ PRO LED Line Projector
Table of contents
Section 1: Safety Information
Section 2: Unpacking and Inspection
Section 3: Setup and Operation
Section 4: Troubleshooting
Section 5: Maintenance
Section 6: Warranty Information

laserglow.com/industrial VirtuaLine™ PRO LED Line Projector
Section 1: Safety Information
READ THIS FIRST
Keep flammable materials away from the fixture (minimum distance to flammable material is 1 foot / 30 cm).
Place the Virtualine™ LED PRO in a location that has good air flow.
Do not look directly into the light source; it is extremely bright.
Always disconnect the fixture from power before performing any service on the unit.
ELECTRICAL SAFETY
Use only a power source that complies with local building and electrical codes and which has both overload
and ground-fault protection.
Disconnect the fixture from power before handling.
Do not use the fixture if the power cable or power plug is in any way damaged, defective, or wet, or if they
show signs of overheating. If the power cable or plug for the fixture is damaged, it must only be replaced by
Laserglow or an authorized service agent to avoid an electric shock or fire hazard.
The light source contained in this luminaire shall only be replaced by Laserglow or an authorized service
agent.
Light fixtures should be installed and maintained only by qualified personnel with experience in lighting
equipment and general electrical experience.
When suspending the fixture above ground level, verify that the structure can hold at least 10 times the
weight of all installed devices. Use the safety cable to secure the fixture in addition to the primary mounting
bracket.
The Virtualine™ LED PRO is suitable for indoor use only.

laserglow.com/industrial VirtuaLine™ PRO LED Line Projector
Section 2: Unpacking and Inspection
This product was shipped to you wrapped in a double-walled box to protect it from damage during storage and transit.
However, unexpected things can occur during shipping, so it is important to inspect and test your product as soon as it
arrives. Claims for shipping damage must be made within 7 days of receipt. Beyond this time, any damage to the product
will be considered to have occurred while it was in your possession, which may void your warranty.
2. Unpack the Virtualine™ LED PRO and power supply: Carefully remove the projector from the box and
inspect it for any physical damage which may have occurred during shipping, then do the same for the power
supply, if included. If any physical damage or moisture is present, contact Laserglow immediately to report it.
1. Inspect the shipping carton: Look for obvious signs of damage or exposure to moisture. If either are
present, contact Laserglow immediately for instructions on how to proceed. In the unlikely event that the
product is damaged this information may be important for filing a claim with the carrier.
3. Check the contents of the shipment against the packing list: Every fixture¹ includes a mounting
bracket² and power supply³. If you ordered multiple products, check the packing list and make sure that all of
the listed items are present. If everything is included and there is no evident damage, proceed through this
manual for instructions on how to set up and install your Virtualine™ LED PRO. If there is any discrepancy,
please contact Laserglow immediately.
2
1
3

laserglow.com/industrial VirtuaLine™ PRO LED Line Projector
Section 3: Setup and Operation
You will receive Virtualine with mounting bracket attached
to the unit as shown in fig. Ideally, it is recommended to
use the marked holes to mount the unit on Ceiling or any
other available mounting surface.
CAUTION: The magnets in the magnetic mount accessory are very powerful! Do not allow the magnets to slam together,
as this may damage the magnets and they will be very difficult to separate. NEVER PUT YOUR FINGERS BETWEEN
THE MAGNETS AND THE MOUNTING SURFACE OR OTHER MAGNETS. The magnets are strong enough to cause
serious injury! The heatsink on the back of the Virtualine LED PRO must be kept clear to allow adequate airflow for
cooling. Do not cover the heatsink with any material.
Then affix the Virtualine™ LED PRO to your mounting
surface using hardware designed for that type of
mounting surface (drywall anchors for drywall without a
stud, concrete screws for concrete). Once the fixture is in
place, clear any dust or debris out of the rear heatsink
area before powering on the fixture.
Finally, be sure to loop the included steel safety cable
through the eyelet on the back of the Virtualine™ LED
PRO and around the nearest secure object, pipe, or rail.
This is to prevent injury in the unlikely event that the
primary mount fails.
If you purchased the magnetic mount accessory, your
mounting bracket will already have the magnets installed.
Simply stick the magnets to the desired surface and loop
the included steel safety cable around the attachment
point to prevent the fixture from falling if the magnets fail.
The magnets hold with approximately 90 pounds (41 kg)
of force.
1 2
3 4
✔

laserglow.com/industrial VirtuaLine™ PRO LED Line Projector
The projected line can be focused by rotating the small
red knob on the back of the fixture. Adjust until the line is
as thin as possible. There will only be one ideal focus
position.
5
X
✔
The projector does not have a power switch and will turn
on as soon as power is connected.
6
NOTE: When installing the power supply, do not add cable extensions between the power supply and the light fixture.
The length of cable between the power supply and fixture should be as short as possible (6 feet maximum, 3 feet or less
recommended). Any extensions required to bring power to the projector should be added on the AC side of the power
supply.
MOUNTING RECOMMENDATION
To produce the clearest possible projection, it is recommended that the Virtualine™ LED PRO be mounted directly above
the center point of the projected line. Mounting the fixture near one end of the line will cause the far end of the line to lose
focus, which will cause it to appear wider with more blurry edges. Mounting the fixture off to one side of the line, such as
on a wall, will cause the line to appear wider and with more blurry edges, particularly the far edge. In many environments it
will not be possible for the fixture to be mounted directly above the center of the projection, for example due to
obstructions or other obstacles. If this is the case, it is recommended to mount the fixture as near as possible to the ideal
position to minimize distortion of the projected line.
It is normal for the ends of the line produced by the Virtualine™ LED PRO to fade out to nothing over a distance, and for
the middle of the line to be the brightest area.
✔
✔

laserglow.com/industrial VirtuaLine™ PRO LED Line Projector
X X
WALL MOUNTING This mounting type will distort the line
projection to an elliptical shape – thicker in the middle,
thinner at the edges.
IDEAL MOUNTING Unit should be mounted
perpendicular to the surface exactly midway of the
desired projected length. E.g. if the unit produces a 20ft
line from the defined mounting height, the unit should be
mounted 10ft away from the start of the line
OFFSET MOUNTING This mounting type will distort the
line projection to a conical shape – thinner closest to the
units, wider it moves away. Also, the line intensity will
scale brighter to fainter as you move further away.
✔
CREATING A PATHWAY USING MULTIPLE UNITS
To create a continuous line, Virtualine™ LED PRO units
should be evenly spaced from each other at the same
distance as the projected line length. For optimal results,
the ends of the line from each projector should be
overlapped slightly to create a continuous line as shown
above.

laserglow.com/industrial VirtuaLine™ PRO LED Line Projector
Section 4: Troubleshooting
If you are experiencing trouble with your projector, please check if the symptom is listed in this guide. Many common
problems can be solved without requiring a return. If you need further assistance, please contact us. Do not attempt to
disassemble or repair your projector, as this may void your warranty.
Solution
Check the electrical source to ensure that it is turned on.
Try disconnecting and reconnecting the power supply to the fixture.
Mount the fixture directly above the midpoint of the line being
projected on the floor, or as close to this point as possible.
Mount the fixture directly above the midpoint of the line being
projected on the floor, or as close to this point as possible. Or adjust
the focus until the projected line is as narrow as possible.
The lens fan angle cannot be changed by the user. Contact Laserglow
for assistance.
Adjust the focus until the projected line is as narrow as possible.
Problem
No light emitted from fixture.
Line is blurry on one side.
Line is thin at one end, but
wide at the other end.
Line is not long enough.
Projected line is very blurry or
washed out.
Possible Cause
Power supply is not receiving electricity.
Power supply connection loose.
Fixture is mounted to the side of the
projected line.
Fixture is mounted near one end of the
line or Focus is not set correctly.
Wrong lens fan angle for application.
Focus is not set correctly.

laserglow.com/industrial VirtuaLine™ PRO LED Line Projector
Section 5: Maintenance
Laserglow's Virtualine™ LED PRO fixtures require very little maintenance. Depending on the cleanliness of your
environment, maintenance may be required with some regularity, or never at all. Inspect the fixture regularly to ensure
there is no buildup of debris or dust on the output lens or rear heatsink.
CLEANING THE OUTPUT LENS
Depending on the operating environment, it is possible that some dust may accumulate on the output lens of the projector.
You can use a can of clean compressed air to try to blow the dust off of the lens or use a soft cloth to wipe away any
debris. Do not use alcohol or any other chemicals to clean the lens – doing so may cause irreversible damage to the lens
and is not covered under warranty.
If these steps fail to improve the quality of the beam please contact us for further assistance.
NEVER USE tissue paper, paper towel, facial tissues, etc. The wood fibers in these products can damage
the coatings on the lens.
NEVER USE cleaning solutions other than those explicitly mentioned here. The lens coatings are
delicate and can be damaged by common cleaning products. NEVER touch the lens or other optics with your
fingers as oil from your skin can contaminate and damage the coatings. Failure to follow these warnings can
result in damage to your laser which will not be covered by warranty.
1. Compressed air: You can use a can of clean compressed air to try to blow the dust off of the lens without
making physical contact with the lens itself. These are commonly used to clean computer keyboards and can
be purchased at any office supply store. They usually have a long tube or nozzle attached to them. Carefully
insert this tube a few mm into the aperture of the laser to blow air over the lens. Be careful not the touch the
lens with this tube. Hold the can upright or it may produce some liquid which can leave deposits on the lens.
2. Microfiber cloth: If there are deposits on the lens that cannot be removed with compressed air, you can
try using a microfiber lens cloth to gently wipe the output lens. Ensure that the microfiber cloth is clean before
you use it, since any oil, dirt, or grit may damage the lens. Since the lens is slightly recessed in the housing,
you may need to twist the microfiber cloth into a small "finger" to get it deep enough into the aperture to make
contact. If you still cannot reach the lens with the cloth, you may need to remove the aperture cap from the
front of the laser: DISCONNECT THE POWER BEFORE PROCEEDING. Remove the three set screws from
the aperture cap and thread the cap all the way off. The output lens should now be exposed, and you can
attempt to clean it using the microfiber cloth.
3. Microfiber cloth and lens cleaning solution: If a cleaning solution is required use ONLY a specifically
designed lens cleaning solution. (Available from camera stores or optics companies.) Use a very small
amount and wipe the lens only with a microfiber lens cloth. Do not use any other type of cleaning solution or
you may permanently damage the lens.

laserglow.com/industrial VirtuaLine™ PRO LED Line Projector
Section 6: Warranty Information
LIMITED PRODUCT WARRANTY
Laserglow Technologies ("Laserglow") warrants that this product is guaranteed to operate within the stated specifications,
free from defects in materials and workmanship, for a period of twelve (12) months from the date of delivery. BEFORE
RETURNING ANY ITEM FOR SERVICE, PLEASE CONTACT LASERGLOW TO RECEIVE A RETURN
AUTHORIZATION (RA) NUMBER. ITEMS RETURNED WITHOUT AN RA NUMBER MAY INCUR DELAYS OR
ADDITIONAL FEES.
LASERGLOW'S PLEDGE TO CORRECT PROBLEMS UNDER WARRANTY
At its option, Laserglow will either repair or replace the in-warranty defective unit without charging the customer for costs
of repair or replacement. When parts or products are replaced under warranty the replaced items will automatically
become property of Laserglow. Once an item has been repaired or replaced under warranty, the repaired or replacement
item assumes the remaining period of warranty based on the original date of delivery, plus the period of time during which
the laser was out of the customer's possession. Within North America only, and within the first 30 days of the warranty
period, Laserglow will cover the cost of shipping the defective item back to Laserglow and the cost of shipping the
repaired/replacement item to the customer. After 30 days, or for overseas shipments, the customer will cover the cost of
shipping the defective item back to Laserglow and Laserglow will cover the cost of shipping the repaired/replacement item
to the customer. Where Laserglow covers the cost of shipping, the carrier and method of shipping will be at Laserglow's
discretion. Items returned to Laserglow as warranty issues, which upon inspection are deemed not to have any defect, will
incur a diagnosis service charge of $119.
NOT COVERED UNDER THIS WARRANTY
This warranty will become void if any of the following conditions are met:
• The product has been modified or tampered with in any way.
• The product has been dropped or subjected to shock in excess of 100 G.
• The product has been exposed to water, any liquid, or condensing atmospheric humidity.
• The unit was powered from a source other than those which are specified in the instruction manual.
• The unit was operated in an area with ambient temperature outside of the operating temperature range, as stated in the
product specifications and instruction manual.
• The serial number or other identifying marks are removed.
• Ownership of the product has changed. (This warranty is not transferable).
• The warranty period has expired.
NEITHER THIS WARRANTY NOR ANY OTHER WARRANTY OR GUARANTY, EXPRESSED OR IMPLIED STATUTORY OR OTHERWISE,
INCLUDING ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL EXTEND
BEYOND THE WARRANTY PERIOD. NO RESPONSIBILITY IS ASSUMED FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING,
WITHOUT LIMITATION, DAMAGES RESULTING FROM PRODUCT MALFUNCTION, INACCURACY, OR MATHEMATICAL INACCURACY OF THE
PRODUCT SPECIFICATIONS. NOTHING IN THIS WARRANTY AFFECTS YOUR STATUTORY RIGHTS.

laserglow.com/industrial VirtuaLine™ PRO LED Line Projector
OTHER BENEFITS (NON-WARRANTY) THAT ARE ACCORDED TO YOU BY LASERGLOW
10% Replacement/Upgrade Credit: At any time, for the lifetime of the product, you may return the product to us in any
condition, functional or not, for a trade-in credit equal to 10% of the original purchase price or 10% of the current retail
price, whichever is less. The new product which you select must be of equal or greater value than the trade-in product,
based on the value used to calculate the 10% credit amount.
Out-of-Warranty Repairs
The cost of any out-of-warranty repair will be $100/hr for labor, plus materials.
Rebuild/Complete Product Refurbishment
The cost of a complete rebuild or refurbishment of an out-of-warranty product will be no more than 60% of the current
retail price.
LASERGLOW TECHNOLOGIES
99 Ingram Dr. Unit B
North York, ON, M6M 2L7, Canada
[phone]
Fax: [phone]
