Lawnba HEDGEBOT TC-G158 lead-acid User manual

Please read this manual carefully before use
Please keep this manual for future reference ROHS
USER MANUAL

CONTENTS
1. INTRODUCTION AND SAFETY 1
2. PRESENTATION 3
3. INSTALLATION 6
4. REMOTE CONTROL 10
5. USE 10
6. MAINTENANCE AND STORAGE 11
7.TROUBLE SHOOTING 13
8. EXPLODED VIEW 15

IMPORTANT!
Robot lawn mower can be dangerous
if incorrectly used!
WARNING
The following pages contain important safety and
Carefully read and reviewinstructions in this manual.
all safety instructions, warnings and cautions contained
in this manual.
Failure to read and follow these instructions, warnings
and cautions statements may result in severe injury or
death to persons and pets or damage to personal
1. INTRODUCTION AND SAFETY
operating instructions. Please read and follow all
property. It’s not permitted to modify the original design
1. INTRODUCTION AND SAFETY
1.1 Introduction
The products are manufactured by POWERDECAL
HOLDINGS, LLC.
Thank you for purchasing our product.
You'll enjoy the extra free time while using our robot
lawn mower to mow your lawn. You will be impressed
with your lawn's appearance and best of all,
HEDGEBOT will have done it for you.
The robot mower may be used only by those who
know how to operate it after reading and
understanding the instructions in this manual.
Model: TC-G158
CE, RoHs approved.
Product, product specifications and this document are
subject to change without notice. All other trademarks
are property of their respective owners.
1. INTRODUCTION AND SAFETY1. INTRODUCTION AND SAFETY1. INTRODUCTION AND SAFETY
IMPORTANT INFORMATION
Read through the Operators Manual
carefully and understand the content before
using your Robot.
1.2 Symbols on Mower
These symbols can be found in the mower. Study them
carefully so you understand their significance.
WARNING
3. Specifications symbol
Pasted on mower Pasted on charging station
: Waste electrical products should not be disposed
waste. Please recycle where of as household
Authority or facilities exist. Check with your Local
ADDRESS: XX
Taizhou Tianchen Intelligence &Electrics Co,Ltd
Product name: Robot lawn mower
Model: XXXXX IPX4
Input: XXX V --- 2A 85W
20XX
Made in China
S.N.:XXXXXXXXXXX
RoHS
S.N.: XXXX XX XX XXX
year month date number
Product name: Robot lawn mower
Model: TC-G158 IP54
Input: 24-29.4 V 4A 85W
Made in China
ROHS
S.N.:XXXXXXXXXXX Address:XX
Product name: Robot lawn mower
Model: TC-G158 IP54
Input: 24-29.4 V 4A
Ouput 24-29.4
4A
: V
Made in China
ROHS
POWERDECAL HOLDINGS, LLCPOWERDECAL HOLDINGS, LLC
retailer for recycling advice.
of robot. All modifications are made at your own risk.
- 1 -
1. The symbol is pasted on the top cover,
Please read the means carefully before use
the appliance.
WARNING
Severe injury or death may cause
if incorrectly lift the mower.
Carry the mower by the handle at the rear under
the mower. Carry the mower with the blade device
away from the body.
1 2
0
54 6
7 8 9
1. WARNING-this is a dangerous power tool. Use care when operating and follow all
safety instructions and warnings.
2. Read the owners/operating manual carefully and follow all safety instructions
before operating the machine.
3. Objects can be thrown from mower while operating, keep a safe distance from the
machine when operating, take caution.
4. Keep children, pets and bystanders away from mower when operating.
5. WARNING-Operate the disabling device before working on or lifting the machine.
6. Never use a high-pressure washer or even running water to clean the mower.
7. Sharp rotating blades. Keep hands and feet away and do not attempt to lift mower
from this area.
8. WARNING-Do not ride on the machine.
2. Handle

1. INTRODUCTION AND SAFETY
This label is pasted on chargingstation, please make
sure to position this side towards lawn interior. Failure
to do may result in damage to property or persons.
DANGER! Sharp rotating
blade. Keep hands and feet
injury can away. Serious
4. Charging station symbol.
5. Warning symbol.
occur.
1.3 Symbols in the User Manual
These symbols can be found in this user manual.
A warning box indicates a risk of personal injury exist.
An information box indicates a risk of material damage
exist, especially when the stated instructions are not
followed. The box is also used where there is a risk of
WARNING
xxxxxxxxxxxxxxxxxxxxxxxxx.
IMPORTANT INFORMATION
xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx.
user error.
1.4 Safety instructions
- Read the owners/operation manual carefully and
and warning instructions.follow all the safety
- This machine has sharp rotation blades! Never allow
operate unattended; keep bystanders,the mower to
mower when in operation.children and pets away from
- Never allow anyone to ride or sit on mower.
- Never allow anyone or person who is not familiar with
of the mower to operate the mower.the safe operation
- Keep hands and feet away from the cutting blades
and parts.other moving
- Never attempt to service or adjust the mower while it
- Inspect and clear the mowing area of all debris (toys,
items of clothing, anything with a heighttree branches,
mower.less than 6cm) before operating the
- Never raise the mower or attempt to inspect the
is operating.blades while the mower
- Always turn off the power before lifting the mower or
adjustment.attempting any
- When operating the mower in manual mode, maintain
wear proper foot apparel.
- Do not operate the mower on slopes greater than 30
a firm footing is not possible.
device is damaged or inoperable.
- Do not attempt to disable or defeat any safety feature
is in operation.
from behind or around the mower anda safe distance
manual operation on slopes wheredegrees or use it in
- Do not operate the mower if any safety feature or
or device.
- Use heavy gloves when inspecting or servicing the
- Wear eye protection and use gloves when installing
driving the wire stakes/pegs. Firmlythe virtual wire and
wire from becomingdrive all pegs in order to keep the
- Do not use the charging station power supply with an
- Use only the original equipment power pack and power
with this mower.supply/charger
- Do not use the power supply/charger if the cord has
- Do not place metal objects in the area of the charging
charging station.sheets on the
- Do not place metal objects across the charging heads
- Do no spray water directly into the docking area of the
or onto the control panel on chargingcharging station
- The mower has sharp rotating blades! Please care the
mowing, in case of serious injury occur.mower when it is
- Keep the lawn mower in perfect operating conditions
maintenance procedures outlinedby performing the
maintenanceby the manufacturer. Good guarantees
better performance and longer service life.
- In order not to irreversibly damage electric and
wash the robot with water jetselectronic parts, do not
partially orat a high pressure and do not plunge it
- It is absolutely forbidden to use the robot in explosive
environments.and flammable
- The operator or user is responsible for accidents or
other people or their property.hazards occurring to
blades.
a tripping hazard.
extension cord.
become damaged.
of the mower.
station.
thoroughly in water, as it is not watertight.
- Fill up all small holes and even all small mounds inside
working area. It’s to keep the robot with perfect operating.
CAUTION!
Position this side of the Charging Station
towards lawn interior.
DANGER
- 2 -

32313029
28
27
2625
24
23
22
12
13
11
10
14
9
1
232 2
3
2. PRESENTATION
Consumable parts:
1. Blades
2. Virtual wire
3. Virtual wire connectors
4. Pegs
5. Stakes
6. Remote control battery
7. Inner hexagon spanner
2. PRESENTATION
This chapter contains information you should be aware of before installation.
2.1 What’s in box
- 3 -
8. Rear running wheels
9. Front wheels
8
7
456
19
18
17
20
15
16
21
1 Handle
2 Bumper:
To change direction when it
bumps obstacles.
3 Charging head
4 Emergency switch:
Press it at any time, the mower
turns off at once.
5Charging terminal:
Connect with charger for recharge
directly.
6Rain sensors:
Mower goes back to charging
station automatically when it rains.
7Power light
8Key switch:
on
off
99
15
Virtual wire light
Red: broken wire/idle
Colorless: good wire connecting
17 Charging light
Red: charging
Green: fully charged or idle
18 Charging terminal
19 Virtual wire terminal
20 Charging sheet
21 Stakes hole
22 Charger
Used for directing the mower to
charging station or for recharge
directly.
23 Virtual wire / 100m
Used to mark mowing area and
create a virtual wall for the mower.
24
Stakes / 4pcs
Used for fix the charging station to
ground.
25
Blades
Two 4cm blades pre-installed on the
mower and two 3cm blades extra.
28
26
Pegs / 100pcs
Used for fix the virtual wire to the
ground around the lawn perimeter
and around obstacles.
Remote control
front wheel
29
Key / 2pcs
30
31
32
Remote control battery
User manual
Wire connectors
Inner hexagon spanner
10 Blade
11 Safety fence:
To keep o ff feet and hands
12 Handle
13 Blade shield
14 Wheel shell
16
Home button
Press this button, mower goes back
to charging station.
27

2. PRESENTATION
2.2 Function of TC-G158
There are tilt sensors installed on the mower too, when
mower is tilted over 30 degrees in any direction, it the
seconds.stops working within 2
- Lift sensor
There are lift sensors located in the front wheel.
If the mower is lifted from ground, it will stop
working within 1 second.
- Tilt sensor
- Two cutting modes
-
wire in auto mode. (we suggest to use 100m-600m of
virtual wire).
The mower will follow virtual wire to charging station,the virtual
on the virtual wirewire acts as a virtual fence. It will get
wire and starts cutting inside.
- Mower stops working if virtual wire is cut off or
power off.charging station is
- Overload protect
Virtual wire
The robot lawn mower can't be operated without a virtual
- Gyroscope
The mower has gyroscope system to keep it
until it meets charging sheets, then it gets off from virtual
- 4 -
going straight on inclines.
The mower should be turned on by key. And it can’t
start working without a matching charging station.
- Cutting width: 28cm
- Cutting height selection
There are two choices, 3cm and 4cm.
- Auto recharge system
When the mower senses a low battery situation, it will
shut off the cutting motor and search for the virtual wire.
then it will follow the virtual wire to the charging station
for recharge automatically. Once charging is completed,
the mower will back up a few centimeters and enter in
in stand by mode.
- Emergency stop switch
There is an emergency stop switch located on the back
of mower in red color. If you press it in any case
during operating, the mower must stop all movement and
stop the rotating of blades immediately. Rotate the switch
to reset it.
Each of the two blade motors and the two wheel driving
motors are continuously monitored during operation
in case any situation that may cause overload to these
motors.
Once detected, the mower will stop operating.
- Bump sensors
There are bump sensors equipped at the front of mower.
they will activate when the mower strikes solid, fixed
object when that object is at least 6cm in vertical height
from the supporting surface of the mower. When the
bump sensor is activated, the mower will stop movement
in that direction and reverse itself away from the
obstacle.
- Rain sensors
There are two rain sensors on top cover of mower. The
mower will go back to the charging station automatically
when it's raining.
- Wireless remote controller
- Anti-theft function
If virtual wire is cut or broken, or the charging
station loses power, the mower will stop working within 3
seconds
- Three steps to safely start the mower
1. Connect charging station to power supply by charger
and make sure the recharging light is green in color.
2. Connect virtual wire to charging station and make sure
the connection is strong (virtual wire light colorless).
3. Turn on the key switch and release the emergency
switch.
There are two cutting modes of the mower, go straight
efficiency).and go circle (high
In Auto, mower selects cutting mode intelligently.
It goes straight if the grass is sparse or it has been cut off,
long.and it goes circle if the grass is dense or
In manual mode, the mower will just go where you direct it.
Waterproof design, there is an inner cover under top
inside parts from humidify. cover which protect
The waterproof class is I
P54.
- Waterproof

2. PRESENTATION
2.3 Technical date
2.4 Working route
- 5 -
Model
Coverage(for once charging)
600m ±20％
1500m ±20％
Working capacity
56*51*25cm(LWH) 56*51*25cm(LWH)
21KGS 18KGS
18KGS 15KGS
Mower size
Gross weight
Net weight
82W 82W
≤65db ≤65db
2pcs
2pcs
3cm, 4cm 3cm, 4cm
28cm 28cm
25m/min 25m/min
30degree Max slope
30degree Max slope
40℃40℃
Qty for cutting blades
Blades rotate speed
Max ambient functioning temp.
Power
Noise
Cutting height
Cutting width
Cutting speed
Hill capability
Mower technical data
PS:
How large an area is mown per once recharge
depends primarily on the condition of the blade
and the type of grass, growth rate and humidity.
The shape of garden is also significant. If the
garden mainly consists of open lawns, mower
600m
100m
Virtual wire maximum length
Standard virtual wire length
Charging station size
Charging station and virtual wire
TC-G158 lead-acid TC-G158 lithium
45*38.5*20cm(L W H)
2
2
Intelligent lawn testing
Rain sensor
Auto recharge
Intelligent spiral
Go straight
Anti theft
Lift sensor
Tilt sensor
Bump sensor
Waterproof
Emergency switch
Rain sensor
Functions:
≤3hours ≤3hours
Lead-acid battery Lithium battery
7.2Ah 6.6Ah
2-3hours 2-3hours
Average working time
Type of battery
battery
Charging time
Mower can’t be started when
virtual wire has been cut
Mower can’t be started when
charging station is out of power
can mow more per hour than if the garden
consists of several small lawns separated by
trees, flower beds and passages.
4000rpm±10% 4000rpm±10%
600m ±20％
2
1500m ±20％
2

- Read the instructions carefully. Be familiar with the
proper use of the mower.controls and the
- Never allow people unfamiliar with these instructions
the mower. Local regulationsor children to use
- The operator or user is responsible for accidents or
to other people or their property.hazards occurring
3.2 Hardware adjustments
3. INSTALLATION
3. INSTALLATION
This chapter describes how you to install this mower.
Before starting the installation, read the previous
chapter.
Read the whole of this chapter before starting the
installation. How the installation is made also affects
how well the mower will work. It is therefore important
to plan the installation carefully.
3.1 Preparations
Training
may restrict the age of the operator.
3. Close the clamshell.
Cutting height explanation (3cm level in example)
3.3 Charging station installation
Choose best installation place. Please make sure it is
flat and there is no water,
magnetic interference or obstacle in the front of
charging station.
- Please fix the charging station on an even plane.
Charging station best install place:
1. Make sure it is flat
2. No magnetic interference
3. No water and far away from puddle
4. No obstacle in front of charging station
IMPORTANT INFORMATION
Before fix the charging station on the lawn, please
examine the lawn and decide the best location where
is easy for the mower to find the station for recharge.
IMPORTANT INFORMATION
Do not tread or walk on the charging station plate.
3CM
Grass
Height
Cutting height: 3cm
X
X
OK
- 6 -
3cm
- The cutting height can be varied for 3cm and 4cm. If
the grass is long, it is appropriate to let the mower
start mowing at 4cm. Once the grass is shorter, you
can change it to 3cm.
-To adjust the cutting height:
1. Stop the mower and remove the key
2. Turn over the mower to underside
There are two blades fixed on the
blade holder. Swing the 4 screws on
blades holder and take blades out.
3. There are two kinds of blades: 3cm
and 4cm blades.
4. Choose your cutting height (3cm or
4cm), and then fix the two blades
with screws.
5. Turn over the mower to upside.
Cutting height adjustment finished.
Level 4cm
Blade holder
Level 3cm
- Fix the charging
station with four
stakes by
hammer
Peg
Lay virtual wire
as shown
-

3. INSTALLATION
- Bury the wire
- Bury virtual wire below grass and fasten it on
that the mower shouldthe ground with pegs, so
not cut the wire.
virtual wire
Add pegs to pull the virtual wire
down to the ground surface,
below the grass tips.
OK
3.4 Virtual wire installation
The virtual wire can be installed in one of the following
ways:
-Securing the wire to the ground with pegs.
It is preferable to staple down the virtual wire if you
want to make adjustments to the virtual wire during
the first few weeks of operation.
IMPORTANT INFORMATION
Hard or dry ground may cause pegs to break when
driven into ground. In extreme cases, water the lawn
where the pegs will be driven.
- A minimum distances between the front of the charging
station and an And make sure theobstacle is 2 meters.
leastdistance from corner to front of charging station is at
2.5 meters. Make sure to lay a 2.5 meters minimum
- If a high obstacle, for example a house, wall, fence or
other obstacle which is higher than the cutting lawn
prevent mowerat least 40cm from the obstacle. This will
virtual wire in front of charging station.straight-light of
the virtual wire should be laidborders the working area,
with the obstacle.from colliding
- If a passage or a ground with same height of cutting lawn,
the virtual wire should be laid at least 10cm from the edge.
- A minimum distance between the pool edge of virtual
wire is 40cm.
- A maximum distance of the virtual wire
to and from the island is 1cm, and fix the
- There are two types of set up of the
virtual wire around the charging station.
Put the charging station near corner.
please take location for reference.
Please make sure to set a straight-line
at least of 2.5m in front of charging
station. The charging station should be
far away from puddle.
- 7 -
two wires with one peg.
It is preferable to bury the virtual wire (max depth:
5cm) if you want to detach or aerate the lawn.
If necessary both methods can be combined so one
part of the virtual wire is stapled down and the
remainder is buried.
- Install virtual wire with pegs 1 meter apart. It’s
best to use smooth radius corners than sharp
angles. See pictures.
- A minimum distance between two corners is 1meter.

3. INSTALLATION
- Use the virtual wire to isolate areas inside the working
islands around obstacles that canarea by creating
flower beds andnot withstand a collision, for example,
fountains. Run the wire out to the area, route it
pegs are used, the wire should bethe same route. If
return route. Whenlaid under the same peg on the
the virtual wire to and from the island with a maximum
- If protected obstacles are grouped closely together
isolate them individually. Continuous virtual island
if obstacles are close to edge, leave them out of the
mowing area.
Virtual wire
Max: 1cm
Max: 1cm
Virtual wire
Max: 1cm
40cm
Min: 2m
around the area to be isolated and then back along
distance of 1cm, the mower can drive over the wire.
- The distance between charging station and virtual
loop should be 2 meters at least. - Joining the virtual wire .
If the virtual wire is not long enough
and needs to be spliced: Use supplied
wire connector. It is waterproof and
gives a reliable electrical connection.
To splice: Insert both cable ends in the
connector. Now press down the button on
top of the connector fully. Use a pair of
pliers or the like, as the button on the
connector is difficult to press down by
hand.
- Care must be taken not to create a corner sharper
degrees when setting up virtual wire.shorter than 90
degrees can cause theA corner sharper less than 90
mower to lose track of virtual wire. We can make
Correct corner set up,
using several angle to
avoid an angle of less
than 90°.
Greater than
2m
Proper setup in sharp corners
Incorrect corner
setup
greater than 90 degrees corner like follow picture
shows.
- 8-
Virtual wire connecting
Greater
than 2m
Tree with hole or flowers
around require placing a
wire around it
1cm

3. INSTALLATION
WARNING
Redundant virtual wire at back ofcharging station
must be cut off.
3.6 Power connection.
1 212
- + + -
Power terminal
on charging station
Power terminal
on charger
1. Connect charger terminal with charging station powerb
terminal . a
2. Connect the charger with power supply.
WARNING
The charger is not water-proof, it must be
located on a place where is dry and ventilated.
3.The virtual wire light turns colorless while virtual wire
connected well with charging station.
A failed connecting between virtual wire and charging
station cause a blinking red light and send out a
beeping from charging station.
3.Charging light on station in green: Non-recharging.
charging light on station in red: recharging.
- 9 -
Connect 1 from plug a to 1 from plug b and screw it
it tightly.
3.5 Charging head installation.
- Fix the charging station with four
stakes.
Peg
Virtual wire
3.7 Virtual wire and charging
station connecting
- Redundant virtual wire must be cut.
3.8 Power connection
1. Insert charger to the station.
2. Connect charger with power
supply.
AC80-240V
power supply
Connect the cut two ends of virtual wire to virtual wire
Connect the cut two ends of virtual wire to virtual
terminal located on charging station.
Pls take care of left and right terminal.
Pls take care of left and right terminal.
-
wire terminal located on charging station.

4. 5. USEREMOTE CONTROL
4. Remote control
ON/OFF button: To stop the mower. Press it,
mower enters standby mode.the
Indicator light.
Go forward.
Turn on or turn off the cutting
blade.
Press it when the mower is on standby mode
or working, it goes back to charging station.
Go backward.
1
2
3
4
5
6
7
Turn right.
Turn left.
8
9
10
Enter MANUAL pattern
Enter AUTO pattern
Battery location, with 2pcs AAA battery
11
IMPORTANT INFORMATION
Remove the 2 batteries from remote control while it
12
3
4
5
8
9
3
10 7
6
11
is in idle for a long time.
- 10 -
5. USE
IMPORTANT INFORMATION
- Do not leave the mower to operate unattended if you
are pets, children or people in theknow that there
- Mow only in daylight or in good artificial light.
- Avoid operating the mower in wet grass.
- Do not operate the mower when barefoot or wearing
- Always wear substantial footwear and long trousers.
- Always be sure of your footing on slopes.
- Use extreme caution when reversing the mower
- Always switch on the mower according to instructions
away from the blade.with feet well
5.1 Preparation
- Ensure the correct installation of the virtual wire.
- Periodically inspect the area where the mower
and remove all stones, sticks, wires,is to be used
objects especially the heightbones, and other foreign
- Periodically visually inspect that the blades, blade
cutter assembly are not worn or damaged.bolts and
Read the safety instructions before you start
Keep your hands and feet away from the
rotating blade. Never put your hands or feet
close to or under the body when the motors
WARNING
WARNING
vicinity
open sandals.
towards you.
your mower.
are running.
of objects is less than 6cm.
Replace worn or damaged blades and bolts in sets to
- Connect the two ends of virtual wire to the terminal
on charging virtual wire is in goodstation, and ensure
colorless).connecting. (Light on charging station is in
- Insert charger into charging station and secure it with
charger to powerthreaded cap. And then connect
connectionsupply. Ensure the charging station has a good
preserve balance.
IMPORTANT INFORMATION
charging station is Green.and the light on
- Periodically inspect the lawn is without any small
hole or mound.
User can not start the mower if virtual wire or
charging station is not in good connecting.
Remote control can only be used when it has
a same frequency with mower. (The remote control
was matched with mower before leave the factory).
How to match the remote control with mower:
1. Turn on the charging station.
2. Take the remote control near charging station.
3. Press ON/OFF button on remote control until
the indicator light is blinking. Then release the
ON/OFF button.
4. It finishes matching with the robot while the
indicator light stop blinking.

5. USE
5.2 Starting the mower
- 11 -
1. Turn the key switch on.
2. Clockwise rotate Emergency switch.
3. The mower start.
5.3 Stopping mower /Turning off mower
1. Press power button from remote control.
Mower stops, the blade motor stops.
mower goes into standby mode.
2. The mower also can be turned off by
press emergency switch directly.
3. Turn off the mower by anti-clockwise
the key switch.
5.4 Emergency Switch
Press emergency switch at any time the
mower power off at once. User has to
restart it.
5.5 Recharging
Steps as follow:
1. Turn off the mower by key.
2. Insert charger and screw the
knob.
3. Connect the charger to power
supply.
- The mower could go back to recharge automatically
if it is powerless. Or press the Home button from
could go back toremote control, the mower also
- The mower also can recharge by charger directly.
station for recharge.
6.Maintenance and storage
6. MAINTENANCE AND STORAGE
- During maintenance operations, use the individual
by the Manufacturer ,protections indicated
- Before performing maintenance operations, make sure
has stopped in safety that the robot conditions.
PROGRAMMED MAINTENANCE INTERVALS CHART
6.1 Robot cleaning
1.Stop the robot in safety conditions.
2. Wear protective gloves.
especially when intervening on the blade.
See “Robot
cleaning”
See “Blade
replacement”
Robot Carry out cleaning See “Robot
cleaning”
Frequency Component Type of operation Reference
Every week
Every month
Blade
Clean and check the
efficiency of the
blade
If the blade is bent due
to an impact or if it is
worn-out, replace it.
Every months 3 Robot Carry out for rechage See “Battery”
3.Clean all the outside surfaces of the robot with a
warm water.sponge soaked in
4.Do not use solvents or benzene so not to damage the
surfaces and the plastic components.varnished
5.Do not wash the inside parts of the robot and do not
pressure so not to damage theuse water jets in
WARNING
Never use a high-pressure washer or
even running water to clean the robot.
electric and the electronic components.
7. To remove the deposits and/or other residues from
suitable brush.the blade, use a
6.Check the lower part of the robot (cutting blade area
and remove the deposits and/or residuesand wheels)
correct functioning of the robot.that might obstruct the
8. Clean the outside of the charging station from any
residues.accumulated

- 12-
9. Keep all nuts, bolts and screws tight to be sure the
safe working condition.appliance is in
10. Replace worn or damaged parts for safety.
11. Ensure that only replacement cutting means of the
used.right type are
12. Ensure that batteries are charged using the correct
recommended by the manufacturer.charger
13.Incorrect use may result in electric shock, overheating
of corrosive liquid from the battery.or leakage
6.2 Robot Storage
Packed the mower and all spare parts with the original
package, and storage the carton off the ground in a cool,
dry place. Temperature should not be colder than
6.3 Blade replacement
Blade model: TC-GB
Specifications: 14L
Blade replace steps:
1.Stop the robot in safety conditions.
2. Wear protective gloves.
3. Turn the Robot upside down.
4. Unscrew the blade and remove it.
5. Replace a new blade and screw it.
6. Turn the mower to upside.
14. In the event leakage of electrolyte flush with
agent, seek medical help if itwater/neutralising
etc.comes into contact with the eyes
15. Servicing of the appliance should be according to
manufacturers instructions. This product (include
pack)must be disposed of at a designatedbattery
electrical and electronic waste.collection pint for
your local city officeFor more information, contact
product.or the shop where you purchased the
6.4 Battery
The battery is maintenance-free, but has a limited life
Battery life is dependent on the length of the using season
and how many hours per week the robot is used. A long
season or many hours of use per week, means that the
IMPORTANT INFORMATION
Charge the battery fully at the end of the season before
winter storage.
-4F°(-10℃)
span of 1-3years.
battery must be replaced more regularly.
- Attentions for lead-acid batteries
Charge the batteries at least once every Three months of
The interval of this charge shouldthey are at 25℃.
rise in temperaturebe reduced to 50% by each 10℃
capacityabove 25℃. The self-discharger state, their
may not recover ever after charge. If the batteries
are stored for more than a year at room temperature.
Store the batteries starting from fully charged state to
the batteries being shortened.prevent the life of
Use the batteries as quickly as possible after receiving
gradually deteriorate even under proper them as they
- Attentions of lithium batteries
The life of batteries may be shortened.
storage conditions.
IMPORTANT INFORMATION
Charge the battery fully at the end of the season
before winter storage. And recharge it every 3
months.
Please charge the lithium batteries in accordance with
procedures.standard time and
When the power is too low. It should be started
possible.charging as soon as
Storage, we suggest the optimum storage of lithium
power and keep in the shade.battery is with 80%
- Disused battery processing
Please contact the nearest waste treatment center
recycling and proper disposaland consultation with
of views.
Don’t take apart, repair or modify the battery privately.
Don’t connect the anode and cathode of battery.
6.5 Front wheel cleaning
When front wheels are not easy to rotate, please turn robot
upside down, check it and dismantle the screw cap to take
out the front wheel out of robot, dismantle end caps and
remove the residues, like mud, grass etc from end cap,
reinstall it on the robot.
6. MAINTENANCE AND STORAGE

- 13 -
After turn on the mower by key
and set the operate patten, but
mower still can not start. And the
charging station is beeping.
After turn on the mower by key
and but the set operate patten,
mower still can not start.
No power to plug receptacle or main
power is shut off. Bad communication
between charging station and mower.
Check the power and check the plug.
Connect charging station with power
supplier.
1.The virtual wire fails to send signals.
2. The virtual is broken.
1.Check the virtual wire light (colorless).
Be sure connectedthe virtual wire is
to the motion,charging station that is
and there is no loose place.
2.Connect the wire with virtual wire
7. Trouble shooting
7. Trouble shooting
Problem Solutions
Possible reasons
Mower stop working and beeping. Mower is lifted over 2CM from the
ground.
Put the mower in lever ground, turn
off the mower and restart it.
Remote control does not work. The electricity power is low. Change batteries.
Mower stop working and beeping.
Mower stop working and beeping. Mower is tilted over than 30 degree
from the ground.
Put the mower in lever ground, turn
off the enter mower and restart it by
password and choose operate pattern.
1. Cutting height too low.
2. Blade or running wheels strike
hard objects.
3. The mower is trapped in lawn.
1. Adjust the cutting height to suitable
2. Clean the grass and make sure it is
free from hard objects.
3. Clear the lawn where the mower is
trapped or restart the mower in
another place.
Mower stop working and beeping.
1. Strike bump sensors 8 times
continuously.
2.Bump sensors are locked.
3.Wires of bump sensors have be cut
off. Bump sensor is broken.
1. Restart the mower.
2. Free bump sensors.
3. Change new wires of bump sensors.
Send the mower to provider and
change the bumper sensors.
connectors.
height.
Power nearing natural end of life.
Grass is extremely overgrown or
very wet.
2. Check whether the charger is well
connected.
1. Send the mower to service station
and replace the battery.
Cut the grass appropriate height.
The batteries can not recharged.
Terrain needs landscaping repairs. Fill in all holes, cover or exclude all
exposed roots in order to smooth
the terrain.
Mower does not complete the edge. Obstacle along the path. Watch the ful operation of edge and
confirm no obstacle are present.

- 14 -
Problem Solutions
Possible reasons
Mower drives but
blade will not mow.
1. On manual pattern, Mow on
remote off.control has be turned
2. The cutting motor is broken.
1. Turn on the mower button.
2. Send the mower to service station
and motor.replace a new cutting
Power is not fully charged for
operation
The ground before the charging
station is not flat.
Short run time, operates less time
than normal
Mower does not detect the
charging station contacts.
Recharge the mower fully.
Reset the charging
station in a flat place.
Confirm the ground before the
charging station is leveled with
the charging station if necessary fill
area with dirt and level off.
Height difference between the
charging station and the lawn
surface at the entrance to the
charging station.
Mower reached the charging
station when its contacts are
above the charging station
contacts.
Relocate the virtual wire.
Virtual wire incorrectly placed.
The robot behaves in an
anomalous manner around the
flower beds.
The robot is very noisy. 1. Damaged running motor.
2. Grass too high.
1. Get the motor repaired or
replaced by service station.
2. Increase the cutting height or use
a lawn mower.normal
1. Replace the blade with a new one.
2. Stop the robot in safety conditions,
use protection gloves to avoid the
risk of cuts on hands, remove the
fold cause from the blade.
3. Start the robot in a new place.
1. Damaged cutting blades.
2. Cutting blade flooded by residues
(tapes, ropes, plastic fragments, etc)
3.The start of the robot occurred with
obstacles being too closed (less than
1m away) or in presence of unexpected
obstacles (fallen branches, forgotten
objects, etc.)
The robot is very noisy.
7. Trouble shooting

- 15 -
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
Handle- to p
Han dle- down
Up cove r
Key switch
Battery
Bat ten of battery
Power light
Rain se nso r
Emerge ncy switch
Cutting motor
Blade holder
Blade
Motor pres su re plate
Running motors
Running m oto r ge ar
Bear ing
pressure plate
Wheel Gear
Bearing
Axl e
Wheel
Shell
Bottom cover
Lift sensor
Scr ew cap
Gasket
Omni-directional wh ee ls
Spring sheet
Micro switch
PCB
Midd le bumper
Charging head
Side bumper
Oil seal
Charging terminal
8.1 Mower Exploded View
8.2 Charging Station Exploded View
1
2
3
4
5
6
7
1.top cover
2.PCB
3.Power terminal
4.Virtual wire terminal
5.Underpan
6.Copper sheet
7.Copper sheet permanent seat
8. Exploded View

USER MANUAL
