Ledy Gobo User manual
Zhengzhou Ledy Optical-Electrical Technology Co., Ltd.
Owner Manual
Of
LEDY Gobo Projector
Note: The reflection rate of projecting surface has big effect on projector brightness.
When projecting on white surface, it can reflect all light and absorb other colors,
brightness is the highest; When project on black surface, brightness is lowest.
Therefore, please give full consideration to the reflection rate of projecting surface.
Thanks for your use LEDY gobo projector. Please read this instruction carefully before
installation.
Working principle
Under the drive of power supply, light from lamp bead gathered by optical system
project on logo gobo, to get corresponding image through lens.
Zhengzhou Ledy Optical-Electrical Technology Co., Ltd.
Projector Structure & Application
1-lens 2-hand screw 3-projector shell 4-radiator
5-bracket 6-power box 7-fans 8- gobo control button
9-power cord
8- gobo control button :
Press the button to change the image status to rotate/stop or the rotating direction.
Press the button 3 seconds each time, to change the rotating speed –slow, normal or fast.
Technical parameters
Model
Voltage
Rated output
Rated frequency
Waterproof
Color temperature
DFL-100R
AC110v-240v
102w
50-60Hz
IP65
6500k
Installation & Operation
Choose the projector install location and position, fix the projector by M4 bolts,
adjust the projection angle accordingly.
Connect the power cord properly to ensure the power line contacts well.
Zhengzhou Ledy Optical-Electrical Technology Co., Ltd.
Gobo replacement
Please turn off the power supply before changing gobo. Twist the hand screws and
silicone pads, then get off the front cover. As below figure shown.
As below figure shown, put the new gobo on magnet base, adjust the gobo and the
base to be concentric.
17-magnet base 18-gobo 19-motor
Sharpness Adjust
Turn on the projector power, rotate the lens. When projection distance is long, shorten
the lens till image clear; While distance is short, lengthen the lens till image clear. And
the last, please fasten the lock nut to avoid loosening of lens.
Zhengzhou Ledy Optical-Electrical Technology Co., Ltd.
Appended Description Of Remote controller
Size
102*40*15mm
Working
Voltage
DC12V(23A battery)
Working
Current
35mA
Standby
Current
0mA
Working
Freqency
315MHz
Modulation
Type
OOK(AM)
Max
Distance
50m
Working
Temperature
-10°C ~ 70°C
A: Press 3 seconds to turn on or turn off the light.
Short press to control image stop, rotating clockwire or anticlockwise.
B: Short press to control image rotating speed –stop, slow, normal or fast.
Zhengzhou Ledy Optical-Electrical Technology Co., Ltd.
Maintenance & Attention
1. Please read the installation instructions carefully before use, and operate in strict
accordance with this manual sheet.
2. Because of the high calorific value when projector works, it cannot be installed in
flammable explosive place, or the place that can be touched, in order to avoid
accident. If you want to install where can touch easily, need to add partition or
warning board.
3. Please ensure that all maintenance work is under the condition of power off.
4. Please clean lens and gobo regularly.
5. Please regularly check the products operation condition(3 months suggested), in
order to avoid safety accident caused by the product problems.
6. This projector can be used indoor or outdoor, but not in the place such as vibration,
dust, moisture, mist, to avoid causing fire, electric shock, malfunction.
7. Please do not modify or replace the non-consumable parts voluntarily.
8. When projector is abnormal, please cut off the power supply immediately. Please
ask professional staff to check and maintain, to avoid fire, falling and hurt.
9. The power line color:
red(brown) –firing line, blue –zero line, yellow –ground line.
10.For waterproof model, please pay attention to the front lens cover when you put it
back to projector, all the screws must be tightened, make sure there is no gap
between the gasket, the front cover and the projector shell, as shown in below
figure.
