Lenkeng LKV318PRO User manual

4kx2k 8 ports HDMI SPLITTER
USER MANUAL
Introduction:
This product distributes 1 way HDMI signal from STB, DVD, notebook,
D-VHS and HD-Player etc to 8 ways identical HDMI signal simultaneously.
It supports 3D HDMI and HDMI1.4 (4kx2K).
Safety notes:
1. Use DC5V power supply only. Make sure specification matched if using
adapters not supplied by factory.
2. Put this product in dry and ventilated place for normal heat dissipation.
3. Keep this product away from strong static and magnetic environment.
1. Package contents
1. Product 1pcs
2. User manual 1pcs
3. Power adapter5V3A 1pcs
4. Screws (to hang on wall) 4pcs
2. Installation requirement
1. HDTV or other display with HDMI port
2. HDMI video source, such as DVD,PS3,STB,PC.etc
3. High standard HDMI cable (can support HDMI1.4)
3.Installation steps
1. Connect the HDMI video source output port to the splitter input port by
HDMI cable
2. Connect the splitter output port to HDMI display by HDMI cable
3. Set the TV input to right HDMI channel.
4. Power on the splitter(power indicator led will light on in red)
4. Operation notes:
1.Before output HDMI signal, the splitter will read EDID information of
connected TVs and send it back to HDMI source part to let it determine the
output mode
2. Indicator led shows the working status
3. Power supply larger than 5V will damage product.
5. Trouble shooting
1. No image output
A: Check and make sure all connections are good and correct.
B. Check and make sure the TV has been set up to the right
channel.
C. Check if the matched output indicator led lights on.
2. Display is unstable, splash screen, snowflakes or audio stuck
A. Check and make sure all connections are good and correct
B. Use HDMI 1.4 cable if transmitting 4KX2K HDMI signal.

6.Specification
Model
LKV318PRO
Power supply
DC5V / 3A
Input ports
HDMI CONNECTER X1
Outpurt ports
HDMI CONNECTER X8
Power port
DC 1.7mm x1
Power indicator led
Orange LED X1
Signal indicator led
Blue LED X8
DVI Specification
Compliant DVI Specification 1.0
HDMI Specification
HDMI Specification 1.4a Compliant
HDMI HDCP
compliant with HDCP Rev 1.3
specification Supports HDCP Repeater
Frequency Range
25MHz - 340MHz
Max transmission rate
3.4G X 3= 10.2Gbps
Color depth
Supports 12-bit Deep Full HD, Full 3D
and 4K2K video
Audio
Support standard audio and DSD（Direct
Stream Digital ）Audio and HD (HBR) Audio
Support HDMI
resolution
480i@60Hz, 480P@60Hz,
576i@50Hz ,576P@50Hz, 720P@50@60Hz
1080i@50@60Hz, 1080P@50@60Hz
3DHDMI(720P@50@60Hz ,1080P@24Hz) 3840 X
2160P@24Hz
Dimension
213X80 x 19mm
Net weight
390g
Color
Black
Working temperature
0~60℃
