RAPIDDOC®LITE KIOSK INSTALLATION GUIDE
1
MTI P/N 063-00216 rev C ©2021 MTI All Rights Reservedwww.MTIGS.com | T:801.653.3807
Overview
185-00528 Through-Hole Mounting Accessory (Sold Separately)
Materials in Box
Mounting
Plate
Alcohol Wipes (10)
Mounting Screws (4)
Screws (5)
Threaded Pipe
Adhesive Pad
Nut
Security Screws (2)
185-00461
Power Supply
Red Handle Tool
Authorization Card
If lost or
stolen, contact
customer
service for
replacement.
Access Card (5)
RapidDoc®Kiosk
C.A. Cover
(Minimal Cables)
C.A. Cover
(No Cables)
Cable Access
(C.A.) If the Kiosk is not mounted to a counter
or table it may fall, causing damage to
the Kiosk or a person. USB cables may
be disconnected as it moves around
a surface. See page 9 for mounting
instructions.
The applied nameplate is located at the
bottom of the product.
Use only power supply with output ratings 5.6VDC max., 4A
max., of PS2 or LPS
The socket-outlet (power adaptor) shall be installed near the
EQUIPMENT and shall be easily accessible.
-CONTROLLED DOCUMENT- 063-00216 C-0 Status: Approved ECO-112352
ECO-112352

RAPIDDOC®LITE KIOSK INSTALLATION GUIDE
2
MTI P/N 063-00216 rev C ©2021 MTI All Rights Reservedwww.MTIGS.com | T:801.653.3807
CABLE ACCESS COVER INSTALLATION
REPLACING THE LID
REMOVING THE LID
1
1
1
2
2
2
Lift up the front of the lid (above the ArmorActive logo).
Tuck the RFID cable into the void in the base and
place the lid on the kiosk base.
With the lid off of the kiosk base, place the Cable
Access Cover into the opening from the inside.
Slide the lid back, using care when removing the lid as
not to damage the RFID cable.
Slide the lid into place and press down on the lid.
Press until it clicks into place.
Cut-away side view
-CONTROLLED DOCUMENT- 063-00216 C-0 Status: Approved ECO-112352
ECO-112352

RAPIDDOC®LITE KIOSK INSTALLATION GUIDE
3
MTI P/N 063-00216 rev C ©2021 MTI All Rights Reservedwww.MTIGS.com | T:801.653.3807
1
3
2
4
BASEPLATE MOUNTING
Using the mounting screws, place the mounting plate
in the desired location. See Page 9 for a Mounting Plate
drill template.
Lock the kiosk into place by rotating it counter
clockwise on the plate.
Place the kiosk by lining up the opening on the bottom of
the kiosk with the teeth on the mounting plate.
Secure the kiosk to the mounting plate using the two
security screws and the Red Handle Tool.
-CONTROLLED DOCUMENT- 063-00216 C-0 Status: Approved ECO-112352
ECO-112352

RAPIDDOC®LITE KIOSK INSTALLATION GUIDE
4
MTI P/N 063-00216 rev C ©2021 MTI All Rights Reservedwww.MTIGS.com | T:801.653.3807
1
1
2
2
Clean the surface you are mounting on with the Alcohol
wipes included in the box. Peel the film on the VHB on the
bottom of the kiosk.
Place in desired location and firmly press down for full
adhesive contact. Allow 24 hours for full VHB adhesion.
VHB MOUNTING
CABLE ROUTING
1.
1.
2.
2.
1. Through Hole Cable Routing
2. Table Top Cable Routing
3. Power
3.
-CONTROLLED DOCUMENT- 063-00216 C-0 Status: Approved ECO-112352
ECO-112352

RAPIDDOC®LITE KIOSK INSTALLATION GUIDE
5
MTI P/N 063-00216 rev C ©2021 MTI All Rights Reservedwww.MTIGS.com | T:801.653.3807
1
3
2
4
ACCESS CARD REGISTRATION
Make sure the RapidDoc®RFID Module is powered and
ready.
Place the RFID Authorization Card on the RFID Module
until the LED flashes.
If no Access Card is detected, the Base will return to
normal condition waiting for registered Access Card to
unlock the Base. The Base can register a maximum of
20 Access cards. The process will need to be repeated
for each card. If a 21st card is registered, the first regis-
tered card will be deregistered.
Place a RFID Access card on the RFID Module until
LED flashing stops and returns to solid green.
IF AUTHORIZATION
CARD IS LOST OR
STOLEN, CONTACT
CUSTOMER SERVICE FOR
REPLACEMENT.
-CONTROLLED DOCUMENT- 063-00216 C-0 Status: Approved ECO-112352
ECO-112352

6
MTI P/N 063-00216 rev C ©2021 MTI All Rights Reservedwww.MTIGS.com | T:801.653.3807
1
1
2
2
REMOVING THE ENCLOSURE (OR TABLET) MANUALLY
REMOVING THE ENCLOSURE (OR TABLET) VIA RFID
Insert the Red Handle Tool into the security screw hole
at the side of the RapidDoc®base-disk under the tablet.
Turn the Red Handle Tool clockwise until resistance is
felt (about halfway) and hold. NOTE: Do not grab the
tablet until after you twist the Red Handle Tool.
Place the RFID Access Card until the base clicks. NOTE:
Do not grab the tablet until after you hear the click.
While holding the Red Handle Tool, remove the tablet
using one hand on the bottom left or right hand corner.
Remove the tablet using one hand on the bottom left or
right hand corner.
-CONTROLLED DOCUMENT- 063-00216 C-0 Status: Approved ECO-112352
ECO-112352

RAPIDDOC®LITE KIOSK INSTALLATION GUIDE
7
MTI P/N 063-00216 rev C ©2021 MTI All Rights Reservedwww.MTIGS.com | T:801.653.3807
LED STATUS INDICATORS
Visual Reference System Status Condition
Solid Green LED Tablet docked
Solid Red LED Tablet removed
click
Flashing Green with audible click Tablet ready for removal
Flashing Yellow-Green and Red Ready to register an Access card
Flashing Red
Multiple undock attempts
If an Access Card is swiped more the 10 times
within 2 minutes, the LED will flash Red and
not allow undock attempts for 2 minutes.
click-click x10
Remains Red with multiples clicks
12V Tablet Error
RapicDoc Lite only supports 5V Tablets (e.g.
Apple and Android). If you place a 12V Tablet
on a Lite base, the LED will not turn green,
and the base will emit 10 sets of 2 clicks.
Remove the tablet between the pairs of clicks.
If not removed, the Tablet will be locked for 2
minutes.
-CONTROLLED DOCUMENT- 063-00216 C-0 Status: Approved ECO-112352
ECO-112352

RAPIDDOC®LITE KIOSK INSTALLATION GUIDE
8
MTI P/N 063-00216 rev C ©2021 MTI All Rights Reservedwww.MTIGS.com | T:801.653.3807
1
3
5
2
4
6
The base can register a maximum of 20 Access cards.
Example:
NOTE: The above grid is a conceptual visual representation of
the Electronic Register.
Example:
Example:
If a card is lost or stolen:
Then re-register the remaining cards plus the new one
ordered through Customer Service. Example:
If a 21st card is registered, the first registered card will
be deregistered.
Example:
Example:
Take any of the remaining access cards and register it 20
consecutive times:
ACCESS005
ACCESS004
ACCESS003
ACCESS002
ACCESS001
ACCESS005
ACCESS004
ACCESS003
ACCESS002
ACCESS001
ACCESS006
ACCESS005
ACCESS004
ACCESS002
ACCESS001
ACCESS006
ACCESS005
ACCESS004
ACCESS003
ACCESS002
ACCESS001
ACCESS001
ACCESS001
ACCESS001
ACCESS001
IF AUTHORIZATION CARD IS LOST OR STOLEN,
CONTACT CUSTOMER SERVICE FOR REPLACEMENT.
Access Card Registration
-CONTROLLED DOCUMENT- 063-00216 C-0 Status: Approved ECO-112352
ECO-112352

RAPIDDOC®LITE KIOSK INSTALLATION GUIDE
9
MTI P/N 063-00216 rev C ©2021 MTI All Rights Reservedwww.MTIGS.com | T:801.653.3807
1
3
5
2
4
6
THROUGH-HOLE MOUNTING
3”
Secure the kiosk to the mounting plate using the two
security screws and the Red Handle Tool.
Place the kiosk by lining up the opening on the bottom of
the kiosk with the teeth on the mounting plate. Lock the
kiosk into place by rotating it counter clockwise on the
plate.
NOTE: The Through-Hole Mounting Accessory is sold
separately. Peel the film on the included adhesive pad
and adhere it to the underside of the mounting plate.
Place the assembly into a pre-drilled hole 3” wide.
Attach the threaded pipe to the mounting plate with the
5 included screws.
Secure into place by twisting the nut over the threaded
pipe.
-CONTROLLED DOCUMENT- 063-00216 C-0 Status: Approved ECO-112352
ECO-112352

RAPIDDOC®LITE KIOSK INSTALLATION GUIDE
10
MTI P/N 063-00216 rev C ©2021 MTI All Rights Reservedwww.MTIGS.com | T:801.653.3807
Federal Communication Commission interference statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures: -Reorient or relocate the receiving
antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into
an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an
experienced radio/TV technician for help.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. this device may not cause harmful interference and
2. this device must accept any interference received, including interference that may cause undesired
operation
RF Exposure Warning
The equipment complies with RF exposure limits set forth for an uncontrolled environment. The
antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
You are cautioned that changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
FCC Statement
