MPTL96DD 1 Rev. 01/10/05
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this
type of work. To reduce your exposure to these chemicals: work in a well
ventilated area, and work with approved safety equipment, such as those
dust masks that are specially designed to filter out microscopic particles.

MPTL96DD 2 Rev. 01/10/05
1. Do not use tools in damp or wet locations: keep
work area well lit and clean. Do not use tools in the
presence of flammable liquids or gases.
2. Guard against electric shock. Avoid body contact
with grounded surfaces while changing battery.
3. Store idle tools. When not in use, tool should
be stored in a dry locked place, out of reach of
children.
4. Do not force the tool. It works much safer at the rate
for which it was intended.
5. Do not abuse the cord. Never yank the charger
cord to disconnect it from the socket. Keep the
cord away from heat, oil and sharp edges while
changing the battery.
6. Check for alignment of moving parts, binding of
moving parts, breakage of parts, mounting and
any other condition that may affect its operation.
7. Any part that is damaged should be properly
repaired or replaced by Tri-County Power Tool,
Inc.
8. To ensure the designed operational integrity
of these power tools, do not remove installed cover
or screws.
9. Do not wipe plastic parts with the following solvents:
gasoline, thinner, benxine, carbon tatrachloride,
alcohol, ammonia and oil containing chloric annex
which may damage and crack plastic parts. Wipe
plastic parts with a soft cloth lightly dampened with
soapy water.
GENERAL OPERATIONAL PRECAUTIONS
1. CAUTION: To reduce risk of injury, charge
only Matco rechargeable batteries. Other types
of batteries may burst causing personal injury
and damage.
2. Before using battery
charger, read all
instructions and
cautionary markings on
batteries and chargers.
3. Do not expose charger
to rain or snow.
4. To reduce the risk of damage to electric plug
and cord, pull by plug rather than cord when
disconnecting charger.
5. Use of an attachment not recommended or sold by
the battery charger manufacturer may result in a
risk of fire, electric shock, or injury to persons.
6. Make sure cord is located so it will not be stepped
on, tripped on, tripped over, or otherwise subjected
to damage or stress.
7. Do not operate charger with damaged cord or
plug. Replace them immediately.
8. Do not operate charger if it has received a sharp
blow, been dropped, or otherwise damaged in
any way. Return tool to Tri-County Power Tool, Inc.
for repair.
9. To reduce the risk of electric shock, unplug
charger from outlet before attempting any
cleaning. Turning off controls will not reduce
this risk.
10. Do not disassemble charger or battery cartridge.
Return tool to Tri-County Power Tool, Inc. when
repair is required. Incorrect reassembling may
result in a risk of electric shock or fire.
IMPORTANT SAFETY INSTRUCTIONS FOR CHARGER & BATTERY CARTRIDGE
V . . . . . . . . . . . . . . . . . . . Volts
A . . . . . . . . . . . . . . . . .Amperes
Hz . . . . . . . . . . . . . . . . . . Herts
W . . . . . . . . . . . . . . . . . .Watts
. . . . . Alternating Current
. . . . . . . . . Direct Current
SYMBOLS

MPTL96DD 3 Rev. 01/10/05
MPTL96DD
3/8" 9.6v Drill and Driver with LED Light
1. Do not charge battery cartridge when temperature
is below 10˚C (50˚F) or above 40˚C (104˚F).
2. Do not attempt to use a set-up transformer, an
engine generator or DC power receptacle.
3. Do not allow anything to cover or clog the charger
vents.
4. Always cover the battery ternimals with the battery
cover when the battery cartridge is not used.
5. Do not short the battery cartridge:
Do not touch the terminals with any conductive
material.
Avoid storing battery cartridge in a container with
other metal objects such as nails, coins, etc.
6. Do not store the machine and battery cartridge
in locations where the temperature may reach or
exceed 50˚C (122˚F).
7. Do not incinerate the battery cartridge even if it
is severely damaged or completely worn out. The
battery cartridge can explode in a fire.
8. Be careful not to drop, shake or strike the battery.
9. Do not charge inside a box or container of any kind.
The battery must be placed in a well ventilated area
during charging.
ADDITIONAL SAFETY RULES FOR CHARGER AND BATTERY CARTRIDGE
View the Major Parts
Torque Adjustment Ring
Chuck
Battery
High/Low Regulator
Forward/Reverse Switch
Accessory
Charger
General Precaution for Charging
the Battery
• Use only the specified MPT96C charger and MPT96B
battery.
• Other chargers may damage the battery.
• General battery charging cycle is about 500
cycles, but an unqualified charger may reduce the
battery life.
Trigger

MPTL96DD 4 Rev. 01/10/05
MPTL96DD
3/8" 9.6v Drill and Driver with LED Light
How to Remove/Insert the Battery
• Push the release buttons on both sides of the battery pack
and slide forward toward the chuck to remove the battery
from the unit.
• To reinstall the battery, slide the battery into the unit until
the battery is fully engaged. This is confirmed when the
battery “clicks” into place.
Charging the Battery
Do not charge the battery cartridge when temperature is below 10˚C (50˚F) or above 40˚C (104˚F).
1. While charging the cool battery (below 5˚C) in the warm indoors, keep the battery in the room for one hour
to warm up before starting the battery. A cool battery may not charge properly.
2. Unplug the charger once the battery is completely charged.
3. The charger should sit for one hour after charging continuously for 3 hours.
4. Do not use a generator for charging the battery.
The LED Light on the Charger Indicates:
Red light – Battery is charging
Green light – Battery fully charged and Trickle charging
Do not change the battery in the rain, snow or in a high temperature environment.

MPTL96DD 5 Rev. 01/10/05
MPTL96DD
3/8" 9.6v Drill and Driver with LED Light
Operating the Tool
Select the applied torque from the adjustment ring.
There are 17 positions available. Select the speed by pushing
the High/Low Speed Regulator
Low Speed
(For Screwdriver)
High Speed
(For Drill)
Reverse
Forward
Forward/Reverse Switch
1. How to insert and remove a bit.
To remove a bit from the chuck, hold the “B” ring firmly by one hand and turn the
“A” ring counterclockwise.
To insert a bit into the chuck, hold the “B” ring firmly by one hand and turn the
“A” ring clockwise.
2. Forward/Reverse selection button.
Select the forward or reverse direction of the tool by pushing the switch.
3. High/Low speed selection.
Use “High” for drilling application.
Use “Low” for screwdriver application.
4. Select the applied torque by using the 17 torque positions provided, selecting the right torque for the
application.
5. Drill Model
Make sure the torque ring is positioned for maximum torque.
Remove the bit
Turn
Counterclockwise
Turn Clockwise
Insert the bit
A
B

MPTL96DD 6 Rev. 01/10/05
MPTL96DD
3/8" 9.6v Drill and Driver with LED Light
Maintenance
Remove the battery from the unit and pull power socket of charger from power outlet before repair
or maintenance.
1. Wipe plastic parts with a soft cloth lightly dampened with water. Do not wipe plastic parts with solvents such
as gasoline, thinner, or alcohol.
2. Check the screws in the main housing regularly and tighten if necessary.
3. Keep children away from the tool. Do not expose the tool to rain.
4. Do not lock the drill for more than 5 seconds while trigger is engaged. Extended periods of locking the drill
may damage the motor and increase heat rapidly.
5. Do not change the High/Low speed knob while the drill is running to avoid damaging the gear mechanism.
How to Replace the Chuck
1. Hold “A” ring firmly and turn “B” ring counterclockwise until the chuck is fully open.
2. Release the left-hand screw inside the chuck. B A
Left-hand screw

MPTL96DD 7 Rev. 01/10/05
MPTL96DD
3/8" 9.6v Drill and Driver with LED Light
NO. PART NO. DESCRIPTION QTY.
12 RS14412 MAIN HOUSING — L & R 1
13 RS19613 BATTERY CONNECTOR 1
14 RS19614 LED WIRE ASSEMBLY 1
15 RS14415 LED SWITCH 1
16 RS14416 LED SWITCH KNOB 1
17 RS14417 LED 1
18 RS14418 SCREW 8
19 MPT96B BATTERY — 9.6V 1
20 RS19620 LABEL - R — 9.6V 1
21 MPT96C CHARGER — 9.6V 1
NO. PART NO. DESCRIPTION QTY.
1 RS14401-1 SCREW FOR 3/8" CHUCK 1
2 RS19602 KEYLESS CHUCK — 3/8" 1
3 RS19603 GEAR BOX (1/2"SHAFT) 1
4 RS19604 HIGH/LOW SPEED KNOB 1
5 RS14405 KNOB SPRING 1
6 RS14406 SPEED CHANGE SPRING 1
7 RS14407 MOTOR CONNECTOR 1
8 RS14408 SCREW 2
9 RS19609 MOTOR ASSEMBLY — 9.6V 1
10 RS14410 FORWARD/REVERSE ROD 1
11 RS14411 SWITCH 1

MPTL96DD 8 Rev. 01/10/05
Matco warrants this tool for a period of 1 year from original purchase. We will repair any MPTL96DD covered
under this warranty which proves to be defective in material or workmanship during the warranty period.
In order to have your tool repaired, return the tool to Tri-County Power Tool, Inc. at the address listed below, freight
prepaid. Please include your name and address, evidence of the purchase date, and description of the suspected
defect. The tool will be inspected and if any part or parts are found to be defective in material or workmanship, the
tool will be repaired free of charge and returned to you freight prepaid. This warranty does not cover damage to
equipment or tools arising from alteration, abuse, misuse, damage and does not cover any repairs or replacement
made by anyone other than Matco or Tri-County Power Tool, Inc. The foregoing obligation is Matco's sole
liability under this or any implied warranty and under no circumstances shall we be liable for any incidental or
consequential damages.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
TRI-COUNTY POWER TOOL, INC.
4957 Pearl Rd.
Cleveland, OH 44109
[phone] (toll-free)
[phone]
[phone] (fax)
Model# MPTL96DD Limited Warranty
