MODEL NUMBER
MDG2500BWW
When requesting service or ordering parts, always
provide the following information:
- Product Type - Part Number
- Model Number - Part Description
DRYER
©2005 Maytag Services

Section: CONTROL PANEL
LD11-106
Model: MDG2500BWW
1

CONTROL PANEL
No. Part No. Description
Section:
Series Qty
1 Y22002339 SCREW 10 3
1 33002563 PANEL, CONTROL (WHT) 10 1
2 33001621 SKIRT, TIMER DIAL (WHT) 10 1
3 22001659 TIMER KNOB - GREY 10 1
4 22001664 TIMER KNOB INSERT/CAP (WHT) 10 1
5 33001619 BUTTON, PUSH TO START (WHT) 10 1
6 33001690 SCREW, TIMER 10 2
7 33001632 TIMER 10 1
8 33001806 BACK, CONSOLE PANEL 10 1
8 216423 SCREW 10 2
9 22002285 CONSOLE (WHT) 10 1
10 216423 SCREW 10 1
11 33001623 BUZZER, NON-ADJUSTABLE 10 1
12 33001861 SWITCH, PUSH TO START (WHT) 10 1
13 33001916 WIRE HARNESS, MAIN 10 1
14 33001641 SWITCH, TEMPERATURE (GAS) 10 1
15 22001663 KNOB, SELECTOR SWITCH (WHT) 10 1
16 2206693 MANUAL, USE & ARE TRILINGUAL 18 1
16 33002525 MANUAL, USE & CARE (TRI) 10 1
2
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: CABINET-FRONT
LD12-57
Model: MDG2500BWW
3

CABINET-FRONT
No. Part No. Description
Section:
Series Qty
1 33002631 COVER, TOP (WHT-AS PK) 36 1
1 33001896 COVER, TOP (WHT) 10 1
2 N 22003643 CABINET ASSY. (WHT AS PK) 38 1
2 N 33001897 CABINET (WHT) 10 1
- 22002643 WIRE HARNESS, MAIN 10 1
3 22002049 CLIP 10 2
4 213280 FRONT PANEL BRACKET/FASTENER 10 2
5 22001995 SCREW 10 2
6 22003298 RETAINER, WIRE 10 1
- 22003409 SCREW----NA 36 6
7 213007 SCREW, CABINET 10 6
8 310376 CLIP, WIRE HARNESS 10 1
4
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: CABINET-REAR
LD12-76
Model: MDG2500BWW
5

CABINET-REAR
No. Part No. Description
Section:
Series Qty
1 N 33002643 CABINET ASSY. (WHT AS PK) 38 1
- 22001995 SCREW 36 1
1 N 33002624 CABINET, ASSY. (WHT-AS PK) 36 1
1 N 33001897 CABINET (WHT) 10 1
- 22003367 HINGE, PLASTIC 36 1
2 22001995 SCREW 10 2
3 33001795 COVER, TERMINAL BLOCK 10 1
4 22001995 SCREW 10 1
5 211881 GROMMET, CORD 10 1
6 33002494 CORD, POWER (AS WRAP) 10 1
6
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: DOOR
LD17-26
Model: MDG2500BWW
7

DOOR
No. Part No. Description
Section:
Series Qty
1 33001767 SEAL, SHROUD 10 1
2 22002247 HOOK, SECURITY 10 2
3 33001900 SHROUD (WHT) 10 1
4 22001995 SCREW 10 8
5 33001768 SCREW, SHROUD 10 2
6 33001509 SWITCH, DOOR 10 1
7 33001760 BRACKET, HINGE 10 4
8 N 33001174 PLUG, DOOR CATCH 10 1
9 Y304578 CATCH, DOOR (FEMALE) 10 1
- 33001791 CATCH, DOOR (W/PLUG) 10 1
10 33002094 SEAL, DOOR 10 1
11 22002038 CLIP, DOOR (DOUBLE) 10 4
12 33001793 BRACKET, STRIKE 10 1
13 33001761 STRIKE, DOOR (MALE) 10 1
14 22002039 CLIP, DOOR (SINGLE) 10 2
15 33001763 PLUG, INNER DOOR 10 1
- 22002039 CLIP, DOOR (SINGLE) 10 2
- 22002063 SCREW #8-18AB WAFER HD 10 2
16 33001899 DOOR, INNER (WHT) 10 1
- 22001817 SHEET, SOUND DAMPER (FT. PNL) 10 1
17 33001904 DOOR, OUTER (WHT) 10 1
18 33001759 HINGE, DOOR 10 2
19 22002062 SCREW 10 4
20 22002063 SCREW #8-18AB WAFER HD 10 8
21 33001764 COVER, HINGE HOLE (WHT) 10 2
22 33001787 SCREW, HINGE 10 2
23 22002012 SCREW, HINGE 10 2
24 33001901 PANEL, FRONT (WHT) 10 1
25 33001771 BUSHING, INNER DOOR 10 2
8
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TUMBLER
LD13-46
Model: MDG2500BWW
9

TUMBLER
No. Part No. Description
Section:
Series Qty
1 33001799 OUTLET DUCT ASSEMBLY 10 1
2 33001808 FILTER, LINT 10 1
3 33001758 SEAL, BLOWER 10 1
4 33002190 SCREW (#10-3/8") 10 4
5 22003298 RETAINER, WIRE 10 1
6 33001802 FRONT, TUMBLER (W/SEAL) 10 1
7 410233 RING, RETAINING 10 2
8 306508 TUMBLER BEARING KIT 10 2
9 210720 RIVET 10 4
10 216423 SCREW 10 2
11 210932 SCREW, #8 X 9/16 CTSK 10 1
12 N 312311 SCREW----NA 10 1
13 33001855 SCREW (HEX HEAD) 10 4
14 33001807 SEAL, TUMBLER 10 2
15 33001756 BAFFLE (TALL) 10 2
16 33001755 BAFFLE (SHORT) 10 1
17 33001889 TUMBLER 10 1
18 33001777 BELT, TUMBLER 10 1
19 33001788 SCREW, BAFFLE 10 6
20 33003037 TUMBLER BACK & SEAL 19 1
- 33002779 TUMBLER BACK & SEAL AS-PACK 1
20 33001801 BACK, TUMBLER (W/SEAL) 10 1
21 33001443 NUT, HEX (ROLLER SHAFT) 10 2
22 Y313347 WASHER, SPRING (ROLLER SHAFT) 10 2
23 312948 SHAFT, TUMBLER ROLLER 10 2
24 Y303373 BEARING & ROLLER ASSEMBLY 10 2
25 312535 WASHER, ROLLER SHAFT 10 2
10
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: GAS VALVE
CD14-5
Model: MDG2500BWW
11

GAS VALVE
No. Part No. Description
Section:
Series Qty
1 306195 CONVERSION KIT (NATURAL TO LP) 10 1
2 306204 CONVERSION KIT (LP TO NATURAL) 10 1
3 304971 SCREW 10 1
4 304970 IGNITER ASSY, GAS VALVE 10 1
5 33001247 BURNER ASSY. 10 1
6 306176 VALVE, GAS 10 1
7 306106 COIL, HOLDING & BOOSTER 10 1
8 306105 COIL, SECONDARY 10 1
9 N 313561 SCREW----NA 10 2
10 N 33001834 BRACKET, GAS VALVE----NA 10 1
11 314082 SCREW 10 1
- 314568 SCREW-GAS VALVE TO BRACKET 10 1
12 310632 SCREW 10 1
13 33001842 CONNECTOR, ANGLE Note: INCORPORATED INTO ITEM 14 AT SERIES 20 10 1
14 33001735 PIPE & BRACKET ASSY. 21 1
14 33003029 CONTROL, GAS ASSEMBLY 20 1
14 33001735 PIPE & BRACKET ASSY. 10 1
15 211294 SCREW 10 7
16 33002765 INLET DUCT ASSEMBLY (GAS) 1
16 33001810 DUCT ASSY., INLET (GAS) 10 1
17 303395 THERMOSTAT, HI-LIMIT (GAS) 10 1
18 303377 SENSOR, RADIANT 10 1
19 216423 SCREW 10 2
19 33001835 CONE ASSY., COMBUSTION 10 1
20 Y303841 CONE, EXTENSION (COMBUSTION) 10 1
21 216423 SCREW 10 2
21 Y312890 RETAINER, HEATER CHAMBER 10 1
22 33001693 CAP, GAS PIPE 10 1
23 216423 SCREW 10 4
12
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: MOTOR DRIVE
LD11-85
Model: MDG2500BWW
13

MOTOR DRIVE
No. Part No. Description
Section:
Series Qty
1 33001789 HOUSING, BLOWER 10 1
2 33001800 DUCT ASSY., EXHAUST 10 4
- 22001995 SCREW 10 1
3 410233 RING, RETAINING 10 2
4 33001790 WHEEL, BLOWER 10 1
5 312967 CLAMP, BLOWER HOUSING 10 1
6 33001855 SCREW (HEX HEAD) 10 8
7 N 313561 SCREW----NA 10 1
8 307250 THERMOSTAT, MULTI-TEMP (GAS) 10 1
9 216423 SCREW 10 2
10 33001762 FUSE, THERMAL (W' BRACKET) 10 1
11 314848 SCREW 10 1
12 22002244 CLIP, GROUNDING 10 1
13 N 33001873 COVER, BLOWER HOUSING----NA 10 1
14 314818 SCREW 10 4
15 33002478 MOTOR 10 1
16 Y015825 CLIP, MOTOR 10 2
17 33001854 SWITCH, MOTOR 10 1
- 33002461 PLUG FOR SPRING 10 1
- 33002157 GROMMET 10 1
18 33002460 SPRING, IDLER Note: SPRING & PLUG KIT 33002459 10 1
19 33001840 IDLER ARM & SHAFT ASSY. 10 1
20 312527 WASHER, IDLER SHAFT (QTY-1) 10 2
21 33001783 BEARING, IDLER ASSEMBLY 10 1
22 312958 RETAINING RING, IDLER SHAFT 10 1
23 315772 SLEEVE, IDLER ARM 10 1
24 Y014874 SCREW 10 1
- N 313561 SCREW----NA 10 1
25 33002466 SUPPORT, MOTOR 10 1
26 N 313561 SCREW----NA 10 2
27 N 33002465 BASE, (LWR)----NA 10 1
27 N 33002465 BASE, (LWR)----NA 38 1
27 33002622 BASE, (LWR) 36 1
28 410490 SPRING, WIRE HARNESS 10 2
29 305086 ADJUSTABLE LEG & NUT 10 4
30 Y052740 NUT 10 4
31 314137 FOOT, RUBBER 10 4
32 22002239 CLIP, LOWER FRONT PANEL 10 2
33 310632 SCREW 10 2
14
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: WIRING INFORMATION
15002735
Model: MDG2500BWW
15
