MDG75V
(1.000 CFM/Phase 5 and D.T.)
Installation Manual
112602JEV/mcronan PartNo.113160
RETAINTHESEINSTRUCTIONS INASAFE
PLACE FOR FUTURE REFERENCE
WARNING: Foryoursafetytheinformationin
thismanual must befollowedto minimize the
riskof fire orexplosionor topreventproperty
damage,personalinjuryordeath.
— Donotstore or use gasolineorotherflammable
vapors and liquids in the vicinity of this or any
otherappliance.
— WHATTODO IFYOU SMELLGAS:
• Donottrytolightanyappliance.
• Donottouchanyelectricalswitch;donot
useanyphoneinyourbuilding.
• Cleartheroom,buildingorareaofall
occupants.
• Immediatelycallyourgassupplierfroma
neighbor’sphone. Followthegassupplier’s
instructions.
• Ifyoucannotreachyourgassupplier,call
thefiredepartment.
— Installationandservice must beperformedbya
qualified installer, service agency or the gas
supplier.
AVERTISSEMENT: Assurez-vous de bien
suivrelesinstructionsdonnéesdanscettenotice
pourréduireau minimum lerisqued’incendie
ou d’explosion ou pour éviter tout dommage
matériel,touteblessureoulamort.
— Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides inflammables à
proximité de cet appareil ou de tout autre
appareil.
— QUEFAIRESIVOUSSENTEZUNEODEUR
DEGAZ:
• Nepastenterd’allumerd’appareils.
• Netouchez à aucun interrupteur. Ne pas
vousservirdestéléphonessetrouvantdans
lebâtiment.
• Évacuezlapièce,lebâtimentoulazone.
• Appelezimmédiatementvotrefournisseur
degazdepuisunvoisin. Suivez les
instructionsdufournisseur.
• Sivousnepouvez rejoindrelefournisseur
degaz,appelezleservicedesincendies.
— L’installationetl’entretiendoiventêtreassuréspar
uninstallateurouunserviced’entretienqualifié
ouparlefournisseurdegaz.

Retain This Manual In ASafe Place For Future Reference
This product embodies advanced concepts in engineering, design, and safety. If this product is properly maintained, it will
provide many years of safe, efficient, and trouble free operation.
ONLY qualified technicians should service this equipment.
OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with
the dryer.
The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.
“IMPORTANTNOTETOPURCHASER”
Informationmustbeobtainedfromyourlocalgassupplierontheinstructions
tobefollowediftheusersmellsgas. Theseinstructions mustbeposted in a
prominentlocationnearthe dryer.
We have tried to make this manual as complete as possible and hope you will find it useful. The manufacturer reserves the
right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to
change or discontinue models. The illustrations included in this manual may not depict your particular dryer exactly.
Important
For your convenience, log the following information:
DATE OFPURCHASE________________________________ MODELNO. __________________________________________
DEALER’SNAME __________________________________________________________________________________________
Serial Number(s) ________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
Forreplacementparts, contact the dealerfromwhichthedryerwas purchased or contact:
Maytag Co.
403 West Fourth Street North
Newton, Iowa 50208
[phone]
FORYOURSAFETY
Donot store orusegasolineor
otherflammablevaporsand
liquidsinthevicinityofthisor
anyotherappliance.
POURVOTRESÉCURITÉ
Nepasentreposerniutiliser d’essence
nid’autresvapeursou liquides
inflammablesàproximitédecet
appareiloude tout autre appareil.

IMPORTANT
YOUMUSTDISCONNECTANDLOCKOUTTHEELECTRICSUPPLYANDTHEGAS
SUPPLY OR THE STEAM SUPPLY BEFORE ANY COVERS OR GUARDS ARE
REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING,
ADJUSTING, INSTALLATION, OR TESTING OFANY EQUIPMENT PER OSHA
(OccupationalSafety andHealthAdministration) STANDARDS.
WARNING
CHILDRENSHOULDNOTBEALLOWEDTOPLAYONORNEARTHEDRYER(S).
CHILDRENSHOULDBESUPERVISEDIFNEARDRYERSINOPERATION.
CAUTION
DRYERSSHOULDNEVERBELEFTUNATTENDEDWHILEINOPERATION.
FORYOURSAFETY
DONOTDRYMOPHEADSINTHEDRYER.
DONOTUSEDRYERINTHEPRESENCEOFDRYCLEANINGFUMES.
WARNING
UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switch,
or heat safety circuit ever be disabled.
“Caution: Label all wires prior to
disconnection when servicing controls. Wiring
errors can cause improper operation.”
«Attention: Au moment de l’entretien des
commandes,étiquetez tousles filsavant de
les débrancher. Des erreurs de câblage
peuvent entraîner un fonctionnement
inadéquatet dangereux.»

WARNING
The dryer must never be operated with any of the back guards, outer tops, or service
panelsremoved. PERSONALINJURYORFIRECOULDRESULT.
IMPORTANT
PLEASEOBSERVEALLSAFETYPRECAUTIONSdisplayedontheequipmentand/or
specified in the installation manual included with the dryer.
WARNING
DRYERMUSTNEVERBE OPERATEDWITHOUTTHELINTFILTER/SCREENIN
PLACE,EVENIFANEXTERNALLINTCOLLECTIONSYSTEMISUSED.
Dryer mustnotbe installed or stored in an area where it willbe exposed to water or weather.
The wiring diagram for the dryer is located in the front electrical control box area.

Table of Contents
SECTION I
IMPORTANT INFORMATION............................................................................... 3
A. ReceivingandHandling ............................................................................................................... 3
B. SafetyPrecautions ...................................................................................................................... 4
SECTION II
SPECIFICATIONS ....................................................................................................6
A. Specifications ............................................................................................................................. 6
B. ComponentIdentification ............................................................................................................ 8
SECTION III
INSTALLATION PROCEDURES .........................................................................10
A. LocationRequirements ............................................................................................................. 10
B. Unpacking/SettingUp ............................................................................................................... 11
C. DryerEnclosureRequirements .................................................................................................. 12
D. FreshAirSupplyRequirements ................................................................................................. 13
E. ExhaustRequirements ............................................................................................................... 14
F. ElectricalInformation ................................................................................................................ 19
G. GasInformation ........................................................................................................................ 25
H. Preparation ForOperation/Start-Up ......................................................................................... 29
I. PreoperationalTests ................................................................................................................. 30
J. PreoperationalInstructions ........................................................................................................ 32
K. ShutdownInstructions............................................................................................................... 32
SECTION IV
SERVICE/PARTS INFORMATION......................................................................33
A. Service ..................................................................................................................................... 33
B. Parts ........................................................................................................................................ 33
SECTION V
ROUTINE MAINTENANCE..................................................................................34
A. Cleaning ................................................................................................................................... 34
B. Adjustments ............................................................................................................................. 35
C. Lubrication ............................................................................................................................... 35
D. LintDrawerRemoval................................................................................................................ 36

SECTION VI
TROUBLESHOOTING...........................................................................................37
SECTION VII
DATA LABEL INFORMATION.............................................................................43
A. DataLabel ............................................................................................................................... 43
SECTION VIII
PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT
COMPONENTS .......................................................................................................45

3
SECTIONI
IMPORTANTINFORMATION
A. RECEIVINGAND HANDLING
The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or
optional box) as a means of preventing damage in transit. Upon delivery, the dryer and packaging, and wooden
skid should be visually inspected for shipping damage. If any damage whatsoever is noticed, inspect further
before delivering carrier leaves.
Dryers damaged in shipment:
1. ALL dryers should be inspected upon receipt and before they are signed for.
2. If there is suspected damage or actual damage, the trucker’s receipt should be so noted.
3. If the dryer is damaged beyond repair, it should be refused. Those dryers, which were not damaged in a
damaged shipment, should be accepted, but the number received and the number refused must be noted
on the receipt.
4. If you determine that the dryer was damaged after the trucker has left your location, you should call the
delivering carrier’s freight terminal immediately and file a claim. The freight company considers this
concealed damage. This type of freight claim is very difficult to get paid and becomes extremely difficult
when more than a day or two passes after the freight was delivered. It is your responsibility to file freight
claims. Dryer/parts damaged in transit cannot be claimed under warranty.
5. Freight claims are the responsibility of the consignee, andALL claims must be filed at the receiving end.
Manufacturer assumes no responsibility for freight claims or damages.
IMPORTANT: Thedryer mustbe transportedand handledin anupright position atALLtimes.

4
B. SAFETY PRECAUTIONS
WARNING: Foryoursafety, theinformationinthismanualmustbefollowedtominimizethe riskof
fireorexplosionortopreventpropertydamage,personalinjury,orlossoflife.
WARNING: The dryermust neverbeoperated withany ofthe backguards,outer tops,or
servicepanels removed. PERSONALINJURYOR FIRECOULD RESULT.
1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
2. Purchaser and user should consult the local gas supplier for proper instructions to be followed in the event
the user smells gas. The instructions should be posted in a prominent location.
3. WHAT TO DO IF YOU SMELL GAS...
a. DO NOT try to light any appliance.
b. DO NOT touch any electrical switch.
c. DO NOT use any phone in your building.
d. Clear the room, building, or area of ALL occupants.
e. Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
f. If you cannot reach your gas supplier, call the fire department.
4. Installation and service must be performed by a qualified installer, service agency, or gas supplier.
5. Dryers must be exhausted to the outdoors.
6. AlthoughMaytag produces a very versatile dryer, there are some articles that, due to fabric composition or
cleaning method, should not be dried in it.
WARNING: Dry only waterwashedfabrics. DONOTdry articlesspottedor washed indry
cleaningsolvents,acombustibledetergent,or“allpurpose”cleaner.
EXPLOSIONCOULDRESULT.
WARNING: DONOT dryragsorarticles coated orcontaminatedwithgasoline,kerosene,oil, paint,
orwax.
EXPLOSIONCOULDRESULT.

5
WARNING: DONOTdry mop heads. Contamination by waxorflammablesolventswillcreatea
firehazard.
WARNING: DONOTuse heat fordryingarticlesthatcontainplastic, foam, sponge rubber,or
similarlytexturedrubbermaterials. Drying inaheatedbasket(tumbler)maydamage
plasticsorrubber and maybeafirehazard.
7. A program should be established for the inspection and cleaning of lint in the burner area, exhaust ductwork,
and area around the back of the dryer. The frequency of inspection and cleaning can best be determined
from experience at each location.
WARNING: Thecollectionoflintintheburnerareaandexhaustductworkcancreateapotentialfire
hazard.
8. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the
National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION or in Canada, the Canadian Electrical
Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.
NOTE: Failuretodoso willVOIDTHEWARRANTY.
9. UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switch, or heat safety
circuit ever be disabled.
WARNING: PERSONALINJURYORFIRECOULD RESULT.
10. This dryer is not to be used in the presence of dry cleaning solvents or fumes.
11. Remove articles from the dryer as soon as the drying cycle has been completed.
WARNING: Articlesleftinthedryerafterthedrying and cooling cycles havebeencompletedcan
createafire hazard.
12. READ AND FOLLOW ALL CAUTION AND DIRECTION LABELS ATTACHED TO THE
DRYER.
13. For safety, proper operation, and optimum performance, the dryer must not be operated with a load less
than sixty-six percent (66%) 50 lbs (22.7 kg) of its rated capacity.
WARNING: YOU MUSTDISCONNECTANDLOCKOUTTHEELECTRICSUPPLYAND
THEGAS SUPPLY BEFOREANYCOVERSOR GUARDSAREREMOVED
FROMTHEMACHINETOALLOWACCESS FORCLEANING,
ADJUSTING, INSTALLATION,ORTESTINGOFANYEQUIPMENTPER
OSHA(OccupationalSafetyandHealthAdministration)STANDARDS.

6
SECTIONII
SPECIFICATIONS
A. SPECIFICATIONS
*ALLMDG75V reversing dryers are supplied with two (2) 3-phase (3ø) motors standard: a 1/2 HP (0.37 kw)
blower motor and a 1/2 HP (0.37 kw) drive motor.
** Size of piping to dryer varies with installation conditions. Contact factory for assistance.
NOTE: Manufacturerreservestherighttomake changes in specificationsatanytimewithoutnotice
orobligation.
Gas
MAXIMUM CAPACITY (DRY WEIGHT) 75 lbs 34 kg
BASKET (TUMBLER) DIAMETER 37” 94 cm
BASKET (TUMBLER) DEPTH 36” 91.5 cm
BASKET (TUMBLER) MOTOR 1 HP* 0.745 kw
DOOR OPENING (DIAMETER) 21-1/2” 54.61 cm
BASKET (TUMBLER) VOLUME 22.4 cu. ft. 0.634 cu.m.
EXHAUST CONNECTION (DIAMETER) 8” 20.3 cm
AIRFLOW 1000 cfm 28.3 cmm
DRYERS PER 20'/40' CONTAINER 10/20
DRYERS PER 48'/53' TRUCK 24/26
VOLTAGE AVAILABLE 120-460v 1ø-3ø 3, 4w 50/60 Hz
APPROX. WEIGHT (UNCRATED) 721 lbs 327 kg
APPROX. WEIGHT (CRATED) 771 lbs 349.7 kg
HEAT INPUT 175,000 btuh 44,100 kcal/hr
INLET PIPE CONNECTION 3/4” F.P.T.**
Shaded areas are stated in metric equivalents
