Maytag MGD5600TQ1 User manual

TOP AND CONSOLE PARTS
1
For Model: MGD5600TQ1
(White)
10−07 Litho in U.S.A.(LT) Part No. W10155382 Rev. A
29" GAS DRYER

TOP AND CONSOLE PARTS
2
For Model: MGD5600TQ1
(White)
W10155382
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10088775 Use & Care Guide
8578217 Wiring Diagram
W10089170 Sheet,
Cycle Feature
2
W10113080 Wire, Jumper
Mini−Buzzer
3 694419 Buzzer, Mini
4
W10112578 Bracket, Harness
5 717252 Plug, 2−Way
Terminal
6
W10112577 Panel, Rear
Console
7 3399639 Switch,
Temperature
8 8312709 Clip−Console (2)
9 693995 Screw, Hex
Washer Head
10 8565972 Screen, Lint
11 8536939 Clip, Spring
12 8533971 Screw, 8−18 x 5/16
13 688983 Screw, 8−18 x 5/8
14
W10110861 Wire, Jumper
(Temperature)
15 3395683 Connector
(Motor)
16
W10112597 Top
17 359625 Screw, 8−18 x 1/2
18
W10110029 Knob, Control (2)
19 3394427 Clip−Harness
20 3936144 Connector
21 8299765 Timer Assembly
(60 Hz.)
22 3397269 Connector−Timer
23 3401144 Connector,
(PTS Relay)
24 3403499 Connector,
2−Position
(Gas Valve)
25 3403498 Connector,
3−Position
(Gas Valve)
26
W10086704 Console & Control
Panel Assembly
(Includes,
Illus. 6 & 30)
27
W10117655 Switch,
Push−To−Start
28
W10110030 Timer−Knob
Assembly
29 94614 Terminal, Female
30
W10112569 Badge−Assembly
31
W10110992 Harness, Wiring
32
W10112603 Seal−Harness
33 3347243 Connector
6−Circuit

CABINET PARTS
3
For Model: MGD5600TQ1
(White)
W10155382

CABINET PARTS
4
For Model: MGD5600TQ1
(White)
W10155382
Illus. Part
No. No. DESCRIPTION
1 697776 Screw, 10−32 x 5/8
(External Ground)
2 343641 Screw, 10−16 x 1/2
3 693995 Screw, Hex Head
4 8541400 Bracket, Cabinet
5 3396795 Cover, Block
6 3404162 Clamp, Motor
(W/Shield)
7 3396805 Panel, Rear
8 3403630 Clip,
9 3980175 Clamp−Elbow
10 3406107 Door Switch
Assembly
11 697773 Screw, 6−20 x 7/8
12 344020 Cord, Power
13 341029 Clamp, Pipe
14 3404413 Plug−Hole
15 3394083 Clip, Front Panel
16 3392100 Foot, Dryer
279810 Foot−Optional
(Extended Length)
(Package of 2)
(Not Included.)
17 660658 Clamp, Motor
18 8530603 Cabinet
(Includes
Illus. 4)
19 98234 Clip, Ground (2)
20 690363 Lock, Front Top (2)
21 3403447 Panel Front
22 8066217 Hinge, Top (2)
23 685203 Clip, Felt Pad (2)
24 3389441 Catch, Door
Assembly
25 3405246 Seal, Door
26 691366 Idler & Pulley
Assembly
27 342055 Screw, 8−18 x 1/2
28 3405514 Hinge, Door
29 8066206 Motor Assembly
30 8066184 Pulley−60 Hz.
31 8066065 Belt, Drive
32 3400500 Bolt,
5/16−18 x 3/4
33 3403431 Strike, Panel
34 348780 Base, Motor
35 3402341 Door, Rear
36 3402335 Door, Front
37 8565970 Handle, Door
38 3406129 Seal & Bearing
Assembly
39 3394975 Plug, Front Panel
40 8318272 Burner, Assembly
60 HZ.
(See Pages 7 & 8
For Further
Burner Breakdown)

BULKHEAD PARTS
5
For Model: MGD5600TQ1
(White)
W10155382

BULKHEAD PARTS
6
For Model: MGD5600TQ1
(White)
W10155382
Illus. Part
No. No. DESCRIPTION
1 348368 Lint Chute
Assembly
2 489463 Screw, 8−18 x 5/8
3 3388703 Washer−Support
4 347139 Seal, Lint
Chute
5 90767 Screw, 8−18 x 3/8
6 487909 Screw, 8−15 x 1/2
7 3392519 Thermal−Fuse (91C)
8 8066086 Drum Hole
Plug
9 3387134 Thermostat,
Internal−Bias
10 694089 Wheel, Blower
11 8577230 Housing, Blower
12 3398161 Clip
13 343641 Screw, 10−16 x 1/2
14 8530285 Box, Heater
15 3403140 Thermostat, 205 F
(96 C)
16 280010 Kit,
Thermal Cut−Off
(Includes
Illus. 15)
17 3390647 Screw, 8−18 x 1/2
18 8066049 Funnel, Burner
19 3403634 Socket Assembly
20 3406124 Bulb
22 3977373 Bracket, Drum
Light
23 3406022 Bracket, Bulkhead
24 3401707 Wire, Jumper
25 690997 Ring, Tri
26 3399506 Shaft, L.H.
27 3399507 Shaft, R.H.
28 3397590 Roller, Support
29 348197 Washer, Support
30 3359452 Nut, 3/8−16
31 3403413 Bulkhead
32 338906 Sensor, Radiant
33 3402841 Lens, Drum Light
34 692526 Ring, Bearing
35
W10109200 Screw, 11−16 x 3/4
36 3406130 Seal, Rear Drum
37 695587 Drum Assembly
38 692490 Baffle, Drum (2)
39 3976434 Bracket, Support
40 90296 Clip
41 3403636 Baffle, Drum (1)
42 339956 Seal
43 696302 Shield, Exhaust

BA−150
8318272 BURNER ASSEMBLY
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
7
For Model: MGD5600TQ1
(White)
W10155382

Illus. Part
No. No. DESCRIPTION
BA−150
8318272 BURNER ASSEMBLY
USE WITH TYPE 1 − NATURAL
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
1 8318272 Burner Assembly
60 Hz.
(Type 1)
(White Rodgers)
2 688617 Tube, Burner
3 694298 Bracket, Ignitor
4 686590 Ignitor
5 3393909 Screw & Washer
(8−32 x 5/8)
6 343641 Screw, 10−16 x 1/2
7 693986 Base, Burner
8 3387057 Screw, 8−18 x 3/8
9 Orifice, Burner
234826 Type 1
229742 Type 4 (Butane)
234868 Type 4 (Propane)
10 8318277 Valve, 60 Hz.
(Includes Pipe &
Illus. #7)
11 694421 Screw,
8−32 x 1/2 (2)
12 694538 Bracket, Coil
13 694540 Coil, 60 Hz.
(2 Terminal)
(Main)
14 694539 Coil, 60 Hz.
(Split)
(3 Terminal)
(Pilot Position)
15 694424 Leak Limiter
16 694423 Screw, Regulator
Adjustment
17 694422 Spring, Regulator
20 239822 Plug, Pipe
25 341029 Clamp, Pipe
694572 Conversion Kit
(Type 1)
to Type (4) L.P.G.
Following Parts Not Illustrated
8
For Model: MGD5600TQ1
(White)
W10155382

OPTIONAL PARTS (NOT INCLUDED)
9
For Model: MGD5600TQ1
(White)
W10155382
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
279948 Kit,
Dryer Repair
346764 Kit, Hold−Down
(Gas Dryer Mobile
Home Installation)
8522199 Kit, Dryer
Vent Testing
3406839 Dry Rack
PAINT, TOUCH−UP (1/2oz.)
72017 White
4392899 Biscuit
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
4392901 Biscuit
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
4392900 Biscuit (Uncut)
