Maytag W10873035A User manual

W10873035A
W10873049A - SP
ELECTRIC or GAS DRYER
USE AND CARE GUIDE
Table of Contents Table des matières
DRYER SAFETY ............................................................2
CHECK YOUR VENT SYSTEM
FOR GOOD AIR FLOW .................................................4
USE SENSOR DRY CYCLES FOR BETTER
FABRIC CARE AND ENERGY SAVINGS......................4
CONTROL PANEL & FEATURES..................................5
CYCLE GUIDE...............................................................6
USING YOUR DRYER ...................................................7
DRYER CARE................................................................9
TROUBLESHOOTING.................................................11
WARRANTY.................................................................13
ASSISTANCE OR SERVICE....................BACK COVER
SÉCURITÉ DE LA SÉCHEUSE ...................................14
VÉRIFICATION D’UNE CIRCULATION
D’AIR ADÉQUATE POUR LE SYSTÈME
D’ÉVACUATION ..........................................................16
UTILISATION DES PROGRAMMES DE SÉCHAGE
PAR DÉTECTION POUR UN MEILLEUR SOIN
DU TISSU ET DAVANTAGE D’ÉCONOMIES
D’ÉNERGIE..................................................................16
TABLEAU DE COMMANDE
ET CARACTÉRISTIQUES ...........................................17
GUIDE DE PROGRAMMES ........................................18
UTILISATION DE LA SÉCHEUSE...............................19
ENTRETIEN DE LA SÉCHEUSE.................................21
DÉPANNAGE. ..............................................................24
GARANTIE...................................................................26
ASSISTANCE
OU SERVICE. ........................COUVERTURE ARRIÈRE
SÉCHEUSE
ÉLECTRIQUE ou À GAZ
GUIDE D’UTILISATION
ET D’ENTRETIEN
Para una versión de estas instrucciones en español, visite www.maytag.com

2
DRYER SAFETY

3

4
CHECK YOUR VENT SYSTEM FOR GOOD AIR FLOW
Good air ow
Along with heat, dryers require good air ow to
efciently dry laundry. Proper venting will reduce your
drying times and improve your energy savings. See
“Installation Instructions.”
The venting system attached to the dryer plays a big role in
good air ow.
Service calls caused by improper venting are not covered
by the warranty and will be paid by the customer, regardless
of who installed the dryer.
Maintain good air ow by:
Good Better
USE SENSOR DRY CYCLES FOR BETTER FABRIC CARE
AND ENERGY SAVINGS
Use the SENSOR DRY cycles to provide the most energy savings and enhanced fabric care from the dryer. During SENSOR DRY
cycles, drying air temperature or moisture level are sensed in the load. This sensing occurs throughout the drying cycle and the
dryer shuts off when the load reaches the selected dryness. The Energy Preferred cycle will provide optimal energy savings.
With Timed Dry, the dryer runs the amount of time set and sometimes results in shrinkage, wrinkling, and static due to over-drying.
Use Timed Dry for the occasional damp load that needs a little more drying time or when using the drying rack.
n Cleaning your lint screen before each load.
n Replace plastic or foil vent material with 4" (102 mm)
diameter heavy, rigid vent material.
n Use the shortest length of vent possible.
n Use no more than four 90° elbows in a vent system;
each bend and curve reduces air ow.
n Remove lint and debris from the exhaust hood.
n Remove lint from the entire length of the vent system at
least every 2 years. When cleaning is complete, be sure
to follow the “Installation Instructions” supplied with your
dryer for nal product check.
n Clear away items from the front of the dryer.

5
CONTROL PANEL & FEATURES
TEMPERATURE
Select a drying temperature based on the fabrics in your
load. If you are unsure of the temperature to select for a
load, select the lower setting rather than the higher setting.
SIGNAL
The Signal produces an audible sound when the drying cycle
is nished. Promptly removing clothes at the end of the cycle
reduces wrinkling.
Turn the SIGNAL knob to select the desired setting (Off,
Low, or High).
CYCLE KNOB
Use Cycle Knob to select available cycles on your dryer.
Turn the knob to select a cycle for your laundry load. See
“Cycle Guide” for detailed descriptions of cycles.
TIMED DRY
Will run the dryer for the specied time on the control.
On models with a selectable temperature knob, you
may choose a setting based on the fabrics in your load.
On some models, temperature is included in the cycle
selections. Drying time and temperature will depend on
your dryer model.
SENSOR DRY
Senses moisture in the load or air temperature and
shuts off when the load reaches the selected dryness
level. Gives the best drying in the shortest time. Drying
time will vary based on fabric type, load size, and
temperature setting.
1
2
5
WRINKLE CONTROL Feature
The WRINKLE CONTROL feature will run after your drying
cycle is complete. It periodically starts and stops the dryer,
tumbling the load without heat to help avoid wrinkling.
WRINKLE CONTROL automatically starts at the end of the
cycle. Opening the door will stop this feature.
n Get up to 120 minutes of heat-free, periodic tumbling at
the end of a cycle. Turn the WRINKLE CONTROL knob
to OFF, 60 min., or 120 min. at any time before the cycle
has ended.
NOTE: A signal will sound periodically when the WRINKLE
CONTROL setting is selected, but only if the Signal is also
selected.
PUSH TO START
Press the PUSH TO START knob to start the dryer.
Not all features and options are available on all models.
Appearance may vary.
52 3 41
3
4

6
SENSOR DRY - Senses moisture in the load or air temperature and shuts off when the load reaches the selected dryness level.
Choose ENERGY PREFERRED cycle for optimal energy savings.
Not all cycles and settings are available on all models.
Items to dry: Temperature: Available
Options: Cycle Details:
Signal
Wrinkle Control
CYCLE GUIDE — SENSOR DRY CYCLES
CYCLE GUIDE — TIMED DRY CYCLES
TIMED DRY - Will run the dryer for the specied time on the control.
Not all cycles and settings are available on all models.
NOTE: If loads do not seem as dry as you would like, select More Dry next time you dry a similar load. If loads seem drier than you
like, select Less Dry next time you dry a similar load.
Casual, shirts, pants,
lightweight items,
synthetics, delicates,
athletic wear
Signal
Wrinkle Control
Jeans, heavy work
clothes, towels
More Dry
Energy Preferred
Less Dry
More Dry
Energy Preferred
Less Dry
More Dry
Energy Preferred
Less Dry
Signal
Wrinkle Control
Automatic cycles give the best drying
in the shortest time. Drying time varies
based on fabric type, load size, and
dryness setting.
Select a drying temperature based on
the fabrics in your load. If you are unsure
of the temperature to select for a load,
select the lower setting rather than the
higher setting.
Dryness Level:
High
Medium or
Low
Low
Work clothes, medium
weight fabrics, sheets
Items to dry: Temperature:Cycle: Available
Options: Cycle Details:
Setting the Drying Temperature
If your dryer has multiple heat settings:
A High temperature setting may be used for drying
heavyweight items such as towels and work clothes.
A Low to Medium temperature setting may be used for drying
medium-weight items such as sheets, blouses, dresses,
underwear, permanent press fabrics, and some knits.
Use the Air Fluff (no heat) setting for foam, rubber, plastic, or
heat-sensitive fabrics.
Line dry bonded or laminated fabrics.
NOTE: If you have questions about drying temperatures for
various loads, refer to the care label directions.
Rubber, plastic, heat
sensitive fabrics Timed Dry Air Fluff Signal No heat drying.
Any load Freshen Up Any Signal Use low to medium temperature to
smooth out wrinkles, such as those
found in clothes packed in a suitcase or
in items wrinkled from being left in the
dryer too long.
Towels, bedding,
children’s clothing Sanitize Sanitize Signal Extended high-heat drying cycle intended to help sanitize items such as
bedding, towels, and baby wear. This
cycle is not recommended for all fabrics.
For best results, run cycle to completion,
do not interrupt.

7
USING YOUR DRYER
1. Clean the lint screen
Clean the lint screen before each load. Pull the lint screen out
of its holder. Roll lint off the screen with your ngers. Do not
rinse or wash screen to remove lint. Push the lint screen rmly
back into place.
For additional cleaning information, see “Dryer Care”.
2. Load the dryer
Place laundry in the dryer. Close the door.
Do not tightly pack the dryer; clothes should be able to
tumble freely.
NOTE: Your model may have a different door than the one
shown. Some models have drop down doors.
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this dryer.
Before using your dryer, wipe the dryer drum with a damp cloth
to remove dust from storing and shipping.
3. Select the desired cycle
Select the desired cycle for your load. See the Cycle Guide
for more information about each cycle.
SENSOR DRY Cycles
You can select a different dryness level, depending on your
load, by turning the knob to dryness level.
Selecting More Dry, Energy Preferred, or Less Dry
automatically adjusts the dryness level of the fabrics at which
the dryer will shut off.
SENSOR DRY cycles give the best drying in the shortest time.
Drying time varies based on fabric type, load size, and dryness
setting. Choose Energy Preferred for optimal energy savings.
Less Dry removes less moisture and is used for loads you may
want to put on a hanger to complete drying.
More Dry removes more load moisture. Energy Preferred is
used for a starting point for SENSOR DRY cycles.

8
7. Press PUSH TO START to begin
cycle
Push and hold the PUSH TO START knob to begin the cycle.
4. Set temperature
Select temperature by turning the knob to the desired position
or select the Sensor Dry cycle that has the temperature
included in the cycle selections. Turn the TEMPERATURE knob
to change the drying temperature setting. See “Setting the
Drying Temperature”.
NOTE: Not all options and settings are available with all cycles.
5. Select Signal (if desired)
Turn the SIGNAL knob to select the desired setting (Off, Low,
or High). The Signal produces an audible sound when the
drying cycle is nished. Promptly removing clothes at the end
of the cycle reduces wrinkling.
DRYING RACK
To purchase a drying rack for your dryer, please refer to
“Assistance or Service” on the back cover of the manual or
contact the dealer from whom you purchased your dryer.
Part Number Accessory
3406839 Drying rack - ts 29" Super Capacity Plus
6. Select Wrinkle Control (if desired)
Select Wrinkle Control by turning the knob to the
desired position.
Get up to 120 minutes of heat-free, periodic tumbling at the
end of a cycle. Turn the WRINKLE CONTROL knob to OFF,
60 min., or 120 min. at any time before the cycle has ended.
NOTE: Not all options and settings are available with
all cycles.

9
DRYER CARE
Keep dryer area clear and free from items that would
block the air ow for proper dryer operation. This includes
clearing piles of laundry in front of the dryer.
Cleaning the lint screen
Every load cleaning
The lint screen is located in the dryer. A screen blocked by
lint can increase drying time.
To clean:
1. Pull the lint screen out of its holder. Roll lint off the
screen with your ngers. Do not rinse or wash screen to
remove lint. Wet lint is hard to remove.
2. Push the lint screen rmly back into place.
IMPORTANT:
n Do not run the dryer with the lint screen loose,
damaged, blocked, or missing. Doing so can cause
overheating and damage to both the dryer and fabrics.
n If lint falls off the screen into the dryer during removal,
check the exhaust hood and remove the lint. See
“Venting Requirements.”
As needed cleaning
Laundry detergent and fabric softener residue can build
up on the lint screen. This buildup can cause longer drying
times for your clothes, or cause the dryer to stop before
your load is completely dry. The screen is probably clogged
if lint falls off while the screen is in the dryer.
Clean the lint screen with a nylon brush every 6
months, or more frequently, if it becomes clogged due
to a residue buildup.
To wash:
1. Roll lint off the screen with your ngers.
2. Wet both sides of lint screen with hot water.
3. Wet a nylon brush with hot water and liquid
detergent. Scrub lint screen with the brush to
remove residue buildup.
4. Rinse screen with hot water.
5. Thoroughly dry lint screen with a clean towel. Reinstall
screen in dryer.
Cleaning the dryer interior
To clean dryer drum
1. Apply a liquid, nonammable household cleaner to the
stained area of the drum and rub with a soft cloth until
stain is removed.
2. Wipe drum thoroughly with a damp cloth.
3. Tumble a load of clean cloths or towels to dry the drum.
NOTE: Garments that contain loose dyes, such as denim
blue jeans or brightly colored cotton items, may discolor the
dryer interior. These stains are not harmful to your dryer and
will not stain future loads of clothes. Dry these items inside
out to avoid drum staining.
Removing accumulated lint
From Inside the Dryer Cabinet
Lint should be removed every 2 years, or more often,
depending on dryer usage. Cleaning should be done by a
qualied servicer.
From the Exhaust Vent
Lint should be removed every 2 years, or more often,
depending on dryer usage.
Cleaning the dryer location

10
Vacation, storage, and moving care
Non-Use or Storage Care
Operate your dryer only when you are at home. If you will
be on vacation or not using your dryer for an extended
period of time, you should:
1. Unplug dryer or disconnect power.
2. (For gas dryers only): Close shut-off valve to gas supply
line.
3. Clean lint screen. See “Cleaning the Lint Screen.”
Moving Care
For power supply cord-connected dryers:
1. Unplug the power supply cord.
2. Make sure leveling legs are secure in dryer base.
3. Use tape to secure dryer door.
For direct-wired dryers:
1. Turn off power at fuse or breaker box.
2. Disconnect wiring.
3. Make sure leveling legs are secure in dryer base.
4. Use tape to secure dryer door.
For gas dryers:
1. Unplug or disconnect power to dryer.
2. Close shut-off valve in gas supply line.
3. Disconnect gas supply line pipe and remove ttings
attached to dryer pipe.
4. Cap the open fuel supply line.
5. Make sure leveling legs are secure in dryer base.
6. Use tape to secure dryer door.
Reinstalling the Dryer
Follow the “Installation Instructions” to locate, level, and
connect the dryer.
Changing the drum light
(on some models)
1. Unplug dryer or disconnect power.
2. Open the dryer door. Locate the light bulb cover on the
back wall of the dryer. Using a Phillips-head screwdriver,
remove the screw located in the lower right-hand corner
of the cover. Remove the cover.
3. Turn bulb counterclockwise. Replace the bulb with
a 10-watt appliance bulb only. Replace the cover and
secure with the screw.
4. Plug into a grounded outlet or reconnect power.
