McDonnell Douglas MiniDV MD80 User manual

Please read this user manual carefully and thoroughly before any
attempt to install and operate this product and retain it for your future
reference.
Memorize every wonderful moment
with our cool recording gadget.
The smallest digital video camera in the world
with high resolution image.

TABLE OF CONTENTS
INTRODUCTION............................................................................1-2
Approval Information.....................................................................1
OVERVIEW........................................................................................3
APPLICATION ..................................................................................4
FEATURES.........................................................................................5
PACKING CONTENTS.......................................................................6
PRODUCT STRUCTURE....................................................................7
INSTALLATION...............................................................................8-9
OPERATION GUIDE............................................................10-11
SAVING FILE...................................................................................12
Adapter.......................................................................................2
SPECIFICATIONS...........................................................................14
PC CAMERA.....................................................................................13

INTRODUCTION
Thank you for purchasing . has the unique, ultra-small
and delicate design. It can be used in many recording situations.
MD80 brings more convenience, safety and funs to your daily life.
MD80 MD80
Approval Information
All our products meet the requirements of approval FCC or CE, and
are granted the FCC or CE certification. They are authorized to
bear FCC or CE mark.
FCC
This product has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
CE
This product complies with standards including Low Voltage Device
Directive 73/23/EEC; EMC Directive 89/336/EEC and R&TTE
-1-

Directive1999/5/EC. It passed the subject tests by the authority
concerned and is authorized to bear CE mark.
-2-
NOTICE:
When using the power adapter, make sure the rating voltage on it is compatible
with that of the device to avoid potential damages resulting from incorrect usage
of power supply.

Along with the improvement of people’s living standard and the
development of picture compression and memory technology, the
digital video memory has been a part of our daily life. MD80, a high-tech
product, just meets a plenty of needs of people and market. It
possesses a series of advanced functions including digital
photography, voice memory, sound trigger recording, high speed USB
data transferring and USB charging.
OVERVIEW
-3-
EU Environmental Protection
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling
advice.

APPLICATION
-4-
Family entertainment
recording Interview/business
meeting recording
RC toy recording
Happy time recording
Home & business
security recording Evidence collection
Babysitter monitoring
Outdoor sports/
Hunting recording
Pet fun recording

FEATURES
>Thumb size alloy housing
>Manually and sound activated recording
>Web camera for online video chat
>Support AVI video format
>Low illumination, high resolution image with 2000K pixels
>High speed recording and quick light response
>30 frames per second for 640*480 video output
>Support USB1.1/2.0
>Support 8G Micro SD card(Max)
>Built-in Li rechargeable battery lasting for 2 hours
>Easy operation with LED indicator
>Flexible installation with clip and bracket
-5-

PACKING CONTENTS
-6-
CD
Velcro
USB Cable
Lens Brush
Pouch
Adapter
Chain
Nails
Micro SD Card

PRODUCT STRUCTURE
Sound
Trigger
Switch
Micro
SD Card
Slot
Power
Switch
USB Jack
Record
Switch
Bracket Clip
Hanging
Ring
LED
Indicator
-7-
ON
OFF
VOX
Mirco SD
ON
OFF
PWER
O

INSTALLATION
Load camera into clip Load clip into bracket Finished mount
1. With unique clip design and flexible installation, MD80 can be fixed on
the backpack, hat, pocket, collar and other suitable locations per various
monitoring demands.
-8-
ON
OFF
VOX
Mirco SD
ON
OFF
VOX
Mirco SD
Mirco SD
OFF
VOX
ON

Nails or Screws Velcro Magnet
o
2. Unique bracket design can support wide angle shooting, pan:360 ,
o
tilt:150 , bracket can be mounted with nails, screws, velcro or magnet.
-9-
3. Charm chain/key chain hanging for easy carrying.
o
360
o
150
ON
OFF
VOX
Mirco SD
ON
OFF
VOX
Mirco SD
4. Other usage modes.

OPERATION GUIDE
-10-
1. Insert Micro SD card.
2. The indicator will be blue when the power is on.
3.Recording mode
① Recording manually:when the sound trigger switch is off.
Press “Record Switch ”to start recording when power on ,
meanwhile the green indicator flashes slowly.
Press “Record Switch ”again to stop recording and the files will be
saved as “*.AVI” format.
NOTICE:
1 The blue indicator will flash slowly when the battery is low, after 2 minutes,MD80 will
power of f automatically.
2 The indicator turns green and flash quickly when there is no Micro SD card.
3 MD80 will enter standby mode if it is not used for 2 minutes when battery is not low.
NOTICE:
1 In standby mode, press “Record Switch” once to wake up the system while the indicator
displays blue color, and press “Record Switch”again to activate recording mode while the
indicator displays green color and flashes slowly.
2 The indicator will keep in green when the Micro SD card is full.

-11-
4.After recording, the files will be saved automatically.
B: MD80 will automatically enter standby mode when the sound
outside is lower than 65 decibel standing for 2 minutes.
C: In the standby mode ,if the sound outside is up to 65 decibel,
MD80 will enter recording mode again .
NOTICE:
Turn off the power during recording, recording stream will not be saved as file.
② Sound trigger recording: when the sound trigger switch is on.
A: Turn on the power, MD80 will enter recording mode if the sound
outside is up to 65 decibel.
5. The indicator will show red when MD80 is powered by USB or AC
adapter, when MD80 is full of charge, the indicator will go out.
6. The indicator sketch map.
Indicator State Motion
red always bright
go out
charge up
full of charge
green
always bright
flash quickly
flash slowly
full of card
no card
recording
blue
always bright
go out
power on
low battery
Standby
flash slowly
flash quickly copy data

SAVING FILE
Connect MD80 to PC by USB cable after recording, then copy the data
from MD80 to PC. You also can use card reader directly.
-12-
NOTICE:
Pay attention to the following conditions after connecting MD80 to PC with USB cable:
1. When the power is off,MD80 can be charged and the indicator turns red.
2. You can only copy the data from MD80 when the power is on and the sound trigger switch
is off.
3. MD80 can be used as a PC camera when the power is on and the sound trigger switch is on.
4.Turn off the power before plug and pull the USB cable.
USB Cable
PC
USB Jack
MD80
ON
OFF
POWER

-13-
PC CAMERA
Please install the camera driver before using PC camera. After
connecting MD80 to PC with USB cable, turn on the power and sound
trigger switch, then a video device will appear on the PC which indicates
MD80 can be used as a PC camera now.
ON
OF F
Sound trigger
switch
NOTICE:
You can only copy the data from MD80 when the sound trigger switch is off and the power
is on .
VOX
Web camera
for video chat
(Skype, MSN,
QQ)
Mirco SD

SPECIFICATIONS
-14-
*Specifications are subject to minor change with upgrade and update. Please base on real object.
Pixel 2000000 color CMOS
View Angle
Battery Capacity
o
62
260mAH
Consumption Current
Store Temperature
Operation Temperature
Operation Humidity
Memory medium
120mA/3.7V(Max.)
o o
-20 -80 C
o o
-10 C-50 C
15-85%RH
Micro SD card(TF Card)
SD Capability Max 8GB Micro SD Card
Video Function and
Format
USB Jack
Weight
Dimension
Operation System
Video decode use motion JPEG,recording for AVI format.
VGA(640 x 480@30frame/second)
USB1.1/2.0
50g(approx.)
55x28x20mm(approx.)
2000/XP/Vista 32
Minimum Illumination 1Lux(min)
Charge Time
Store Consumption
2h
1GB per 40 min
Standby Time 260h
