McLaughlin VERSA-MOLE McL-10H Operating instructions

COMPONENTS AND
REPAIR MANUAL
MODEL McL-10H VERSA-MOLE
UTILITY DRILL
PART NO. 8080000
Serial #__________________________________
Purchased &
Serviced Thru: ____________________________
Purchase Date: ___________________________
TABLE OF CONTENTS
Specifi cations & Maintenance....................................................................................... Section 1.0.0
Frame Assembly............................................................................................................ Section 2.0.0
Carriage Assembly........................................................................................................ Section 3.0.0
Console Assembly......................................................................................................... Section 4.0.0
Breakout Assembly........................................................................................................ Section 5.0.0
Hydraulics...................................................................................................................... Section 6.0.0
Water Parts.................................................................................................................... Section 7.0.0
Zap-AlertTM Operating Instructions/Strike Alert Components........................................ Section 8.0.0
Repair Instructions......................................................................................................... Section 9.0.0
Warranty Statement/Return Goods Policy................................................................... Section 10.0.0
© 2008 by McLaughlin Group, Inc.
All rights reserved. No part of this manual may be reproduced in any form or by any
means without prior permission of McLaughlin Group, Inc.
Repair Manual Part No.: E250060
Revision Date: 09/19/08

SPECIFICATIONS & MAINTENANCE
McL-10H VERSA-MOLE
McL-10H UTILITY DRILL
CAPABILITIES:
Dry Auger: 2" - 12" (5.1 - 30.5 cm)
Wet Guided Pilot: 2 - 2-7/8" (5.1 - 7.3 cm)
Back Reaming: 12" (30.5 cm)
Chuck Options:
Threaded: Tapered 1-5/8" (4.1 cm)
Hex Size: Customer to specify
13/16" 2.0 cm
1-1/8" 2.8 cm
1-3/8" 3.5 cm
1-5/8" 4.1 cm
PERFORMANCE:
Maximum Pressure: 2500 psi 170 bar
Maximum Flow: 25 gpm 95 lpm
Spindle Speed: 0 - 125 rpm 0 - 125 rpm
Thrust @ 2500 psi:
Forward: 17,670 lbs. 78,600 N
Pullback: 13,250 lbs. 58,950 N
Spindle Torque @ 2500 psi: 1030 ft.*lbs. 1400 Nm
DIMENSIONS: McL-10H-5 (5' version) McL-10H-7 (7'version)
Length: 60" 152.4 cm 84" 213.4 cm
Width: 45" 114.3 cm 45" 114.3 cm
Overall Height: 51" 129.5 cm 51" 129.5 cm
Drill Centerline: 12.25" 31.1 cm 12.25" 31.1 cm
Drill Height: 26" 66.0 cm 26" 66.0 cm
Drill Rod:
Length: 28" 71 cm 48" 122 cm
Weight 15 lbs. 7 kg 19 lbs. 9 kg.
Weight:
Complete Machine:
1100 lbs.
500 kg.
1200 lbs.
545 kg.
1.1.0

GENERAL MAINTENANCE
McL-10H VERSA-MOLE
CARRIAGE
Check all screws and nuts initially and then every week when
in continuous use. Tighten all loose nuts and screws. Replace
missing nuts or washer.
HYDRAULICS
Check all hoses and fi ttings for leaks initially and then every
week when in continuous use. When tightening fi ttings, be care-
ful not to twist hoses from their original positions.
Relieve system pressure before disconnecting hoses.
Clean the quick-disconnects and install the dust caps.
LUBRICATION
Lubricate the cam rollers with 1-2 pumps of grease each week.
Lubricate the chain drive every 2-3 days when in continuous use.
Use the grease fi tting on the sprocket guard and use 4-5 pumps
of all-purpose grease. Rotate the spindle while greasing the
chain.
Lubricate the bearing carrier every 4-5 days when in continuous
use. Use the grease fi tting on the top of the bearing housing.
Use about 4-5 pumps of all-purpose bearing grease. (Photo 1)
Disassemble, inspect and re-pack spindle bearings every 1000
hrs or every 12 months.
CHUCK
Check threaded chuck, each day in use. Check for scarred
threads. NOTE: Always use an approved drill thread lubricant
on the chuck and drill rods to prevent damage to the threads.
Use Jet-Lube - KOPR-KOTE with CZ-EX or equivilent. (Photo 2).
Check hex chuck evey day in use.
Lubricate hex on augers and chuck with penetrating oil.
NOTE: If the carriage is submerged under water:
Drain sprocket guard by removing bottom plug.
Re-lubricate bearing carrier, 4-5 pumps of grease.
Re-lubricate chain, 4-5 pumps of grease.
FRAME
SHEET METAL GUARDS
Check sheet metal guards each day. Make sure that guards are
properly secured at the top and the bottom. DO NOT OPERATE
MACHINE WITHOUT GUARDS IN PLACE. Replace missing or
damaged guards immediately. (Photo 3).
CONVEYOR GUARDS
Check condition of belting material each day. Replace as neces-
sary.
THRUST CHAIN
Check tension on thrust chain each week. Tighten as required
using the bottom adjusting nut. The chain should be tight when
tapped with a wrench. (Photo 4).
LUBRICATION
Grease the thrust chain once a week. Apply a light fi lm of
grease to the top and bottom of the chain. The thrust chain must
be re-lubricated after each time it is cleaned with a pressure
washer.
1.2.0
1
2
3
4
5
1
3

GENERAL MAINTENANCE
McL-10H VERSA-MOLE
1.3.0
6
8
MAKING AND BREAKING ROD JOINTS
Always use an approved thread lubricant on rods.
MAKING JOINTS
Insert the new rod into the existing rod clamped in
the breakout.
Rotate the rod 2-3 turns by hand to get threads
started.
Slowly position the carriage so the new rod
threads onto the chuck.
Rotate the spindle - but DO NOT THRUST - allow
the carriage to “walk” forward as the rod and
chuck screw together.
Run the machine over relief to tighten rods prop-
erly.
BREAKING JOINTS
Retract the carriage until the slider angle is even
with the rear notch in the side rail.
Activate the front clamp. Run it over relief.
Actuate the breakot cylinder. The joint at the
breakout should be loose.
Unscrew the rod about halfway out of the
clamped rod.
Retract the Float Indicator to the rear position.
Again, actuate the breakout cylinder.
The joint at the chuck should be loose.
Unscrew the chuck from the rod.
Fully retract the carriage.
Disengage the breakout.
Remove the rod.
IF FRONT JAW SLIPS, RE-ENGAGE TO FULL
SYSTEM PRESSURE.
IF JAWS SLIP, REPLACE THEM IMMEDIATELY.
(Photo 5).
Lubricate the pulley sheaves with penetrating oil. (Photo 6).
HYDRAULICS
Check for hydraulic leaks and tighten fi ttings as needed.
OPERATOR’S PLATFORM
Check that operator’s platforms fi ts securely on machine.
CONSOLE
HYDRAULICS
Check for hydraulic leaks and tighten fi ttings as needed.
Check guages for damage and accurate readings.
Check relief pressure setting. Run carriage to the front
or back of the frame and check the pressure on the thrust
guage.
SAFETY AND OPERATION MANUAL
Safety and Operation manual must be kept with the machine
at all times. Call McLaughlin Group, Inc. for a free replace-
ment.
GUARDS
Repair or replace guards which could restrict valve handle
movement or view of guages.
BREAKOUT WRENCH
Test breakout wrench each time before going into service.
Test Procedure:
Assemble (2) rods and insert them into the breakout.
Screw the rod onto the chuck.
Move the carriage so the rods are properly positioned in the
breakout.
Clamp the front rod in the front vise.
Tighten the rods with the spinde. Run the machine over
relief 2500 psi (172 BAR).
Break the rod joint with the rear cylinder.
Break the spindle joint with the spindle.
LUBRICATION
Grease cylinder pins with 1-2 pumps of grease. (Photo 8).
Grease jaw mounting blocks with cylinders extended.
JAWS
Inspect jaws daily for wear and damage.
Jaws that slip must be replaced immediately.
NEVER USE PIPE WRENCHES TO UNSCREW RODS.
BREAKOUT HOLD DOWNS
Hold downs must always be securely installed on the frame
rails.
CLEANING MACHINE
Clean machine after each use and before storing.
Clean all dirt off of machine.
Remove side panels and clean out dirt from around chains
8

2.1.0

2.1.0

2.2.0

2.2.0

SADDLE & SPACERS
McL-10H VERSA-MOLE
2.3.0
SADDLE & SPACERS
McL-10H VERSA-MOLE
ITEM# QTY. NUMBER DESCRIPTION
1 1 8080090 Saddle Weldment
2 2 8080094 Saddle Shoe

THRUST CYLINDER - SEAL KIT
McL-10H VERSA-MOLE
ITEM# QTY. NUMBER DESCRIPTION
1 1 8080022 Seal Kit, Includes Items #1 - #7
Item #1 - Wiper
Item #2 - Seal
Item #3 - O-Ring
Item #4 - Back-Up Washer
Item #5 - Back-Up Washer
Item #6 - Seal
Item #7 - O-Ring
8 1 8080243 Retaining Ring
McL-10H-5
9 1 8082043 Cylinder Rod
McL-10H-7
9 1 8080242 Cylinder Rod
2.4.0
THRUST CYLINDER - SEAL KIT
McL-10H VERSA-MOLE

3.1.0

3.1.0
ITEM QTY NUMBER DESCRIPTION
1 1 8080070 CARRIAGE FRAME
1 T500020 GREASE FITTING .125 MNPT
2 1 T200080 HYDRAULIC MOTOR
4 U070020 SCREW, C-BORE .500-13 X 1.50
4 U210100 WASHER, LOCK .500
3 1 8080071 SPINDLE SHAFT
5 U000817 SCREW, HC .500-13 X 1.00 GR8
1 8080220 KEY, SQ. .500 (SPECIAL)
4 1 8080227 FRONT LIP SEAL
5 1 8080229 THRUST BEARING, FRONT
6 1 8080228 THRUST BEARING CUP
7 1 8080339 SLIDER ANGLE WELDMENT, LEFT SIDE
2 U000900 SCREW, .500-13 X 2.50
2 U100120 NUT, HEX .500-13
2 U210100 WASHER, LOCK .500
2 U200100 WASHER, FLAT .500
8 1 8080230 TANGED BEARING WASHER
9 1 8080231 BEARING LOCK NUT
10 1 8080046 CHAIN GUARD
7 U000180 SCREW, HC .312-18 X .750
7 U210040 WASHER, LOCK .312
1 SILICONE SEALER
1 T405060 PLUG, #8 MP
1 T500020 GREASE FITTING, .125 MNPT
11 1 8080218 REAR SHAFT SEAL
12 1 8080112 SEAL CARRIER
5 U000020 SCREW, HC .250-20 X .500
5 U210020 WASHER, LOCK .250
13 1 8080232 WATER SWIVEL .750 NPT (WET VERSION)
1 T405065 PLUG, #12 MP (DRY VERSION)
14 1 8080225 TAPER LOCK BUSHING
3 U000500 SCREW, HC .375-18 X 2.00
3 U210060 WASHER, LOCK .375
1 U240030 SCREW, SET .375-18 X 2.00
15 1 8080224 SPROCKET, 45 TOOTH
16 1 8080222 DRIVE CHAIN, #60
1 P600210 CONNECTING LINK, #60
17 1 8080223 SPROCKET, 16 TOOTH
2 U024010 SCREW, SET .250-20 X .500
18 4 HD20082 SPACER
19 4 W000020 CAMROLLER BEARING, 1.25 DIA.
4 U100140 NUT, HEX .500-20
2 T500080 GREASE FITTING, .1875 STR.
2 T500090 GREASE FITTING, .1875 65 DEG.
20 1 8080337 SLIDER ANGLE WELDMENT, OPER.SIDE
2 U000900 SCREW, .500-13 X 2.50
2 U100120 NUT, HEX .500-13
2 U210100 WASHER, LOCK .500
2 U200100 WASHER, FLAT .500
21 1 W200210 O-RING, #01-229
22 1 8080350 BASE CHUCK WELDMENT, MCL-10H
1 8080351 BASE CHUCK WELDMENT, MCL-10H
1 8080351-1 THREAD LOCK, BIT SUB MCL-10H
23 1 8080190 CHUCK, .812 HEX
1 8080191 CHUCK, 1.125 HEX
1 8080192 CHUCK, 1.375 HEX
1 8080193 CHUCK, 1.625 HEX
24 1 8080119 CHUCK BOLT LOCKDOWN

SEAL KIT, HYDRAULIC MOTOR
McL-10H VERSA-MOLE
3.2.0

SEAL KIT, HYDRAULIC MOTOR
McL-10H VERSA-MOLE
ITEM# QTY. NUMBER DESCRIPTION
1 1 T200081 Seal Kit, Shaft
2 1 T200082 Seal Kit, Rear Motor
3.2.0

CHAIN TENSIONER
CHAIN TENSIONER
McL-10H VERSA-MOLE
McL-10H VERSA-MOLE
ITEM# QTY. NUMBER DESCRIPTION
McL-10H-7
1 2 8080018 Thrust Chain, Long, Rear
4 8080217 Connecting Link, BL-534
2 2 8080043 Threaded Chain Clevis, R.H. Thd.
3 1 8080066 Float Indicator, Operator Side Only
1 U810025 Shaft Collar, .625, Left Side
4 2 8080042 Turnbuckle
5 2 8080044 Threaded Chain Clevis, L.H. Thd.
6 2 8080019 Thrust Chain, Short, Front
4 8080217 Connecting Link, BL-534
McL-10H-5
1 2 8082018 Thrust Chain, Long, Rear
4 8082017 Connecting Link, BL-534
6 2 8082019 Thrust Chain, Short, Front
4 8082017 Connecting Link, BL-534
3.3.0

McL-10H VERSA-MOLE
CHAIN ANCHOR ASSEMBLY
CHAIN ANCHOR ASSEMBLY
McL-10H VERSA-MOLE
ITEM# QTY. NUMBER DESCRIPTION
McL-10H-7
12 8080018 Thrust Chain, Long, Rear
4 8080217 Connecting Link, BL-534
2 2 8080043 Threaded Chain Clevis, R.H. Thd.

McL-10H VERSA-MOLE
CONSOLE ASSEMBLY
4.1.0

CONSOLE ASSEMBLY
McL-10H VERSA-MOLE
ITEM# QTY. NUMBER DESCRIPTION
1 1 8080101 Console Weldment
2 3 T720020 Pressure Gauge (0-3000 psi)
3 1 E250210 Operation & Safety Manual Box
1 E250205 Operation & Safety Manual
4 1 8080182 Hydraulic Control Valve
3 U000300 Screw, HC .312-18 X 3.000 Lg.
3 U200040 Washer, Flat .312
3 U120105 Nut, Hex .312-18
5 1 8080076 Console Threaded Handle
6 1 8080157 Shuttle Valve (Thrust)
2 U000100 Screw, HC .250-20 X 1.500 Lg.
2 U210020 Washer, Lock .250
7 1 8080260 Strike Alert Receptical
2 U000040 Screw, HC .250-20 X .750 Lg.
2
U120100
N
u
t
,
H
e
x
L
o
c
k
.
2
5
0
-
2
0
4.1.0

5.1.0

5.1.0
