Mia Cucina CV25M User manual

Model: CV25M

CV25M

GB
4
GB
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, injury to persons
or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including
the following:
1.
Warning: Liquids and other foods must not
be heated in sealed containers since they are
liable to explode.
2.
Warning: It is hazardous for anyone other
than a competent person to remove a cover
which gives protection against exposure to
microwave energy.
3. Warning: Only allow children to use the
oven without supervision when adequate
instructions have been given so that the child
is able to use the oven in a safe way and
understand the hazards of improper use.
4.
Warning: When the appliance is operated in
the combination mode, children should only
use the oven under adult supervision due to
the temperatures generated. (only for grill
series)
5.
Only use utensils suitable for use in
microwave ovens.
6.
The oven should be cleaned regularly and any
food deposits should be removed.
7.
Read and follow the specific:"PRECAU-
TIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY".
8.
When heating food in plastic or paper
containers, keep an eye on the oven due to
the possibility of ignition.
9.
If smoke is observed, switch off or unplug the
appliance and keep the door closed in order
to stifle any flames.
10.
Do not overcook food.
11. Do not use the oven cavity for storage
purposes. Do not store items, such as
bread, cookies, etc. inside the oven.
12.
Remove wire twist-ties and metal handles
from paper or plastic containers/bags before
placing them in the oven.
13. Install or locate this oven only in
accordance with the installation
instructions provided.
14. Eggs in the shell and whole hard-boiled
eggs should not be heated in microwave
ovens since they may explode, even after
microwave heating has ended.
15. Use this appliance only for its intended
uses as described in manual. Do not use
corrosive chemicals or vapors
in this appliance. This oven is especially
designed to heat. It is not designed for
industrial or laboratory use.
16. If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in
order to avoid a hazard.
17. Do not store or use this appliance
outdoors.
18. Do not use this oven near water, in a wet
basement or near a swimming pool.
19.
The temperature of accessible surfaces may
be high when the appliance is operating.
Keep cord away from heated surface, and
do not cover any events on the oven.
20. Do not let cord hang over edge of table or
counter.
21. Failure to maintain the oven in a clean
condition could lead to deterioration of
the surface that could adversely affect the
life of the appliance and possibly result in
a hazardous situation.
22. The contents of feeding bottles and baby
food jars shall be stirred or shaken and the
temperature checked before consumption,
in order to avoid burns.
23 Microwave heating of beverages can
result in delayed eruptive boiling,
therefore take care when handling the
container.
24.Steam cleaner is not to be used.
25.During use the appliance becomes hot.Care should be taken to avoid touching heating
elements inside the oven.
26.Accessible parts may become hot during use. Young children should be kept away. 27.Do
not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door
glass since they can scratch the surface, which may result in shattering.

GB
5
GB
28.The appliance is not intended for use by persons (including children) with reduced
physical , sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
29.
Children should be supervised to ensure that they do not play with the appliance. 30.The
appliances are not intended to be operated by means of an external timer or
separate remote-control system.
31. WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the
possibility of electric shock.
32. Only use the temperature probe recommended for this oven.(for ovens provided with a
facility to use a temperature-sensing probe.)
33 The door or the outer surface may get hot when the appliance is operating.
To Reduce the Risk of Injury to Persons
Grounding Installation
DANGER
Electric Shock Hazard
Touching some of the internal
components can cause serious
personal injury or death. Do not
disassemble this appliance.
WARNING
Electric Shock Hazard Improper
use of the grounding can result in
electric shock. Do not plug into an
outlet until appliance is properly
installed and grounded.
CLEANING
Be sure to unplug the appliance
from the power supply.
1. Clean the inside of the oven after using
with a slightly damp cloth.
2.
Clean the accessories in the usual way in
soapy water.
3.
The door frame and seal and neighbouring
parts must be cleaned carefully with a
damp cloth when they are dirty.
Two-round-pin plug
This appliance must be grounded. In the event of
an electrical short circuit, grounding reduces the risk
of electric shock by providing an escape wire for the
electric current. This appliance is equipped with a cord
having a grounding wire with a grounding plug. The
plug must be plugged into an outlet that is properly
installed and grounded.
Consult a qualified electrician or serviceman if the
grounding instructions are not completely understood
or if doubt exists as to whether the appliance is
properly grounded. If it is necessary to use an
extension cord , use only a 3-wire extension cord.
1. A short power-supply cord is provided to
reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2.
If a long cord set or extension cord is used:
1)The marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance.
2)The extension cord must be a grounding-
type 3-wire cord.
3)The long cord should be arranged so that it will
not drape over the counter top or tabletop where it
can be pulled on by children or tripped over
unintentionally.

GB
6
GB
UTENSILS See the instructions on "Materials you can use in microwave
oven or to be avoided in microwave oven." There may be
certain non-metallic utensils that are not
CAUTION
Personal Injury Hazard
It is hazardous for anyone
other than a compentent person to
carry out any service or repair
operation that involves the removal of
a cover which gives protection against
exposure to microwave energy.
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
Materials you can use in microwave oven
Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of meat or
poultry to prevent overcooking. Arcing can occur if foil is too close to oven
walls. The foil should be at least 1 inch (2.5cm) away from oven walls.
Browning dish
Dinnerware
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Follow manufacturer’s instructions. The bottom of browning dish must be at
least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the
turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars are
not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not
use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make slits
to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended while
cooking.
Use to cover food for reheating and absorbing fat. Use with supervision for a
short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food inside
gets hot. "Boiling bags" and tightly closed plastic bags should be slit, pierced
or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.

GB
7
GB
Materials to be avoided in microwave oven
Utensils Rem arks
Aluminum tray
Food carton with
May cause arcing. Transfer food into microwave-safe dish. May
cause arcing. Transfer food into microwave-safe dish.
metal handle
Metal or metal-
Metal shields the food from microwave energy. Metal trim may
trimmed utensils cause arcing.
Metal twist ties
Paper bags
Plastic foam
Wood
May cause arcing and could cause a fire in the oven. May
cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed to
high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity. Your oven
comes with the following accessories:
Glass tray 1 A
Turntable ring assembly 1
Instruction Manual 1
F
E
D
G
Grill Rack( Only for Grill series )
C B
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system

GB
8
GB
Turntable Installation
Hub (underside)
Glass tray
Turntable shaft
a. Never place the glass tray upside down. The glass tray
should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed on
the glass tray for cooking.
d. Ifglass tray or turntable ring assembly cracks or breaks,
contact your nearest authorized service center.
Turntable ring assembly
Installation and connection
1.This appliance is only intended for domestic use.
2.This oven is intended for built-in use only.It is not intended for counter-top use or for use
inside a cupboard.
3. Please observe the special installation instructions.
4.The appliance can be installed in a 60cm wide wall-mounted cupboard(at lease 55cm deep and
85cm off the floor).
5.The appliance is fitted with a plug and must only be connected to a properly installed earthed
socket.
6.The mains voltage must correspond to the voltage specified on the rating plate. 7.The
socket must be installed and connecting cable must only be replaced by a
qualified electrician.If the plug is no longer to accessible following installation,an
all-pole disconnecting device must be present on the installation side with a contact gap of
at lease 3mm.
8.Adapters,multi-way strips and extension leads must not be used. Overloading can result in
a risk of fire.
The accessible surface
may be hot during
operation.

GB
9
GB
Operation Instructions
1. Clock Setting
When the microwave oven is electrified, the LED will display "0:00", buzzer will ring once.
1) Press " Clock/ Pre-Set ", the hour figures will flash.
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " Clock/ Pre-Set ", the minute figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press "
Clock/ Pre-Set " to finish clock setting. ":" will flash, and the time will light.
Note: 1) If the clock is not set, it would not function when powered.
2) During the process of clock setting, if you press " will
go back to the previous status automatically.
2. Micr owave Coo ki n g
Stop/Clear
", the oven
Press " Microwave/Grill/Combi. ", the LED will display "P100. Press
"
Microwave/Grill/Combi. " for times or turn " " to choose the power you want,
and "P100", "P80" "P50", "P30" or "P10" will display for each added press. Then
press"
Start/+30Sec./Confirm
" to confirm, and turn " " to set cooking time from
0:05to 95:00. Press " Start/+30Sec./Confirm " again to start cooking.
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
1) Press " Microwave/Grill/Combi. " once, the screen display "P100".
2) Press " Microwave/Grill/Combi. " once again or turn" " to choose 80%
microwave power.
3) Press "
Start/+30Sec./Confirm
" to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press "
Start/+30Sec./Confirm
" to start cooking .
Note: the step quantities for the adjustment time of the coding switch are as follow: 0---1
min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes

GB
10
GB
"Microwave/Grill/Combi." Pad instructions
Order
Microwave
Grill
Display
1P100
2 P80
3 P50
4 P30
5 P10
6
G
7 C-1
8 C-2
Power 100%
80%
50%
30%
10%
0%
55%
36%
Power
100%
45%
64%
3. Gril l or Com b i. Coo kin g
Press " Microwave/Grill/Combi.
" once,"P100" displays and then press
"Microwave/Grill/Combi.
" for times or turn the " " to choose the power you
want, and "G","C-1" or "C-2" will display for each added press. Then press
"
Start/+30Sec./Confirm "to confirm, and turn " " to set cooking time from 0:05 to
95:00. Press "
Start/+30Sec./Confirm
" again to start cooking.
Example: If you want to use 55% microwave power and 45% grill power(C-1) to cook for 10
minutes, you can operate the oven as the following steps.
1) Press " Microwave/Grill/Combi. " once, the screen display "P100".
2) Press " Microwave/Grill/Combi. " times or turn " " to choose combi. 1 mode.
3) Press "
Start/+30Sec./Confirm
"
to confirm, and the screen displays "C-1".
4) Turn " " to adjust the cooking time until the oven displays "10:00".
5) Press "
Start/+30Sec./Confirm
" to start cooking .
Note:If half the grill time passes, the oven sounds twice, and this is normal.

GB
11
GB
In order to have a better effect of grilling food, you should turn the food over, close the
door, and then if no operation the oven will continue cooking.

GB
12
GB
4. Quic k Start
1) In waiting state, Press " Start/+30Sec./Confirm" to start cooking with 100% power, each
added press will increase 30 seconds cooking time up to 95 minutes.
2) In microwave, grill, combi. cooking or time defrost state, each press of
"Start/+30Sec./Confirm
"
can increase 30 seconds of cooking time.
3) In waiting state, turn " " anti-clockwise to set cooking time with 100%
microwave power, then press "
5. Defr os t B y Weig h t
Start/+30Sec./Confirm
" to start cooking.
1) Press " Weight/Time Defrost " once, and the oven will display "dEF1".
2) Turn " " to select the weight of food from 100 to 2000 g.
3) Press "
Start/+30Sec./Confirm
" to start defrosting.
6. Defro s t B y Time
1) Press " Weight/Time Defrost " twice, and the oven will display "dEF2".
2) Turn " " to select the defrost time.
3) Press "
Start/+30Sec./Confirm
"
to start defrosting.
7. Au t o Menu
1) Turn " " right to choose the menu, and "A-1" to "A-8" will display, which
means pizza, potato, meat, vegetable, fish, pasta, soup and porridge.
2) Press " Start/+30Sec./Confirm
"
to confirm.
3) Turn " " to choose the default weight as the menu chart.
4) Press " Start/+30Sec./Confirm
" to start cooking.
Example: If you want to use "Auto Menu" to cook fish for 350g.
1) Turn " " clockwise till "A-5" display.
2) Press " Start/+30Sec./Confirm " to confirm.
3) Turn " " to select the weight of fish till "350" display.
4) Press " Start/+30Sec./Confirm
"
to start cooking.

GB
13
The menu chart:
Menu
Weight
Display
A-1
Pizza
200 g
200 g
400 g
400 g
A-2
Potato
200 g
200 g
400 g
400 g
600 g
600 g
A-3
Meat
250 g
250 g
350 g
350 g
450 g
450 g
A-4
Fish
250 g
250 g
350 g
350 g
450 g
450 g
A-5
Vegetable
200 g
200 g
300 g
300 g
400 g
400 g
A-6
Beverage
1cup(120ml)
1
2cup(240ml)
2
3cup(360ml)
3
A-7
Pasta
50g(with 450ml cold water)
50g
100g(with 800ml cold water)
100g
A-8
Popcorn
50g
50g
100g
100g
A-9
Chicken
200g
200g
400g
400g
600g
600g
800g
800g
A-10
Reheat
200g
200g
400g
400g
600g
600g
8. Pro gram set in Ad vance
1) Set the clock first. (Consult the instruction of clock setting.)
2) Input the cooking program. Two stages can be set at most.
Defrost should not be set as the cooking program.
Example: If you want to cook with 80% microwave power for 7 minutes, operate it as the following:
a.
Press " Microwave/Grill/Combi. " once, the screen display "P100".
b.
Press " Microwave/Grill/Combi. " once again or turn " " to choose 80% microwave
power.

GB
14
c.
Press "
Start/+30Sec./Confirm
" to confirm, and the screen displays "P 80".
d.
Turn " " to adjust the cooking time till the oven displays "7:00".
After the aboved steps, be careful not to press " Start/+30Sec./Confirm " to start
cooking.
3) Press " Clock/ Pre-Set ", the hour figures will flash.
4) Turn " " to adjust the hour figures, the input time should be within 0--23.
5) Press " Clock/ Pre-Set ", the minute figures will flash.
6) Turn " " to adjust the minute figures, the input time should be within 0--59.
7) Press " Start/+30Sec./Confirm " to finish setting. If the door is closed, buzzer will ring twice
when the time arrives, then cooking will start automatically.
9. Multi-section cooking
At most 2 sections can be set for cooking. In multi-section cooking, if one section is
defrosting, then defrosting shall be placed in the first section.
Example: If you want to defrost food for 5 minutes and then cook with 80% microwave power
for 7 minutes, operate it as the following:
1) Press " Weight/Time Defrost
"
twice, and the oven will display "dEF2".
2) Turn " " to select the defrost time till "5:00" display.
3) Press " Microwave/Grill/Combi. " once, the screen display "P100".
4) Press " Microwave/Grill/Combi.
microwave power.
"
once again or turn " " to choose 80%
5) Press "
Start/+30Sec./Confirm
"
to confirm, and the screen displays "P 80".
6) Turn " " to adjust the cooking time till the oven displays "7:00".
7) Press " Start/+30Sec./Confirm" to start cooking, and buzzer will sound once for the first
section, defrosting time counts down; buzzer will sound once again entering the second
cooking. when cooking finish, buzzer sounds five times.

GB
15
10. Inquiring Function
(1) In states of microwave,grill and combination cooking, press " Microwave/Grill/Combi. ", the
current power will be displayed for 3 seconds. After 3 seconds, the oven will turn back to the
former state;
(2) In cooking state, press " Clock/ Pre-set " to inquire the time and the time will display for 3
seconds.
(3) In preset state, press " Clock/ Pre-set " to inquire the preset time, and the preset time
will display for 3 seconds.
11. Lock-out Function for Children
Lock: In waiting state, press "
Stop/Clear
"
for 3 seconds, there will be a long beep
denoting entering the children-lock state and the locked indicator will display if the time
has been set, otherwise, the LED will display " ".
Lock quitting: In locked state, press " Stop/Clear " for 3 seconds, there will be a long "beep"
denoting that the lock is released.

GB
16
Trouble shooting
If something does trouble shooting; before seeking assistanace carry out the following checks
first.
It is forbidden to run the unit without any food inside. It
is very dangerous.
CUSTOMER ASSISTANCE SERVICE
If you cannot identify the cause of the operating anomaly: switch off the appliance (do not subject it to
rought treatment) and contact the Assistance Service.
PRODUCT SERIAL NUMBER. Where can I find it?
It is important that you to inform the Assistance Service of your product code and its serial number (a 16 character
code which begins with the number 3); this can be found on the guarantee certificate or on
the data plate located on the appliance.
It will help to avoid wasted journerys to technicians, thereby (and most significantly) saving the
corresponding callout charges.

IT
17
GB
This appliance is marked according to the European directive
2002/96/EC on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate
waste handling of this product.
The symbol on the product indicates that this product may not be
treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic equipment
Disposal must be carried out in accordance with local environmental regulations for
waste
disposal.
For more detailed information about treatment, recovery and recycling of this
product, please contact your local city office, your household waste disposal service or
the shop where you purchased the product.

201702
C V 2 5 M
