MK Diamond Products MK-2000P System manual

08.2018
MK-2000P Hand held Wet Core Drill
OWNER’S MANUAL &
OPERATING INSTRUCTIONS
www.mkdiamond.com
Caution: Read all safety and operating instructions
before using this equipment. This parts list MUST
accompany the equipment at all times.
Revision 101
Manual Part# 158490

2
INTRODUCTION
Congratulations on your purchase of a MK-2000P Handheld Drill. We are certain that you will
be pleased with your purchase. MK Diamond takes pride in producing the nest construction
power tools and diamond blades in the industry.
Operated correctly, your MK-2000P Handheld Drill should provide you with years of service. In
order to help you, we have included this manual. This owner’s manual contains information
necessary to operate and maintain your MK-2000P Handheld Drill safely and correctly. Please
take the time to familiarize yourself with the MK-2000P Handheld Drill by reading and reviewing
this manual before operating it.
Read and follow all safety, operating and maintenance instructions.
If you should have questions concerning your MK-2000P Handheld Drill, please feel free to call
our friendly customer service department at [phone].
Regards,
MK Diamond
NOTE THIS INFORMATION FOR FUTURE USE:
MODEL NUMBER:
SERIAL NUMBER:
PURCHASE PLACE:
PURCHASE DATE:
NOTE: For your (1) one year warranty to be effective, complete the warranty card
(including the Serial Number) and mail it in as soon as possible.

3
TABLE OF CONTENTS
SAFETY
Safety Messages 4
General Safety 4-7
California Proposition 65 Message 8
Safety Label 9
Pre-Start Safety 9-10
Product Specication 10
OPERATION
Main Instruction 11
Auxiliary Handle 11
Gear Shifting 11
MAINTENANCE & TROUBLESHOOTING
Water Supply & Electrical Safety 12
Care & Maintenance 12
ORDERING and RETURN INSTRUCTIONS
Ordering Information 14
Return Material Policy 14
Packaging Instructions 14
Authorized Service Centers 14
CONTACT and LIMITED WARRANTY
Contact 15
Limited Warranty 15

4
MK-2000P SAFETY
Read and follow all safety, operating and maintenance instructions. Failure to read and follow
these instructions could result in injury or death to you or others. Failure to read and follow these
instructions could also result in damage and/or reduced equipment life. Safety warnings and
guidelines do not by themselves eliminate danger. They are not substitutes for proper accident
prevention procedures and good judgement.
SAFETY MESSAGES
A Damage Prevention Message is to inform the user of important information and/or instructions that
could lead to equipment or other property damage if not followed. Information Messages convey
information that pertains to the equipment being used. Each message will be preceded by the word
NOTE, as in the example below.
DAMAGE PREVENTION AND INFORMATION MESSAGES
NOTE: Equipment and/or property damage may result if these instructions are not followed.
GENERAL SAFETY PRECAUTIONS AND HAZARD SYMBOLS
A safety message alerts you to potential hazards that could hurt you or others. Each safety message is
preceded by a safety alert symbol ( ) and one of three words: DANGER, WARNING, or CAUTION.
DANGER You WILL be KILLED or SERIOUSLY INJURED if you DO NOT follow directions.
WARNING You CAN be KILLED or SERIOUSLY INJURED if you DO NOT follow directions.
CAUTION You CAN be INJURED if you DO NOT follow directions. It may also be used to
alert against unsafe practices.
ALWAYS read this Owner’s Manual before operating the machine. DO NOT operate or
service this equipment before reading this entire manual. Read and understand all warn-
ings, instructions and controls on the machine. Know how to stop the equipment quickly in
case of emergency. It is the operators responsibility to use this machine under safe work-
ing conditions and conform with federal, state and local codes or regulations pertaining to
safety, air, pollution, noise etc...
ALWAYS keep the Blade and Belt Guards in place. DO NOT operate this machine with any
guard or safety device removed. A Guard, or any damaged part should be repaired or
replaced immediately.
NEVER operate this equipment without proper protective clothing, shatterproof
glasses, steel-toed boots and other protective devices required by the job. Non-slip
foot wear is recommended.
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
)
)
ON
(
(
)
)
ON
(
(
)
)
ON
(
(
)
)
In order to prevent injury, the following safety precautions and symbols should be followed at all times!

5
MK-2000P SAFETY
ON
(
(
)
)
ON
(
(
)
)
ON
(
(
)
)
All visitors and children should be kept a safe distance from work area. Maintain a safe
operating distance to other personnel.
KEEP CHILDREN AWAY
MAKE THE WORKSHOP KID PROOF
Make the workshops kid proof by using padlocks, master switches or by removing starter keys.
ROTATING PARTS
Keep hands, feet, hair, and clothing away from all moving parts to prevent injury. Never oper-
ate the motor with covers, shrouds, or guards, removed.
OVER SPEED
NEVER tamper with the governor components or settings to increase the maximum speed.
Severe personal injury and damage to the engine or equipment can result if operated at
speeds above maximum.
ELECTRICAL SHOCK
NEVER touch electrical wires or components while the engine is running. Exposed, frayed or
worn electrical wiring and plugs can be sources of electrical shock which could cause severe
injury or burns. Do not touch the plug with wet hands.
ALWAYS avoid inhalation of and skin contact with silica dust and/or mist. Provide proper
dust removal. Use dust-collection system when applicable.
NEVER operate the machine in an explosive atmosphere or near combustible materials.
Sparks from the cutting-action of this machine can ignite flammable materials, liquids, gases
or dust.
This equipment should not be operated by persons under 18 years of age.
ALWAYS wear approved respiratory, head, ear and eye protection
when operating this machine.
Before starting the engine/motor, be sure the ON/OFF switch is in the OFF position to pre-
vent accidental starting. Place the ON/OFF switch in the OFF position before performing any
service operation. ALWAYS place the power ON/OFF switch in the OFF position when the
machine is not in use.
ACCIDENTAL STARTS!
PERSONAL PROTECTIVE EQUIPMENT
Engine components can become extremely hot from operation. To prevent severe burns,
do not touch these areas while the engine is running, or immediately after it is turned off.
Never operate the engine with heat shields removed.
HOT PARTS!
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
)
)
ON
(
(
)
)
ON
(
(
)
)
ON
(
(
)
)
DO NOT FORCE THE TOOL
A power tool will do a job better and safer operating at the rate for which it was designed.
DO NOT force a tool or an attachment to do a job that it was not designed to do.
ON
(
(
))

6
Consult the owner’s manual for recommended accessories. Using improper accessories
may increase the risk of personal or by-stander injury. Unauthorized equipment
modifications will void all warranties. Manufacturer does not assume responsibility for any
accident due to equipment modifications.
ALWAYS ensure that the machine is on level ground before using.
Serious injury could occur if a power tool is tipped, or if a cutting tool is unintentionally
contacted.
When loading or unloading the machine, use caution. Remove the blade prior to hoisting,
loading and transporting the machine.
USE RECOMMENDED ACCESSORIES
NEVER STAND ON THE TOOL
TRANSPORT
Form a habit of checking to see that keys and adjusting wrenches are removed from
the power tool before it is turned on.
Cluttered work areas and benches invite accidents. Keep area around machine clear of
obstructions which could cause persons to fall.
DO NOT operate equipment in dangerous or hazardous environments. DO NOT use power
tools in damp or wet locations nor expose them to rain. Always keep the work area well
lighted.
REMOVE ADJUSTING KEYS AND WRENCHES
KEEP WORK AREA CLEAN
DO NOT USE IN DANGEROUS PLACES
MAINTAIN TOOLS WITH CARE
Keep tools clean and maintained for the best and safest performance. Always follow
maintenance instructions and examine the machine before use. If any abnormal vibrations
or noises occurs, turn off machine immediately and have the problem corrected before
further use.
DISCONNECT TOOLS
Power tools should always be disconnected before servicing, adjusting or when changing
accessories, such as blades, bits, cutters, and the like.
DO NOT OVERREACH
Keep proper footing and balance at all times by not overreaching.
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
SECURE WORK
Clamps or a vise should be used to hold work whenever practical. Keeping your hands free
to operate a power tool is safer.
ON
(
(
))
USE PROPER APPAREL
DO NOT wear loose clothing, gloves, neckties, rings, bracelets, or other jewelry that may
be caught in moving parts. Non-slip footwear is recommended. Wear protective hair cover-
ing to contain long hair.
ON
(
(
))
MK-2000P SAFETY

7
Before using a power tool, check for damaged parts. A guard or any other part that is
damaged should be carefully checked to determine if it would operate properly and
perform its intended function. Always check moving parts for proper alignment or binding.
Check for broken parts and mountings and all other conditions that may affect the
operation of the power tool. A guard, or any damaged part, should be properly repaired or
replaced. Always check the machine for loose bolts before starting.
A blade or cutter should always be installed so that rotation is in the direction of the
arrow imprinted on the side of the blade or cutter. It should correspond with the rotational
direction of the motor. Always feed work into a blade against the direction of rotation.
TURN POWER OFF - Do not leave a tool until it comes to a complete stop. ALWAYS
turn a power tool OFF when leaving the work area, or, when a cut is finished.
NEVER LEAVE A TOOL UNATTENDED
CHECK FOR DAMAGED PARTS
DIRECTION OF ROTATION
NEVER disconnect any "emergency or safety devices". These devices are intended for
operator safety. Disconnection of these devices can cause severe injury, bodily harm, or
even death! Disconnection of any of these devices will void all warranties. Unauthorized
equipment modifications will void all warranties. Manufacturer does not assume
responsibility for any accident due to equipment modifications.
NEVER operate this equipment under the influence of drugs or alcohol.
NEVER operate this equipment when not feeling well due to fatigue, illness or taking medicine.
NEVER use this machine with any cutter designed for woodworking.
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
ON
(
(
))
On belt driven equipment, overtensioning of belts will result in premature crank and/or bearing
failure.
Whenever necessary, replace nameplate, operation and safety decals when they become
difcult to read.
ALWAYS store equipment properly when it is not being used. Equipment should be stored in
a clean, dry location out of the reach of children
DO NOT lend or rent this equipment without including the Owner's Manual and the Engine/
Motor Manufacturer's Manual.
Check the chemical properties of the material to be cut/grinded and follow all EPA/OSHA
Regulations. (cut/ground)
MK-2000P SAFETY

8
CALIFORNIA PROPOSITION 65 MESSAGE
SILICA DUST WARNING
Grinding/cutting/drilling of masonry, concrete, metal and other materials with silica in their composition
may give off dust or mists containing crystalline silica. Silica is a basic component of sand, quartz,
brick clay, granite and numerous other minerals and rocks. Repeated and/or substantial inhalation of
airborne crystalline silica can cause serious or fatal respiratory diseases, including silicosis. In ad-
dition, California and some other authorities have listed respirable crystalline silica as a substance
known to cause cancer. When cutting such materials, always follow respiratory precautions.
Use appropriate NIOSH-approved respiratory protection where dust hazard may occur. Paper masks
or surgical masks without a NIOSH approval number are not recommended because they do little to
protect the worker. For more information about respirator programs, including what respirators have
received NIOSH approval as safe and effective, please visit the NIOSH website at:
http://www.cdc.gov/niosh/topics/respirators
Observe OSHA regulations for respirator use (29 C.F.R.§1910.134).
Visit http://www.osha.gov for more information.
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities con-
tain chemicals known (to the State of California) to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead, from lead-based paints
• Crystalline silica, from bricks and cement and other masonry products
• Arsenic and chromium, from chemically treated lumber
For further information, consult the following sources:
http://www.osha.gov/dsg/topics/silicacrystalline/index.html
http://www.cdc.gov/niosh/docs/96-112/
http://oehha.ca.gov/prop65/law/P65law72003.html
http://www.dir.ca.gov/Title8/sub4.html
http://www.P65warnings.ca.gov
Your risk from these exposures varies depending on how often you do this type of work. To reduce
your exposure to these chemicals, work in a well-ventilated area, and work with approved safety
equipment, such as dust masks that are specially designed to lter out microscopic particles. Where
use of a dust extraction device is possible, it should be used. To achieve a high level of dust collec-
tion, use an industrial HEPA vacuum cleaner. Observe OSHA 29 CFR part 1926.57 and 1926.103.
MK-2000P SAFETY
Diamond tools improperly used are dangerous. Comply with American National Standards Institute
Safety Code, B7.1 and, Occupational Safety and Health Act covering Speed, Safety Guards, Flanges,
Mounting Procedures, General Operating Rules, Handling, Storage and General Machine Conditions.
CAUTION

9
SAFETY INSTRUCTIONS
1. Working safely with the MK-2000P is only possible if you read this operating instruction
completely and strictly follow the instructions contained within.
2. When drilling through ceilings or walls, make sure you will not cut through electrical wiring, gas
lines or water pipes. Use metal detection systems if needed.
3. Check the MK-2000P for damage prior to use. Inspect the cord and plug for cuts, frays and
damage. Have damage repaired by authorized repair technicians. Take care that the ON/OFF
switch is in the OFF position before inserting the plug into a power receptacle.
4. When using the drill, cooling water is not allowed to get into the motor or any electrical parts.
MK-2000P SAFETY
SAFETY LABELS
Safety labels contain important safety information. Please read the information contained on each
safety label. These labels are considered a permanent part of your drill. If a label comes off or
becomes hard to read, contact MK Diamond or your dealer for a replacement.

10
General Specifications
Motor 120V 15 Amp (Electronic torque limitation)
Watts 1500
Speed 2 speed
Bit Capacity 1-1/2” (38mm) hand-held
4” (102mm) rig mounted
Connecting Threads 1-14” - 7” UNC
5/8” - 11 UNC
Weight 15 lbs. (6.8 kg)
Includes • Quick Release Water Valve
• GFCI
• Plastic Carrying Case
Part # 158365
PRODUCT SPECIFICATIONS
ON/OFF SWITCH
OPERATING THE MK-2000P
Ideal for drilling holes in oors, walls, ceilings and for all concrete anchoring systems. Fast and ef-
cient drilling of reinforced concrete, concrete, brick, block and stone.
The MK-2000P is equipped with an electronic ON/OFF switch.
Each time the switch is pressed, the speed of the drill becomes higher. This allows very precise drill-
ing. Under normal working conditions, always operate the MK-2000P at maximum speed.
In hand held drilling operations, only use the MK-2000P with the Auxiliary Handle xed. The Auxiliary
Handle must be tightened on the collar, by turning the lever.
Auxiliary Handle
5. Use only extension cords and plugs approved for outdoor work.
6. Before starting your work, check that the Ground Fault Circuit Interrupter (GFCI) is functioning
properly by pressing the test button. The GFCI must never lay in the water.
7. Don’t use the machine if a part of the housing is damaged or in case of damages on the switch,
cable or plug (check it every day).
8. Stop working if water is dripping out of the overrunning bore hole and take the machine to an
authorized service center.
9. Overhead-drilling should be done with using suitable safety measures (water collection).
10. When using the machine with manual control always hold it with both hands and take up a safe
position. Pay attention to the reaction torque of the machine.
MK-2000P PRODUCT SPECIFICATION

11
OVERLOAD PROTECTION
The speed of the drill will need to be adjusted in accordance with the size of the core bit being used.
The speed of the drill is adjusted by rotating the Speed-selector in the clockwise direction, while turn-
ing the drill shaft by hand until the clutch is engaged.
If the Speed-selector is in the “o” position, drill speed can be adjusted from 0 to 1000 rpm.
If the Speed-selector is in the “oo” position, drill speed can be adjusted from 0 to 2000 rpm.
It is easier to start a hole with a centering bit. The switch allows the drill to be operated at slow speed
for safely introducing the bit into the material. A normal pilot hole should be from .2 to .4 inches (5 to
10 mm) in depth. Once the pilot hole is created, the centering bit can be removed and replaced for full
speed operation.
If the core bit is suddenly blocked in the hole, a clutch will slip, disengaging the bit from the motor.
If excessive penetration speed results in an overload condition, an electronic switch will open discon-
necting the motor from the power supply.
Once the drill is removed from the hole and the electronic switch is reset, coring may resume.
If the drill is operated in a continuous overload condition and the Electronic Overload Protective device
fails, the Thermal Overload protective device will interrupt power to the motor.
Once actuated, the motor must be allowed to cool to reset the Thermal Overload protective device.
Time required for the Thermal Overload protective device to reset will vary depending on the tempera-
ture of the motor and ambient temperature.
To protect the operator and the drill, the MK-2000P is equipped with three overload protective devices -
mechanical, electronic and thermal. In case of overload, the MK-2000P is equipped with warning device.
For core bits with diameters above 2.8 in. / 70 mm, operate the drill using the “o” (0 to 1000) rpm range.
For core bits with diameters below 2.8 in. / 70 mm, operate the drill using the “oo” (0 to 2000) rpm range.
1. When using the handheld method, operate the drill in the 0 to 2000 rpm range only.
2. Always check the core bit manufacturer’s recommendation for use.
3. Gear shifting should only be performed in the clockwise direction when the drill is stopped.
Gear Shifting
Starting a Hole
Mechanical Overload Protection
Electronic Overload Protection
Thermal Overload Protection
MK-2000P OPERATION
CAUTION

12
MK-2000P MAINTENANCE
WATER SUPPLY
CARE AND MAINTENANCE
The MK-2000P is equipped with an intake cooling water ow control valve that can be placed vertically
of horizontally. A quick disconnect is supplied with the unit for ease of operation.
Water ow enters through the ow control valve and exits directly through the center of the motor shaft.
Cooling ow may be adjusted using the cooling water ow control valve.
Clean the MK-2000P following use.
Do not allow particles or parts to penetrate inside the tool.
The carbon motor brushes require inspection by a qualied maintenance technician after 300 hours of
operation. If the brushes are shorter than .2 inches (5 mm), they must be replaced.
During inspection of the motor brushes, the motor commutator must also be inspected. In case of ir-
regular coloring or scratches, the commutator must be repaired by a qualied service center.
After replacement, the motor brushes must be run at an idle for 20 minutes.
The MK-2000P requires inspection and gearbox cleaning by a qualied service center after 500 hours
of operation.
Do not operate with water pressure greater than 43.5 PSI (3 Bars).
CAUTION
In case of overload, a continuous acoustic warning signal will sound.
When the Acoustic Overload Warning is heard, it is recommended that the operating speed and ap-
plied pressure be immediately reduced, and /or, the core bit be operated under a no-load condition.
If the MK-2000P stops due to the activation of one of the overload protective devices, this
should not be considered an equipment failure.
Acoustic Overload Warning
NOTE:

13
NOTES

14
MK-2000P ORDERING, RETURN & PACKAGING
ORDERING INFORMATION
You may order MK Diamond products through your local MK Diamond distributor or, you may order
direct from MK Diamond.
When ordering direct from MK Diamond, please have the following information ready before calling:
• The Model Number of the drill
• The Serial Number of the drill
• Where the drill was purchased and when
• The Part Number for the part(s) being ordered
• The Part Description for the part(s) being ordered
NOTE: There is a $25.00 minimum order when ordering direct from MK Diamond. A $5.00 charge will
be added to orders having a net billing value under $50.00. All purchases must be made using VISA,
MasterCard or American Express.
All parts may be ordered by calling toll free to – 800 421-5830 or 310 539-5221 and asking for
Customer Service. For technical questions, call – 800 474-5594.
RETURN MATERIALS POLICY
To expedite the service relative to the return of a product purchased through MK Diamond, please
observe the following:
NOTE: When returning all items, they must have been purchased within the previous twelve (12)
months.
• Have the Model Number of the drill
• Have the Serial Number of the drill
• Have the location of where the drill was purchased
• Have the date when the drill was purchased
• Contact Customer Service for approval to return the item(s)
• Obtain a Returned Goods Number (RGA) authorizing the return
• Follow the packaging instructions in the following section
• Ensure your item(s) are prepaid to the destination
For returned items, call toll free to – 800 421-5830 or 310 539-5221 and ask for Customer Service.
For technical questions, call – 800 474-5594 or 310 257-2845.
PACKAGING INSTRUCTIONS
• Remove the Core Bit and Support Handle
• Dry the equipment before shipping
• When packing, include the following: Core Drill and Handle
• Package the unit in its original container or one of comparable size (do not ship the unit partially
exposed)
• Ensure all parts are secured in the packaging to prevent moving
AUTHORIZED SERVICE CENTERS
For quicker repair time, you may contact MK Diamond Customer Service, toll free, at 800 421-5830
or 310 539-5221 for the Authorized Service Center closest too you or visit our web site at
www.mkdiamond.com. For technical questions, call – 800 474-5594.

15
CONTACT
Please contact MK Diamond Products, Inc. Customer Service Department with any questions you
might have regarding distributors, parts or service.
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Customer Service Hours: Monday through Friday, 6AM-4PM PST
MK Diamond Products, Inc.
1315 Storm Parkway
Torrance, CA 90501
© COPYRIGHT 2012, MK DIAMOND PRODUCTS, INC. ALL RIGHTS RESERVED.
The MK Diamond logo is a registered trademark of MK Diamond Products, Inc. and may not be used,
reproduced, or altered without written permission. All other trademarks are the property of their re-
spective owners and used with permission.
MK Diamond may have patents, patent applications, trade marks, copyrights of other intellectual
property right covering this product in this document.
This manual MUST accompany the equipment at all times. This manual is considered a permanent
part of the equipment and should remain with the unit if resold.
The information and specications included in this publication were in effect at the time of approval for
printing.
MK DIAMOND PRODUCTS, INC. will guarantee every machine they build, to be free from defects in
material and workmanship for (1) one year from date of purchase. The obligation of MK DIAMOND
PRODUCTS, INC. under this warranty is limited to the repair or replacement of any parts which,
under normal use, prove to be defective in material or workmanship. The parts involved or the unit
in question should be returned to MK DIAMOND PRODUCTS, INC. or to a point designated by us,
transportation prepaid.
This warranty does not obligate us to bear the cost of labor or transportation charges in connection
with replacement or repair of defective parts. Likewise, it shall NOT apply to any unit which has been
subjected to misuse, neglect or accident. This warranty does NOT apply to any machine which has
been repaired or altered outside our factory.
This warranty does NOT obligate MK DIAMOND PRODUCTS, INC., with respect to items not of our
manufacture, such as engines, motors, hydraulics, etc., which are subject to their own guarantees and
warranties.
We shall in no event be liable for consequential damages or contingent liabilities arising out of failure
of any equipment or parts to operate properly.
MK DIAMOND PRODUCTS, INC. LIMITED WARRANTY
MK-2000P CONTACT & WARRANTY

MK-2000 Handheld Drill
OWNER'S MANUAL & OPERATING INSTRUCTIONS
MK Diamond Products, Inc.
1315 Storm Parkway
Torrance, CA 90501
Toll-Free: [phone]
Phone: [phone]
Fax: [phone]
www.mkdiamond.com
