MOTY-KO 14DD User manual

LMD, LLC.
www.motyko.com
1445 Brookville Way, Suite J, Indianapolis, IN 46239
TEL: [phone] FAX: [phone]
MOTY- KO Model #’s
14DD/18HD
CORDLESS HAMMER DRILL / DRILL
INSTRUCTION MANUAL
WARNING:
Please read the following instruction carefully before the tool used.

GENERAL SAFETY RULES
PERSONAL SAFETY
1. USE SAFETY GLASSES. Use a face or dust mask if operation is dusty.
2. DRESS PROPERLY. Do not wear loose clothing or jewelry. They can be
caught in moving parts. Rubber gloves and non-skid footwear are
recommended when working outdoors. Wear protective hair covering to
contain long hair.
3. STAY ALERT. Watch what you are doing. Use common sense. Do not
operate tool when you are tired.
4. REMOVE ADJUSTING KEY & WRENCHES. From habit of checking to
see that keys and adjusting wrenches are removed from tool before
turning it on.
5. CHECK DAMAGED PARTS. Before further use of tool, a guard or other
part that is damaged should be carefully checked to determine that it will
operate properly and perform its intended function. Check for alignment of
moving parts, binding of moving parts, breakage of parts, mounting, and
any other conditions that may affect its operation. A guard or other part
that is damaged should be properly repaired or replaced by and authorized
service center unless otherwise indicated elsewhere in this instruction
manual. Have defective switches replaced by authorized service center.
Do not use tool if switch does not turn it on and off.
6. DO NOT OVERREACH. Keep proper footing and balance at all times.
WORK AREA
1. KEEP WORK AREA CLEAN. Cluttered areas and benches invite injuries.
2. CONSIDER WORK AREA ENVIRONMENT. Don‘t expose power tools to
rain. Don‘t use power tools in damp or wet locations. Keep work area well
lit.
3. GUARD AGAINST ELECTRIC SHOCK. Prevent body contact with
grounded surfaces; for example, pipes, radiators, ranges, and refrigerator
enclosures.
4. KEEP CHILDREN AWAY. All visitors should be kept away from work area.
Do not let visitors contact tool.
5. DO NOT OPERATE portable electric tools near flammable liquids or in
gaseous or explosive atmospheres. Motors in these tools normally spark,
and the sparks might ignite fumes.
6. USE EXTREME CAUTION. When drilling or driving into wall, ceilings or
other areas where electrical wire may be contact. The metal portions of
tools are not insulated from the driver spindle. Be careful not to touch any
exposed electrical terminals with the tool.
TOOL AND CHARGER USE
1. DON‘T FORCE TOOL. It will do the job better and safer at the rate for
which it was intended.
2. USE RIGHT TOOL. Don‘t force small tool or attachment to do the job of a
heavy-duty tool. Don‘t use tool for purpose not intended; for example,
don’t use circular saw for cutting tree limbs or logs.
3. SECURE WORK. Use clamps or a vise to hold work. It‘s safer than using
our hand and it frees both hands to operate tool.
4. MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for better
and safe performance. Follow instructions for lubricating and changing
accessories. Keep handles dry, clean, and free from oil and grease.
5. DISCONNECT OR LOCK OFF TOOLS. When not in use, before servicing,
and when changing accessories, such as blades, bits, cutters.
6. AVOID UNINTENTIONAL STARTING. Be careful not to activate the
switch when charging accessories, or carrying the tool. To prevent
damaged to charger, do not run the tool with the charger connected.
TOOL AND CHARGER CARE
1. STORE IDLE TOOLS. When not in use, tools should be stored in dry, high
or secured place - out of the reach of children.
2. DON‘T ABUSE CORD. Never carry charger by cord or yank it to
disconnect from receptacle. Keep cord from heat, oil, and sharp edges.
3. DO NOT ALTER OR MISUSE TOOL. These tools are precision built.
Any alteration or modification is misuse and may result in a dangerous
condition.
4. MAINTAIN TOOLS WITH CARE. Keep tools clean for better and safer
performance. Follow instructions for lubricating and changing accessories.
Inspect charger cords periodically and if damaged, have repaired by
authorized service facility. Inspect extension cords periodically and replace
if damaged. Keep handles dry, clean and free from oil and grease.

IMPORTANT SAFETY INSTRUCTIONS FOR
BATTERY CHARGER
Before using charger, read all instructions and cautionary marking on charger,
battery pack, and product using battery pack.
WARNING: 120 volts or 230 volts present at charging terminal. Do not probe
with conductive objects. Danger of electric or electrocution.
WARNING: If battery pack case is cracked or damaged, do not inset into
charger. Danger of electric or electrocution.
1. The charger and battery pack is specially designed to work together. DO
NOT attempt to charge the battery pack with any other chargers.
2. Do not expose charger to rain or snow.
3. The charger is not intended for any uses other than charging MOTY-KO
rechargeable batteries. Any other uses may result in risk of fire, electric
shock or electrocution.
4. To reduce risk of damage to electric plug and cord, pull by plug rather than
cord when disconnecting charger.
5. Make sure cord is located so that it will not be stepped on, tripped over, or
otherwise subjected to damage or stress.
6. An extension cord should not be used unless absolutely necessary. Use of
improper extension cord could result in risk of fire, electric shock, or
electrocution.
7. An extension cord must have adequate wire size (AWG or American Wire
Gauge) for safety. When using more than one extension to make up the
total length, be sure each individual extension contains at least the
minimum wire size.
Recommended Minimum AWG Size for Extension Cords
Total Extension Cord Length (feet)
25 50 75 100 125 150 175
Wire Gauge
18 18 16 16 14 14 12
8. The charger is ventilated through slots in the top and the bottom of the
housing. Do not place any object on top of charger or place the charger
on a soft surface that might block the ventilation slots and result in
excessive internal heat. Place the charger in a position away from any
heat source.
9. Do not operate charger with damaged cord or plug - have them replace
immediately.
10. Do not operate charger if it has received a sharp blow, been dropped, or
otherwise damaged in any way; take it to an authorized service center.
11. Do not disassemble charger; take it to an authorized service center when
service or repair is required. Incorrect reassemble may result in a risk of
electric shock, electrocution or fire.
12. To reduce risk of electric shock, unplug charger from outlet before
attempting any cleaning. Removing the battery pack will not reduce this
risk.
13. NEVER attempt to connect 2 chargers together.
14. DO NOT store or use the tool and battery pack in locations where the
temperature may reach or exceed 105(such as outside sheds or metal
buildings in summer).
15. The charger is designed to operate on standard household electrical
power. Do not attempt to use it on any other voltage!
IMPORTANT SAFETY INSTRUCTIONS FOR
BATTERY PACKS
1. The battery pack is not fully charged out of the carton! First read the safety
instructions below. Then follow charging notes and procedures.
2. Do not incinerate the battery pack even if it is severely damaged or is
completely worn out. The battery pack can explode in a fire.
3. A small leakage of liquid from the battery pack cells may occur under
extreme usage or temperature conditions. This does not indicate a failure.
However, if the outer seal is broken and this leakage gets on your skin:
a. Wash quickly with soap and water.
b. Neutralize with a mild acid such as lemon juice or vinegar.
c. If battery liquid gets into your eyes, flush them with clean water for a
minimum of 10 minutes and seek immediate medical attention.
(Medical note: The liquid is 25-35% solution of potassium hydroxide.)
4. Never attempt to open the battery pack for any reason. If the plastic
housing of the battery pack breaks or cracks, immediately discontinue use
and do not recharge.
5. Do not carry extra battery packs in aprons, pockets, or toolboxes along
with their metal objects. Battery packs could be short-circuited causing
damage to the battery pack and possibly causing severe burns or fire.
6. Charge the battery packs only in MOTY-KO chargers.
7. NOTE: Review and observe all of the “Important Charging Notes” in the
charger instruction section of this manual.
8. NOTE: The batteries in your battery pack are the nickel-cadmium types.
Cadmium is considered to be a toxic material by the Environmental

Protection Agency. Before disposing of damaged or worn out
Nickel-Cadmium battery packs, check with your state Environmental
Protection Agency to find out about special restrictions on the disposal of
these battery packs or return them to a MOTY-KO certified service center
for recycling.
IMPORTANT CHARGING NOTES
1. Do not charge the tool in damp or wet environment.
2. Longest life and best performance can be obtained if the battery pack is
charged when the air temperature is between 32and 113(0 -45).
DO NOT charge the battery pack in an air temperature below +32(+0),
or above +113(+45) . This is important and will prevent serious
damage to the battery pack.
3. The charger and battery pack may become warm to touch while charging.
This is a normal condition, and does not indicate a problem.
4. To prevent overheating, do not cover the charger and do not charge
battery packs in direct sunlight or near heat sources.
5. If the battery pack does not charge properly
(1) Check current at receptacle by plugging in a lamp or other appliance.
(2) Check to see if receptacle is connected to a light switch, which turns
power off when you turn out the lights.
(3) Move charger and battery pack to a location where the surrounding air
temperature is approximately 32- 113(0 -45).
(4) If charging problems persist, take or send the tool, battery pack and
charger to your local service center.
6. The battery pack should be recharged when it fails to produce sufficient
power on jobs, which were easily done previously. DO NOT CONTINUE to use
under these conditions. Follow the charging procedure. You may also
charge a partially used pack whenever you desire with no adverse affect
on the battery pack.
7. Under certain conditions, with the charger plugged in to the power supply,
the exposed charging contacts inside the charger can be shorted by
foreign material. Foreign materials of a conductive nature such as, but not
limited to, steel wool, aluminum foil, or any buildup of metallic particles
should be kept away from charger cavities. Always unplug the charger
from the power supply when there is no battery pack in the cavity. Unplug
charger before attempting to clean.
8. Do not freeze or immerse charger in water or any other liquid.
WARNING: Don‘t allow any liquid to get inside charger. Electric shock may
result. To facilitate the cooling of the battery pack after use, avoid placing
the charger or battery packs in a warm environment such as in a metal shed, or
an uninsulated trailer.
CAUTION: Never attempt to open the battery pack for any reason. If the
plastic housing of the battery pack breaks or cracks, return to a service center
for recycling.
IMPORTANT: This product is not user serviceable. There are no user
serviceable parts inside the charger. Servicing at an authorized service center
is required to avoid damage to static sensitive internal components.
READ ALL OF THE INSTRUCTIONS IN THE BATTERY CHARGER SECTION OF THIS
MANUAL BEFORE ATTEMPT TO CHARGE THE BATTERY PACK FOR YOUR TOOL.
Always use correct battery pack (pack supplied with tool or replacement pack
exactly like it.) Never install any other battery pack. It will ruin your tool and
may create a hazardous condition.
INTRODUCTION:
These unite have the idea speed and torque combination required for both
drilling and screw driving application. To get an optimum performance and
protect your self, please read the following instruction carefully to get before the
tool used. FEATURES
VARIABLE SPEED SWITCH
The variable speed switch provides safety feature to the user for screw driving.
To turn the tool on, squeeze the trigger switch. To turn the tool off, release the
trigger switch (see Fig. 1A). Your tool is equipped with a brake. The chuck will
stop as soon as the trigger switch is fully released. The variable speed switch
enables you to select the best speed for a particular application. The farther
you squeeze the trigger, the faster the tool will operate. Use lower speeds for
starting holes without a center punch, drilling metals or plastic, driving screws
and drilling ceramics, or in any application requiring high torque. Higher speeds
are better drilling in wood,wood compositions and for using abrasive and
polishing accessories. For maximum tool life, use variable speed only for
starting holes or fasteners.
NOTE:Continuous use in variable speed range is not recommended. It may
damage the switch and should be avoided.
B
A
Fig. 1

FORWARD / REVERSE CONTROL BUTTON
A forward/reverse control button determines the direction of the tool and also
serves as a lock off button. To select forward rotation, RELEASE THE TRIGGER
SWITCH (see Fig. 1A), and depress the forward/reverse control button (see Fig.
1B), toward left side of the tool. To select reverse, depress the forward/reverse
control button (see Fig. 1B), toward right side of the tool. The center position
of the control button (see Fig.1B) locks the tool in the off position. When
change the position of the control button, making sure the trigger is released.
NOTE: The first time the tool is run after changing the direction of rotation, you
may hear a click on start up. This is normal and does not indicate a problem.
TORQUE ADJUSTMENT COLLAR
The clutch feature of your Driver/Drill is an adjustable torque screwdriver
mechanism for driving and removing a wide array of fastener shapes and sizes
(see Fig. 2). The clutch allows you to instantaneously regulate the torque,
based on the force applied.
FOR THE DRILL DRIVER:
Circling the collar are numbers ranging from 1 to 23 and a drill bit symbol.
These numbers are used to set the clutch to deliver a torque range. The higher
number on the collars, the higher torque and larger the fastener which can be
driven. To select any of the numbers, rotate until the desire number aligns with
the selector.
DUAL RANGE GEARING
The dual range feature of your Driver/Drill allows you to shift gears for greater
versatility. To select the low speed, high torque setting (position L), turn the
tool off and permit to stop. Push the button forward towards the chuck (see Fig.
3). To select the high speed, low torque setting (position H), turn the tool off
and permit to stop. Slide the gear shifter back (away from chuck).
NOTE: Do not change gears when the tool is running. If you are having trouble
changing gears, make sure that the dual range gear button is either completely
pushed forward or completely pushed back.
CLUTCH LOCK
To lock the clutch for drilling operations, simply move the Driver/Drill selector to
the “Drill” position as described under “Operation as a Drill”
This symbol indicates the DRILL POSITION. To select this mode for
high speed drilling (Wood, Aluminum, and Steel) and the clutch
will be locked. The trigger has to be released to stop the running
motor when the chuck slipping or shaft locked.
To select this mode with high speed provides for masonry or
concrete drilling. The trigger has to be released to stop the
running motor when the chuck slipping or shaft locked.
INSERTING AND REMOVING DRILL AND SCREWDRIVER BITS
CAUTION
Always set the reversing button to the center (locked “OFF”) position
when installing and removing bits.
1. The three-jaw chuck is designed for self-centering of the bit. Open
jaws large enough by turning the sleeve (A) Fig.4 counterclockwise,
when viewing the chuck from the bit end, so that the bit shank can
be inserted easily.
2. Clean and insert the smooth end of the bit as far as it will go into the
chuck, or up to the flutes for small bits.
3. While holding the bit with one hand, turn the sleeve (A) Fig4
Fig. 3
Fig. 2

clockwise until the bit is gripped in the chuck.
4. Tighten the chuck by turning the sleeve (A) clockwise. Tighten
securely.
5. To remove the bit, reverse procedure.
WARNING
Do not operate the drill motor while installing or removing bits. This
action may cause the bit to be thrown form the chuck, causing personal
injury.
DRIVER BIT STORAGE
Convenient storage areas with retaining clip, for screwdriver bits are provided
on each side of the tool. (See Fig. 5A)
OPERATION MANUAL
NORMAL CHARGING
Make sure power circuit voltage is the same as that shown on the charger
specification plate. Connect charger to power source. The orange light (A) Fig.
6, should light up. This indicates the charger is ready to begin charging.
Position battery pack on charger; align rails (see Fig. 6D), on battery charger
with four tabs (see Fig. 7E) on battery pack. Slide battery forward onto charger
until it stops.
The red light (see Fig. 6B), should begin to glow continuously, indicating that
the battery pack is receiving a “Fast Charge” (if the red light does not glow
continuously, and the green light (see Fig. 6C), begins to glow: remove battery
and re-insert when battery temperature is between 32(0) and 113(45).
After approximately one hour, the “Fast Charge” indicator light (red) should go
out indicating that the battery pack is fully charged and that the charger is now
in a “Trickle Charge” mode (green light). The battery pack can be left on “Trickle
Charge” until you are ready to use it. Depending on room temperature, line
voltage, and existing charge level, initial battery charging may take longer than
one hour. Disconnect charger from power source when not is use.
bbb
Fig. 5
A
B
C
D
D
A
E
E
Fig 6 Fig.7
Fig. 4
A

INSTALLING OR REMOVING BATTERY PACK
TO REMOVE BATTERY PACK : Depress the battery release button (see Fig.
8B), and pull battery pack out of tool.
TO INSTALL BATTERY PACK : Align rails (see Fig 8A), on the tool with the
four tabs on the battery pack, and push battery pack onto tool until it locks in
place.
CHUCK REMOVAL
ALWAYS WEAR EYE PROTECTION
Turn the adjustment collar to the “drill” position and low speed gear shifter.
Tighten the chuck around the shorter end of a hex key (not supplied) of 1/4” or
greater size. Using a wooden mallet or similar object, strike the longer end in
the clockwise direction. This will loosen the screw inside the chuck.
1. Open chuck jaws fully.
2. Insert a screwdriver into front of chuck between jaws to engage screw
head. Remove screw by turning clockwise.
3. Place a hex key in chuck and tighten. Using a wooden mallet or similar
object, strike key sharply in the counterclockwise direction (see Fig. 9).
This will loosen the chuck so that it can be unscrewed by hand.
CHUCK INSTALLATION
1. Screw the chuck on by hand as far as it will go and insert screw (LH
thread).
2. Tighten screw securely.
3. Tighten the chuck around the shorter end of a 1/4”a or large hex key (not
supplied) strike the longer end in the clockwise direction with a wooden mallet
(see Fig. 10).
OPERATION AS A DRILL
Turn the collar to the drill bit symbol. Install and tighten the desired drill bit in
the chuck. Select the desired speed/torque range using the dual range gear
shifter to match the speed and torque to the planned operation. Follow these
instructions for best results when drilling.
DRILLING
Use sharp drill bits only. For WOOD, use twist drill bits, spade bits, power auger
bits, or hole saws. For METAL, use high-speed steel twist drill bits, or hole saws.
For MASONRY, such as brick, cement, cinder block, etc., use carbide-tipped
bits. Be sure the material to be drilled is anchored or clamped firmly. If drilling
thin material, use a “back-up” block to damage to the material. Always apply
pressure in a straight line with the bit. Uses enough pressure to keep the drill
biting, but do not push hard enough to stall the motor or defect the bit.
Hold tool firmly to control the twisting of the drill.
Fig. 9 Fig. 10
Fi
g
. 8
A B

IF DRILL STALLS, it usually because it is being overloaded RELEASE
TRIGGER IMMEDIATELY, removes drill from work, and determine cause of
stalling. DO NOT CLICK TRIGGER OFF AND ON IN AN ATTEMPT TO START
A STALLED DRILL - THIS CAN DAMAGE THE DRILL.
To minimize stalling or breaking through the material, reduce pressure on drill
and ease the bit through the last fractional part of the hole.
Keep the motor running when pulling the bit back out of a drilled hole. This will
help prevent jamming.
With variable speed drills there is no need to center punch the point to be
drilled. Use a slow speed to start the hole is deep enough to drill without the bit
skipping out. Operate at full on after starting the bit.
DRILLING IN WOOD
Holes in wood can be made with the same twist drills use for metal. These bits
may overheat unless pulled out frequently to clear chips from the flutes. For
large hole, use low speed wood bits. Work that is likely to splinter should be
backed up with a block of wood.
DRILLING IN METALS
Use a cutting lubricant when drilling metals. The exceptions are cast iron and
brass, which should be drilled dry. The cutting lubricants that work best are
sulphurized cutting oil or lard oil; bacon grease also serves the purpose.
DRILLING MASONRY
Use carbide tipped masonry bits at low speeds. Keep even force on the drill but
not so much that you crack brittle materials. A smooth, even flow of dust
indicates the proper drilling rate.
OPERATION AS A SCREWDRIVER
Turn the river/Drill selector to the symbol of a screw. Select the desired
speed/torque range using the dual range gear shifter on the top of tool to match
the speed and torque to the planned operation. Insert the desired fastener
accessory into the chuck as you would any drill bit. Make a few practice runs in
scrap or unseen areas to determine the proper position of the clutch collar.
MAINTENANCE
CLEANING: With the motor running, blow dirt and dust out of all air vents with
dry air at least once a week. Wear safety glasses when performing this.
Exterior plastic parts may be cleaned a damp cloth and mild detergent.
Although these parts are highly are solvent resistant, NEVER use solvent.
CHARGER CLEANING INSTRUCTIONS:
Dirt and grease may be removed from the exterior of the charger using a cloth
or soft non-metallic brush. Do not use water or any cleaning solutions.
WARNING: Disconnect the charger from the AC outlet before cleaning
solutions.
ACCESSORIES
Recommended accessories for use with your tool are available at extra cost
from your local service center.
IMPORTANT! To assure product SAFETY and RELIABILITY, repairs,
maintenance and adjustment (including brush inspection and replacement)
should be performed by certified service centers or other qualified
service organizations, always using identical replacement parts.
SPECIFICATION
Maximum Drilling
Capacity

mm

Model
Number Volts No Load Speed (rpm) Torque (In.- lbs.) Mild
Steel Soft
Wood Concrete
Charging
Time
Tool
Weight
(lbs.)
14DD 14.4V 0-360/0-1150 415 13 32 - 1 Hr 4.70
18HD 18V 0-400/0-1200 430 13 38 16 1 Hr 5.10
Warranty:
One year warranty on parts & labor from date of purchase. Receipt is required.
Warranty does not cover abuse or negligence. Please contact your dealer for
service.
