Neolab LAMY NWP-F80 User manual

Quick Start Guide
Front Back
Ballpoint (Lamy M 21 ballpoint pen refill)
NCODE camera
Micro USB port (charging)
Power buttonLED indicator
Power on
How to use
We are analog beings living in the digital environment.
We connect your handwriting to the digital world to dream,
create and achieve more.
Charging
Tap
here!
STEP 1 Download NEO STUDIO™ STEP 2 Connect
STEP 3 Start to write
간단 사용 설명서 / Schnellstartanleitung / クイックガイド
전면부 / Ansicht oben / 前面
충전하기 / Aufladen / 充電
다운로드 / Download / ダウンロード NEO STUDIO™
Web viewer supported / 웹 뷰어 지원 /
Web Viewer unterstutzt / Webビューア対応
필기하기 / Schreiben / 書く
사용방법 / Anwendungsweise / 使い方ガイド
연결하기 / Verbinden / 接続
후면부 / Ansicht unten / 背面
전원켜기 / Einschalten / 電源オン
볼펜 (Lamy M21 리필심) / Ballpoint (M 21 LAMY Kugelschreiber-Mine) / ボールペン 替え芯D1 마이크로USB충전단자 / Micro-USB-Anschluß (aufladen) / Micro-USB端子
LED 상태표시등 / LED-Anzeige / LEDランプ
※上記はLAMY safari all black ncodeとLAMY digital paperでお使いいただける機能です
전원버튼 / Ein-Schalter / 電源ボタン NCODE 카메라 / NCODE-Kamera / NCODEカメラ
ver.1G14 / NC70-0112 A
Experience the LAMY safari all black ncode
LAMY safari all black ncode와의 특별한 경험 / Produkt-Highlights LAMY safari all black ncode / LAMY safari all black ncodeで紙からデジタルの世界へ
File share
파일 공유
Dateien teilen
ファイルを共有
Search
필기 검색
Suche
検索
Media share
미디어 공유
Medien teilen
メディア共有
Bookmark
즐겨찾기
Lesezeichen
お気に入り
※The above functions are supported when using LAMY safari all black ncode and LAMY digital paper.
※위 기능들은 LAMY safari all black ncode와 LAMY digital paper를 사용할 때, 지원됩니다.
※Die oben genannten Funktionen werden bei Verwendung von LAMY safari
all black ncode und LAMY digital paper unterstützt.
GRIDA Board™ in Chrome web browser
https://gridaboard.io/
.

NeoLAB Convergence warrants the included hardware product and accessories
against defects in materials and workmanship for one year from the date of original
retail purchase. NeoLAB Convergence does not warrant against normal wear and
tear, nor damage caused by accident or abuse. Please contact the store where you
purchased the product or NeoLAB Convergence for customer service/support. Keep
the product no. (serial no.) in a safe place as it is required for checking the product
warranty period when requesting customer service/support. The product no. (serial
no.) is attached on the surface of the product package.
NeoLAB Convergence übernimmt die Gewähr für das Schreibgerät und dessen Zubehör
gegen Material- und Verarbeitungsfehler für ein Jahr ab dem Datum des ursprünglichen
Einzelhandelskaufs. NeoLAB Convergence übernimmt keine Gewähr für normalen
Verschleiß noch für Schäden durch Unfall oder Missbrauch. Bitte wenden Sie sich entweder
an das Geschäft, in dem Sie das Produkt gekauft haben oder direkt an den Kundenservice/
Support von NeoLAB Convergence. Bewahren Sie die Produkt-Nr. (Seriennummer) an
einem sicheren Ort auf, da diese zur Überprüfung der Produktgarantiezeit benötigt wird,
wenn Sie den Kundenservice/Support kontaktieren. Die Produkt-Nr. (Seriennummer) ist auf
der Oberfläche der Produktverpackung angebracht.
네오랩컨버전스는 하드웨어 제품 및 액세서리의 재료 또는 제작 과정에서의 결함에 대하여
최초 구입일로부터 1년 동안 보증 서비스를 제공합니다. 정상적인 마모 및 흠집, 사고 또는 남
용으로 인한 파손은 보증 받을 수 없습니다. 제품 번호(Serial No.)는 A/S 신청 시 제품 보증
기간을 확인하기 위해 꼭 필요한 항목이니 분실되지 않도록 주의해 주세요. 제품 번호(Serial
No.)는 제품의 제품 포장물 겉면에 부착되어 있습니다.
日本国内でお求めの方は別添の製品保証書をご利用ください
LED Colour Status Information Precautions
Product Warranty
Serial No. / 제품번호 / Seriennummer
Date of Purchase / 구입일자 / Kaufdatum
Seller / 구입처 / Verkäufer
FCC Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
·
· Reorient or relocate the receiving antenna.
·
· Increase the separation between the equipment and receiver.
·
· Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
·
· Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT NOTE : FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 0.5 centimeters between the
radiator and your body. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Caution
THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS
NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH
MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
과학기술정보통신부 고지에 따른 고지사항
·
·
해당 무선설비는 운용 중 전파 혼선 가능성이 있으므로 인명 안전과 관련된 서비스는 할 수 없습니다.
·
· 이 기기는 가정용(B급) 전자파 적합기기로서 주로 가정에서 사용하는 것을 목적으로 하며,
모든 지역에서 사용할 수 있습니다.
Regulatory Compliance Information
LED 표시 안내 / LED-Statusanzeige / LEDカラーのステータス 주의 / Vorsichtsmaßnahmen / 注意
규정 준수 정보 / Rechtshinweise
제품 보증 / Produktgarantie
Status
상태 / ペンの状態
LED colour
LED 컬러 / LED-Farben / LEDの状態
Power ON
전원 ON / Eingeschaltet / 電源オン
App connection
앱과 연결 시
Verbindung mit der App
アプリ接続時
Low battery power
배터리 부족
Geringe Batterieladung
バッテリー残量わずか
Sensor recognition or
usage environment check
인식센서 또는 사용환경 점검 필요
Überprüfung der Sensorerkennung
oder der Verwendungsumgebung
光学センサーまたは使用環境の確
認
Para ver el manual en español, utilice el código QR de la izquierda.
Per accedere al manuale in italiano scansionare il codice QR qui a sinistra.
Veuillez scanner le code QR à gauche pour accéder au manuel français.
Gebruik de QR-code aan de linkerkant om de Nederlandse handleiding te bekijken.
R-C-NCV-NWP-F80 XU101635-21033A
203-JN1169
NWP-F80 HT76360
