NuPrime CDT-10 User manual

NuPrime
CDT-10

NuPrime
1
FCC Notice - Declaration of Conformity Information
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
 Consult the dealer or an experienced radio/TV technician for help.
WARNING: Only peripherals complying with the FCC class B limits may be attached to this
equipment.
Changes or modifications made to this equipment, not expressly approved by us or parties authorized
by us could void the user’s authority to operate the equipment. This device complies with part 15 of
the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
EU Declaration of Conformity
Hereby, NuPrime Audio, Inc. declares that this device is in compliance with the essential requirements
and other relevant provisions of Directive 2004/108/EC.
The manufacturer of this product is NuPrime Audio, Inc., 1712 Pioneer Ave. Ste 1817, Cheyenne,
Wyoming 82001, USA.
The Authorized Representative for EMC and product safety is NuPrime Audio, Inc., 1712 Pioneer Ave.
Ste 1817, Cheyenne, Wyoming 82001, USA.
For any service or guarantee matters please refer to the addresses given in separate service or
guarantee documents.
For customers in Europe
Disposal of Old El
ectrical & Electronic Equipment (Applicable in the European Union and other
European countries with separate collection systems)
This symbol on the product or on its packaging indicates that this product shall not be treated as
household waste. Instead it shall be handed over to the applicable collection point for the recycling
of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. The recycling of materials
will help to conserve natural resources. For more detailed information about recycling of this
product, please contact your local Civic Office, your household waste disposal service or the shop
where you purchased the product.

NuPrime
2
SAFETY INSTRUCTIONS
There are two categories of Safety Instructions included in this manual:
 Product Warnings, (i.e., what must never be done to assure avoiding those hazards that
could cause bodily injury or property damage); and
 User Directions (i.e., what must always be done to assure the safe use of your device).
The Safety Instructions contained in this manual have been categorized in accordance with the
seriousness of the potential hazards through the use of Signal Words. Those Signal Words, and their
intended meanings, are as follows:
DANGER: Indicates that a failure to observe the Safety Instructions could result in death or
catastrophic bodily injury.
WARNING: Indicates that a failure to observe the Safety Instructions could result in serious bodily
injury.
CAUTION: Indicates that a failure to observe the Safety Instructions could result in minor bodily
injury or property damage.
NOTE: Designates important information that relates to activities and/or conditions that might result
in loss of data and/or damage to your device.
Safe Use and Operation of Your Device
This equipment emits stray RF energy and will interfere with the reception of signals by airborne
electronic navigational devices or medical devices. Do not operate this equipment near any sensitive
medical devices.
WARNING: Use only grounded AC power cords.
Always immediately disconnect the power to the equipment in the event the device emits an unusual
odor or sound or generates smoke.
WARNING: Never attempt to disassemble, repair or make any modification to your device.
Disassembly, modification or any attempt at repair could cause bodily injury or property damage, as
well as damage to the device itself.
WARNING: Your device is not a toy. Never allow children to play with your device. Misuse, rough or
improper handling of your device by children could result in serious bodily injury for any of the
enumerated safety warnings in this manual. In addition, always keep all accessories and components
out of the reach of small children as small parts might present a choking hazard. Seek immediate
medical attention if choking occurs or if any small part has been swallowed.
CAUTION: Never raise the sound volume level too high when using your device with earphones. An
excessive sound volume level could cause damage to your hearing.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to moisture or water.
Do not allow foreign objects to get into the enclosure. If the unit is exposed to moisture, or a foreign
object gets into the enclosure, immediately disconnect the power cord from the wall. Take the unit to
a qualified service person for inspection and necessary repairs.
Read all the instructions before connecting or operating the component.
Keep this manual so you can refer to these safety instructions.
Heed all warnings and safety information in these instructions and on the product itself. Follow all
operating instructions.

NuPrime
3
Do not use this unit near water.
You must allow a minimum 10 cm or 4 inches of unobstructed clearance around the unit. Do not place
the unit on a bed, sofa, rug, or similar surface that could block the ventilation openings. If the unit is
placed in a bookcase or cabinet, there must be ventilation of the cabinet to allow proper cooling.
Keep the component away from radiators, heat registers, stoves, or any other appliance that
produces heat.
The unit must be connected to a power supply only of the type and voltage specified on the rear
panel. Connect the component to the power outlet only with the supplied power supply cable or an
exact equivalent. Do not modify the supplied cable.
Do not route the power cord where it will be crushed, pinched, bent, exposed to heat, or damaged in
any way. Pay particular attention to the power cord at the plug and where the cord exits the back of
the unit.
The power cord should be unplugged from the wall outlet during a lightning storm or if the unit is to
be left unused for a long period of time.
Immediately stop using the component and have it inspected and/or serviced by a qualified service
agency if:
 The power supply cord or plug has been damaged.
 Objects have fallen or liquid has been spilled into the unit.
 The unit has been exposed to rain.
 The unit shows signs of improper operation.
 The unit has been dropped or damaged in any way.

NuPrime
4
Introduction
NuPrime CDT-10 is a highly accurate professional CD player with powerful DSP-based decoder that
provides all Red Book error-correction capabilities with master-clock control of the entire decoding
system, thus lowering jitter significantly. The transport’s single speed minimizes vibration and
unbalanced discs. A selectable sampling rate converter (SRC) up samples the CD format to higher
sampling rate with ultra-low jitter and distortion.
Features
Highly Accurate CD Playback
 A powerful ARM chip LPC2103F CD reads, writes and controls error correction
 Philips SAA7824HL high-end laser reads/writes head control and decodes chips
 Supports CD-DA CD-R, CD-RW
 Algorithm reduces digital interference and jitter
 Coaxial output with a dedicated isolation transformer
 Low jitter I2S output for professional use
Sampling Rate Converter
 The sampling rate of CD playback can be up sampled to PCM and DSD, from 44.1kHz to
768kHz or DoP256
 The conversion is achieved by up-sampling to mega hertz before down converting to the
targeted sampling rate with ultra-low jitter and distortion
Power and Mechanical
 Custom R-type professional transformer with shielding
 Low power consumption in Standby Mode
 High quality aluminium remote control
 Isolation shielding of CD transport from electronics and power supply
 CD transport stabilizing design
 AC filter
 Available in black or silver anodized aluminium finish
Specifications
 Optical Sampling Rates Converter (SRC): 44.1KHz, 48KHz, 88.2KHz, 96KHz, 176.4KHz,
192KHz, DoP64
 Coaxial Sampling Rates Converter (SRC): 44.1KHz, 48KHz, 88.2KHz, 96KHz, 176.4KHz,
192KHz, 352.8KHZ, 384KHz, 705KHZ, 768KHZ, DoP64, DoP128, DoP256
 HDMI I2S Sampling Rates Converter (SRC): 44.1KHz, 48KHz, 88.2KHz, 96KHz, 176.4KHz,
192KHz, 352.8KHZ, 384KHz, 705KHZ, 768KHZ, DoP64, DoP128, DoP256
 AES / EBU Sampling Rates Converter (SRC): 44.1KHz, 48KHz, 88.2KHz, 96KHz, 176.4KHz,
192KHz, 352.8KHZ, 384KHz, 705KHZ, 768KHZ, DoP64, DoP128, DoP256
 Bit Resolution: 24-bits
 Dimensions: 386.2 mm W x 215.4 mm D x 59 mm H (including feet)
 Weight: 6Kg
 Worldwide AC voltage: (90VAC~130VAC // 210VAC~ 250VAC) With Voltage Select Switch
 AC Fuse: Slow-blow,T1A, 250VAC

NuPrime
5
Quick Start Guide
Front Panel View:
1. OPEN / CLOSE button
2. STANDBY button
3. STOP button
4. CD TRAY
5. DISPLAY
6. PLAY / PAUSE button
7. TRACK Selection buttons
Rear Panel View:
Outputs:
1. Coaxial Output (up to 24 bits / 768KHz) (DoP256)
2. Optical Output (up to 24 bits / 192 kHz) (DoP64)
3. AES / EBU Balance Output (up to 24 bits / 768KHz) (DoP256)
4. HDMI I2S Output (up to 24 bits / 768KHz) (DoP256)

NuPrime
6
Remote Control :
: Power ON / OFF
DIS : Display information
RPT : Repeat & shuffle CD playlist
: Opening / Closing CD tray
: Stop CD playback
: Play / Pause CD playback
: Previous track
: Next track
: Search backward
: Search forward
SRC : SRC Menu / Setting
: SRC selection Previous
: SRC selection Next
Battery Replacement:
To change the battery, please remove the 4 screws and the bottom cover to reveal the battery casing.
I2S PIN Define:
AC Inlet Voltage Selector:
Make sure that the AC Voltage selector switch at the bottom of the
unit is switched to the appropriate voltage for your country. All CDT-
10 are shipped with the switch set to 230V AC in order to prevent
accidental damage.
PIN 1: I2S_DATA- PIN 11: GND
PIN 2: GND PIN 12: I2S_MCK-
PIN 3: I2S_DATA+ PIN 13: NC
PIN 4: I2S_BCK+ PIN 14: DSD ON
PIN 5: GND PIN 15: NC
PIN 6: I2S_BCK- PIN 16: NC
PIN 7: I2S_LRCK- PIN 17: GND
PIN 8: GND PIN 18: NC
PIN 9: I2S_LRCK+ PIN 19: NC
PIN 10: I2S_MCK+

NuPrime
7
Start Up
Long press power knob for 3 seconds or power button on remote control to turn on CDT-10.
Note: During DISC loading, all function is disabled until DISC status is ready.
CD PLAYER:
The full album information is displayed once the DISC is successfully loaded.
1. Playback Mode 2. Total tracks of the album 3. Total time of the album
1. Playback Mode: Display current playback mode. Repeat One, Repeat All, Shuffle All, Shuffle Repeat,
& no repeat or shuffle.
2. Total tracks of the album: Display how many tracks are content in the album. Up to 99 tracks can be
displayed.
3. Total time of the album: Display the combine play time of all tracks in the album. Up to 99 hours and
99 minutes can be displayed.
If no DISC is placed or incorrect format is being loaded, No DISC is displayed.

NuPrime
8
CD Function: Eject
To load DISC, please press OPEN/CLOSE button on the front panel or on remote control to Eject the
CD tray.
Once the tray is out, place CD DISC onto the tray and press again for closing.
After closing, DISC is loaded and status is displayed.
CD Function: Play / Pause
Once the DISC status is successfully loaded, press PLAY/PAUSE button on the front panel or remote
control to begin playback
If no Playback Mode is selected, playback begins from track 1 of the album.
During playback, press PLAY/PAUSE button again to pause playback. In pause mode, a flashing PAUSE is
displayed.
To resume, press PLAY/PAUSE button again.
CD Function: Previous/Search Backward & Next track/Search Forward
Briefly press Previous & Next buttons & to skip to previous track or next track during playback.
If playback is still in the first 3 sec, pressing Previous button will skip to previous track. If playback is more
than 3 sec in,Pressing Previous button will repeat current track from the beginning. While in CD status
menu, briefly press Previous & Next buttons to select desire track. Once the desire track is selected, press
PLAY button to begin playback.
