Operating Instructions

Before operating this product, please read the instructions carefully and save

this manual for future use.

S0205N3097 -M

Printed in Japan

Memory Card Video Recording System

ENGLISH

VQT0Q80-3

Car Use only

Model No. AG-CPD10CRUP

WARNING:

• TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD, DO NOT

EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.

• TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD, KEEP THIS

EQUIPMENT AWAY FROM ALL LIQUIDS. USE AND STORE ONLY

IN LOCATIONS WHICH ARE NOT EXPOSED TO THE RISK OF

DRIPPING OR SPLASHING LIQUIDS, AND DO NOT PLACE ANY

LIQUID CONTAINERS ON TOP OF THE EQUIPMENT.

CAUTION:

TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD AND

ANNOYING INTERFERENCE, USE THE RECOMMENDED

ACCESSORIES ONLY.

indicates safety information.

CAUTION:

In order to maintain adequate ventilation, do not install or place this

unit in a book case, built-in cabinet or any other confined space.

To prevent risk of electric shock or fire hazard due to overheating,

ensure that curtains and any other materials do not obstruct the

ventilation.

FCC Note:

This equipment has been tested and found to comply with the limits for a

class A digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy, and if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

Warning: To assure continued FCC emission limit compliance, the user

must only use shielded interface cables when connecting to external

units. Also, any unauthorized changes or modifications to this equipment

could void the user’s authority to operate it.

• The recorder and camera are designed for use and installation in a

vehicle. For example, the components may be mounted on the center

console, in the trunk, or attached to a sun visor using a fastening hole

or similar method.

• The recorder and camera installation must only be performed by a

professional installer.

• The rating plate is on the underside of the recorder.

indicates safety information.

CAUTION:

To reduce the risk of fire, the red (BATT) and white (SIGNAL) wires

of the power cable must be connected via fuses (5 A – 20 A) having

UL Listing (see page 14).

IMPORTANT SAFETY INSTRUCTIONS

(1) Read these instructions.

(2) Keep these instructions.

(3) Heed all warnings.

(4) Follow all instructions.

(5) Do not use this equipment near water.

(6) Clean only with a dry cloth.

(7) Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

(8) Do not install near any heat sources such as radiators, heat registers, stoves,

or any other equipment (including amplifiers) that produce heat.

(9) Only use attachments/accessories specified by the manufacturer, and as

outlined in this manual.

(10) Refer all servicing requests to qualified service personnel. Servicing is

required when the equipment has been damaged in any way, such as

damage to the power supply cord or plug, liquid being spilled on or objects

have fallen into the equipment, the equipment has been exposed to rain or

moisture and does not operate normally, or has been dropped.

Information on software for this product

•

Included with this product is software licensed under the GNU General Public License

(GPL) and GNU Lesser General Public License (LGPL), and users are hereby informed

that they have the right to obtain, change and redistribute the source codes of this software.

Details on GPL and LGPL can be found in the GPL and LGPL sections of this manual.

To obtain the source codes, go to the following home page.

https://eww.pavc.panasonic.co.jp/pro-av/

The manufacturer asks users to refrain from directing inquiries concerning the source

codes they have obtained and other details to its representatives.

• Included with this product is software licensed under the OpenSSL License. Details on

the OpenSSL License can be found in the OpenSSL License section of this manual.

• Included with this product is software licensed under the Blowfish License. Details on

the Blowfish License can be found in the Blowfish License section of this manual.

• Included with this product is software licensed under the DES License. Details on the

DES License can be found in the DES License section of this manual.

• For information on other licensed software included with this product and their license

conditions, go to the following home page.

https://eww.pavc.panasonic.co.jp/pro-av/

• This product is licensed under the MPEG-4 Visual patent portfolio license for the

personal and noncommercial use of a consumer for (i) encoding video in compliance

with the MPEG-4 Visual Standard (“MPEG-4 Video”) and/or (ii) decoding MPEG-4

Video that was encoded by a consumer engaged in a personal and noncommercial

activity and/or was obtained from a video provider licensed by MPEG LA to provide

MPEG-4 Video. No license is granted or shall be implied for any other use. Additional

information including that relating to promotional, internal and commercial uses and

licensing may be obtained from MPEG LA, LLC.

See http://www.mpegla.com/

Contents

IMPORTANT SAFETY

INSTRUCTIONS...........................4

Features.......................................5

Configuration and included

accessories .................................6

Options ........................................6

Before use ...................................6

Notes on handling ......................8

Control reference guide ...........10

Connections..............................14

P2 card insertion and removal 16

Recording and stopping ..........18

Camera operation .....................22

LEDs and recorder status........23

Factory default settings ...........25

Connector signals ....................31

Troubleshooting .......................34

GPL ............................................38

LGPL ..........................................41

OpenSSL License .....................45

Blowfish License ......................46

DES License..............................46

Specifications ...........................47

LIMITED WARRANTY ...............49

Features

Video recorder with long

recording capability

The recorder uses memory cards

identified by the P2 logo, such as

the separately available AJ-

P2C016RG. (This type of card is

called a “P2 card” in this manual.)

For example, when one 32-gigabyte

P2 card is inserted, available

recording time is up to 128 hours at

the 512 kbps rate setting.

Wide-angle, high-sensitivity

camera with IR function

The IR capable camera improves

the quality of images recorded at

night. The wide angle lens ensures

that a wider area is covered.

File recording

Video and audio files are recorded

on the P2 card using a compressed

format (MPEG4 and G.726).

In addition, meta data such as

recording date and time, recording

trigger and other information can

also be recorded.

File playback and archiving

Recorded files can be played back

on a desktop computer.

Recorded files can also be

uploaded to an archival server via a

LAN based network. (A specified

application software running on a

computer is required.)

Configuration and included accessories

This product consists of a recorder, camera, and the following accessories.

Power cable.......................................1

Camera cable

(divided into 2 pieces)........................1

External trigger cable.........................1

LAN cable (crossing type)..................1

Wide conversion lens

(installed on the camera) ...................1

P2 card (4 GB) AJ-P2C004HG..........1

USB 2.0/LAN adapter

(including driver CD)..........................1

Camera mount...................................1

Key.....................................................1

Recorder mount adapter

(installed on the recorder)..................2

P2 card (16 GB) AJ-P2C016RG P2 card (32 GB) AJ-P2C032RG

(release to be determined)

Set the internal clock

Before using the recorder for the

first time or after reconnecting it to

the power supply, check that the

power cable is connected correctly

and then use the Toughbook-

Arbitrator Front End Software to set

the date, time, and time zone of the

internal clock.

Exclusion of liability

Panasonic does not accept liability

for any problems related directly or

indirectly to data loss or failure to

record video data, audio data, or

meta data, that may be due to a

malfunction of recorder, camera, or

P2 card.

Be sure to perform a trial

recording

Before any important recording

application, be sure to first test the

system to confirm that video and

sound are recorded properly.

Checking the correct settings is

especially important when using the

“backlight compensation” and “IR

enabled night recording” functions.

Use with specified application

Use only the specified application

software for recorder and camera

setup and control. This application

software runs on a computer and

allows recorder and camera setup

and control via a network

connection. For information on how

to obtain the application software,

consult the supplier of this product.

In this manual, the application

software is referred to as the

“Toughbook-Arbitrator Front End

Software”.

Options

Before use

Before use (continued)

•In no event will Panasonic be liable for any damages, including any incidental

or consequential damages, stemming from a failure to record data or from lost

settings or data.

Any of the following actions can result in problems:

• Power supply to the recorder is interrupted or impaired during recording, for

example by starting an engine.

• If a P2 card is ejected while it is being accessed.

Finding related information

In this manual, the format “see page

00” is used to indicate pages with

relevant information.

Compatible memory cards

Only P2 cards identified by the P2

logo can be used with the recorder.

Before using a new 16 GB or higher

P2 card, be sure to format it on a

computer that has the P2 card

driver installed. The number of files

that you can record on a 16 GB or

higher P2 card is as follows.

Never remove the P2 card

while it is being accessed

In some rare cases, the P2 card slot

may become inoperative. When this

is detected, the recorder automatically

restarts itself.

Before disconnecting the

power cable, make sure that

recorder shutdown was

performed properly

Never disconnect the power cable

while the recorder is operating. In

particular, if the power cable is

disconnected during recording, P2

card managing information and data

setting information may be lost or

damaged. If the P2 card managing

information has been damaged and

files can no longer be read properly,

you should format the P2 card.

AJ-

P2C016RG

AJ-

P2C032RG

62 days

130 days

339 files/

508 files

339 files/

508 files

Card model

number

Number of

recording

days

Number of maximum

recording files/days

(with and without

bookmarks)

Notes on handling

Installation

• Install the recorder and camera

properly as described in the

installation manual, so that the

units cannot come loose or fall off.

• Do not place heavy objects on the

power cable and other connection

cables.

• Do not exceed the rating of any

connection cables and other wiring

parts.

• Use only the supplied accessories

and specified optional accessories.

• Keep the recorder, camera, P2

card, power cable and connection

cables away from heat sources.

• Protect the recorder, camera and

P2 cards from oily smoke,

humidity, moisture, and dust.

• Do not touch the power supply

connector with wet hands.

• Do not block the ventilation holes

of the recorder.

Usage

• The recorder is designed to be

powered from a 12-volt source. It

cannot be used in vehicles with a

different electrical source voltage.

(Never connect the recorder to a

24-volt source.)

• When using the recorder for the

first time or after reconnecting it to

the power supply, be sure to set

the date, time, and time zone of

the internal clock using the

Toughbook-Arbitrator Front End

Software.

• Do not place any container with

liquid or any small metal objects

on top of the recorder, camera, or

P2 card.

• Do not insert any foreign objects

into the openings of the unit.

• Do not attempt to modify the

recorder, camera, or P2 card.

• Take care not to damage the

power cable or connection cables.

Do not modify, bend, twist, curl, or

pull these parts or subject them to

a strong stress force. Also avoid

exposure to high temperatures.

• Protect the recorder, camera, and

P2 cards from moisture and do not

expose them to water.

• Do not place heavy objects on the

recorder or camera and do not

step on these parts. Do not

suspend any heavy objects from

the mounted camera.

• Before moving the recorder or

camera, be sure to disconnect the

power cable and other connection

cables.

• Do not handle the recorder or

camera while driving a vehicle.

• Only P2 type memory cards can

be used in the recorder. Do not

use any other type of card,

because this will damage the

recorder.

• When inserting a P2 card, proceed

carefully and do not use excessive

force. Otherwise the P2 card or

the card slot will be damaged.

• Do not insert the P2 card upside

down.

• Do not insert a damaged or

deformed P2 card.

• Do not disconnect the power cable

while the recorder is operating. Be

sure to perform recorder shutdown

before disconnecting the cable.

Otherwise recorder setting files

and P2 card managing information

may be lost or damaged.

When the SIGNAL pin at the DC

IN connector goes OFF, the

recorder will perform shutdown

after an interval set with the

Toughbook-Arbitrator Front End

Software.

• Do not open the cover during P2

card access (BUSY LED is lit or

flashing). Do not exert undue force

on the cover to prevent damage.

• Never remove the P2 card from

the card slot during P2 card

access (BUSY LED is lit or

flashing). Otherwise data on the

P2 card will be destroyed.

• Take care not to pinch your fingers

in the P2 card slots or the cover.

• Protect the connector section of

the P2 card from dust, sand,

moisture etc. If a card has been

exposed to any of these, do not

insert it in the P2 card slot.

• Take care that no dust, sand,

moisture etc. can enter a P2 card

slot.

• Before closing the cover, make

sure that the EJECT button is

folded to the right.

• Do not exert undue force on the

EJECT button to prevent damage.

What to do in case of a problem

• If the recorder or camera was

dropped, or if a foreign substance

has entered a unit, stop recording,

shut down the unit and disconnect

the power cable.

• If a component emits smoke,

unusual smell or noise, or if another

problem occurs, disconnect the

power cable.

Maintenance

• Before performing any maintenance

operation, make sure that the

recorder is not operating and then

disconnect the power cable.

• Regularly check the ventilation

holes for blockage by dust etc.

Notes on handling (continued)

Precautions when using

16 GB or higher P2 cards

• Use only one P2 card. If you insert a

16 GB or higher P2 card into slot 1, for

example, do not insert anything into

slot 2.

•Be sure to format new cards on a

computer that has the P2 card

driver installed.

•Formatted P2 cards contain

folders necessary for operation on

the Memory Card Video Recorder.

Do not modify (delete, copy,

move, etc.) these folders using a

computer or other device.

•If the folders on a card have been

modified on a computer or other

device, you must reformat the

card.

•If the limit on the number of

recording days or files has been

exceeded on a card, the card will

be detected as full even if there is

space left on it.

Control reference guide

Recorder front panel

REC button ( )

Starts recording of video and sound

to a P2 card.

STOP button ( )

Stops recording.

P2 card slots 1, 2

Insert P2 cards here.

Up to two cards can be inserted

simultaneously.

(2 GB, 4 GB, 8 GB cards only)

EJECT button

Serves to eject a P2 card.

REC LED

Lights up during recording. If the

combined remaining recording time

for the cards inserted in the P2 card

slots 1 and 2 is less than 30

minutes (see page 23), the LED

starts to flash.

READY LED

Lights up when recording is

possible on a P2 card inserted in a

P2 card slot (see page 23).

BUSY LED

Lights up or flashes while a P2 card

is accessed (recording or playback;

see page 23).

Lock

Serves to lock and unlock the cover

of the P2 card slots.

Cover

Protects the P2 card slots.

Control reference guide (continued)

Recorder rear panel

VIDEO IN connector

(Pin jack)

This is a composite signal input.

VIDEO OUT connector

(Pin jack)

This is a composite signal output.

The signal from the camera cable

connector or the VIDEO IN

connector can be supplied here. For

information on how to select the

signal, see the documentation of the

Toughbook-Arbitrator Front End

Software.

AUDIO IN 1, 2 connectors

(Pin jack)

These are line level signal inputs.

The output signals of audio

components can be connected

here. For details on the connection,

see the installation manual.

MIC IN connector (Pin jack)

This is a microphone level signal

input. For details on the connection,

see the installation manual.

Cable clamp

This clamp can be used to fasten

the video cable, audio cable,

camera cable, and power cable.

LAN port

This port allows a 100BASE-TX

connection to a computer. Use the

supplied LAN cable.

Camera cable connector

Use the supplied camera cable to

connect the camera to the supplied

recorder.

GPIO/SERIAL connector

This connector serves as a

combined trigger signal input (8

lines), record tally output (1 line),

and serial port.

DC IN connector

This is the power supply connector.

Note:

Do not disconnect the power cable

while the recorder is operating. In

particular, if the power supply is

interrupted during recording, P2

card managing information and data

setting information may be lost or

damaged.

Control reference guide (continued)

Recorder mount adapter

187.4 (7-3/8 ")

(2-5/32 ")

(1-5/32 ")

Trunk mounting holes

These holes are used to mount the

recorder in the trunk.

For details, see the installation

manual.

Spaces for center console

mounting holes

In these spaces the holes can be

made to mount the recorder on the

center console.

For details, see the installation

manual.

Control reference guide (continued)

Camera front, rear, and top

REC LED

Lights up during recording.

The LED starts to flash when the

combined remaining recording time

for the cards inserted in the P2 card

slots 1 and 2 is less than 30

minutes (see page 23). The LED

can also be permanently turned off

using a Toughbook-Arbitrator Front

End Software setting. For details on

the setting procedure, see the

documentation of the Toughbook-

Arbitrator Front End Software.

Sun shade

Protects the lens from direct sunlight.

Wide conversion lens

The wide conversion lens enables a wider

viewing angle when recording video.

Backlight compensation

button

Controls the backlight compensation

function. Each push of the button

switches the function ON or OFF.

Light button

Controls the camera operation

panel illumination. Each push of the

button switches the illumination ON

or OFF.

Camera cable connector

Use the supplied camera cable to

connect the camera to the supplied

recorder.

Zoom buttons

Control the zoom function. The W

button serves to zoom out and the

T button to zoom in.

Auto zoom button

Pressing this button causes the

camera to automatically zoom in,

pause for a certain period, and

zoom out. The zoom factor and

pause duration can be set. For

details on the setting procedure,

see the documentation of the

Toughbook-Arbitrator Front End

Software.

REC button

Pressing this button causes the

recorder to start recording.

Camera mount holes

The supplied camera mount can be

attached here.

When the wide conversion lens is

mounted, use the front hole (A).

When the wide conversion lens is

removed, use the rear hole (B).

Notes:

•Use only the wide conversion lens

that was mounted on the camera

when delivered.

•Use only the specified camera

mount positions to install the

camera.

Connections

•Turn power to all components off and disconnect the power cables before making

any connections. Be sure to finish all other connections first, and then connect

the power cables last. Also refer to the connector signal diagram on page 31 and

to the documentation of the components that are to be connected.

•

Verify that recording is not in progress prior to disconnecting any cables from the recorder.

Be sure to disconnect the power cable first, and then disconnect any other cables.

•A wrong power cable connection will lead to malfunction. Make sure that the

power cable is connected correctly.

•To reduce the risk of fire or shock hazard, installation and wiring must only be

performed by a professional installer.

•To reduce the risk of fire, the red (BATT) and white (SIGNAL) wires of the

power cable must be connected via fuses (5 A –20 A) having UL Listing.

•The provided power cable is not for use in the engine compartment.

Video

Input Output

(line level) (mic level)

Audio input

Camera

(supplied)

Camera cable (supplied)

LAN cable (supplied)

External trigger

cable (supplied)

Power cable (supplied)

Computer

(available separately)

Others: Input signal lines

White (SIGNAL): Connect the signal line via

timer equipment and a fuse

Black (GND): Connect to the negative

terminal of the battery

Red (BATT):

Connect via a fuse to a power supply

that is constantly on, regardless of

ignition key ON/OFF status

White: Rec Tally output line

RS-232C: Connect to equipment

with serial connectors

Black: Connect to the negative

terminal of the battery

Connections (continued)

P2 card insertion and removal

Never open the cover or remove the P2 card while the P2 card is being

accessed. Otherwise the data on the card may be lost or damaged, and the P2

card slot may become inoperative.

Inserting a P2 card

(1) Open the cover.

Insert the key into the lock and

turn it clockwise by 60 degrees.

(2) Insert a P2 card into the P2

card slot and push it in until

the EJECT button pops out.

Do not push in this

direction.

EJECT button

Insert the card

with the P2 logo

facing up.

Do not touch to avoid

the risk of injury.

Notes:

•To prevent damage, do not exert

undue force on the open cover.

•Do not try to turn the key further

than the stop position, and do not

move it unnecessarily, to prevent

damage to the key and lock.

(3) Fold the protruding EJECT

button to the right.

Note:

Make sure that the EJECT button

has been properly positioned as

illustrated above before closing the

cover. Otherwise the EJECT button

will be damaged.

P2 card insertion and removal (continued)

Note:

If a P2 card was removed while

data was being accessed, files may

be corrupted. In some rare cases,

the P2 card slot may become

inoperative. If this case, the files

must be restored by controlling the

recorder from the Toughbook-

Arbitrator Front End Software.

When this is detected, the recorder

automatically restarts itself.

(4) Close the cover.

Return the cover to its original

closed position and press the

section marked .

PUSH

When you close the cover after

inserting a P2 card, the READY LED

indicates the recorder status (see page

23).

(5) Turn the key counterclockwise to

lock the cover and to allow

removal of the key from the lock.

Removing a P2 card

(2) Raise the EJECT button.

(1) Open the cover

(see previous page).

(3) Push the EJECT button so

that the P2 card pops out.

(4) Close the cover

(see top left of this page).

(5)

Turn the key counterclockwise

to lock the cover and to allow

removal of the key from the lock.

Recording and stopping

Recording

Recording can be started by one of the

following methods:

•

Pressing the REC button on the recorder.

•

Pressing the REC button on the camera.

•Clicking the REC button in the

Toughbook-Arbitrator Front End

Software.

• Activating a recording start trigger

from a device connected via the

GPIO/SERIAL connector on the

recorder. (A setting must first be

made with the Toughbook-

Arbitrator Front End Software.)

•

Setting the SIGNAL pin of the power

cable connected to the DC IN connector

of the recorder to ON. (A setting must

first be made with the Toughbook-

Arbitrator Front End Software.)

When recording starts, the prerecording

function operates to ensure that material

from a certain interval before the start

point is included in the recording. (For

details on prerecording, see page 20.)

The duration of this interval can be set

with the Toughbook-Arbitrator Front End

Software. For details, see the

documentation of the Toughbook-

Arbitrator Front End Software.

Make sure that the camera cable,

external trigger cable, and audio cables

(available separately) as well as any

other cables are connected correctly, as

described in the installation manual.

Notes:

•Recording can be started only if

the READY LED on the recorder is

lit. If recording is not possible when

the REC button is pressed or the

recording start trigger signal is

activated, the REC LED on the

recorder and the camera will flash

for about 1 second.

•The video signal from the input

selected with the Toughbook-

Arbitrator Front End Software will

be recorded (see page 21).

•

When recording is started by a

recording start trigger signal, the

recorded video signal will always be

the signal originating from the

camera unit, via the camera input

cable. If a recording start trigger

signal is activated while recording a

video signal from the VIDEO IN

connector, recording will

automatically switch to the video

signal originating from the camera

unit, via the camera input cable.

•The audio signal from the input

selected with the Toughbook-

Arbitrator Front End Software will

be recorded (see page 21).

•If the cover is opened during

recording, recording will stop.

•If the cover is not closed, recording

cannot be restarted.

•Even if there is space left on a P2

card, recording will not start under

the following conditions.

- The maximum number of

recording days has been

exceeded on a 16 GB or higher

P2 card.

- The maximum number of files that

can be recorded on a single day

has been exceeded on a 16 GB or

higher P2 card. (However, you can

start recording on the next day

(according to world standard time)

if the maximum number of

recording days has not been

exceeded.)

Recording can be stopped by one of

the following methods:

•Pressing the STOP button on the

recorder.

•

Clicking the STOP button in the Toughbook-

Arbitrator Front End Software.

When recording is stopped, the post-

recording function operates to ensure

that material from a certain interval

after the stop point is included in the

recording. The duration of this interval

can be set with the Toughbook-

Arbitrator Front End Software.

Notes:

•The entire video and audio content

of the recording period, including

the prerecording and post-

recording intervals, is stored as

one file on the P2 card.

•If recording time goes beyond about

17 hours or recording file size

exceeds 4 GB, then the recorded

file will be automatically split.

Stopping

Recording and stopping (continued)

Recording also stops under the

following conditions.

•There is no space left on the P2

card.

•The P2 card slots cover on the

Memory Card Video Recorder is

open.

•Administrator setup has been

started.

•An error is detected on the P2

card, and recording is no longer

possible.

•The maximum number of

recording days or files has been

exceeded while a 16 GB or higher

P2 card is inserted.

Recording and stopping (continued)

Write-protect switch

The P2 card is equipped with a write-

protect switch. If you set this switch to

the PROTECT position, no data can

be written to the P2 card and no

existing file can be deleted.

PROTECT

write-protect switch

Prerecording and post-recording

Prerecording is the capability of including

material from an interval before the

specified start point in a recording.

Similarly, post-recording is the capability of

including material from an interval after the

specified stop point in a recording. The

intervals (prerecord time and post-record

time) can be set using the Toughbook-

Arbitrator Front End Software.

Audio recording can be disabled during

prerecord and/or post-record.

If recording is started

immediately after system startup

Prerecord time will be shorter.

If recording is started during

post-record interval

Post-recording will be terminated

and next recording starts. There is

no prerecording interval for the

second recording.

REC button pressed

(Recording starts)

STOP button pressed

(Recording stops)

Actual recording time

Prerecord time Post-record time

REC button pressed

(Post-recording halted and

next recording starts)

STOP button

pressed

(Recording stops)

STOP

button

pressed

Actual recording time

REC button pressed

(Recording starts)

STOP button pressed

(Recording stops)

Startup

completed

Post-record time Post-record time

In the cases shown below, the actual

prerecord and post-record time may be

shorter than the respective setting.

Notes:

•

If you press the REC button and

STOP button alternately in rapid

succession, the system may not

separate the two recording sessions,

resulting in a single video file.

•

If the remaining capacity of the P2

card is low, the prerecord time or post-

record time may become shorter.

Notes:

•Any attempt to change the position

of the write-protect switch during

power-on will have no effect. To

produce the effect, turn the power

off and then turn it on again or

remove the card and then insert it

again.

•If the write-protect switch is set to

the PROTECT position on any of

the cards in the two card slots,

recording will not start.

Actual recording time

Time

Table of contents

Panasonic AG-CPD10CRUP User manual
