Philips 32PFK5109 User manual

Register your product and get support at LED TV
www.philips.com/welcome 32PFK5109
40PFK5109
48PFK5109
55PFK5109
User Manual

Contents
1 Your new TV 3
1.1 Pause TV and recordings 3
1.2 EasyLink 3
2 Setting up 4
2.1 Read safety 4
2.2 TV stand and wall mounting 4
2.3 Tips on placement 4
2.4 Power cable 4
2.5 Antenna cable 5
2.6 Satellite dish 5
3 Connections 6
3.1 Tips on connections 6
3.2 EasyLink HDMI CEC 7
3.3 Common interface - CAM 8
3.4 Set-top box - STB 8
3.5 Satellite receiver 8
3.6 Home Theatre System - HTS 9
3.7 Blu-ray Disc player 10
3.8 DVD player 10
3.9 Game console 11
3.10 USB Hard Drive 11
3.11 USB flash drive 12
3.12 Camcorder 12
3.13 Computer 12
3.14 Headphones 13
4 Switch on 14
4.1 On or Standby 14
5 Remote control 15
5.1 Key overview 15
5.2 IR sensor 15
5.3 Batteries 16
5.4 Cleaning 16
6 TV channels 17
6.1 Watching TV channels 17
6.2 Channel installation 20
7 Satellite channels 24
7.1 Watching satellite channels 24
7.2 Satellite channel list 24
7.3 Favourite satellite channels 24
7.4 Lock satellite channels 25
7.5 Satellite installation 26
7.6 Problems with satellites 28
8 TV guide 30
8.1 Using the TV guide 30
8.2 Recordings 30
8.3 Receiving TV guide data 30
9 Sources 31
9.1 Sources list 31
9.2 From standby 31
9.3 EasyLink 31
10 Timers and clock 32
10.1 Sleep timer 32
10.2 Clock 32
10.3 Auto switch off 32
11 Your photos, videos and music 33
11.1 From a USB connection 33
12 Pause TV 35
12.1 Pause TV 35
13 Recording 36
13.1 What you need 36
13.2 Record a programme 36
13.3 Watch a recording 36
14 Settings 37
14.1 Picture 37
14.2 Game or computer 38
14.3 Format and edges 38
14.4 Sound 39
15 Specifications 42
15.1 Environmental 42
15.2 Reception for PxHxxx9 / PxTxxx9 42
15.3 Reception for PxKxxx9 43
15.4 Display 43
15.5 Power 43
15.6 Dimensions and weights_5109 43
15.7 Connectivity 44
15.8 Multimedia 44
16 Software 45
16.1 Software update 45
16.2 Software version 45
16.3 Open source software 45
16.4 Open source license 45
17 Troubleshooting and support 64
17.1 Troubleshooting 64
17.2 Register 65
17.3 Help 65
17.4 Online help 65
17.5 Consumer Care / Repair 65
18 Safety and care 67
18.1 Safety 67
18.2 Screen care 68
19 Terms of use, copyrights and licenses 69
19.1 Terms of use 69
19.2 Copyrights and licenses 69
Index 71
2

1
Your new TV
1.1
Pause TV and recordings
If you connect a USB Hard Drive, you can pause and record a
broadcast from a digital TV channel.
Pause your TV and answer that urgent phone call or simply take
a break during a sports match, while the TV stores the broadcast
on the USB Hard Drive. You can start watching again later.
1.2
EasyLink
With EasyLink you can operate a connected device, like a Bluray
Disc player, with the remote control of the TV.
EasyLink uses HDMI CEC to communicate with the connected
devices.
3

2
Setting up
2.1
Read safety
Read the safety instructions first before you use the TV.
In Help, go to Safety and care > Safety.
2.2
TV stand and wall mounting
TV stand
You can find the instructions for mounting the TV stand in the
Quick Start Guide that came with the TV. In case you lost this
guide, you can download it from www.philips.com.
Use the product type number of the TV to look for the Quick
Start Guide to download.
Wall mounting
Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the wall mount .
. .
To fix the bracket securely, use screws with a length indicated in
the drawing.
- 32Pxx5109 - VESA MIS-F 400x200, M6
- 40Pxx5109 - VESA MIS-F 400x200, M6
- 48Pxx5109 - VESA MIS-F 400x200, M6
- 55Pxx5109 - VESA MIS-F 400x400, M6
Caution
Wall mounting the TV requires special skills and should only be
performed by qualified personnel. The TV wall mounting should
meet safety standards according to the TV's weight. Also read
the safety precautions before positioning the TV.
TP Vision Europe B.V. bears no responsibility for improper
mounting or any mounting that results in accident or injury.
Wall mounting
Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the wall mount .
. .
To fix the bracket securely, use screws with a length indicated in
the drawing.
- 42Pxx5199 - VESA MIS-F 200x200, M6
- 47Pxx5199 - VESA MIS-F 400x400, M6
- 55Pxx5199 - VESA MIS-F 400x400, M6
Caution
Wall mounting the TV requires special skills and should only be
performed by qualified personnel. The TV wall mounting should
meet safety standards according to the TV's weight. Also read
the safety precautions before positioning the TV.
TP Vision Europe B.V. bears no responsibility for improper
mounting or any mounting that results in accident or injury.
2.3
Tips on placement
- Position the TV where light does not shine directly on the
screen.
- Position the TV up to 15 cm away from the wall.
- The ideal distance to watch TV is 3 times its diagonal screen
size. When seated, your eyes should be level with the centre of
the screen.
4

2.4
Power cable
- Insert the power cable into the POWER connector on the
back of the TV.
- Make sure the power cable is securely inserted in the
connector.
- Make sure that the power plug, in the wall socket, is accessible
at all times.
- When you unplug the power cable, always pull the plug, never
pull the cable.
Although this TV has a very low standby power consumption,
unplug the power cable to save energy if you do not use the TV
for a long period of time.
2.5
Antenna cable
Insert the antenna plug firmly into the ANTENNA socket at the
back of the TV.
You can connect your own antenna or an antenna signal from
an antenna distribution system. Use an IEC Coax 75 Ohm RF
antenna connector.
Use this antenna connection for DVB-T and DVB-C input
signals.
2.6
Satellite dish
Attach the satellite F-type connector to the satellite connection
SAT at the back of the TV.
5

3
Connections
3.1
Tips on connections
Connectivity guide
Always connect a device to the TV with the highest quality
connection available. Also, use good quality cables to ensure a
good transfer of picture and sound.
If you need help to connect several devices to the TV, you
can visit the Philips TV connectivity guide. The guide
offers information on how to connect and which cables to use.
Go to www.connectivityguide.philips.com
Antenna
If you have a Set-top box (a digital receiver) or Recorder,
connect the antenna cables to run the antenna signal through
the Set-top box and/or Recorder first before it enters the TV. In
this way, the antenna and the Set-top box can send possible
additional channels to the Recorder to record.
HDMI
HDMI CEC
An HDMI connection has the best picture and sound quality.
One HDMI cable combines video and audio signals. Use an
HDMI cable for High Definition (HD) or Full HD (FHD) TV
signals. For best signal quality transfer, use a High speed HDMI
cable and do not use an HDMI cable longer than 5 m.
EasyLink HDMI CEC
If your devices are connected with HDMI and have EasyLink, you
can operate them with the TV remote control. EasyLink HDMI
CEC must be switched On on the TV and the connected
device.
DVI to HDMI
Use a DVI to HDMI adapter if your device only has a DVI
connection. Use one of the HDMI connections and add an
Audio L/R cable (mini-jack 3.5mm) to Audio In for sound, on
the back of the TV.
Copy protection
DVI and HDMI cables support HDCP (High-bandwidth Digital
Content Protection). HDCP is a copy protection signal that
prevents copying content from a DVD disc or Blu-ray Disc. Also
referred to as DRM (Digital Rights Management).
HDMI ARC
HDMI 1 connection on the TV have HDMI ARC (Audio Return
Channel). If the device, typically a Home Theatre System (HTS),
also has the HDMI ARC connection, connect it to HDMI 1 on
this TV. With the HDMI ARC connection, you do not need to
connect the extra audio cable that sends the sound of the TV
picture to the HTS. The HDMI ARC connection combines both
signals.
In case you prefer to switch off ARC on the HDMI connections,
press  and select Setup and press OK. Select TV
settings > Sound > Advanced > HDMI 1 - ARC.
Scart
SCART is a good quality connection. The SCART connection
can be used for CVBS and RGB video signals but cannot be used
for High Definition (HD) TV signals. The SCART connection
combines video and audio signals.
Use the SCART adapter cable to connect your device.
6

Audio Out - Optical
Audio Out - Optical is a high quality sound connection. This
optical connection can carry 5.1 audio channels. If your device,
typically a Home Theatre System (HTS), has no HDMI ARC
connection, you can use this connection with the Audio In -
Optical connection on the HTS. The Audio Out - Optical
connection sends the sound from the TV to the HTS.
You can set the type of the audio out signal to fit the audio
capabilities of your Home Theatre System.
If the sound does not match the video on screen, you can adjust
the audio to video synchronization.
3.2
EasyLink HDMI CEC
EasyLink
With EasyLink you can operate a connected device with the TV
remote control. EasyLink uses HDMI CEC (Consumer
Electronics Control) to communicate with the connected
devices. Devices must support HDMI CEC and must be
connected with an HDMI connection.
EasyLink setup
The TV comes with EasyLink switched on. Make sure that all
HDMI CEC settings are properly set up on the connected
EasyLink devices. EasyLink might not work with devices from
other brands.
HDMI CEC on other brands
The HDMI CEC functionality has different names on different
brands. Some examples are: Anynet, Aquos Link, Bravia Theatre
Sync, Kuro Link, Simplink and Viera Link. Not all brands are fully
compatible with EasyLink.
Example HDMI CEC branding names are property of their
respective owners.
Operate devices
To operate a device connected to HDMI and set up with
EasyLink, select the device - or its activity - in the list of TV
connections. Press  SOURCES, select a device connected to
an HDMI connection and press OK.
Once the device is selected, the TV remote control can control
the device. However  and  OPTIONS keys and some
other TV keys are not forwarded to the device.
If the key you need is not on the TV remote control, you can
select the key in the Options menu.
Press  OPTIONS and select Controls in the menu bar. On
the screen, select the device key you need and press OK.
Some very specific device keys might not be available in the
Controls menu.
Note: Only devices that support EasyLink Remote
Control function will respond to the TV remote control.
EasyLink settings
The TV comes with all EasyLink settings switched on. You can
switch off any EasyLink setting independently.
EasyLink
To switch off EasyLink completely . . .
1. Press  and select Setup and press OK.
2. Select TV settings > General settings > EasyLink.
3. Select EasyLink.
4. Select Off and press OK.
5. Press , repeatedly if necessary, to close the menu.
EasyLink Remote Control
If you want devices to communicate but you don't want to
operate them with the TV remote control, you can switch off
EasyLink remote control separately.
You can control multiple HDMI-CEC compliant devices with
your TV remote control.
In the EasyLink settings menu, select EasyLink Remote
Control and select Off.
7

One-touch play
When you play an HDMI-CEC compliant device, the TV
switches on from standby and switches to the correct source.
One-touch standby
When you press  on the TV remote control, the TV and all
HDMI-CEC compliant devices switch to standby mode.
System audio control
If you connect an HDMI-CEC compliant device that includes
speakers through the HDMI ARC connector, you can choose to
hear the TV audio from those speakers instead of the TV
speakers.
3.3
Common interface - CAM
CI+
This TV is ready for the CI+ Conditional Access.
With CI+ you can watch premium HD programmes, like movies
and sports, offered by digital TV broadcasters in your region.
These programmes are scrambled by the TV broadcaster and
descrambled with a prepaid CI+ module.
Digital TV broadcasters provide this CI+ module (Conditional
Access Module - CAM) when you subscribe to their premium
programmes. These programmes have a high level of copy
protection.
Contact a digital TV broadcaster for more information on terms
and conditions.
CAM
Insert a CAM module
Switch off the TV before inserting a CAM.
Look on the CAM for the correct method of insertion. Incorrect
insertion can damage the CAM and TV.
Use the Common Interface slot on the TV to insert the CAM
card.
With the front of the card facing to you, gently insert the CAM
as far as it will go.
Leave the card in the slot permanently.
It may take a few minutes before the CAM is activated.
Removing the CAM will deactivate the broadcast service on TV.
If a CAM is inserted and subscription fees are paid, (connection
methods can differ), you can watch the TV broadcast. The
inserted CAM is exclusively for your TV.
3.4
Set-top box - STB
Use 2 antenna cables to connect the antenna to the Set-top box
(a digital receiver) and the TV.
Next to the antenna connections, add an HDMI cable to
connect the Set-top box to the TV.
Alternatively, you can use a SCART cable if the Set-top box has
no HDMI connection.
Auto switch off
Switch off this automatic timer, if you only use the remote
control of the Set-top box. Do this to prevent the TV from
switching off automatically after a 4 hour period without a key
press on the remote control of the TV.
To switch off the Switch off timer, press  and select Setup and
press OK.
Select TV settings > General settings > Auto switch off and
set the slider bar to Off.
3.5
Satellite receiver
- Only for TVs with a built-in satellite tuner.
Connect the dish antenna cable to the Satellite receiver.
8

Next to the antenna connection, add an HDMI cable to connect
the device to the TV.
Alternatively, you can use a SCART cable if the device has no
HDMI connection.
Auto switch off
Switch off this automatic timer, if you only use the remote
control of the Set-top box. Do this to prevent the TV from
switching off automatically after a 4 hour period without a key
press on the remote control of the TV.
To switch off the Switch off timer, press  and select Setup and
press OK.
Select TV settings > General settings > Auto switch off and
set the slider bar to Off.
3.6
Home Theatre System - HTS
Connect HTS
Use an HDMI cable to connect a Home Theatre System (HTS)
to the TV. You can connect a Philips Soundbar or an HTS with a
built-in disc player.
Alternatively, you can use a SCART cable if the device has no
HDMI connection.
HDMI ARC
If your Home Theatre System has an HDMI ARC connection,
you can use any HDMI connection on the TV to connect. With
HDMI ARC, you do not need to connect the extra audio cable.
The HDMI ARC connection combines both signals.
All HDMI connections on the TV can offer the Audio Return
Channel (ARC) signal. But once you connected the Home
Theatre System, the TV can only send the ARC signal to this
HDMI connection.
If the Home Theatre System has no HDMI ARC connection,
add an optical audio cable (Toslink) to send the sound of the TV
picture to the Home Theatre System.
Audio to video synchronisation (sync)
If the sound does not match the video on screen, you can set a
delay on most Home Theatre Systems with a disc player to
match the sound with the video.
Audio Out settings
Audio Out delay
With a Home Theatre System (HTS) connected to the TV, the
picture on TV and the sound from the HTS should be
synchronised.
Automatic audio to video sync
With recent Philips Home Theatre Systems, the audio to video
sync is automatically synchronised and always correct.
Audio sync delay
For some Home Theatre Systems you might need to adjust the
audio sync delay to synchronise the audio to video. On the HTS,
increase the delay value until there is a match between picture
and sound. A delay value of 180ms may be required. Read the
user manual of the HTS. With a delay value set up on the HTS,
you need to switch off Audio Out delay on the TV.
To switch off the Audio Out delay . . .
1. Press  and select Setup and press OK.
2. Select TV settings > Sound > Advanced > Audio out delay.
3. Select Off and press OK.
4. Press , repeatedly if necessary, to close the menu.
9

Audio Out offset
If you cannot set a delay on the Home Theatre System, you can
set the TV to sync the sound. You can set an offset that
compensates the time necessary for the Home Theatre System
to process the sound of the TV picture. You can set the value in
steps of 1ms. Maximum setting is 12ms. The Audio out delay
setting should be switched on.
To synchronise the sound on the TV . . .
1. Press  and select Setup and press OK.
2. Select TV settings > Sound > Advanced > Audio out offset.
3. Use the slider bar to set the sound offset and press OK.
4. Press , repeatedly if necessary, to close the menu.
Audio Out format
If you have a Home Theatre System (HTS)
with multichannel sound processing capabilities like Dolby
Digital, DTS® or similar, set the Audio out format to
Multichannel. With Multichannel, the TV can send the
compressed multichannel sound signal from a TV channel or
connected player to the Home Theatre System. If you have a
Home Theatre System without multichannel sound processing,
select Stereo.
To set the Audio Out format . . .
1. Press  and select Setup and press OK.
2. Select TV settings > Sound > Advanced > Audio out
format.
3. Select Multichannel or Stereo.
4. Press , repeatedly if necessary, to close the menu.
Audio Out levelling
Use the Audio Out leveling setting to level the volume
(loudness) of the TV and the Home Theatre System when you
switch over from one to another. Volume differences can be
caused by differences in sound processing.
To level the difference in volume . . .
1. Press  and select Setup and press OK.
2. Select TV settings > Sound > Advanced > Audio out
leveling.
3. If the volume difference is large, select More. If the volume
difference is small, select Less.
Press , repeatedly if necessary, to close the menu.
Audio Out leveling affects both the Audio Out - Optical and
HDMI ARC sound signals.
Problems with HTS sound
Sound with loud noise
If you watch a video from a plugged in USB flash drive or
connected computer, the sound from your Home Theatre
System might be distorted.
1. Press  and select Setup and press OK.
2. Select TV settings > Sound > Advanced > Audio out
format.
No sound
If you cannot hear the sound from the TV on your Home
Theatre System, check the following . . .
- Check if you connected the HDMI cable to a HDMI
ARC connection on the Home Theatre System. All HDMI
connections on the TV are HDMI ARC connections.
- Check if the HDMI ARC setting on the TV is switched On.
Go to  > Setup > TV settings > Sound > Advanced > HDMI
1 -ARC.
3.7
Blu-ray Disc player
Use a High speed HDMI cable to connect the Blu-ray Disc
player to the TV.
If the Blu-ray Disc player has EasyLink HDMI CEC, you can
operate the player with the TV remote control.
3.8
DVD player
Use an HDMI cable to connect the DVD player to the TV.
Alternatively, you can use a SCART cable, if the device has no
HDMI connection.
10
