Phoenix Model Classic User manual

Instruction Manual
All wood construction.
95% almost ready to fly.
All accessories are included.
Most parts are cut by laser machine.
Easy to assemble and easy to prepair.
Pre-covered and decorated
with real iron - on film.
144.5 cm
(56.9 in)
2250 gr
(4.95 lbs)
114.5 cm
(45.1 in)
40 - 46
two stroke
4 channels
4 servos

1011
1 2 3
4 5 6
7 8 9
12
13 14 15
1
Draw a center line. Remove the covering. Glue the wing joiner to the wing.
Apply the epoxy into the wing section. Glue the wing by epoxy. Apply the trim tape to the center
section of the wing where they join.
Remove the covering. Glue the two hard wood by C.A glue. Mark the shape of the servo box to the
wing.
Remove the covering. Glue the servo box by C.A glue. Install and secure the aileron servo.
Install the two nylon control horn. Attach the clevis to the control horn. Cut away the aileron pushrod.
Nylon control horn
J
oinin
g
the win
g
halves
.
Joining the wing halves.
1
Installing the aileron servo and linkage.
2
Center line
Silicon tube
Silicon tube
Instruction Manual Classic

16 17 18
19 20 21
22 23
24 25
27 28
2
Bend "L" the aileron pushrod. Attach the nylon clasp to the aileron
servo arm. Make the same way to install the second aileron pushrod.
Draw a center line. Remove the covering from the fuselage. Attach the horizontal to the fuselage
and check it.
Mark the shape of the fuselage onto the
top and bottom of the horizontal.
Cut away the covering from the
fuselage.
26
Mark the shape of the fuselage onto the
both side of the vertical.
Remove the covering from the vertical. Glue the vertical into the fuselage by
epoxy and check it.
Remove the covering from the top and
bottom of the horizontal.
Glue the horizontal and fuselage by
epoxy and check it.
Nylon clasp
I
nstall
i
ng the hor
i
zontal and vert
i
cal.
Installing the horizontal and vertical.
3
Center line
Check the horizontal and the wing.
A1 A2
A1 = A2
A1 A2
B B 1
AA-1
Check the fin before it dry and remove
the wing out of the fuselage.
a1 a2
a1 = a2
Instruction Manual Classic

29 30 31
32 33 34
35 36 37
3938 40
3
The landing gear and nose gear. Install the collar. Install the wheel.
Cut away the covering on the fuselage.
Install the landing gear. Secure the landing gear.
Install the wheel. Attach the wire pushrod to the steering
arm. Install the nose gear and secure it.
The control horn and pushrod. Insert the silicon tube to the clevis of
the rudder pushrod. Remove the covering.
J
oinin
g
the landin
g
g
ear and nose
g
ear
.
Joining the landing gear and nose gear.
4
I
nstall
i
ng the rudder and elevator pushrod.
Installing the rudder and elevator pushrod.
5
Collar
Gear
Silicon tube
41 42 43
Insert the ruder pushrod into the
fuselage. Install the nylon control horn. Attach the clevis to the control horn.
Control horn
Control horn
Clevis
Instruction Manual Classic

44 45 46
47 48 49
50 51 52
53 54 55
4
Install the rudder servo. Install the metal connector to the servo
arm. Connect the rudder pushrod and the nose gear pushrod to the rudder servo.
Secure the nose gear pushrod. Cut away the rudder pushrod. Bend "L" the rudder pushrod.
Attach the nylon clasp to the servo arm. Remove the covering from the slot. Insert the elevator pushrod into the
fuselage.
Install the control horn. Attach the clevis to the control horn. Install the elevator servo.
56 57 58
Cut away the elevator pushrod. Bend "L" the elevator pushrod. Attach the nylon clasp to the servo arm.
Instruction Manual Classic

59 60 61
62 63 64
65 66 67
68 69 70
5
Cut away the fuel tube. Install the stopper to the tank. Secure the stopper.
Install the silicone tube to the tank. Slide the fuel tank into the fuselage. Secure the fuel tank by foam and wood.
Attach the engine to the engine mount
and mark four hole. Drill four holes onto the engine mount. Attach the throttle rod to the arm of the carburator.
Install the engine and secure it. Install the muffler and secure it. Install the propeller and the spinner.
I
nstallin
g
the fuel tank
.
Installing the fuel tank.
6
I
nstall
i
ng the eng
i
ne, the propeller and sp
i
nner
.
Installing the engine, the propeller and spinner.
7
71 72 73
Install the throttle servo. Secure the servo arm. Attach the throttle rod into the metal
connector and secure it.
Installin
g
the throttle servo.
Installing the throttle servo.
8
5mm
Instruction Manual Classic

6
KIT CONTENTS
AIR FRAME ASSEMBLIES
(2) Wing
(1) Fuselage
(1) Horizontal
(1) Vertical
(1) Instruction manual
main gear assembly
(2) Main gear
(2) 60mm wheel
(4) Collar
(4) 3mm x 4mm screw
(2) Nylon clasp
(4) 3mm x 12mm screw
nose gear assembly
(1) Nose gear
(1) 60mm wheel
(2) Collar
(2) 3mm x 4mm screw
(1) Steering arm
elevator control system
(1) Clevis
(1) Silicon tube
(1) Nylon clasp
(1) Nylon control horn
(2) 2mm x 16mm screw
(1) 1,7mm x 900mm metal rod
rudder control system
(1) Clevis
(1) Silicon tube
(1) Nylon clasp
(1) Nylon control horn
(2) 2mm x 16mm screw
(1) 1,7mm x 900mm metal rod
aileron control horn
(2) Clevis
(2) Silicon tube
(2) Nylon control horn
(2) Nylon snap keeper
(2) 1,7mm x 300mm metal rod
engine mount
(4) 3mm x 20mm screw
(4) Lock washer
FUel TANK
(1) Fuel tank
(1) Clunk
(1) 110mm silicone tube
(1) Stopper
(1) 80mm x 120mm foam
miscellaneous items
(1) Dihedral
(1) Spinner
(1) Trim tape 25mm x 600mm
(12) Rubber band
(2) 12mm dowel
(1) Wooden servo box
(1) Piece of wood
(1) Metal connector
(1) Servo box
77 78 79
Remove the covering from four holes
on the both side of the fuselage. Install two dowels into the fuselage. Install the wing into the fuselage using 8 rubber band.
I
nstallin
g
the win
g
.
Installing the wing.
10
74 75 76
Install the switch. Secure the switch. Install the radio.
Installin
g
receiver batter
y
and switch.
Installing receiver battery and switch.
9
Switch
Receiver
Battery
Instruction Manual Classic

!!!
BALANCING
1. It is critical that your airplane be balanced correctly.
Improper balance will cause your plane to lose
control and crash.
THE CENTER OF GRAVITY IS LOCATED 70 mm
BACK FROM THE LEADING EDGE OF THE
WING, AT THE FUSELAGE.
2. Mount the wing to the fuselage. Using a couple of
pieces of masking tape, place them on the top side
of the wing 70 mm back from the leading edge, at
the fuselage sides.
3. Turn the airplane upside down. Place your fingers on
the masking tape and carefully lift the plane .
4. If the nose of the plane falls, the plane is heavy nose.
To correct this first move the battery pack further
back in the fuselage. If this is not possible or does
not correct it, stick small amounts of lead weight on
the fuselage under the horizontal stabilizer. If the
tail of the plane falls, the plane is tail heavy. To
correct this, move the battery and receiver forward
or if this is not possible, stick weight into the
firewall. When balanced correctly, the airplane
should sit level or slightly nose down when you lift
it up with your fingers.
LATERAL BALANCE
After you have balanced a plane on the C.G. You
should laterally balance it. Doing this will help the
airplane track straighter
CONTROL THROWS
1. We highly recommend setting up a plane using the
control throws listed.
2. The control throws should be measured at the widest
point of each control surface.
3. Check to be sure the control surfaces move in the
correct directions.
1. Turn the airplane upside down. Attach one loop of
heavy string to the engine crankshaft and one to the
tail wheel wire. With the wings level, carefully lift
the airplane by the string. This may require two
people to make it easier.
2. If one side of the wing fall, that side is heavier than
the opposite. Add small amounts of lead weight to
the bottom side of the lighter wing half's wing tip.
Follow this procedure until the wing stays level
when you lift the airplane.
70 mm
Ailerons : 12 mm up 12 mm down
Elevator : 15 mm up 15 mm down
Rudder : 20 mm right 20 mm left
Elevator Control
Aileron Control
12 mm
12 mm
Rudder Control
20 mm
20 mm
15 mm
15 mm
FLIGHT PREPARATION PRE FLIGHT CHECK
1. Completely charge your transmitter and receiver
batteries before your first day of flying.
2. Check every bolt and every glue joint in your plane
to ensure that everything is tight and well bonded.
3. Double check the balance of the airplane
4. Check the control surface
5. Check the receiver antenna . It should be fully
extended and not coiled up inside the fuselage.
6. Properly balance the propeller.
Made in Vietnam
