Pioneer L40S3D13N User manual

Instruction Manual
L40S3D13N
L46S3D13N
L55S3D13N
Smart 3D TV
GB

Contents
1 Safety Warnings ...........................................................................................................................................................................4
2 Preparation...................................................................................................................................................................................6
Unpacking the TV ...............................................................................................................................................................................................................6
Installing the TV Stand (L46S3D13N and L55S3D13N)...........................................................................................................................................7
Installing the TV Stand (L40S3D13N) ...........................................................................................................................................................................8
Mounting the TV to a wall (L40S3D13N).....................................................................................................................................................................8
Mounting the TV to a wall (L46S3D13N & L55S3D13N) .........................................................................................................................................9
− Attaching the cable tidy.......................................................................................................................................................................................9
Front / Right Side View and Controls.........................................................................................................................................................................10
Rear View and Sockets (L40S3D13N) .........................................................................................................................................................................11
Installing Batteries in the Remote Control ..............................................................................................................................................................12
Remote Control Operation Range..............................................................................................................................................................................12
Assembling the 3D Glasses and Installing the Battery .......................................................................................................................................13
Remote Control .................................................................................................................................................................................................................14
3 Connections................................................................................................................................................................................16
Connecting the aerial......................................................................................................................................................................................................16
Connecting a cable box via HDMI ..............................................................................................................................................................................16
Connecting an ethernet cable.....................................................................................................................................................................................17
Connecting the power cable........................................................................................................................................................................................17
4 Initial Setup ................................................................................................................................................................................18
Connecting to the internet and tuning in your TV...............................................................................................................................................18
5 Customising TV Settings ...........................................................................................................................................................22
Basic functions.................................................................................................................................................................................................................. 22
− Changing channels ............................................................................................................................................................................................. 22
− Channel information .......................................................................................................................................................................................... 22
− Adjusting the volume ........................................................................................................................................................................................ 23
− Using headphones .............................................................................................................................................................................................. 23
− ECO mode............................................................................................................................................................................................................... 23
− Changing the source mode ............................................................................................................................................................................. 23
− Options menu ....................................................................................................................................................................................................... 23
− Navigating the menus ....................................................................................................................................................................................... 24
Channel lists....................................................................................................................................................................................................................... 25
− Creating a favourite list...................................................................................................................................................................................... 25
− Viewing a channel from your favourite list................................................................................................................................................ 25
Navigating the Picture menu ...................................................................................................................................................................................... 26
− Advanced settings - picture menu................................................................................................................................................................ 28
Sound menu ...................................................................................................................................................................................................................... 34
Network menu.................................................................................................................................................................................................................. 36
− DLNA - network ................................................................................................................................................................................................... 39
− How to view/play les from your PC............................................................................................................................................................. 39
− Netix settings - network ................................................................................................................................................................................ 40
− Deactivating Netix app................................................................................................................................................................................... 40
− ESN ............................................................................................................................................................................................................................ 40
Settings menu - map .......................................................................................................................................................................................................41
Settings menu................................................................................................................................................................................................................... 42
− Setup menu - settings........................................................................................................................................................................................ 42
− Channel install (manual and auto tuning).................................................................................................................................................. 43
− Organiser (editing channels) - settings - setup......................................................................................................................................... 44
− Lock menu - settings .......................................................................................................................................................................................... 46

6 Using the Features.....................................................................................................................................................................54
Guide .................................................................................................................................................................................................................................... 54
− Viewing the guide ............................................................................................................................................................................................... 54
− Using the guide .................................................................................................................................................................................................... 54
− Setting a recording or reminder from the Guide..................................................................................................................................... 55
− Editing a recording/reminder in the schedule list................................................................................................................................... 57
− Deleting a recording/reminder ...................................................................................................................................................................... 57
Digital Teletext.................................................................................................................................................................................................................. 58
− Teletext within Digital Service........................................................................................................................................................................ 58
7 Entertainment ............................................................................................................................................................................59
Connecting a USB Storage Device............................................................................................................................................................................. 59
Media centre...................................................................................................................................................................................................................... 59
− Viewing photos .................................................................................................................................................................................................... 60
− Copying pictures to other folders/USB drives ...........................................................................................................................................61
− Deleting pictures ..................................................................................................................................................................................................61
− To show all supported les ...............................................................................................................................................................................61
− Listening to music ............................................................................................................................................................................................... 62
− Playback controls (music) ................................................................................................................................................................................. 62
− Watching movies ................................................................................................................................................................................................. 64
− Playback controls (movie)................................................................................................................................................................................. 64
3D TV .................................................................................................................................................................................................................................... 66
− Pairing your 3D glasses to your TV................................................................................................................................................................ 66
− Using the 3D glasses........................................................................................................................................................................................... 66
− Viewing range when watching 3D ............................................................................................................................................................... 67
− Playing a 3D movie.............................................................................................................................................................................................. 67
− Changing 2D TV into 3D.................................................................................................................................................................................... 67
− Gaming in split screen mode .......................................................................................................................................................................... 68
8 PVR (Personal Video Recorder).................................................................................................................................................69
Time Shift Function......................................................................................................................................................................................................... 69
Recording TV Programmes onto a USB Storage Device.................................................................................................................................... 70
Setting a timer recording.............................................................................................................................................................................................. 71
Playing Recorded Programmes ................................................................................................................................................................................. 71
9 Using the Smart TV ....................................................................................................................................................................72
Smart TV overview .......................................................................................................................................................................................................... 72
− Setting your country .......................................................................................................................................................................................... 73
− Searching for apps .............................................................................................................................................................................................. 73
− Adding apps to your favourites...................................................................................................................................................................... 73
− Changing the order of your favourite apps ............................................................................................................................................... 73
− Browsing apps in categories ...........................................................................................................................................................................74
− Browsing the internet (brows'n) .....................................................................................................................................................................74
− Searching app contents ....................................................................................................................................................................................74
Pre-installed apps............................................................................................................................................................................................................ 75
− Skype ....................................................................................................................................................................................................................... 75
10 Other Information......................................................................................................................................................................76
Maintenance.......................................................................................................................................................................................................................76
Hints and Tips.................................................................................................................................................................................................................... 77
Help....................................................................................................................................................................................................................................... 79
Specications .................................................................................................................................................................................................................... 80

4
GB
1 Safety Warnings
Chapter
1
CAUTION
• To prevent the risk of electronic shock,do not remove cover
(or back).No user-serviceable parts inside. Refer servicing to
qualified service personnel.
WARNING
• This equipment is not waterproof. To prevent a fire or shock
hazard, do not place any container filled with liquid near
this equipment(such as a vase or flower pot) or expose it to
dripping , splashing rain or moisture.
• Read all the instructions carefully before using the unit and
keep them for future reference.
• Retain the manual. If you pass the unit onto a third party
make sure to include this manual.
• Check that the voltage marked on the rating label matches
your mains voltage.
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any doubt
about it working normally, or if it is damaged in any way -
switch off, withdraw the mains plug and consult your dealer.
Location of Unit
• The unit must be placed on a flat stable surface and should
not be subjected to vibrations.
• Do not place the unit on sloped or unstable surfaces as the
unit may fall off or tip over.
• The mains socket must be located near the unit and should be
easily accessible.
• This unit is designed for indoor, domestic use only.
Temperature
• Avoid extreme degrees of temperature, either hot or cold.
Place the unit well away from heat sources such as radiators or
gas / electric fires.
• Avoid exposure to direct sunlight and other sources of heat.
Naked Flames
• Never place any type of candle or naked flame on the top of
or near the unit.
Moisture
• To reduce the risk of fire, electric shock or product damage, do
not expose this unit to rain, moisture, dripping or splashing.
No objects filled with liquids, such as vases, should be placed
on the unit.
• If you spill any liquid into the unit, it can cause serious
damage. Switch it off at the mains immediately. Withdraw the
mains plug and consult your dealer.
Ventilation
• WARNING - To prevent a fire hazard,do not place any naked
flame sources(such as a lighted candle) on the equipment.
• WARNING - Slots and openings in the cabinet are provided
for ventilation to ensure reliable operation of the product ,
and to protect it from overheating. To prevent fire hazard,
the openings should never be blocked or covered with items
(such as newspapers,table cloths,curtains) or by operating the
equipment on thick carpet or a bed.
• Do not install or place this unit in a bookcase, built-in
cabinet or in another confined space. Ensure the unit is well
ventilated.
Safety
• Always disconnect the unit from the mains supply before
connecting / disconnecting other devices or moving the unit.
• Unplug the unit from the mains socket during a lightning
storm.
Mains Cable
• Make sure the unit or unit stand is not resting on top of the
mains cable, as the weight of the unit may damage the mains
cable and create a safety hazard.
• If the mains cable is damaged it must be replaced by the
manufacturer, its service agent, or similarly qualified persons
in order to avoid a hazard.
Interference
• Do not place the unit on or near appliances which may cause
electromagnetic interference. If you do, it may adversely affect
the operating performance of the unit, and cause a distorted
picture or sound.
Optimum Viewing
• View the unit in moderate light to prevent eye strain. It is
recommended to watch the unit from a distance
3-7 times that of the screen height.
LCD Screen
• The LCD screen is manufactured using high-precision
technology. However, some tiny black points and / or
bright points (red, blue or green in colour) may constantly
appear on the LCD screen. These points are generated in the
manufacturing process and are normal.
Screen Burn
• A characteristic of Plasma and TV Panels is that displaying the
same image for a long time may cause a permanent after-
image to remain on the screen. This is called screen burn.
Most pictures shown on the unit will be constantly moving
and fill the screen.
• Examples of images that you need to watch out for are as
follows (this is not an all-inclusive list):
1. Black Bars: If black bars appear at the left / right or top /
bottom of the screen, it is recommended to change the
format so that the picture fills the entire screen.
2. TV Channel Logos: e.g. Shopping channel logos and
pricing displays - especially if they are bright and
stationary. Moving or low-contrast graphics are less likely
to cause ageing of the screen.
3. Time Displays
4. Teletext: Do not view a stationary page for long periods
of time.
5. TV Menus
6. Pause Mode: Do not leave the screen in pause mode for
long periods of time, e.g. when watching videos.
• To prevent screen burn if viewing any of the above for long
periods of time, reduce contrast and brightness when viewing.
Once burn-in occurs it will never disappear completely.
• CAUTION - When installing this unit,make sure to leave space
around the unit for ventilation to improve heat radiation
(at least 20 cm at top, 10 cm at rear, and 10 cm at each side).
10 cm 10 cm
20 cm
10 cm

1
Safety Warnings
5
GB
Earphones
• Listening to loud sounds for prolonged periods of time may
permanently damage your hearing.
• Before putting on earphones, turn the volume down then put
the earphones on and slowly increase the volume until you
reach a comfortable listening level.
Standby
• The button on the remote control does not switch off the
unit completely. The unit will continue to draw electricity from
the mains supply while in standby. In the interests of safety
and to avoid unnecessary energy consumption, never leave
the unit in standby while unattended for long periods of time,
e.g. overnight, while on holiday or while out of the house.
Disconnect the mains plug from the mains socket.
Batteries
• Batteries used in the remote control for this unit are easily
swallowed by young children and this is dangerous.
• Keep loose batteries away from young children and make sure
that the battery holder tray is secure in the remote control.
Seek medical advice if you believe a cell has been swallowed.
• Please dispose of batteries correctly by following the
guidance in this manual.
• The batteries shall not be exposed to excessive heat such as
sunshine, fire or the like.
Supervision
• Children should be supervised to ensure that they do not play
with the unit and the remote control.
• Never let anyone especially children push anything into the
holes, slots or any other openings in the case - this could
result in a fatal electric shock
Wireless Networks
• The wireless LAN hardware in your product conforms to the
requirements and provisions set out in European Directive
1999/5/EC (R&TTE ).
• The wireless LAN product is a radio device that uses the 2.4
GHz frequency (2.4 GHz to 2.4835 GHz). In accordance with
the R&TTE Directive 1999/5/EC, this product complies with the
EN 55022 standard Class B digital use in residential, business
and light industrial areas.
• You may also be prevented from using WLAN products by
property owners – in a hospital, for example – where there is
a risk that the product may cause harm. If you are unsure about
any restrictions regarding the use of your product in a building
please seek permission before you turn it on.
• If you use medical devices such as pacemakers, hearing aids,
etc. please check with the manufacturer before using your
WLAN product.
3D Glasses
• Do not use the 3D glasses for purposes other than specified, i.e.
sunglasses it may damage your vision.
• Do not place the 3D glasses in a location exposed to direct sunlight,
fire, heat or water. This may cause the 3D glasses to malfunction.
• When cleaning the 3D glasses, gently wipe with a dry and soft
cloth, Make sure that you remove any dust or dirt from the
cloth first. Spraying chemicals onto the 3D glasses may result in
malfunction or damage to the surface of the 3D glasses.
• Do not apply excessive force to the 3D glasses, do not drop or
bend the 3D glasses, this may result in malfunction.
• Ensure you are within the working distance of the TV when
using your 3D glasses, remove any objects located in front of the
transmitter to avoid the signal being hindered.
• The 3D glasses may not work properly due to the interference from
magnetic fluorescent light (50Hz/60Hz).
• Do not wear the 3D glasses if they are broken or damaged.
• Disassembly or modification of the 3D glasses must be done by a
qualified and authorized technician only.
• Do not walk or move around when wearing the 3D glasses.
• Never scratch, strike and impact the 3D glasses, do not scratch the
lens with various grinding objects.
• It is recommended to have a rest every 2-3hours while watching
3D TV.
• Watching TV while sitting too close to the screen for an extended
period of time may cause eye strain, if you experience eye strain,
stop watching and have a rest.
• Pregnant woman and people who have heart problems should
not wear the 3D glasses to watch 3D images.
• Watching 3D images for an extended period of time may cause
headache or eye strain. For this reason Adults should frequently
check on children who are viewing 3D programmes. If you feel
any discomfort, stop viewing 3D TV and rest for a while. Contact a
medical professional.
• Anyone who has had a seizure, loss of awareness, or other
symptom linked to an epileptic condition, or has a family history
of epilepsy, should contact a health centre provider before using
the 3D function.
• We hereby declare that the electrical product is in compliance
with the essential requirements of Low Voltage Directive:
2006/95/EC, EMC Directive: 2004/108/EC,
RoHS Directive: 2011/65/EU, R&TTE Directive: 1995/5/EC.
•
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the unit’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
manual accompanying the unit.
Service
• To reduce the risk of electric shock, do not remove screws. The
unit does not contain any user-serviceable parts. Please leave
all maintenance work to qualified personnel.
• Do not open any fixed covers as this may expose dangerous
voltages.
Maintenance
• Ensure to unplug the unit from the mains socket before
cleaning.
• Do not use any type of abrasive pad or abrasive cleaning
solutions as these may damage the unit’s surface.
• Do not use liquids to clean the unit.
• The wall socket plug is used as a disconnect device, the
disconnect device should be readily accessible.
• This equipment is a Class II or double insulated electrical
appliance. It has been designed in such a way that it
does not require a safety connection to electrical earth.
To prevent the spread of fire, keep
candles or other open flames away
from this product at all times.

6
GB
Unpacking the TV
Remove all packaging from the TV. Retain the packaging. If you dispose of it, please do so according to local regulations.
The following items are included:
Thank you for purchasing your new Pioneer Smart 3D TV.
Your new TV has many features and incorporates the latest technology to enhance your viewing
experience. We recommend that you spend some time reading this instruction manual so that you fully
understand these features. You will also find some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future reference.
1x YPbPr adapter cable
1x Audio in adapter cable
1x Scart adapter cable
3 x TV stand screws
1 x TV stand
(Model L46S3D13N and L55S3D13N)
1 x TV stand
(Model L40S3D13N)
1 x Metal bracket
(Model L40S3D13N)
2 x 3D glasses
1 x power cable
1 x cable tidy strap
2 x AAA batteries
1 x Remote control
2 Preparation
Chapter
2

2
Preparation
7
GB
1. Disconnect all cables connected to the TV.
2. Lay the TV down on a flat surface preferably a table with the back side facing up. Make sure the neck of the TV stand over
hangs the edge of the table. Please make sure a soft cushioned material (such as a pillow or thick piece of foam) is placed
beneath the screen.
Installing the TV Stand (L46S3D13N and L55S3D13N)
The LCD display is very fragile, and must be protected at all times when installing and removing the TV stand. Be sure that
no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert
pressure on the front of the TV at any time because the screen could crack.
3. Carefully place the glass stand onto the neck of the stand. Then fix into position using the 3 screws provided as shown.
4. The stand for models L46S3D13 and L55S3D13 have a
swivel base to make angling the TV easier.

2
8
Preparation
GB Installing the TV Stand (L40S3D13N)
Mounting the TV to a wall (L40S3D13N)
1. Disconnect all cables connected to the TV.
2. Lay the TV down on a flat surface preferably a table with the back side facing up. Make sure the neck of the TV stand over
hangs the edge of the table. Please make sure a soft cushioned material (such as a pillow or thick piece of foam) is placed
beneath the screen.
The LCD display is very fragile, and must be protected at all times when installing and removing the TV stand. Be sure that
no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert
pressure on the front of the TV at any time because the screen could crack.
3. Carefully place the glass stand onto the neck of the stand. Hold the metal bracket over the holds and fix into position using
the 3 screws provided as shown.
Remove the stand assembly before mounting the TV onto the wall.
1. Remove the neck cover by untightening the screw holding the cover
to the neck.
2. Remove the neck and stand by untightening the 4 screws holding
the neck to the TV.
200mm
200mm
3. This TV is designed to be wall-mounted with a standard 200 mm
x 200 mm mounting kit (sold separately) designed for flat-panel
TVs. Mount this TV according to the instructions included in the
mounting kit. Due to space restrictions, we recommend that you
make all connections before mounting on to the wall.

2
Preparation
9
GB
Mounting the TV to a wall (L46S3D13N & L55S3D13N)
Remove the stand assembly before mounting the TV onto the wall.
Keep all the spare screws should you want to use the stand
assembly option.
1. Remove the neck cover by untightening the screw holding the cover
to the neck.
400mm
400mm
2. Remove the neck and stand by untightening the 4 screws holding
the neck to the TV.
3. This TV is designed to be wall-mounted with a standard 400 mm
x 400 mm mounting kit (sold separately) designed for flat-panel
TVs. Mount this TV according to the instructions included in the
mounting kit. Due to space restrictions, we recommend that you
make all connections before mounting on to the wall.
Attaching the cable tidy
• The cable tidy attaches to the back of
your TV under the sockets.
• Attach by pressing the cable tide into
the small square and circle as shown.
• Fold the cable tidy back on itself to
keep your cables neat and tidy. Its
fully adjustable depending how many
cables you want to attach to your TV.

2
10
Preparation
GB Front / Right Side View and Controls
Item Description
1POWER LED
Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby
mode. The LED will flash when the timer programming has started in standby mode.
The LED also flashes when remote control operated.
2IR (Infrared Receiver) Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3 PR +/- Press to scroll up and down the channels.
Press to select and adjust a setting in the OSD menu.
4 VOL + / – Adjusts the volume.
Press to select and adjust a setting in the OSD menu.
5 / MENU Press to select the menu.
6 OK Press to confirm a command in the menus.
7Switches the TV on from standby mode.
Switches the TV back to standby mode.
1 2
3
6
4
5
7
Always disconnect the TV from the mains socket when not in use for a long period of time.
The button on the right side panel of the TV or on the remote control is only used for switching the TV into standby, it
does not disconnect the TV from the mains power. To completely disconnect the mains power, please remove the mains
plug from the mains socket.

2
Preparation
11
GB
Rear View and Sockets (L40S3D13N)
Item Description
1 HEADPHONE Connects to the headphones.
2 LAN Connects to an Ethernet cable for connecting your TV to the internet. This is the wired
option. Your TV is also Wireless.
3 HDMI1 / HDMI2 / HDMI3 Connects to a High-Definition (HD) signal output device, such as a set-top box, blu-ray
disc player or AV receiver.
4 SCART Adapter Connect to Standard-Definition (SD) devices such as DVD players compatible with RGB,
composite or s-video.
5 VGA Connects to a computer or other devices with a VGA interface.
6 ANTENNA/CABLE INPUT Connects to the aerial socket on the wall with the RF coaxial cable.
7 USB 1 / USB 2 Allows the insertion of a USB storage device to play video, audio, photo and text files
(USB mode) and record TV programmes on to a USB storage device.
8 COMMON INTERFACE Allows the insertion of a Common Access Module.
9 SPDIF Digital optical audio output for connection to home theatre kit / audio unit.
10 AUDIO IN & YPbPr Connects to a DVD player, Digital Set-Top-Box, or other AV devices with component
(YPbPr) video and audio output sockets via the included component adapter cable.
1 2 3 3 4 5 6
7
8
3
9
10
7
COMMON
INTERFACE
USB 2
USB 1
YPbPr
LAN VGA
SCART
ADAPTER
/
HDMI 2HDMI 3 (ARC)
Models L46S3D13N and L55S3D13N have 3 USB sockets. The third USB socket can be
found above USB 2 in the diagram above.

2
12
Preparation
GB Installing Batteries in the Remote Control
1. Slide the battery cover to open the battery
compartment of the remote control.
2. Insert two AAA size batteries. Make sure the (+)
and ( - ) ends of the batteries match the (+) and
( - ) ends indicated in the battery compartment.
3. Slide the battery cover back onto the remote
control to close the battery compartment.
Handling the Batteries
• Improper or incorrect use of batteries may cause
corrosion or battery leakage, which could cause fire,
personal injury or damage to property.
• Only use the battery type indicated in this manual.
• When the batteries are exhausted, the remote will
not function. Replace both batteries at the same time
with new ones.
• Do not install new batteries with used ones and do
not mix different types of batteries.
• Do not dispose of used batteries as domestic waste.
Dispose of them in accordance with local regulations.
Handling the Remote Control
• Take care of your fingernails when you press and hold
the battery release tab.
• Do not drop or cause impact to the remote control.
• Do not spill water or any liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight
or near sources of excessive heat.
• Remove the battery from the remote control when
not in use for a long period of time, as it could
cause corrosion or battery leakage and may result
in physical injury and/or property damage including
fire.
Remote Control Operation Range
Point the remote control at the TV no more than 5 metres from the
remote control sensor on the TV and within 60° in front of the TV.
The operating distance may vary depending on the brightness of the
room.
30° 30°
5M

2
Preparation
13
GB
Assembling the 3D Glasses and Installing the Battery
1. Gently push each arm into the main
body of the glasses as shown below.
Inserting the battery
2. Slide the battery compartment up.
3. Open the battery compartment.
4. Insert the supplied battery (CR2025) making sure
that the ‘+’ symbol is facing down.
5. Close the battery compartment.
6. Slide the battery compartment closed.

2
14
Preparation
GB
1.
Switch the TV between on and standby mode.
2. 3D
Switches the TV into 3D mode.
3. TV
Switches the TV back to TV mode from other viewing modes.
4. 0-9 Number Button
• Press to select a programme.
• Letters can be used to enter channel names only.
5. ECO
Switches ECO modes: OFF - LOW - HIGH
6. SOURCE
• Switches the source: TV - SCART - YPbPr - VGA - HDMI1 -
HDMI2 - HDMI3.
7. MUTE
Switches the sound on and o.
8. V + / –
Adjust the volume.
9. P + / –
• Select a channel.
• Scroll up and down web pages.
10. INFO
• Display programme information.
11. SMART TV
Select Smart TV.
12. OPTION
Selects the Quick Access menu where you can adjust:
Picture preset - Sound preset - Picture preset - T-Link -
Timeshift - PVR - Schedule list.
13. GUIDE
Displays the EPG Electronic Programme Guide.
14. MENU
• Select the main menu.
• Selects a keyboard in some apps and webpages.
15.
• Select menu items.
• Scroll around webpages
16. OK
Select items
17. BACK
Go back through menus or webpages.
18. EXIT
Exit from meuns or Smart mode.
19. Zoom -/+
Adjust the aspect ratio of the picture: 16:9 format - 16:9 zoom up
- 16:9 zoom - 14:9 zoom - cinerama - 4:3 format.
20. HOME
Return to Smart TV main screen.
Remote Control
1
2
3
9
6
13
20
10
16
4
5
8
12
14
15
17
18
19
7
11

2
Preparation
15
GB
23
28
24
21
26
22
27
25
29
21. SLEEP
Set sleep mode: OFF - 10 - 20 - 30 - 40 - 50 - 60 - 90 120
mins
22. PRE-CH
Selects the previous channel
23. LIST
Displays the last channel list that was viewed.
24. FAV
Displays the 'Channel list selection' menu where you can
access: All - Digital - Radio - Free - Favorite list.
25. COLOURED BUTTONS
• Access teletext items.
• Selecting menu items.
26. LANG
Select your audio language.
27. SUBTITLE
Switch subtitles on or o.
28. TEXT
Switch teletext on or o if available.
29. MEDIA MODE BUTTONS
• - Select the previous / next photo, music or video.
• - Stops playback.
• - Play or pause and starts Timeshift recording.
• - Fast reverse / forward.
• - Record.

16
GB
3 Connections
Chapter
3
Connecting the aerial
The following diagram shows you how to connect your aerial to your TV. Follow this connection method if you receive your
television signal via an aerial or if you want to connect your cable box via an RF cable.
Connecting a cable box via HDMI
If you receive your TV via a digital cable box it may not have an RF socket so you will need to connect it using a HDMI cable. If you
connect your TV this way you will not need to tune it in. All you will need to do is select the HDMI socket in the source menu.
Do not connect the TV to the mains supply until you have made all the connections.

3
Connections
17
GB
Connecting an ethernet cable
Your TV is a Smart TV so must be connected to the internet for Smart to function. The faster your internet connection the better
your Smart TV will work. Your TV can connect to the internet via a wireless connection or wired via an ethernet cable. To obtain
the fastest internet connection speed we recommend that you connect an ethernet cable if possible. If you can't connect an
ethernet cable try to position your wireless router as close as you can to your TV to obtain the best connection speed.
Connecting the power cable
Once you have made all the connections connect the power cable to the back of your TV as shown an the other end to the mains
socket.
AC IN ~
If you have decided to connect to the internet via a wireless connection try to keep yo ur router as close to your TV as possible.
Best connection
speed
Wireless Router Wireless Router
Wireless Connection

18
GB
4 Initial Setup
Chapter
4
Connecting to the internet and tuning in your TV
Once you have made all the connections you will need to setup your TV. The Initial setup will get you connected to the internet
and tune in all your TV channels. You don't have to set up the internet at this stage if you don't want to, you can skip that section.
1. Press the STANDBY button to switch your TV on. The red
standby LED will change to blue and your TV will show the
Initial setup menu.
2. Press the buttons to select your desired language. Then
press the button to go to the next screen.
3. Press the buttons to select your desired country. Then
press the button to go to the next screen.
You will now be asked how you would like to connect to the
internet, if you don't want to connect to the internet at the
moment you can skip this section and do it later.
If you do want to connect to the internet we recommend you
choose the Wired option for the best results.
5. Press the buttons to select Wired or Wireless. Then
press the button to go to the next screen.
• If you choose WIRED select AUTO.
4. Press the buttons to select HOME. Then press the
button to go to the next screen.
Shop mode is for the retailer to use. Do NOT select shop
mode.

4
Initial Setup
19
GB
This menu will appear if you chose the wireless option.
We recommend you select Scan, this option will scan and find all
available wireless networks and list them for you.
6. Press the buttons to select scan. Then press the
button to go to the next screen.
7. All the wireless networks will be listed, press the
buttons to select your network (it will probably be the top
one in the list). Then press the button to go to the next
screen.
You will now have to enter your routers password. The password
is case sensitive so you may need to check this.
8. Press the buttons to select each letter then press
the OK button to confirm the letter.
9. Once the password is entered scroll down to the OK button
and press OK.
You will now see the following messages, when you see the
'Connection Successful' message press the button.
Depending how you receive your TV choose Antenna or Cable.
• If you have an aerial the select Antenna.
• If you have cable that connects via the aerial lead then select
Cable.
• If you have a digital cable box that connects via a HDMI
cable, skip this section you do not need to tune in your TV.
You just need to select the HDMI source.

4
20
Initial Setup
GB Tuning via Antenna
10. Press the buttons to select Antenna. Then press the
button to go to the next screen.
11. Press the buttons to select Digital & Analogue
(Recommended), Digital or Analogue. Then press the
button to go to the next screen.
12. Press the buttons to select Scan. Then press the
button to go to the next screen.
Your TV will now start to tune in all available TV channels. Please
be patient this will take a few minutes.
When all of the TV channels have been tuned in the
'Congratulations' screen will appear.
13. Press the OK button to exit the menu and start watching TV.
