Power Max PM4-15 Installation and operating instructions

AC to DC Converter/Charger
AC to DC
CONVERTER/CHARGER
PM4 models 15, 35, 45, 55, 60, 65, 75, 100
and 120 Amp with Built-in 4 Stage Smart
Charging and Fixed Output Modes
Installation & Maintenance
Instructions
1. DISCONNECT DC POWER. Disconnect the battery POS (+) wire at the battery end before connecting this Converter/Charger to any
vehicle/device wiring.
2. LOCATION. The mounting location may be on any interior (out of direct weather) surface. Location chosen must be accessible after
installation. When mounted inside a cabinet, the cabinet must be large enough to allow dissipation of heated air. Make sure that there is a
minimum of 1” (one inch) free air space at each end of the unit so that cooling air can move through the unit properly. AVOID foreign
contaminants such as dirt, metal particles or moisture.
3.
MOUNTING. Flanges with holes are provided for ease of mounting using standard fasteners. Confirm that the surface that the converter is
mounted to is solid and will hold the weight (6 lbs) during vehicle operation.
4.
ELECTRICAL REQUIREMENTS. A 120 VAC receptacle needs to be located within 36 inches of the Converter/Charger to supply power.
Electrical consideration should also be given to mounting near the locations of the batteries and the
12-volt DC distribution panel.
5.
ELECTRICAL CONNECTIONS . Be sure to tighten all connections securely. A loose connection can quickly cause terminals and wires to
overheat. Review unit labels for recommended terminal torque values.
6. THE FAN WILL NOT RUN ALL THE TIME. THE FAN IS TEMPETUR CONTROLD AND WILL ONLY RUN WHEN NEEDED
Never Leave the PowerMax PM4-XX unattended when plugged in.
7. All PM4 Products must be installed by a certified electrician.
120 VAC Connection – First confirm that the 120 VAC power source AC circuit breaker(s) are in the
breakers until installation is complete.
position. DO NOT turn-on AC circuit
Using an 8 AWG minimum size copper wire, attach from the vehicle/device chassis to the Converter/Charger Bonding Lug.
Using the attached power cord on the Converter/Charger, connect firmly to the
120 VAC receptacle
12 VDC Wiring– It is important to use the correct wire gauge. Use a minimum of 8 AWG size copper wire.
The terminal marked
The terminal marked
or POS is for the RV 12 VDC positive connection.
or
NEG is for the RV 12 VDC negative connection.
The 12 VDC output wiring does not require over-current protection because the Converter/ Charger limits current output. However, all
electrical connections need to comply with the appropriate NEC code.
FOR YOUR SAFETY, READ ALL INSTRUCTIONS BEFORE INSTALLATION AND OPERATION.
INSTALLER: Provide these instructions to the end user or consumer.
CONSUMER: Keep these instructions for future reference.
NOTICE: Products are not to be used nor are warranted in aerospace, medical or life safety applications.
SAFETY ALERT
120 VAC is present. This Converter/Charger is designed to convert 120 VAC to 12 VDC . It also provides low voltage
power for charging on-board
12 VDC batteries. The Converter/Charger is a “switch mode” type and is designed to be
maintenance-free with no user serviceable components. The Converter/Charger power output is “current limiting” by
design.
WARNING – Avoid Possible Injury or Death
NEVER store electrical devices in compartments where flammable liquids (such as gasoline) exist.
DO NOT mount/install unit in compartments designed for storage of batteries of flammable liquids.
WARNING – Avoid Personal Injury or Product Damage
WARNING – Avoid Possible Injury or Death
off
–
+

POS
8. 4 STAGE CHARGING MODE:
This is the Factory Settings with the Smart Charging mode 'ON' with the Output Voltages preset to 14.6V / 13.6V and 13.2V.
DESCRIPTION
: This mode provides an automatic charging system in three steps. 1. A fast charge to bring a good, drained battery
back up to full voltage rapidly ("Boost"). 2. A standard charge to bring the battery up to a full charge at a safe rate to prolong the life of the
battery and provide power to run 12V lighting and appliances in the vehicle/device ("Normal"). 3. A trickle charge to keep the battery fresh
during times of load inactivity ("Storage"). The charger automatically changes modes to accommodate changes in conditions. The chart
below is for reference only, voltages may vary.
9. FIXED VOLTAGE Mode:
DESCRIPTION: This mode can be used to directly power 12 Volt equipment and or maintain the battery at that voltage.
To set in fixed mode, with the unit off, move switch A, right to "Fixed Voltage" then plug the unit into 110V power. Turn switch B gently up or
down to adjust the voltage between 13~16.5V until reaching your required output. NOTE: The output voltage you set is now fixed constantly at this
level every time the unit is powered ON. To return the unit to its Factory Settings, power down the unit then move switch A, left to "Four
Stage". Power up the unit and with a voltage meter attached to the output terminals, use switch B to gently turn the voltage up or down until you
reach 14.6V. The unit is now back to the standard “ 4 Stage Charging” Factory Setting
10. TEST. First, disconnect all loads and battery on the Converter/Charger by removing all 12 VDC connections from + or POS . Second,
attach a multimeter instrument between the positive and negative terminals of the Converter/Charger. Then energize the 120 VAC converter
circuit. Test for proper output power using the multimeter. Measure the output voltage from the positive and negative terminals. The voltage
should read
14.6 +/- 0.2 VDC . Add 12 VDC load connections to about 2/3 of the rated capacity of the converter. Recheck the voltage, which
should remain approximately the same as at no load.
NOTE : If the chargers output voltage is set below the battery voltage the charge will
not charge plus the LED will not come on.
11. BATTERY. With the 120 VAC disconnected, reconnect the + or positive terminal to a known good battery. With the converter 120
VAC energized, measure the voltage at the converter and at the battery. The voltage should be about the same in both locations. As with any
battery it is important that the fluid level be checked on a regular basis. When continuously connected to any charging source all batteries will
“Gas” and lose some fluid.
12. HI-POT TESTING. (Vehicle/device Manufacturing Facilities Only) DO NOT Hi-Pot DC wiring with the Converter/Charger connected to the
vehicle/device wiring in order to prevent serious injury and/or damage.
WARNING – Avoid Personal Injury / Product Damage
switch A
switch B

‘Reversed-Battery’ Fuses
LED
Chassis Bonding Lug
12VDC Output Terminals
AIR FLOW FAN
(on back-side)
.
.
.
.
Blows air
out of front
grill vents.
TROUBLESHOOTING
NOTE : Before removing and replacing the Converter/charger, perform the following checks:
a. Disconnect the AC power from the vehicle/device.
b.
Disconnect the wiring and Battery from the Converter Positive
c.
Re-connect the AC power to energize the Converter.
output terminal.
d.
Using a voltmeter, measure the voltage at the Converter and Output terminals.
> The Converter is OK if the voltage reading is between 13 VDC and 14 VDC (typically 13.6 VDC).
> Otherwise check the table below:
CONDITION POSSIBLE CAUSE
.
120 VAC not connected to coach or the coach AC circuit breaker is in the off position.
No 12 VDC output
.
.
.
Reversed battery fuses blown. (Battery wiring connections are reversed),
Severe overload or shorted load. Remove all loads and retest per above instructions.
Converter/Charger internal failure.
Converter cycles On & Off .
.
Fan air flow is inadequate or blocked. (1” minimum free air space at each end required)
Converter/Charger internal failure.
Reversed Battery fuses blown
.
.
Battery wiring connections are reversed. Defective
battery, possible bad cells.
12 VDC output is too low
.
.
Attached load exceeds rating of the Converter/Charger.
Defective battery, possible bad cells.
.
Converter/Charger internal failure.
LED light is not on
.
The output voltage of the charger has dropped below the battery voltage. If charging a battery the unit is
best to be in its factory starting at 14.6V, unless the Battery Manufacturer recommends otherwise.
- Charger internal failure
+
–
+
