PowerG PG14CD-1 Maintenance and service guide

14.4V Cordless Drill
PG14CD-1
Manufacturer: SUMEC Hardware & Tools Co., Ltd
1# Xinghuo Road, National level Nanjing High-Tech Zone,
Nanjing 210061 P.R. China

9
10
1
10
9

2
TECHNICAL DATA
Cordless Drill PG14CD-1
Rated voltage DC 14.4V
No-load speed 650 rpm
Steel 8 mm
capacity Wood 10 mm
Battery Ni-Cd
Battery capacity 1000 mAh
Battery charging time 3-5hours
Battery charger
Input voltage 230-240 V 50 Hz
Output voltage DC 18V 400mA
Sound pressure level (LpA) 75dB(A) KpA=3dB(A)
Power sound level (LwA) 86dB(A) KwA=3dB(A)
Vibration < 2.5m/s2

DESCRIPTION OF SYMBOLS
Please read all of the safety and operating instructions carefully
before using this tool. Please pay particular attention to all sections of
this User Guide that carry warning symbols and notices.
Observe caution and safety notes!
n0No-load speed.
V~ Voltage
mA
A/Ah Milliamps/Amps/Amp-hours
- - - DC (current and voltage type)
Drill setting (torque Preselect )
Protect electrical power tool from moisture!
Check that the device, mains lead and plug are in good condition!
Safety classĊ
Dispose packaging and appliance in an environmentally -friendly way!
3

GENERAL SAFETY INSTRUCTIONS
WARNING!
Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The “power tool” in this instruction refers to your battery-operated (cordless) power
tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) The charger’s plug must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Use battery operated tool only with specifically designated battery pack.
Use of any other batteries may create a risk of fire.
c) Do not expose power tools to rain or wet conditions. Water entering a
powertoolwillincreasetheriskofelectricshock.
4
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges
and moving parts. Damaged or entangled cords increase the risk of electric
shock.

5
e) A battery operated tool with integral batteries or a separate battery pack
must be recharged only with the specified charger for the battery. A
charger that may be suitable for one type of battery may create a risk of fire
when used with another battery.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewelry or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4) tool use and care

6
a) Do not force the power tool. Use the power tool correctly for your
application. The correct use will do the job better and safer at the rate for which
it was designed.
b) Do not use the power tool if the on/off switch is not working correctly . Any
power tool that cannot be controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source and/or the battery pack from
the power tool before making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures reduce the risk of
staring the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from those
intended could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A charger
that is suitable for one type of battery pack may create a risk of fire when used
with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of
any other battery packs may create a risk of injury and fire.

7
c) When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects, Which
can make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected from the battery may
cause irritation or burns.
6) Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
ADDITIONAL SAFETY WARNINGS
1) Specific safety rules
Do not let comfort or familiarity impair your judgment always adherence
to cordless drill safety rules. If you use this power tool unsafely or
incorrectly, you can suffer serious personal injury.
a) Hold tool by insulated gripping surfaces when performing an operation
where the cutting tool may contact hidden wiring. Contact with a “live” wire
will make exposed metal parts of the tool “live” and shock the operator.
b) Be aware that this tool is always in an operating condition, because it
does not have to be plugged into an electrical outlet.
c) Always be sure you have a firm footing.
d) Be sure no one is below when using the tool in high locations.
e) Hold the tool firmly .
f) Keep hands away from rotating parts.

8
g) Do not leave the tool running. Operate the tool only when hand-held.
h) Do not touch the bit or the work piece immediately after operation; they
may be extremely hot and could burn your skin.
i) Some material contains chemicals which may be toxic. Take caution to
prevent dust inhalation and skin contact. Follow material supplier safety
data.
2) Important safety instructions for charger
a) Before using the charger, read all the instructions and cautionary markings on
the charger and battery pack as well as the instructions on using the battery
pack.
b) Only charge your batteries indoors as the charger is designed for indoor use
only.
c) DANGER. If the battery pack is cracked or damaged in any other way, do not
insert it in the charger. There is a danger of electric shock or electrocution.
d) WARNING. Do not allow any liquid to come into contact with the charger. There
is a danger of electric shock.
e) To allow the battery pack to cool down after charging, do not place it in a hot
environment such as a metal shed or open trailer left in the sun.
f) The charger is not intended for any use other than charging the exact type of
rechargeable battery pack as supplied with the charger. Any other use may
result in the risk of fire, electric shock or electrocution.
g) The charger and battery pack supplied with it are specifically designed to work
together. Do not attempt to charge the battery pack with any other charger than
the one supplied.
h) Do not place any object on top of the charger as it could cause overheating. Do
not place the charger near any heat source.
i) Do not pull on the plug of the charger to disconnect it from the power source.
j) Make sure that the charger cable is positioned where it will not be stepped on,
tripped over or otherwise subjected to damage or stress.

9
k) Do not use an extension cord unless it is absolutely necessary. The use of an
improper extension cord could cause the risk of fire, electric shock or
electrocution.
l) Do not use the charger if it has been subjected to a heavy knock, dropped or
otherwise damaged in any way. Take the charger to an authorized service
centre for a check or repair.
m) Do not disassemble the charger. Take it to an authorized service centre when
service or repair is required. Incorrect re-assembly may result in the risk of fire,
electric shock or electrocution.
n) To reduce the risk of an electric shock, unplug the charger from the power
supply before attempting to clean it. Removing the battery alone does not
reduce the risk.
o) Do not store or use the tool and battery pack in locations where the temperature
may reach or exceed 400C (1040C) such as alongside sheds or metal structures
in the summer.
p) The charger is designed for use from a standard household electrical supply
(230V-240V). Do not attempt to connect the charger to a different supply.
q) If you wish to charge a second battery pack, unplug the charger from the mains
supply and leave it for at least 15 minutes. After this time you can charge a
second battery pack.
3) Important safety instructions for battery pack
a) The battery pack for this tool has been shipped in a low charge condition. You
should charge the battery pack fully before use.
b) To ensure the longest battery life and best battery performance, always charge
the battery when the air temperature is between 18-240C (65-750F). Do not
charge the battery pack when the temperature is below40C(400F),or above 400C
(1040F).this is important. Failure to observe this safety rule could cause serious
damage to the battery pack.
c) Do not incinerate the battery pack even if it is seriously damaged or can no

10
longer hold a charge. The battery pack can explode in a fire.
d) A small leakage of liquid from the battery pack may occur under extreme usage
or temperature conditions. This does not necessarily indicate a failure of the
battery pack .however, if the outer seal is broken and this leakage comes into
contact with your skin:
----wash the affected area quickly with soap and water.
----neutralize the liquid with a mild acid such as lemon juice or vinegar.
If the leakage gets in your eyes:
----flush your eyes with clean water for a minimum of 10 minutes and seek
immediate medical attention. Inform the medical staff that the liquid is a 25-35%
solution of potassium hydroxide.
e) Never attempt to open the battery pack for any reason. If the plastic housing of
the battery pack breaks open or cracks, immediately discontinue its use and do
not recharge it.
f) Do not store or carry a spare battery pack in a pocket or toolbox or any other
place where it may come into contact with metal objects. The battery pack may
be short circuited causing damaged to the battery pack, burns or a fire.
g) The battery pack utilizes nickel-cadmium cells. Cadmium is considered to be a
toxic material.
Use an environmentally safe disposal unit at a municipal waste
disposal centre to dispose of a damaged or worn out battery, or
return it to your dealer.
APPLICATION
Intended Use
The machine is intended for driving in and loosening screws as well as for drilling in
wood, metal, ceramic and plastic.
Check the delivery parts

Carefully remove the machine from its packaging and check as the following parts
are complete:
--Cordless drill driver
--Rechargeable battery pack
--battery charger
--14 pcs accessories
--operating instruction
--plastic case
If any parts are missing or damaged, please contact with your dealer.
Product Features
The numbering of the product features refers to the illustration of the machine on the
graphics page (Pic.A-B)
1. Keyless chuck
2. Screwdriver bit
3. On/Off switch
4. Torque preselection
5. Rotational direction switch
6. Handle
7. Battery unlocking button
8. Battery pack
9. Charging indicator
10. Battery charger
The accessories illustrated or described are not included as standard
delivery.
ASSEMBLY
Battery Charging
Only use the battery chargers are matched to the nickel-cadmium battery of
your power tool.(Pic.B-C)
11

12
4) If you leave the battery pack in the charger after the charging cycle is complete,
the charger will switch into its “trickle charge (maintenance charge)”mode.
5) After charging, unplug the charger from the power source.
Note:
a) The battery charger is for charging SUMEC battery pack. Never use it for other
purposes or for other manufacturer’s batteries.
b) When you charge a new battery pack or a battery pack which has not been used
for a long period of time, it may not accept a full charge. This is a normal
condition and does not indicate a problem. You can recharge the battery pack
fully after discharging it completely and recharging a couple of times.
c) If you charge a battery pack from a just operated tool or a battery pack which
has been left in a location exposed to direct sunlight or heat for a long time, the
charging light may flash in red color. If this occurs, wait for a while. Charging will
begin after the battery pack cools. The battery pack will cool faster if you remove
the battery pack from the high capacity battery charger.
d) If the charging light flashes alternately in green and red color, a problem exists
and charging is not possible. The terminals on the charger or battery pack are
clogged with dust or the battery pack is worn out or damaged.

Fitting and removing the battery pack
WARNING
Do not continue to press the On/Off switch after the machine has been
automatically switched off. The battery can be damaged.
The battery is supplied partially charged. Completely charge the battery before using
your power tool for the first time. The battery can be charged at any time without
reducing its service life. Interrupting the charging procedure does not damage the
battery.
a) Always switch off the tool before insertion or removal of the battery pack.
b) To insert the battery pack 8, align the tongue on the battery pack with the groove
in the housing and slip it into place. Always insert it all the way until it locks in
place with a little click. If not, it may accidentally fall out of the tool, causing
injury to you or someone around you. (Pic.(a))
c) To remove the battery pack 8, by pressing the battery unlocking button 7 on
both sides and pulling the battery out of the power tool toward the rear.
d) Do not use force when inserting the battery pack. If the pack does not slide in
easily, it is not being inserted correctly.
Changing Tools
CAUTION:
Always be sure that the tool is switched off and the battery pack is removed
before carrying out any work on the tool.
1) Hold the ring and turn the sleeve counter clockwise to open the chuck jaws.
Place the bit in the chuck as far as it will go.
13

2) Hold the ring firmly and turn the sleeve clockwise to tighten the chuck.
3) To remove the bit, hold the ring and turn the sleeve counter-clockwise.
Operation
Starting Operation
Switching on:
To start the appliance squeeze on the On/Off switch 3 and then keep it pressed
down.
Switching off:
To stop the appliance, release the On/Off switch 3.
Reversing the Rotational Direction
This tool has a reversing switch to change the direction of
rotation. Depress the reversing switch lever from the right 3 side for clockwise
rotation or from the left 2 side for counterclockwise rotation.
When the reversing switch lever is in the neutral position, the switch 3 cannot be
pulled.
Setting the Torque
The fastening torque can be adjusted in 15+1 steps by turning the adjusting ring so
that its graduations are aligned with the pointer on the tool body.
1. Adjusting ring
2. Graduations
3. Pointer
The fastening torque is minimum when the number 1 is aligned with the pointer, and
maximum when the symbol is aligned with the pointer. The clutch will slip to
various torque levels when set at the number 1 to 15.
14

Before actual operation, drive a trial screw into your material or a piece of duplicate
material to determine particular application. Level is required for a particular
application.
Operating Instructions
¾Apply the power tool to the screw only when it is switched off. Rotating tool
inserts can slip off.
Screw driving operation
First, slide the action mode change lever to the position of symbol and select the
fastening torque.
Place the point of the driver bit in the screw head and apply pressure to the tool.
Start the tool slowly and then increase the speed gradually. Release the switch 3 as
soon as the clutch cuts in.
CAUTION:
zMake sure that the driver bit is inserted straight in the screw head, or the screw
and/or bit may be damaged.
zWhen driving wood screws, predrill pilot holes to make driving easier and to
prevent splitting of the workpiece. See the chart.
zIf the tool is operated continuously until the battery pack has discharged, allow
the tool to rest for 15 minutes before proceeding with a fresh battery.
Nominal diameter of wood screw
(mm)
Recommended size of pilot hole (mm)
3.1 (1/8)” 2.0 - 2.2 (5/64” - 3/32” )
3.5 (9/64)” 2.2 - 2.5 (3/32” - 3/32” )
3.8 (5/32)” 2.5 - 2.8 (3/32” - 7/64” )
4.5 (11/64)” 2.9 - 3.2 (7/64” - 1/8” )
4.8 (3/16)” 3.1 - 3.4 (1/8” - 9/64” )
15

5.1 (13/64)” 3.3 - 3.6 (1/8” - 9/64” )
5.5 (7/32)” 3.7 - 3.9 (9/64” - 5/32” )
5.8 (7/32)” 4.0 - 4.2 (5/32” - 11/64” )
6.1 (15/64)” 4.2 – 4.4 (11/64” - 11/64”` )
Drilling operation
First, slide the fastening torque to the position of symbol.
Drilling in wood
When drilling in wood, the best results are obtained with wood drills equipped with a
guide screw. The guide screw makes drilling easier by pulling the bit into the
workpiece.
Drilling in metal
To prevent the bit from slipping when starting a hole, make an indentation with a
center-punch and hammer at the point to be drilled. Place the point of the bit in the
indentation and start drilling. Use a cutting lubricant when drilling metals. The
exceptions are iron and brass which should be drilled dry.
CAUTION:
a) Pressing excessively on the tool will not speed up the drilling. In fact, this
excessive pressure will only serve to damage the tip of your bit, decrease the
tool performance and shorten the service life of the tool.
b) There is a tremendous force exerted on the tool/bit at the time of hole break
through. Hold the tool firmly and exert care when the bit begins to break through
the workpiece.
c) A stuck bit can be removed simply by setting the reversing switch to reverse
rotation in order to back out. However, the tool may back out abruptly if you do
not hold it firmly.
d) Always secure small workpiece in a vise or similar hold down device.
e) If the tool is operated continuously until the battery pack has discharged, allow
the tool to rest for 15 minutes before proceeding with a fresh battery.
16

Cleaning and Maintenance
CAUTION!
Place the direction of rotation direction switch 6 into the middle position before
carrying out any tasks on the device, e.g. changing tools or maintenance, or before
transporting or storing the device. Inadvertent operation of the On/Off switch 7 may
result in injury.
Always pull the battery charger 12 out of the mains socket and remove the battery
pack before you clean or maintain the device.
The cordless Drill/Screwdriver is maintenance-free.
1) Always keep the device clean, dry and free of oil or grease.
2) Clean the device immediately after you have finished using it
3) Do not allow any liquids to enter the device. Use a cloth to clean the
housing.
4) Never use petrol, solvents or cleaning agents that might attack
plastic.
5) Store the tools, instruction manual and where necessary the
accessories in the original packaging. That way you will always have
all the information and parts ready to hand.
Maintenance charge
If you leave the battery pack in the charger to prevent spontaneous discharging after
full charge, the charger will switch into its “trickle charge (maintenance charge)”
mode and keep the battery pack fresh and fully charged.
Tips for maintaining maximum battery life
1) Charge the battery pack before completely discharged. Always stop tool
operation and charge the battery pack when you notice less tool power.
2) Never recharge a fully charged battery pack. Over charging shortens the
battery service life.
17

3) Charge the battery pack with room temperature at 100C-400C (500F-1040F) let
a hot battery pack cool down before charging it.
4) Charge the Nickel-cadmium battery pack when you do not use it for more than
six months.
Do not dispose of electrical appliances with your domestic waste!
1) The packaging comprises exclusively environmentally-friendly
material. Dispose of it in your local recycling containers.
2) Take the battery to your nearest authorized service center or
distributor that has been designated as a battery recycling location.
Guarantee and Service
This product is guaranteed for 1 year from the original date of purchase, the
guarantee applies to material and production defects. This warranty is not valid
without the original dated receipt of purchase.
If the product shows defect as a result of material and production defects during the
period of guarantee, providing that the product has been used properly and for the
purpose which it has been intended, then faulty products will either be replaced or
refunded.
The guarantee does not cover accidental damage or misuse.
This product must be used in accordance with the instructions contained in this
manual.
The guarantee will be rendered invalid if the product has been damaged by
unauthorised repairs or resold.
Accessories are not covered by the guarantee.
If you have any problems or questions concerning the product, please contact our
customer helpline on 0844 856 0793.
18

SUMEC
Declaration of Conformity
We,
SUMEC Hardware & Tools Co.,LTD
1# Xinghuo Road, National level Nanjing High-Tech Zone,
Nanjing 210061 P.R. China
Declare that the product
Cordless Drill
Model No. PG14CD-1
Complies with the essential safety and health requirement of the following directives:
2006/42/EC
2004/108/EC
2006/95/EC
Standards and technical specification referred to:
19
Authorized Signatory
Date: 01.01.2010
Signature:
Name: Cai Jibo
General Manager
SUMEC Hardware & Tools Co.,LTD
EN55014-1:2006
EN55014-2:1997/+A1:2001
EN60745-1:2009
EN60745-2-1:2003+A11:07+A1,A12:09
EN60745-2-2:2003+A11:07+A1,A12:09
EN60335-1:2002+A11:2004+A1:2004+A12:2006
EN60335-2-29:2004
EN50366:2003+A1:2006
EN61000-3-2:2006
EN61000-3-3:1995/+A1:2001/+A2:2005
